POWERQI MQ07 Magnetic Wireless Charger User Manual

100

产品配色与工艺说明图

Product Colour,Material & Finishing Specﬁcations

Tolerance

公差

Product Model

产品型号

Part Number

物料编号

Material

材质

Remark

备注

Original Designer

原设计师

Veriﬁng

审核

Date

日期

Color

颜色

Membrane

表面工艺

Dimension

尺寸

Scale

比例

Job No.

图档编码

Revision

版本号

Change Description

版本变更描述

Brand

品牌

Product Type

产品类

Description

描述

1.0

1:1

说明书

风琴折双面印

2026.6.26

四色印刷

MQ07

128g哑粉纸

(MQ07)

中性

60*75mm

磁吸无线充电器

用户手册

正确充电方式 FCC警告

Magnetic Wireless Charger

User Manual

1. Do not squeeze or collisions.

2. Do not disassemble or throw into fire or water, to avoid

causing a short circuit leakage.

3. Do not use wireless charger in severely hot, humid or

corrosive environments, to avoid circuit damage and

occurs leakage phenomenon.

4. Do not place too close with magnetic stripe or chip

card (ID card, bank cards, etc.) to avoid magnetic failure.

5. Please keep the distance at least 20cm between

implantable medical devices (pacemakers, implantable

cochlear, etc.) and the wireless chargers, to avoid

potential interference with the medical device.

6. To take care of the children, to ensure that they won't

play the wireless charger as a toy, to avoid unnecessary

accidents.

* All the pictures involved in the manual are schematic diagrams.

The final product shall be subject to the actual item.

Included: wireless charger, power cable, user manual.

Charging mode

Notes

Connect to power adapter

连接适配器充电

Thanks for choosing us！

感谢您购买本产品！

Specification

This product is a foldable magnetic wireless charger that

supports smart phone charging.

Please kindly read the user manual before using and keep

it for future reference.

本产品是一款可折叠磁吸无线充电器，支持智能手机充电，

能让您轻松体验数码产品的无限乐趣。

使用本产品前请认真阅读本手册并妥善保存，以备查阅。

规格参数

输入: 5V 3A, 9V 3A, 12V 2.5A, 15V 2A

输出: 25W MAX

规格尺寸: φ60×11mm

产品重量: 43g

工作频率: 110-205kHz, 360kHz

接收距离: ≤3mm

电力转换: ≥70%

Input: 5V 3A, 9V 3A, 12V 2.5A, 15V 2A

Output: 25W MAX

Dimension: φ60×11mm

NW.: 43g

F requency: 110-205kHz, 360kHz

C harging distance: ≤3mm

C onversion: ≥70%

① 将电源适配器插在插座上。

② Type-C电源线一端连接适配器，另一端连接无线充电器。

注：本产品需另外购买PD30W以上的适配器使用，请根据适配器接口选择

是否使用转接头。

Note: This product requires an additional purchase of a PD30W or higher

adapter for use. Please select whether to use an adapter based on the

adapter interface.

① Connect the power adapter to socket.

② Connect one end of the Type-C power cable to the adapter and the

other end to the wireless charger.

1、请勿挤压或碰撞。

2、请勿自行拆卸或投入火中、水中,避免造成短路漏电。

3、请勿在严重高温、潮湿或腐蚀性环境下使用无线充电器，避免

损坏电路出现漏电现象。

4、请勿与带磁条或者芯片的磁卡 (身份证、银行卡等) 放置太近,

避免造成磁卡失效。

5、请保持植入医疗设备 (心脏起搏器、植入性耳蜗等) 与无线充电

器之间的距离至少为20cm,以避免对医疗设备造成潜在干扰。

6、应看管好儿童,以确保他们不将无线充电器当成玩具来玩,以避

免不必要的意外。

注意事项

* 说明书涉及图片均为示意图，最终产品以实物为准。

内含：无线充电器、电源线、用户手册。

* 本产品同时支持对不带磁吸功能的无线充电设备进行充电。

① Make sure the wireless charger is plugged in and in standby mode.

② Place your phone with magnetic wireless charging capability on the

charging pad; the pad will automatically align and adjust the wireless

charging stand to the appropriate angle.

① 确认无线充电器连接电源，并处于待机状态。

② 将带有磁吸无线充电功能的手机放置在充电板上，充电板会自动吸附对

位，调整无线充支架到合适的角度。

* This product also supports charging wireless devices without magnetic

charging capabilities.

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Any changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

NOTE: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or

television reception,which can be determined by turning the

equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

FCC Warning

本设备符合FCC规则第15部分规定，操作受以下两个条件的约束：

(1)本设备不得造成有害干扰；

(2)本设备必须接受收到的任何干扰，包括可能导致意外操作的干

扰。

任何未经合规责任方明确批准的更改或修改都可能导致用户操作设

备的权力失效。

注意：根据FCC规则第15部分规定，本设备已经过测试，并符合B

类数字设备的限值要求。这些限制旨在提供合理的保护，防止住宅

安装中的有害干扰。本设备会产生并使用射频能量，如果未按照说

明安装和使用，可能会对无线电通信造成有害干扰。但是不能保证

在特定安装中不会发生干扰。如果本设备确实对无线电或电视接收

造成有害干扰（可通过关闭设备再打开来确定），我们鼓励用户尝

试通过以下一种或多种措施来纠正干扰：

• 重新定向或重新定位接收天线。

• 增加设备和接收器之间的分离。

• 将设备连接到与接收器连接的电路不同的电路上的出口。

• 咨询经销商或经验丰富的广播/电视技术人员寻求帮助。

FCC辐射暴露声明

该设备符合针对不受控制环境规定的FCC辐射暴露限值。

在安装和操作此设备时，应确保与散热器的距离至少为20厘米，且

避免靠近身体。

FCCRadiationExposureStatement

ThisequipmentcomplieswithFCCradiationexposurelimitsset

forthforanuncontrolledenvironment.Thisequipmentshouldbe

installedandoperatedwithaminimumdistanceof20cm

betweentheradiatorandyourbody.

60.0 mm

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

75.0 mm

conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment

The device has been evaluated to meet general RF exposure requirement.

To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation configurations of the transmitter and its

antenna(s).
