© FISHER & PAYKEL APPLIANCES LIMITED 2026
90005565A UK-IE-EU PLANNING GUIDE VERSION A - FEBRUARY 2026
60CM MINIMAL OVENS AND COMPANIONS
PLANNING GUIDE
SERIES 7 PYROLYTIC OVEN | OB60SAMPTB5
SERIES 7 COMPACT COMBI-STEAM OVEN | OS60NAMVTB5
SERIES 7 COMPACT COMBI-MICROWAVE OVEN | OM60NMTB5
SERIES 9 BUILT-IN COFFEE MAKER | EB60MSB3
SERIES 9 TALL WARMING DRAWER | WB60SMTB3
SERIES 9 INTEGRATED TALL WARMING DRAWER | WB60SDTEI3
SERIES 9 WARMING DRAWER | WB60SMB3
SERIES 9 INTEGRATED WARMING DRAWER | WB60SDEI3
SERIES 9 VACUUM SEAL DRAWER | VB60SMB3
SERIES 9 INTEGRATED VACUUM SEAL DRAWER | VB60SDEI3
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 290005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
CONCEPT DESIGN PAGE
DEVELOPED AND DETAILED DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE
DESIGN CHOICE
Styles 4
Minimal Style 5
Installation Options 6
Overview 7
SPECIFICATION GUIDE
Pyrolytic Oven 9
Compact Combi-Steam Oven 10
Compact Combi-Microwave Oven 11
Built-in Coee Maker 12
Tall Warming Drawer 13
Integrated Tall Warming Drawer 14
Warming Drawer 15
Integrated Warming Drawer 16
Vacuum Seal Drawer 17
Integrated Vacuum Seal Drawer 18
Dimensions - Ovens and Built-in Coee maker 19
Dimensions - Drawers 20
Services 21
SUPPORT
For additional design planning and installation support please
contact the Fisher & Paykel design support team.
designsupport@fisherpaykel.com
CONTENTS | 60CM OVENS AND COMPANIONS
INTRODUCTION
This comprehensive planning guide provides you with the
framework and tools to achieve your desired design outcome
with Fisher & Paykel appliances. In this guide, you will find a
range of conceptual, detailed, and dimensional product
information to bring your ideas to life and create spaces that
truly reflect your vision.
NOTES
The models shown in this Planning Guide may not be available
in all markets and are subject to change at any time. Refer to to
our website fisherpaykel.com for the latest document version.
Product specifications may vary from those shown.
This Planning Guide should not be used as installation guidance
for any product. Specific installation guidance will be available
with the product on delivery and on our website.
<< CONTENTS
CONTENTS
PAGE 3© FISHER & PAYKEL APPLIANCES LIMITED 2026PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 202690005565A UK-IE-EU
DESIGN CHOICE
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 490005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
DESIGN CHOICE | 60CM OVENS AND COMPANIONS STYLES
This Planning Guide is for the Minimal Style featuring 60cm Ovens
and Companions. For information on other styles, please visit the
Fisher and Paykel website. To see what models are available, head
to the 'Overview' section in this Planning Guide.
MINIMAL STYLE MINIMAL STYLE - HANDLELESS CONTEMPORARY STYLE
Celebrating a singular aesthetic to blend seamlessly into the kitchen, Minimal style ovens feature subtle textural and tonal contrasts for a sense
of refinement and purity.
Defined by clean lines and timeless design cues, Contemporary
style ovens bring a sense of balance and refinement. A versatile
aesthetic that complements a range of kitchen styles.
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 590005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
MINIMAL STYLEDESIGN CHOICE | 60CM OVENS AND COMPANIONS
FINISH OVENS COMPANIONS INSTALLATION OPTIONS
PYROLYTIC
COMBI-
STEAM
COMBI-
MICROWAVE
BUILT-IN
COFFEE
MAKER
TALL
WARMING
DRAWER
WARMING
DRAWER
VACUUM
SEAL
DRAWER
Installation in wall
Installation under-bench
*Integrated model, panel ready for a custom front panel.
*
* *
Black
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 690005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
INSTALLATION OPTIONSDESIGN CHOICE | 60CM OVENS AND COMPANIONS
CONSIDERATIONS
Dierent configurations possible, consider
heights for grid and row installations.
STACK HEIGHT
Stack Height is overall product height with
minimum clearance above appliance front
panel to upper cabinetry front panel or
appliance.
