Technical Support and E-Warranty Certificate www.vevor.com/support
OUTDOOR GRILL CART
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Model: TB0110001 & TB0110002
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
OUTDOOR
GRILL CART
Note: the quantity of parts shown in the manual is the actual usage and the
unused parts are spare parts.
1
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
IMPORTANT SAFEGUARDS
Thank you for using this product. In order to make sure that you can
operate the machine correctly, read this instruction carefully before
operation and keep it properly for future reference. Please be sure to read
the precautions and safety rules on this page to ensure your safe use.
This manual will outline safety warnings and precautions, operating,
maintenance and cleaning. The warnings and instructions reviewed in this
manual cannot cover all possible conditions and situations that may occur.
Caution and common sense are not built into this product, since we believe
that the uses will comply with these codes.
Please read ALL the instructions before using your machine.
1. Do NOT let children and minors get close to or touch the product.
2. Do NOT immerse the appliance in water or any other liquid.
3. Using accessories or attachments not provided or recommended by the
manufacturer may cause injury.
4. Do not attempt to modify the machine in any way.
5. If the machine is not to be used for a long period of time, clean and fold it
and store it in a dry and safe place.
6. KEEP IT OUT OF CHILDREN'S REACH.
7. Children shall not play with the machine alone. Cleaning and user
maintenance shall not be made by children without supervision.
8. The machine must never be left unattended during operation or
cleaning.
9. Make sure that the machine is always placed on a firm, level and fire
retardant surface, and also placed far away from combustibles. Improper
placement can cause the product to tip over, slide, or cause items on
the table to fall off !
2
10. While every effort has been made in the manufacture of your machine
to remove any sharp edge, you should handle all components with care in
order to avoid accidental injury.
11. DO NOT CLEAN IT WITH ANY ABRASIVE MATERIAL.
12. The machine should only be repaired or serviced by an authorized
Service Engineer and only genuine approved spare parts should be used.
13. This product cannot be used for other purposes.
14. Not suitable for commercial use.
15. Wear safety goggles and heavy-duty work gloves during assembly and
using.
16. Do not assemble when tired or when under the influence of alcohol,
drugs or medication.
WARNING! Remove all packaging materials and keep them for future
use.Packaging materials are not a toy.
WARNING! Keep children and pets from playing with the packaging
materials. If they swallow the packaging materials, they will suffocate!
WARNING! Keep children and pets away.Children must not operate or
play near this machine.
WARNING! Failure to follow instructions could result in death, serious
bodily injury and property loss.
WARNING! This product is not a toy. Do not allow children to play with or
approach this item.
WARNING! Use as intended only. Do not sit or stand on the table.
ATTENTION! Inspect before every use.Do not use if parts are loose or
damaged.
ATTENTION! Use only on flat, level, hard surfaces.
ATTENTION! The weight on the countertop must be evenly distributed,
careful of tipping and weight falling
！
3
PRODUCT PARAMETERS
Model No.
Product Size
Material Quality
TB01100
01
39.37x25.2x32.87 inch
(1000x640x835 mm)
Q235
TB01100
02
39.37x25.2x32.87 inch
(1000x640x835 mm)
Table: SUS410
Handle: SUS201
Other: Q235
LOADING CAPACITY
Model No.
Loading Capacity
TB0110001 &
TB0110002
Fixed desktop ---Max 220Lbs (100kg)
The hook---Max 11Lbs (5kg) / PCS
ATTENTION!
1. Do not exceed the listed weight capacity. Be aware of dynamic loading!
The sudden load movement may briefly create an excess load, causing
product failure.
4
PRODUCT COMPONENTS
1. Please dispose of all plastic bags carefully and keep them away from
children.
2. Check all components provided according to the list in this manual.
Make sure you have all of the parts listed.
3. Although paying particular attention when manufacturing this product,
you must be careful during the assembly process to avoid being scratched
by sharp edges.
4. Wear safety goggles and heavy-duty work gloves during assembly and
using.
Max 220 LBS (100Kg)
ATTENTION!
The weight on the
countertop must be
evenly distributed,
careful of tipping and
weight falling ！
5
5. Before using the appliance for the first time, peel off any promotional
materials and packaging materials, and check that the machine is clean
and dust-free. If necessary, wipe them over with a damp cloth. Spread over
with an absorbent kitchen towel and wipe off any excess oil.
No.
Diagram
Qty
No.
Diagram
Qty
1
1 PCS
9
1PCS
2
1PCS
10
2PCS
3
1(LF)
PCS
11
1PCS
4
1(RF)
PCS
12
1PCS
5
1(LB)
PCS
13
1PCS
6
1(RB)
PCS
14
1PCS
7
1PCS
15
1PCS
8
2PCS
16
1PCS
17
1PCS
18
4PCS
A
M5x12:
37PCS
D
1PCS
B
M6x50:
2PCS
D
M4x8:
2PCS
6
C
2PCS
NOTE: Assembly requires
the use of a wrench and a
Phillips screwdriver, but
requires self purchase.
Explosion Diagram
7
SETP 1
A: 12pcs
SETP 2
A: 4pcs
8
SETP 3
A: 8pcs
SETP 4
A: 8pcs
9
SETP 5
D: 1pcs
C: 2pcs
SETP 6
B: 2pcs
10
SETP 7
E: 2pcs
SETP 8
A: 3pcs
11
SETP 9
A: 2pcs
SETP 10: PVC Table Mat
only for TB0110001.
PVC Table Mat
NOTE:
1. Although PVC tablecloth have
good high temperature
resistance, it 's still necessary.
2.Due to packaging reasons,
some tablecloth will have a little
smell when they are received,
which is a normal phenomenon,
and the smell can be removed by
blowing on the balcony or
washing with detergent and
drying in the sun.
12
CLEANING MAINTENANCE AND STORAGE
1. For cleaning, wipe the surface with a damp (not wet) cloth or wipe dry
with a clean lint free cotton cloth.
2. Keep the product dry after cleaning
3. Put the cleaned products and accessories into the carton.
Note: Only clean when the product is not working.
