All-In-One Portable Cooker
OWNER’S MANUAL
ASSEMBLY AND OPERATING IN STRUC TIONS
WARNING
HAZARDOUS EXPLOSION MAY RESULT IF THESE
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ AND
FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH
OR PROPERTY DAMAGE.
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH
THE COOKER OWNER FOR FUTURE
REFERENCE .
SAVE THIS MANUAL FOR FUTURE REFERENCE
Model GAS6100AS
NOT FOR COMMERCIAL USE
THIS INSTRUCTION MANUAL
CONTAINS IMPORTANT
INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY
AND SAFE USE OF THE
APPLIANCE. READ AND
FOLLOW ALL WARNINGS
AND INSTRUCTIONS BEFORE
ASSEMBLING AND WHEN
USING THE APPLIANCE.
5029777
1
WE WANT YOU TO ASSEMBLE AND USE YOUR COOKER AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL
IS TO ATTRACT YOUR ATTENTION
TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR COOKER.
WHEN YOU SEE THE SAFETY ALERT SYMBOL
PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR COOKER.
DANGER
IMPORTANT SAFETY
WARNINGS
IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. If odor continues, keep away from the appliance and immediately call your gas supplier or your
re department.
Failure to follow these instructions could result in re or explosion,
which could cause property damage, personal injury or death.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3m) of any structure, combustible material of other
gas cylinder.
3. Never operate this appliance within 25 feet (7.5m) of any ammable liquid.
4. Never allow the oil/grease to get hotter than 400 *F (200 *C). If the temperature exceeds 400 *F
(200 *C) or if the oil begins to smoke, immediately turn the burner or gas supply OFF.
5. Heated liquids remain at scalding temperatures long after the cooking process. Never touch
cooking appliance until liquids have cooled to 115 *F (45 *C) of less.
6 If a re should occur keep away from the appliance and immediately call your Fire Department.
Do not attempt to extinguish oil/grease re with water.
Failure to follow these instructions could result in re, explosion or burn hazard
which could cause property damage, personal injury or death.
a) Do not store a spare LP cylinder under or near this appliance.
b) Never ll the cylinder beyond 80% full.
c) If the information in (a) and (b) is not followed exactly, a re causing death or
serious injury may occur.
WARNING
DANGER
2
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
LP Gas Cylinder Speci cation and Installation . . . . . . . . . . . . . . . . . . . . . . 5-6
Hose Speci cation and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Leak Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Pre-start Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Lighting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Proper Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Transporting and Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-17
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Be alert to the possibility of serious bodily injury if the instructions are not followed. Be sure to read and
carefully follow all of the messages.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
TABLE OF CONTENTS:
CALIFORNIA PROPOSITION 65 WARNING
WARNING: This product can expose you to chemicals including carbon monoxide, which is
known to the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov
WARNING: CONTAINS LEAD. MAY BE HARMFUL IF EATEN OR CHEWED. COMPLIES
WITH FEDERAL STANDARDS. KEEP OUT OF REACH OF CHILDREN.
3
WARNING
• This appliance shall be used OUTDOORS only. Do NOT use in a building, home, garage, balcony,
porch, tent or any other enclosed area. Cookers/Boilers shall not be used on or under apartment or
condominium balcony or deck. Do NOT install or use in or on recreational vehicles and/or boats.
• When cooking, the cooker/boiler must be on a level, stable, noncombustible surface in an area clear
of combustible material. An asphalt surface (blacktop) may not be acceptable for this purpose.
• Do not use on combustible ooring or surfaces.
• Do NOT operate appliance any closer than 10 feet from any combustible materials including walls or
railings or under overhead construction as these materials could ignite should grease re occur.
• Smoking oil is an indication that the oil is too hot and may ignite. Oil ignites at varying temperatures;
therefore, never allow the oil to exceed 400°F (200°C) and NEVER LEAVE HEATING OIL
UNATTENDED.
• Carefully monitor the temperature of the oil with a thermometer and regulate the temperature so that
it does not overheat. If necessary, turn the gas OFF to the appliance to allow the oil to cool.
• If the temperature exceeds 400°F (200°C) or if oil begins to smoke, immediately turn the burner OFF
and wait for the temperature to decrease to less than 350°F (175°C) before relighting burner. (See
instructions on page 7 for relighting.)