STACKED INSTALLATION GRID INSTALLATION ROW INSTALLATION
Stack Height
750mm
Stack Height
600mm
Stack Height
600mm
Stack Height
600mm
Stack Height
600mm
Stack Height
1200mm
Stack Height
1210mm
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 790005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OVERVIEWDESIGN CHOICE | 60CM OVENS AND COMPANIONS
SIDE
ELEVATION
FRONT
ELEVATION
*
PYROLYTIC OVEN COMPACT COMBI-STEAM
OVEN
COMPACT COMBI-
MICROWAVE OVEN
BUILT-IN COFFEE TALL WARMING DRAWER WARMING DRAWER VACUUM SEAL DRAWER
Series Series 7 Series 7 Series 7 Series 9 Series 9 Series 9 Series 9
Black OB60SAMPTB5 OS60NAMVTB5 OM60NMTB5 EB60MSB3 WB60SMTB3 WB60SMB3 VB60SMB3
Integrated Models - - - - WB60SDTEI3 WB60SDEI3 VB60SDEI3
Interface 5" Touchscreen 5" Touchscreen 5" Touchscreen 4.3" Touchscreen - - -
Overall Height 598mm 458mm 458mm 458mm 290mm 140mm 140mm
Overall Width 596mm 596mm 596mm 596mm 596mm 596mm 596mm
Control Panel/Front
Panel Thickness
20mm 20mm 20mm 20mm 20mm 20mm 20mm
*Integrated models available.
*
*
<< CONTENTS
PAGE 8© FISHER & PAYKEL APPLIANCES LIMITED 2026PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 202690005565A UK-IE-EU
SPECIFICATION GUIDE
SERIES 7 & 9
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 990005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB60SAMPTB5SPECIFICATION GUIDE | PYROLYTIC OVEN, 60CM
OVERVIEW
Designed to complement Minimal style appliances, this oven
delivers a seamless, flush finish – ideal for modern kitchen
designs. The pyrolytic self-cleaning function breaks down food
residue for an easy clean, while precise cooking methods with
temperature and heat type recommendations for a wide range
of food types are easily accessed via the touch screen and
SmartHQ™.
PRODUCTS
OB60SAMPTB5 - Black
60cm Series 7 Minimal Pyrolytic Oven
SERIES & STYLE
Series 7
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
3 Premium soft open and close door
4 Generous 72L useable capacity
5 5” touchscreen is intuitive and easy to use
6 Create perfect results with precise cooking methods, with
temperature and heat type recommendations for your food
type
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Pyro-proof Side Ladders
2 Telescopic Sliding Runners
3 Wire Shelf
4 Multi-functional Air Fry Tray
ACCESSORIES
5 Roasting Dish
6 Flat Brushed Baking Tray
7 Wired Temperature Sensor
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1090005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OS60NAMVTB5SPECIFICATION GUIDE | COMPACT COMBI-STEAM OVEN, 60CM
OVERVIEW
Designed to complement Minimal style appliances, this Combi-
Steam oven delivers a seamless, flush finish – ideal for modern
kitchen designs. With versatile cooking options including steam
or convection, plus a Steam Clean function for easy
maintenance. Precise cooking methods with temperature and
heat type recommendations for a wide range of food types are
easily accessed via the touch screen and SmartHQ™.
PRODUCTS
OS60NAMVTB5 - Black
60cm Series 7 Minimal Compact Combi-Steam Oven
SERIES & STYLE
Series 7
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Versatile cooking options with steam or convection heat for
optimal results
3 Premium soft open and close door
4 Compact 45L useable capacity
5 5” touchscreen is intuitive and easy to use
6 Create perfect results with precise cooking methods, with
temperature and heat type recommendations for your food
type
7 Moisture control and even heat distribution thanks to
ActiveVent™ and AeroTech™ technology
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Telescopic Sliding Runners
3 Wire Shelf
4 Multi-functional Air Fry Tray
5 Roasting Dish
ACCESSORIES
6 Large Perforated Steam Dish
7 Small Perforated Steam Dish
8 Large Steam Dish
!0
Wired Temperature Sensor
!1
Descale Solution x2 sachets (Part 580295)
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1190005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OM60NMTB5SPECIFICATION GUIDE | COMPACT COMBI-MICROWAVE OVEN, 60CM
OVERVIEW
Designed to complement Minimal style appliances, this Combi-
Microwave oven delivers a seamless, flush finish – ideal for
modern kitchen designs. Versatile cooking options including
microwave or convection oer ecient heating across a variety
of dishes. Precise cooking methods with temperature and heat
type recommendations for a wide range of food types are easily
accessed via the touch screen and SmartHQ™.
