56-1/4” (142.9 cm)
34-5/8” (88.0 cm)
30” (76.2 cm)
2-1/4”
(5.7 cm)
25-3/8”
(64.4 cm)
21-11/16”
(55.1 cm)
SIDE
FRONT
TOP
35-1/2”
(90.0 cm)
32-1/4”
(81.8 cm)
3-1/4”
(8.3 cm)
8”
(20.4 cm)
2-1/8”
(5.4 cm)
27-15/16”
(71.0 cm)
34-1/2”
(87.7 cm)
34-5/8” (87.9 cm)
Shelves Down
56-1/4” (149.2 cm)
Shelves Extended
30” (76.2 cm)
10-1/8”
(25.9 cm)
29-7/8” (75.9 cm)
34-7/8” (88.6 cm)
DOORS OPEN AT 90 DEGREES
GAS LOCATION
CORD
LOCATION
11”
(27.9 cm)
15-1/8”
(38.3 cm)
2-1/4”
(5.7 cm)
49-5/8”
(126.2 cm)
57-5/8”
(147.1 cm)
15-1/8”
(38.3 cm)
21-7/8”
(55.5 cm)
1-1/16”
(2.7 cm)
DOORS OPEN AT 90 DEGREES
L501
30” GRILL
Sedona by LYNX