• Hot oil or water can cause severe burns and permanent dis gurement; use caution and common
sense when operating this product.
• Do not leave the appliance unattended. Keep children and pets away from the appliance at all times.
Carefully monitor all activity around cooker to avoid burns or other injuries. Do not wear loose
clothing or allow long hair to hang freely while lighting or using cooker.
• Use caution when walking or standing near cooker as splattered oil may have created a slick surface.
Do not walk between cooker and propane tank as this creates a trip hazard. Tripping over the hose
could overturn the cooker or knock cooking vessel with hot liquid from cooker causing severe burns.
• Avoid bumping of or impact with the appliance to prevent spillage or splashing of hot cooking liquid.
• Never drop food or accessories into hot cooking liquid. Lower food and accessories slowly into the
cooking liquid in order to prevent splashing or over ow. When removing food from the appliance care
shall be taken to avoid burns from hot cooking liquids.
• Never over ll the cooking vessel with oil, grease or water.
• In the event of rain, snow, hail, sleet or other forms of precipitation while cooking with oil/grease,
cover the cooking vessel immediately and turn off the appliance burner and gas supply. Do not
attempt to move the appliance or cooking vessel.
• Introduction of water or ice from any source into the oil/grease may cause over ow and severe burns
from hot oil and water splatter. When frying with oil/grease, all food products MUST be completely
thawed and towel dried before being immersed in the cooker.
• Do not move the appliance when in use. Allow the cooking vessel to cool to 115°F (45°C) before
moving or storing.
• This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection from
hot surfaces or splatter from cooking liquids.
• When cooking with oil/grease, have a type BC or ABC re extinguisher readily available. In the event
of an oil/grease re immediately call the Fire Department. Do not attempt to extinguish with water. A
Type BC or ABC re extinguisher may, in some circumstances, contain the re.
• Check all gas connections by following directions in the “Gas Leak Testing” section on page
5 of this
manual. Never test for gas leaks with a lighted match or open ame. Do not operate this cooker with
a gas leak.
• Do not store or use gasoline or other liquid/aerosols with ammable vapors in the vicinity of this
cooker.
• Storage of this appliance indoors is permissible only if the cylinder is disconnected and removed
from the appliance and left outdoors. Cylinders must be stored outdoors out of the reach of children
and must not be stored in a building, garage or any other enclosed area.
GENERAL WARNINGS:
4
WARNING
• Position propane tank and cooker, as illustrated on page 9, to protect hose from contact with hot
surfaces which could create a leak. Never use a hose that shows signs of cracking or damage.
• DO NOT use external electrical sources with this appliance.
• An appliance is considered to be outdoors if installed with shelter no more inclusive than with walls on
three sides, but with no overhead cover; all openings must be permanently open; sliding doors, garage
doors, windows, or screened openings are not considered as permanent openings.
• An appliance is considered to be outdoors if installed with shelter no more inclusive than within a
partial enclosure that includes an overhead cover and no more than two sidewalls. The sidewalls
may be parallel, as in a breezeway, or at right angles to each other; all openings must be permanently
open; sliding doors, garage doors, windows, or screened openings are not considered as permanent
openings.
• An appliance is considered to be outdoors if installed with shelter no more inclusive than within a
partial enclosure that includes an overhead cover and three sidewalls, as long as 30% or more of
the horizontal periphery of the enclosure is permanently open. All openings must be permanently
open; sliding doors, garage doors, windows, or screened openings are not considered as permanent
openings.
• The installation shall conform with local codes or, in the absence of local codes CSA B149.1,CSA
B149.2.
• The pressure regulator assembly supplied with the appliance must be used. Only use replacement
regulator # 4100-600-4100-15. This regulator can be obtained by contacting Even Embers at 1-855-735-
9922 or email us at [email protected].
• The use of alcohol, prescription or non-prescription drugs may impair your ability to properly assemble
or safely operate this appliance. Use caution and common sense.
• This appliance is not intended for and should never be used as a heater.
• Do not use this cooker for other than its intended purpose. Properly dispose of packaging materials.
• Only use replacement/accessory parts manufactured by Even Embers. Repairs should be performed by
Even Embers.