PRODUCTS
OM60NMTB5 - Black
60cm Series 7 Minimal Compact Combi-Microwave Oven
SERIES & STYLE
Series 7
Minimal
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Combines fast microwave cooking with even convection
heat for versatile, efficient heating across a variety of dishes
3 With soft open and close, the CoolTouch door is safe to
touch from the outside - protecting hands and surrounding
cabinetry
4 Compact 38L useable capacity
5 5” touchscreen is intuitive and easy to use
6 Create perfect results with precise cooking methods, with
temperature and heat type recommendations for your food
type
7 Versatile microwave only, convection only or combi-
microwave functions to suit a range of cooking styles
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Wire Shelf
3 Step Down Wire Shelf
4 Glass Tray
5 Grill Rack
6 Wired Temperature Sensor
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1290005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
EB60MSB3SPECIFICATION GUIDE | BUILT-IN COFFEE MAKER, 60CM
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Intuitive touch display brews a perfect cup of coffee at the
touch of a button
3 Programmable timer turns on the Coffee Maker at the ideal
time each day
4 Personalised coffee and smart self-learning menu
preferences with 13 functions to suit any taste
5 Allows you to prepare hot milk or creamy froth in seconds
6 Stainless steel conical burr grinder with 13 coarseness
positions
7 15 bar pump pressure
8 Self-cleaning function and easy-to-empty coffee grounds
container and drip tray
9 2.4L water tank capacity
ACCESSORIES
1 Milk Container (Auto-Froth)
2 Steam Wand
3 Coffee Spoon
4 Cleaning Brush
5 Descaler Solution – 1 bottle
6 Water Hardness Indicator Paper
7 Water Filter
OVERVIEW
Designed to complement Minimal style appliances, this Coee
Maker delivers a seamless, flush finish – ideal for modern
kitchen designs. It learns your preferences over time, oering
personalised coee at the touch of a button. With precise
grinding, creamy milk frothing, and eortless self-cleaning, it
brings barista-quality coee home.
PRODUCTS
EB60MSB3 - Black
60cm Series 9 Minimal Built-in Coee Maker
SERIES & STYLE
Series 9
Minimal
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1390005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB60SMTB3SPECIFICATION GUIDE | TALL WARMING DRAWER, 60CM
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 16 standard-sized place settings
7 Six tailored programmes including Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
OVERVIEW
Designed to complement Minimal style appliances, this
Warming Drawer delivers a seamless, flush finish – ideal for
modern kitchen designs. Featuring a push-to-open mechanism,
intuitive touch controls, and a smooth glass base for easy
cleaning. With six tailored programmes and space for 16 place
settings, it keeps meals ready to serve.
PRODUCTS
WB60SMTB3 - Black
60cm Series 9 Minimal Tall Warming Drawer
SERIES & STYLE
Series 9
Minimal
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1490005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB60SDTEI3SPECIFICATION GUIDE | INTEGRATED TALL WARMING DRAWER, 60CM
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 16 standard-sized place settings
7 Six tailored programmes including Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
ACCESSORIES
1 Accessory rack for optimising space
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Warming Drawer with kitchen cabinetry
for a cohesive kitchen look. Featuring a push-to-open
mechanism, intuitive touch controls, and a smooth glass base
for easy cleaning. With six tailored programmes and space for
16 place settings, it keeps meals ready to serve.
PRODUCTS
WB60SDTEI3
60cm Series 9 Integrated Tall Warming Drawer
SERIES & STYLE
Series 9
Integrated
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1590005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB60SMB3SPECIFICATION GUIDE | WARMING DRAWER, 60CM
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 6 standard-sized place settings
7 Six tailored programmes including Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
OVERVIEW
Designed to complement Minimal style appliances, this
Warming Drawer delivers a seamless, flush finish – ideal for
modern kitchen designs. Featuring a push-to-open mechanism,
intuitive touch controls, and a smooth glass base for easy
cleaning. With six tailored programmes and space for 6 place
settings, it keeps meals ready to serve.
