42” BELT DRIVE DRUM FAN
INDUSTRIAL FLOOR FAN
MODEL 2VAFDRUMB42
OWNER’S MANUAL
2
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
PRODUCT SPECIFICATIONS
• Model No: 2VAFDRUMB42
• Item Name: Belt Drive Industrial Drum Floor Fan
• Rated Voltage: 120V (60Hz)
• Rated Power: 610W
• Mode Fan Speeds: Low / High
• Fan Blade Diameter: 42 Inch
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store name/location and date
purchased below:
Store Name: _____________________________________________________________________________________________________
Location: ________________________________________________________________________________________________________
Date Purchased: _________________________________________________________________________________________________
3
CONTENTS
IMPORTANT NOTE:
Please read and save these instructions. Read through this owner’s manual carefully before using this
product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to
comply with instructions could result in personal injury and/or damage to property. Illustrations in this manual
are for explanatory purposes only, your actual product may look slightly dierent. SAVE THIS MANUAL FOR
FUTURE REFERENCE.
Important Instructions .............................................................................................................................................................4
Product Diagram ......................................................................................................................................................................4
Assembly Instructions .............................................................................................................................................................. 5
Operation Instructions .............................................................................................................................................................6
Storage & Maintenance ............................................................................................................................................................ 6
Troubleshooting .......................................................................................................................................................................7
4
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
INSTRUCTIONS
PLEASE READ CAREFULLY- ALWAYS MAINTAIN SAFETY
WHEN WORKING WITH ANY APPLIANCE
1. Check that the power supply voltage corresponds with
the rating of the appliance before operating.
2. To protect against electric shock. Do not immerse cords
plugs or appliances in water or any other liquid.
3. Do not leave any appliance unattended while it is
operating.
4. Close supervision is necessary when any appliance is
used by or near children or inrm persons.
5. Unplug from the outlet when not in use or before
cleaning. Allow cooling before taking o any parts.
6. Do not operate the appliance with damaged power cords
or plugs, and do not use a damaged appliance. If the
power cord or appliance is damaged, it must be replaced
by the manufacturer, service agent, or similarly qualied
professional to avoid a hazard.
7. The use of accessory attachments not recommended by
the appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let the cord hang over the edge of a table or
counter or let it come into contact with any hot surfaces
10. To disconnect-remove the plug from the outlet. Do not
pull the plug out by the cord.
11. Do not use this product for anything other than its
intended use. This appliance is for household use only.
12. No liability can be accepted for any damage caused by
non-compliance with these instructions or any other
improper use or mishandling.
13. Do not use the appliance without the protective grills.
14. Do not attempt to force the grill to make the fan turn or
stop.
15. Never put objects into the grills when the appliance is
connected to the mains.
16. It is not advisable to expose people, especially babies or
older people, to a continuous cold air stream for a long
time.
A. Switch
B. Fan Body
C. Handle
D. Wheels
E. Leg
D
A
B
C
E
IMPORTANT INSTRUCTIONS
PRODUCT DIAGRAM
5
PACKAGE & ASSEMBLY
(Continued)
ASSEMBLY INSTRUCTIONS
Axle
Wheel
Screw
Frame
1. Insert axle shaft through the
frame. Align the holes in the frame
to the holes in the axle. Secure
screws with a screw driver as
shown.
2. Press the spring pin on the wheel
stem and gently push it into the
corresponding hole on axle.
1. Fan Body x 1
2. Wheels x 2
3. Screws x 2
4. Axle x 1
1
2
4
3
PACKAGE INCLUDES
Spring Pin
6
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
OPERATION INSTRUCTIONS
1. Plug the power cord into 120V the volt AC wall outlet.
2. You can press the rocker switch to select
low (I) / high speed (II)
STORAGE & MAINTENANCE GUIDELINES
1. Turn the control OFF and unplug the fan before cleaning.
2. Use only a soft damp cloth to clean the fan.
3. Do not place the fan in water and never allow water to drip
into the Motor Housing.
4. Do not use gasoline, paint thinner or other chemicals to
clean the fan.
5. To clean the fan blade, remove the front grill and wipe the
blade and grills.
6. Store the fan in its original box or cover the fan to protect it
from dust.
7. Store it in a cool and dry place.
OPERATION & CARE
HIGH
OFF
LOW
7
TROUBLESHOOTING
ISSUE POSSIBLE CAUSE RECOMMENDED SOLUTION
Fan not turning on
Power cord not plugged in securely Ensure the power cord is fully inserted into a working outlet.
Circuit breaker has tripped or
fuse blown
1. Check your circuit breaker panel for a tripped breaker.
2. Reset the breaker, or replace the fuse if blown.
Fan switch not in the “On” position
Turn the fan speed control switch to the “On” position or
desired speed.
Faulty power outlet
Test the outlet with another device (e.g., a lamp) to ensure it’s
functioning. If the outlet is faulty, use another outlet.
Motor issue
If the fan doesn’t turn on after checking the power supply,
unplug the fan and contact customer service.
Unusual noise
during operation
Loose screws or parts
1. Turn o and unplug the fan.
2. Inspect all screws on the housing and blades.
3. Tighten any loose screws using a screwdriver.
Fan blades are unbalanced
1. Turn o and unplug the fan.
2. Inspect each blade for bends or damage.
3. Remove any objects or debris obstructing the blades.
Fan placed on an uneven surface
1. Ensure the fan is placed on a stable, level surface.
2. If necessary, move the fan to a dierent location.
Worn or loose belt
Contact customer service for further assistance or a belt
replacement if necessary.
Fan vibrating
excessively
Fan placed on an uneven surface
1. Ensure the fan is placed on a stable, level surface.
2. If necessary, move the fan to a dierent location.
Loose fan blade
1. Turn o and unplug the fan.
2. Check if the fan blades are securely attached and tighten
any loose screws.
Fan overheating
Dust or debris buildup in motor vents
1. Turn o and unplug the fan.
2. Clean the motor vents using a soft brush to remove dust.
3. Wipe down the fan blades and housing with a dry cloth.
Prolonged use in a poorly ventilated
space
1. Turn o the fan and allow it to cool down.
2. Ensure it is operating in a well-ventilated area.
Electrical issue
3. If the fan continues to overheat, unplug it and contact
customer service for further assistance.
Reduced airow
Dirty or obstructed fan blades
1. Turn o and unplug the fan.
2. Clean the blades with a soft, dry cloth to remove dirt or debris.
Worn or slipping belt
Contact customer service for further assistance or a belt
replacement if necessary.
833-950-1185 | support@visionairproducts.com | www.visionairproducts.com
4560 West 160th Street
Cleveland, OH 44135
Printed in China | 1024_M095