• Not for commercial use. DO NOT use this cooker for anything other than its intended purpose.
WARNING: Do not use this appliance under extended awnings. Failure to comply could result in a
re or personal injury.
DANGER: Do not put appliance in storage or travel mode immediately after use. Allow appliance
to cool to touch before moving or storing. Failure to do so could result in re resulting in property
damage, personal injury, or death.
WARNING: Disconnect the appliance from the gas supply prior to storage or transportation.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GAS COOKER.
FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS MANUAL
COULD RESULT IN SEVERE BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
LP GAS CYLINDER (TANK) SPECIFICATIONS AND INSTALLATION:
WARNING
• ONLY connect this cooker to a Type 1 cylinder valve. The Type 1 valve can be identi ed with the
large external threads on the valve outlet.
• DO NOT connect to a propane cylinder exceeding a 20 lb. (9.1 kg) capacity.
• DO NOT connect to a cylinder that uses any other type of valve connection device.
• Inspect the propane tank valve rubber seal for cracks, wear or deterioration prior to use. A
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.
• Turn off the cylinder valve when your cooker is not in use.
• Handle the tank with care.
• Always secure the cylinder in an upright position.
• Never connect an unregulated LP gas cylinder to your cooker.
• DO NOT expose LP gas cylinders to excessive heat or ignition sources.
• DO NOT store a spare LP gas cylinder under or near your cooker.
• Allow only quali ed LP gas dealers to ll or repair your LP gas cylinder.
• DO NOT allow the cylinder to be lled beyond 80% capacity.
• Read and follow all warnings and instructions that are on the cylinder and that accompany this
product.
• DO NOT store a spare LP gas cylinder (full or empty) near your cooker. This could cause
excess pressure to be expelled through the vapor relief valve resulting in re, explosion, or
severe personal injury, including death.
• Propane gas is heavier than air and will collect in low areas. Proper ventilation is extremely
important. Keep the ventilation opening(s) of the LP gas cylinder enclosure free and clear from
obstructions and debris.
• DO NOT insert any foreign objects into the cylinder valve outlet as this could damage the
rubber seal. Do not use propane tank with a damaged rubber seal. A damaged rubber seal can
cause a gas leak, possibly resulting in explosion, re, severe bodily harm, or death. Inspect
rubber seal for cracks, wear or deterioration prior to use.
• Always keep cylinder (tank) in upright position during use, transit or storage.
• Do not put appliance in storage or travel mode immediately after use. Allow appliance to cool
to touch before moving or storing. Failure to do so could result in re resulting in property
damage, personal injury, or death.
DANGER
5
LP GAS CYLINDER (TANK) SPECIFICATIONS:
LP gas cylinder (not supplied with this cooker)
The LP (Liquid Propane) gas cylinder speci cally designed to be used with this cooker must be 12” (30.5 cm)
diameter x 18” (45.7 cm) tall and have a 20 lb. (9.1 kg) capacity incorporating a Type 1 cylinder valve and an
over- lling protection device (OPD).
This cooker is designed to t Worthington, Manchester or SMPC brand 20 lb. (9.1 kg) cylinders. Other brand
DOT cylinders may t this cooker if the cylinder has similar dimensions of the top and bottom rings.
The installation of this appliance must be in accordance with:
All applicable local codes, or in the absence of local codes, either:
• National Fuel Gas Code ANSI Z223.1 NFPA 54
• Natural Gas and Propane Installation Code: CAN/CGA B149.1
• Natural Gas Installation Code: CAN/CGA B149.1 (Canada)
• Propane Installation Code: CAN/CGA B149.2 (Canada)
6
• Allow only quali ed licensed LP gas dealers to properly ll or repair your LP gas cylinder.
• New tanks should be purged prior to lling; inform LP gas dealer if you are using a new tank.
• DO NOT allow the cylinder to be lled beyond 80% capacity. Over- lled tanks can create a
dangerous condition. Over- lled tanks can build-up pressure and cause the relief valve to expel
propane gas vapors. The vapor is combustible and if it comes in contact with a spark source or
ame an explosion causing severe burns, bodily harm, or death could occur.
• Always use a protective cylinder cap when cooker is not connected to cylinder.
• If you exchange a cylinder with a quali ed exchange program, the new cylinder must have
a Type 1 valve and an over- lling prevention device (OPD).