PRODUCTS
WB60SMB3 - Black
60cm Series 9 Minimal Warming Drawer
SERIES & STYLE
Series 9
Minimal
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1690005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
WB60SDEI3SPECIFICATION GUIDE | INTEGRATED WARMING DRAWER, 60CM
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Automatic switch-off and delayed start functionality to help
keep dishes warm until it is time to serve
6 Room for 6 standard-sized place settings
7 Six tailored programmes including Warming, Proofing,
Dehydrating, and Slow Cooking offer convenience and
flexibility
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Warming Drawer with kitchen cabinetry
for a cohesive kitchen look. Featuring a push-to-open
mechanism, intuitive touch controls, and a smooth glass base
for easy cleaning. With six tailored programmes and space for 6
place settings, it keeps meals ready to serve.
PRODUCTS
WB60SDEI3
60cm Series 9 Integrated Warming Drawer
SERIES & STYLE
Series 9
Integrated
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1790005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
VB60SMB3SPECIFICATION GUIDE | VACUUM SEAL DRAWER, 60CM
FEATURES
1 Minimal style is designed to fit flush with cabinetry. Matches
our Minimal style family of appliances
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
6 Allows effortless preparation for sous vide cooking
7 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately
ACCESSORIES
1 External Vacuuming Accessory Kit
2 Large BPA-free Vacuum Seal Bags - 50 bags (Part 793034)
3 Small size BPA-free Vacuum Seal Bags - 50 bags (Part
793033)
OVERVIEW
Designed to complement Minimal style appliances, this Vacuum
Seal Drawer delivers a seamless, flush finish – ideal for modern
kitchen designs. A push-to-open mechanism and intuitive touch
controls oer eortless use, while three vacuum and heat
sealing levels support sous vide preparation, marinating, and
food storage, using reusable and BPA-free food-grade bags.
PRODUCTS
VB60SMB3 - Black
60cm Series 9 Minimal Vacuum Seal Drawer
SERIES & STYLE
Series 9
Minimal
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1890005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
VB60SDEI3SPECIFICATION GUIDE | INTEGRATED VACUUM SEAL DRAWER, 60CM
FEATURES
1 Panel ready design allows for seamless integration and
customisation with kitchen cabinetry for a cohesive kitchen
look
2 Push-to-open drawer, designed for added convenience
3 Simple and intuitive touch controls for effortless operation
4 Easy-to-clean glass base
5 Three levels of vacuum and heat sealing - for easy re-
sealing, food portioning, marinating, storage and extending
shelf life
6 Allows effortless preparation for sous vide cooking
7 Our food-grade, BPA-free bags are an excellent storage
option — these can be re-used if sealed and cut
appropriately
ACCESSORIES
1 External Vacuuming Accessory Kit
2 Large BPA-free Vacuum Seal Bags - 50 bags (Part 793034)
3 Small size BPA-free Vacuum Seal Bags - 50 bags (Part
793033)
OVERVIEW
Panel ready design allows for seamless integration and
customisation of this Vacuum Seal Drawer with kitchen
cabinetry for a cohesive kitchen look. A push-to-open
mechanism and intuitive touch controls oer eortless use,
while three vacuum and heat sealing levels support sous vide
preparation, marinating, and food storage, using reusable and
BPA-free food-grade bags.
PRODUCTS
VB60SDEI3
60cm Series 9 Integrated Vacuum Seal Drawer
SERIES & STYLE
Series 9
Integrated
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 1990005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB60SAMPTB5, OS60NAMVTB5,
OM60NMTB5, EB60MSB3SPECIFICATION GUIDE | 60CM OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
PYROLYTIC OVEN
OB60SAMPTB5
COMPACT COMBI-STEAM OVEN
OS60NAMVTB5
COMPACT MICROWAVE OVEN
OM60NMTB5
BUILT-IN COFFEE MAKER
EB60MSB3
PRODUCT DIMENSIONS mm mm mm mm
A Overall height
598 458 458 458
B Overall width
596 596 596 596
C Chassis height
575 435 435 445
D Chassis width
556 556 556 560
E Chassis depth
545 545 545 460
F Control panel thickness
20 20 20 20
Depth with door/drawer fully open* 463 324 324 435
*Measured from front of control panel.
CAVITY DIMENSIONS mm mm mm mm
G Minimum inside height of cavity
580 440 440
450
H Minimum inside width of cavity
560 560 560
560*
I Minimum inside depth of cavity**
550 550 550***
545***
Recommended cabinet height
600 460 460
460
Recommended cabinet width
600 600 600
600
*Cabinetry requires additional vertical sidewalls to secure the product. **Measured from front of chassis. ***A rear ventilation air vent totalling 280cm² is required. The air vent must be located at the rear of the cabinet, it can be positioned at the base, sides, back or top of
the cavity.
