PMP48IR
Portable Megaphone with Built-in Battery
Megaphone Speaker with Built-in Rechargeable Battery,
Aux (3.5mm) Input for MP3/Music, Siren Alarm
www.PyleUSA.com
PMP48IR
Portable Megaphone with Built-in Battery
Megaphone Speaker with Built-in Rechargeable Battery,
Aux (3.5mm) Input for MP3/Music, Siren Alarm
This user manual contains important information for safe operation and
optimal megaphone performance. Please carefully read and follow safety
notes and instructions. Save this manual for future reference. Make sure that it
is available to all persons using this device.
2
Play Button
Siren Button
ON/OFF Button
Record Button
Microphone
Volume
Control
OPEN button
Battery Container
Back Cover
Grip
Speaker
Audio Line IN
www.PyleUSA.com
OPERATION
• Open the back cover by pressing down on the ‘Open’ Button
• Insert 6 x 'D' Batteries then close back cover until locks into position.
Now, you’re megaphone is ready for operation.
• To activate the megaphone, press the ‘ON/OFF’ button on the back cover.
• When using the megaphone, place your lips as close as possible to the
megaphone when speaking. Adjust the ‘Volume Control’ to the desired
level without causing any howling or feedback.
• Press the ‘Play’ button to play recorded voice or press the ‘Siren’ button to
activate emergency siren/alarm. To switch o the siren, press the same
button again, or press the ‘ON/OFF’ button.
• Adjust the volume control to the min. before recording. To record, press
the RECORD button. Now your megaphone s ready for recording.
The longest record time is about 10 seconds. Press the RECORD button
again after recording is done.
• Press the PLAY Button to activate the recorded materials circularly.
PRECAUTIONS
• Ensure correct polarity of Batteries used. Insert the batteries in the correct
direction by aligning the (-) marks on the batteries with the spring in the
back cover.
• Use new batteries/cells whenever possible.
• When the megaphone is not in use for a long period of time, remove the
dry Batteries and replace.
• Drained Batteries or rechargeable battery will not give sucient sound
volume.
BATTERY CHARGING
1. The megaphone features a removable rechargeable battery, that plugs-in
directly into the wall power outlet for charging. Once connected to the
wall power outlet, the battery will begin charging automatically (average
time for full-charge : 8.5 hours). A Red light will be lit while charging and
turns Green when fully charged.
3
www.PyleUSA.com
2. Once fully charged, insert the battery into the megaphone using the
release button in the rear of the megaphone. Be sure to slide the battery
into the compartment properly, ensuring the power connection cable is
exposed.
3. Once the battery is inserted, connect the battery power cable connector
into the megaphone power input (You may need to partially close the
open megaphone compartment to make the connection).
4
www.PyleUSA.com
PMP48IR
Portable Megaphone with Built-in Battery
Megaphone Speaker with Built-in Rechargeable Battery,
Aux (3.5mm) Input for MP3/Music, Siren Alarm
Features:
• (3) Audio Modes: Record, Siren Alarm and Talk
• 10 Second Integrated Audio Memory with Replay Ability
• Built-in Rechargeable Battery Charges via Wall Outlet
• *Or can be Battery Operated: (6) x 'D' Batteries, Not Included
• Adjustable Volume Control
• Ergonomic Pistol Grip and Light-Weight Chassis
• Button Activated Siren Alarm
• Aux (3.5mm) Input Connector Jack
• Connect & Stream Audio from External Devices
(iPhone, Android, Smartphone, MP3 Player, Tablet, etc.)
• 1,000 Square Yard Range
• Used by U.S. Armed Forces
What's in the Box:
• Megaphone Speaker
• Removable Rechargeable Battery
• Wired Plug-in Handheld Microphone
Technical Specs:
• MAX Power Output: 40 Watt
• Rechargeable Battery: 7.4V Lithium-iOn, 1500mAh (11.1Wh, 124g)
• Power: 220-240V Compatible
• Dimensions: Horn Diameter 8.0'' x Length 13.1'' -inches
• Sold as: Unit