• Inspect the propane tank valve rubber seal for cracks, wear or deterioration prior to use. A
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.
FILLING THE LP GAS CYLINDER (TANK):
WARNING
To check your local codes, see your local LP gas dealer or natural gas company. This cooker was not
intended to be connected to a natural gas supply line. If an external electrical source is utilized, it must be
electrically grounded in accordance with local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA 22.1.
When purchasing or exchanging a cylinder for your gas cooker, it must be constructed and marked in
accordance with the speci cations for LP gas cylinders of the U.S. Department of Transportation (DOT)
or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of
Dangerous Goods; and Commission, as applicable; and provided with a listed over- lling prevention device
(OPD), and provided with a cylinder connection device compatible with the connection for outdoor cooking
appliances.
The cylinder must also be equipped with:
• A shut-off valve terminating in a Type 1 gas cylinder valve outlet.
• A Type 1 valve that prevents gas ow until a positive seal is obtained.
• An arrangement for vapor withdrawal.
• A collar to protect the cylinder shut-off valve.
• A safety relief device having direct communication with the vapor space of the cylinder.
• A listed over- lling prevention device (OPD).
• Inspect the propane tank valve rubber seal for cracks,
wear or deterioration prior to use. A damaged rubber
seal can cause a gas leak, possibly resulting in an
explosion, re or severe bodily harm.
• Inspection should be done each time the propane tank is
connected to the cooker, has been re lled, exchanged or
has not been used for more than 60 days.
• Do not use a propane tank with a damaged rubber seal.
Exchange the tank or have the rubber seal replaced at a
quali ed propane lling station.
LP GAS CYLINDER (TANK) RUBBER SEAL INSPECTION:
Good
Rubber Seal
Damaged
Rubber Seal
HOSE AND REGULATOR:
Your supply hose is equipped with a Type 1 connection device with the following features:
1. The system will not allow gas ow from the cylinder until a positive connection to the valve has been made.
Note: The cylinder valve and cooker regulator knob must be turned OFF before any connection is made
or removed.
2. A ow limiting device, when activated, restricts the ow of gas to 10 cubic feet per hour. If the ow limiting
device is activated, perform Resetting Procedure.
Note: If your cooker will not get hot enough to cook, the ow limiting device may have been activated.
CONNECTING HOSE TO LP GAS CYLINDER:
1. Inspect the propane tank valve rubber seal for cracks, wear or
deterioration prior to use. A damaged rubber seal can cause a gas leak,
possibly resulting in an explosion, re or severe bodily harm. Do not use a
propane tank with a damaged rubber seal.
2. Check that the cylinder valve is closed by turning the knob clockwise.
3. Check that the cooker’s regulator knob is in the “OFF” position.
4. Visually inspect the hose assembly prior to each use for evidence of
damage, excess wear, or deterioration. If found, replace the assembly
before using your cooker. Only the manufacturer’s supplied replacement
should be used.
5. Remove the protective plastic cap from the cylinder valve.
6 Check that the hose does not contain kinks, does not contact sharp edges, and does not contact
surfaces that may become hot during use.
7. Insert the brass nipple into the LP cylinder valve outlet. Ensure that the device is centered properly.
8. Turn the large coupling nut clockwise by hand and tighten to a full stop. Take care not to cross thread
the coupling nut onto the cylinder valve. Do not use tools to tighten connection.
Note: If you are unable to make the connection, repeat Steps 6 and 7.
9. Leak check all ttings before lighting your cooker. See section on “Leak Testing” in this manual.
Note: To remove hose from propane tank, turn off the tank valve and rotate the large coupling nut
counter-clockwise and remove.
RESETTING PROCEDURE:
If your cooker will not get hot enough to cook, the ow limiting device may have been activated.
Mini Reset: Turn regulator knob to “OFF”, turn off the cylinder valve. Wait one minute. Slowly turn cylinder
valve ON and relight cooker. If burner ame is higher and cooker heats up properly – proceed
with cooking.
Full Reset: Turn regulator knob to “OFF”, turn off the cylinder valve. Disconnect hose and regulator from
cylinder. Wait two minutes, reattach hose and regulator and perform leak test.