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
Ventilation
required
Ventilation
required
A
B
C
D
E
F
g
h
i
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 2090005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
TALL WARMING DRAWER
WB60SMTB3
TALL INTEGRATED WARMING
DRAWER
WB60SDTEI3
WARMING DRAWER
WB60SMB3
INTEGRATED WARMING
DRAWER
WB60SDEI3
VACUUM SEAL DRAWER
VB60SMB3
INTEGRATED VACUUM SEAL
DRAWER
VB60SDEI3
PRODUCT DIMENSIONS mm mm mm mm
A Overall height
290
290
140 140 140 140
B Overall width
596
596
596 596 596 596
C Chassis height
290
290
140 140 140 140
D Chassis width
543
559*
543 559* 556**
559**
E Chassis depth***
547
566
547 566 545
563
F Front panel thickness
20
min 16****
20
min 16****
20
min 16****
Front panel height
286
min 286 136 min 136 136 min 136
Front panel width
596
min 596 596 min 596 596 min 596
Depth of drawer open*****
414
414 414 414 414 414
*Including side brackets. **Including side brackets and anti-tip brackets. ***Including power plug. ****A clearance of 2mm between the cabinet and the custom panel is required for the push-to-open mechanism (spacer included). Maximum custom panel weight 5kg.
*****Measured from front of control panel.
CAVITY DIMENSIONS mm mm mm mm
G Minimum inside height of
cavity
292 292
142 142 142 142
H Minimum inside width of
cavity
560 560
560 560 560 560
I Minimum inside depth of
cavity*
550 570
550 570 550 570
Recommended cabinet height
294 294
144 144 144 144
Recommended cabinet width
600 600
600 600 600 600
*Measured from front of chassis. Note: Drawers can fully support 60cm Fisher & Paykel ovens, without adding shelf in between.
CAVITY DIMENSIONS
PRODUCT DIMENSIONS
WB60SMTB3, WB60SDTEI3, WB60SMB3,
WB60SDEI3, VB60SMB3, VB60SDEI3 SPECIFICATION GUIDE | 60CM OVENS AND COMPANIONS
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
A
B
C
D
E
F
g
h
i
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2026 PAGE 2190005565A UK-IE-EU PLANNING GUIDE 60CM OVENS AND COMPANIONS VERSION A - FEBRUARY 2026
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
ALL MODELS
PYROLYTIC OVEN
OB60SAMPTB5
COMPACT COMBI-STEAM
OVEN
OS60NAMVTB5
COMPACT COMBI-
MICROWAVE OVEN
OM60NMTB5
BUILT-IN COFFEE MAKER
EB60MSB3
TALL WARMING DRAWER
WB60SMTB3
INTEGRATED TALL
WARMING DRAWER
WB60SDTEI3
WARMING DRAWER
WB60SMB3
INTEGRATED WARMING
DRAWER
WB60SDEI3
VACUUM SEAL DRAWER
VB60SMB3
INTEGRATED VACUUM SEAL
DRAWER
VB60SDEI3
PRODUCT REQUIREMENTS
Dedicated Circuit (A) 16 16 16 10 10 10 10
Rated Power (W) 2800 - 3300 2800 - 3300 3350 - 3800 1350 810 810 320
Supply (Hz) 50 50 50 50 50 50 50
Voltage (V) 220 - 240 220 - 240 220 - 240 220 - 240 220 - 240 220 - 240 220 - 240
Connection
Hard-wired
min 1500mm**
Hard-wired
min 1500mm**
Hard-wired
min 1500mm**
Flex cord
1700mm*
Flex cord
1800mm*
Flex cord
1800mm*
Flex cord
1800mm*
*Supplied with product. **The electrician provides sucient free length of power supply cable to reach from the bottom rear of the cavity to at least 1.5m in front of the bottom edge of the opening.
Note: For multi-residential installs, use the Rated Power to calculate the demand.
CAPACITY
Total Oven capacity 85L 55L 49L - - - -
Total water tank capacity - 1.4L - 2.4L - - -
Note: All Coee Makers and Steam Ovens have internal water tanks which need to be filled manually. No external water supply is required.
SERVICES | 60CM OVENS AND COMPANIONS
ISOMETRIC
VIEW
<< CONTENTS