Inspect Rubber Seal (see page 6)
7
HOSE SPECIFICATIONS AND INSTALLATION:
• DO NOT attempt to connect cooker, as purchased for LP (propane) gas, to any other fuel supply
source such as a natural ga
s line.
• The pressure regulator assembly supplied with the appliance must be used. Only use replacement
regulator # 4100-600-4100-15. This regulator can be obtained by contacting Even Embers at 1-855-735-
9922 or email us at [email protected]
• DO NOT attempt to adjust or repair a regulator. The regulator is designed to operate at a
maximum output pressure of 11 inches water column (WC).
• Ensure the tank valve is CLOSED prior to connecting the LP gas cylinder to your cooker.
Turn the valve knob clockwise to properly close the valve. Read and follow all instructions
and warnings on the supply hose safety tags. Read and follow all warnings in this manual
concerning the safe use of LP gas cylinders and the hose and regulator before connecting
cylinder to cooker. Read and follow all warnings on the LP cylinder.
WARNING
WARNING
• Never use your cooker without leak testing all gas connections and propane tank. Follow the
section on “Leak Testing” in this manual for proper procedures.
LEAK TESTING:
To prevent re or explosion hazard:
• DO NOT smoke or permit ignition sources in the area while conducting a leak test.
• Perform test OUTDOORS in a well ventilated area that is protected from the wind.
• Never perform a leak test with a match or open ame.
• Never perform a leak test while the cooker is in use or while cooker is still hot.
DANGER
WHEN TO PERFORM A LEAK TEST:
• After assembling your cooker and before lighting for the rst time, even if purchased fully assembled.
• Every time the LP gas cylinder is re lled, exchanged or if any of the gas components are disconnected or
replaced.
• Any time your cooker has been moved.
• At least once per year or if your cooker has not been used for more than 60 days.
CHECKING FOR LEAKS USING A 20 LB. LP CYLINDER:
CAUTION: Strong odors, colds, sinus congestion, etc. may prevent the detection of propane by smell.
Use caution and common sense when testing for leaks.
Note: The leak test must be performed in an area that has adequate lighting in order to see if bubbles
are developing and not in a windy or noisy area so larger leaks can be detected by smell or sound.
1. Create a mixture of 50% water and 50% liquid dishwashing soap.
2. Turn on the gas at the cylinder valve. Turn the cylinder valve knob counter-clockwise to full open. If you
hear a rushing sound or smell gas, turn the gas off. Tighten any leaking connections. If leak is detected at
connection nut and tightening does not stop leak, reinspect propane tank
rubber seal. Open regulator control valve fully.
3. Apply the soapy water mixture to the following:
Supply tank (cylinder) weld.
Connection nut to tank valve.
Back side of connection nut to supply hose.
The full length of gas supply hose.
Tank valve to cylinder.
Gas supply hose connection to regulator assembly.
4. Check each place listed (A–F) for growing bubbles, which indicates a leak.
Large leaks may not be detected by bubbles but should produce a rushing
sound or gas smell.
5. Turn off gas supply at cylinder valve.
6 Turn regulator control knob to “OFF” position.
7. Tighten any leaking connections. If leak is detected at connection nut and
tightening does not stop leak, reinspect propane tank rubber seal. (see
page 6)
8. Repeat soapy water test until no leaks are detected.
9. Turn off gas supply at cylinder valve until you are ready to use your cooker.
10. Wash off soapy residue with cold water and towel dry.
11. Wait 5 minutes to allow all gas to evacuate the area before lighting cooker.
WARNING: DO NOT use the cooker if leaks cannot be stopped. Contact a
quali ed gas appliance repair service.
8
A
B
C
D
E
F
Watch For Bub bles
D
E
C
B
A
F
CHECKING FOR LEAKS USING 1 LB. LP CYLINDER:
CAUTION: Strong odors, colds, sinus congestion, etc. may
prevent the detection of propane by smell. Use caution
and common sense when testing for leaks.
Note: The leak test must be performed in an area that has adequate
lighting in order to see if bubbles are developing and not in a
windy or noisy area so larger leaks can be detected by smell or
sound.
1. Create a mixture of 50% water and 50% liquid dishwashing soap.
2. Attach propane tank onto regulator.
3. Apply the soapy water mixture to the connection between propane
tank and regulator
A
.
4. Check for growing bubbles, which indicates a leak. Large leaks
may not be detected by bubbles but should produce a rushing
sound or gas smell.
5 Wash off soapy residue with cold water and towel dry.
6. Wait 5 minutes to allow all gas to evacuate the area before lighting
cooker.
WARNING: DO NOT use the cooker if leaks cannot be stopped.
Contact a quali ed gas appliance repair service.
Watch For Bub bles
A
9
DANGER
Property damage, bodily harm, severe burns, and death could result from failure to follow these
safety steps. These steps should be performed after the cooker has been assembled and prior to
each use. DO NOT operate this cooker until you have read and understand ALL of the warnings and
instructions in this manual.
• Ensure that the cooker is properly assembled.
• Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is
evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the cooker
being used. A replacement hose can be obtained by contacting customer service at 1-855-735-9922.
• Leak check all gas connections, hose and propane tank. See section on “Leak Testing”.
• Ensure that all electrical supply cords are properly grounded. Keep any electrical supply cord and the
fuel supply hose away from any heated surfaces. Hose should be at least 3 inches from hot surfaces.
• Position your cooker on a non-combustible level surface in a well ventilated location, a safe distance
from combustible materials, buildings and overhangs.
WARNING Hose is a trip hazard. Do not walk between cooker and cylinder.
Note: Due to the intense heat from burner, it is normal for discoloration to occur on cooker during the rst
few uses.
PRE-START CHECK LIST:
10 ft.
12 ft.
Wind Direction
20˝
(50.8 cm)
1 lb. Propane
Cylinder
WARNING
LIGHTING INSTRUCTIONS:
Follow the instructions exactly. Read, understand and follow all warnings and instructions contained
in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections
of this manual.
LIGHTING THE BURNER:
1. Make sure regulator control knob is in the OFF position.
Note: When using 20 lb. LP cylinder, turn on gas supply at
cylinder before proceeding to Step 2.
2. Push to turn on the control knob then rotate the knob
counterclockwise to LOW.
3. DO NOT stand with head, body, or arms over the cooker
when lighting.
4. Strike and place a long wooden match or butane lighter
approximately ½ ” (1 to 2 cm) from the burner.
5. If burner does NOT ignite immediately, turn the regulator
control knob to OFF, wait 5 minutes for gas to evacuate and
repeat steps 1 through 4 until burner ignites.
6. If the burner does not light within the rst few attempts, there
is a problem with the gas supply. Turn off the gas at the
burner and cylinder. DO NOT attempt to operate the cooker
until the problem is found and corrected.
10
TURNING OFF THE COOKER:
1. Turn regulator control valve to the “OFF” position.
2. Disconnect propane tank from the regulator control valve.
3. If using 20 lb. cylinder, turn off propane tank valve and remove hose
from cylinder.
BURNER FLAME CHECK
Adjust ame height using regulator control knob. Rotate air shutter to achieve mostly blue ame. The air
shutter mounted on the front of your burner helps to control the amount of air that mixes with the LP gas.
A blue ame with little or no yellow ame provides the best heat. Adjust the air shutter until the desired
ame is achieved.
2"
1"
0"
Rotating
A
ir Shutter
Air Opening
YELLOW
BLUE
BURNER ASSEMBLY/MAINTENANCE:
• Keep appliance area clear and free from combustible materials, gasoline and other ammable vapors and
liquids.
• Although your burner is constructed of cast iron, it may rust as a result of the extreme heat and acids
from cooking foods. Regularly inspect the burner for cracks, abnormal holes, and other signs of corrosion
damage. If found, replace the burner.
WARNING: DO NOT obstruct the ow of combustion and ventilation air. Burner tube can become blocked by
spiders and other insects building their nests. A blocked burner tube can prevent gas ow to the
burner and could possibly result in a burner tube re. To clean the Burner Assembly follow these
instructions to clean and/or replace parts of burner assembly or if you have trouble igniting the
cooker.
1. Turn gas off at control knob and disconnect regulator from burner.
2. Use a narrow bottle brush or a stiff wire bent into a small hook to run through the burner tube.
Note: Wear eye protection when cleaning burner with compressed air.
3. Check each port to make sure air comes out each hole.
4. Wire brush entire outer surface of burner to remove food
residue and dirt.
5. If burner is damaged, obtain a replacement burner.
6. Reinstall burner and retaining nuts on support strap inside
burner stand.
Spider Web
PROPER CARE AND MAINTENANCE:
11
COOKER SEASONING INSTRUCTIONS:
For best results, we recommend seasoning the cooker before cooking.
Step 1 Make sure cooker is wiped clean of debris.
Step 2 Ignite cooker by following the lighting instructions. Turn control knob to HIGH and wait 10 to 15
minutes until your cooker starts to discolor.
Step 3 Pour 3 tablespoons of oil on cooker surface. Any cooking oil will work.
Step 4 Use cooking tongs or heat resistant gloves to hold folded paper towels. Spread the cooking oil over
the surface of cooker evenly by using the folded paper towel. Be sure to cover every part of the
cooker (i.e. corners, sides, etc.).
Step 5 Once your cooker is covered with a thin layer of cooking oil, allow cooker to heat on HIGH. Smoking
will occur as the oil begins to bond with the cooker surface, creating a non-stick surface.
Step 6 When cooker surface has stopped smoking and there isn’t a noticeable amount of sheen, repeat
steps 3-5 at least three more times.
Note: Your cooktop is porcelain coated and we recommend using a protective coating to prevent sticking.
Note: Your Even Embers cooker was pre-treated with vegetable oil as a protective coating. This coating
may leave a discoloration on the surface, but this will not affect the seasoning process.
12
BURNER CLEANING AND MAINTENANCE:
• Visually check burner ames for proper operation (see pictorial in above). Spiders or other insects can nest in
the burner causing gas blockage.
• For safe cooking and peak performance of your cooker, perform these checks at least twice per year or after
extended periods of storage.
• Be sure to tighten up all hardware (nuts, screws, etc.) before each use.
CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary.
• Clean appliance with mild dishwashing detergent, hot water and sponge. A soft bristle brush can also be used.
• Inspect entire appliance including regulator and replace any damaged or worn parts. Use only parts speci ed
by Even Embers.
• Never move a cooker when hot or in use.
• Make sure that the control knob is in the off position.
• DO NOT store a spare LP gas cylinder ( lled or empty) under or near the cooker.
• Never store ammable liquids or spray canisters under or near the cooker.
• If the outdoor cooking gas appliance is not in use, the propane tank must be disconnected.
• Storage of an outdoor cooking gas appliance indoors is permissible only if the cylinder is
disconnected and removed from the outdoor cooking gas appliance.
• Cylinders must be kept out of reach of children.
WARNING
TRANSPORTING AND STORAGE:
BEFORE STORING YOUR COOKER:
• Ensure that the control knob is in the off position and remove propane tank from regulator.
• Clean all surfaces. Lightly coat the cooker with cooking oil to prevent excess rusting.
• If storing the cooker indoors, disconnect the propane tank.
• Place dust cap on propane tank valve outlet whenever the cylinder is not in use. Only install the type of dust cap on
the cylinder valve outlet that is provided with the propane tank. Other types of caps or plugs may result in leakage of
propane.
• Check and clean burner prior to use after storing, at the beginning of grilling season or after a period of not being used.
Spiders and insects like to build nests in burner tubes (especially during colder months). Blocked burner tubes can
prevent gas ow to the burners and could result in a burner tube re or re beneath the cooker. See “Burner Assembly/
Maintenance” under Proper Care and Maintenance.
• In order to extend and maintain the life and condition of the cooker, we recommend that the unit be covered when stored
outside.
13
TROUBLE SHOOTING:
Problem Possible Cause Prevention/Cure
Burner will not light LP gas tank is low or empty Check if propane tank is empty. If empty, replace.
LP gas leak 1. Turn control knob valve to “CLOSED”
2. Wait 5 minutes for gas to clear
3. Follow “Leak Testing” in the owner’s manual
LP gas tank not fully connected Tighten propane tank hand tight to regulator
Obstruction of gas ow Clean burner assembly
Spider webs or insect nest in venturi Clean venturi and burner assembly
Burner ports clogged or blocked Clean burner ports
Cooker does not get hot
enough
Out of gas Replace propane tank
Irregular ame pattern.
Flame does not run full
length of burner
Burner ports are clogged or blocked Clean burner ports
Air shutter on burner needs adjustment See section on “Burner Adjustment”
Flame is yellow or orange New burner may have residual manufacturing
oils
Burn cooker for 15 minutes on “HIGH”.
Spider webs or insect nest in venturi Clean venturi and burner assembly
Food residue, grease, etc. Clean burner assembly
Poor alignment of valve to burner venturi Make sure burner venturi is properly engaged with valve
Air shutter on burner needs adjustment See section on “Burner Adjustment”
Flame blows out High or gusting winds Do not use cooker in high winds
Low on LP gas Replace or propane tank
Burner holes may be obstructed Refer to “Burner Assembly/Maintenance” instructions
Oil does not reach
desired temperature
Food is not fully defrosted Do not attempt to fry a frozen or partially frozen food. Ensure the
food is completely thawed prior to placing in hot oil.
The control knob valve is not fully opened Fully open the control knob valve. The control knob
valve is opened in counter-clockwise direction.
14
ASSEMBLY INSTRUCTIONS:
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR COOKER.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT.
The following tools are required to assemble this Even Embers
All-In-One Cooker:
• Phillips Screwdriver
• Adjustable Wrench
PARTS LIST:
1 Cooktop
1 Frame Assembly
1 Wind Guard
1 Regulator Assembly
1 Long Leg
1 Medium Leg
1 Short Leg
1 20 lb. Tank Adapter
1
3
4
2
1
2
3
4
5
6
7
8
HARDWARE LIST:
6 M6 x 20 mm Bolts
6 M6 Lock Nuts
A
B
5
6
7
8
15
1
2
Open frame assembly
2
and secure with latch pin.
2
A
2
B
5
6
7
Attach the short leg
7
,
medium leg
6
and long leg
5
to frame assembly
2
using six M6 x 20 mm bolts
A
and M6 lock nuts
B
.
Note: The legs are different
lengths so you must match
the leg number to the frame
number.
Place wind guard
3
over
burner.
Note: Align pins in wind guard
with holes in legs to secure.
16
3
3
4
4
1
Place cooktop
1
on
assembled frame
2
.
Attach regulator assembly
4
to burner by turning
clockwise until secure.
Note: Regulator assembly
will still be free to rotate after
connection to the burner.
5
To use the 20-pound
propane tank adapter
8
, simply connect the
adapter’s tting to the
regulator assembly
4
and the other end to
a 20-pound propane
tank, ensuring a
secure connection and
checking for gas leaks
before use.
8
4
17
18
OM6100AS
0425
Owner’s Manual for Model
GAS6100AS
©2025 The Fair Game Group LLC.
Carrollton, Texas 75006 U.S.A.
www.evenembers.com
The Fair Game Group warrants to the original pur chas er that the Even Embers All In One Cooker is free from defects due to workmanship or
materials for:
One-year: on valves, frame, and other related parts
The Fair Game Group’s obligations under this warranty are limited to the following guidelines:
• This warranty does not cover gas cookers that have been altered/modi ed or damaged due to: normal wear, rust, abuse, improper
maintenance and/or improper use.
• This warranty does not cover surface scratches, rust or heat damage to the nish, which is considered normal wear.
• The Fair Game Group may elect to repair or replace damaged units covered by the terms of this warranty.
• This warranty extends to the original purchaser only and is not trans fer able or assignable to subsequent purchasers.
The Fair Game Group requires reasonable proof of purchase. Therefore, we strongly recommend that you retain your sales receipt or invoice. To
obtain replacement parts for your Even Embers
All In One Cooker under the terms of this warranty, please call Customer Service Department
at 1-855-735-9922. A receipt will be required. The Fair Game Group will not be responsible for any gas cookers forwarded to us without prior
authorization.
EXCEPT AS ABOVE STATED, THE FAIR GAME GROUP MAKES NO OTHER EXPRESS WARRANTY.
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO THOSE
LISTED ABOVE FROM THE DATE OF PURCHASE. SOME STATES DO NOT ALLOW LIM I TA TIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF THE EVEN EMBERS
ALL IN ONE COOKER TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED. CUSTOMER ACKNOWLEDGES
THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET OUT ABOVE. SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
WARRANTY
