Note: When replacing included Transmitter batteries:
Use alkaline batteries only.
Do not mix old and new batteries.
Do not mix alkaline, standard or rechargeable batteries.
Switch vehicle OFF
when not in use.
Wipe body with a
soft rag or cloth.
Do not use chemicals
or water to clean.
Brush areas where
dirt gets trapped.
Problem - Vehicle does not move or moves slowly.
- Make certain there are fresh batteries in the transmitter and that they have been installed in the
correct position. You may need to re-sync the transmitter and vehicle. Refer to sync instructions in
section 7.
- Are the (+) and (-) markings on the batteries in the same position as the (+) and (-) markings in the
Transmitter Battery Compartment?
- Has the Battery Pack been installed in the vehicle?
- Has the rechargeable Battery Pack been fully charged?
- Are the (+) and (-) markings on the Battery Pack in the same position as the (+) and (-) markings in
the Battery Compartment?
- Are the metal contact tabs touching, rusty or dirty in the transmitter?
- Make certain that the vehicle ON/OFF switch is in the "ON" position.
Problem - Vehicle moves by itself or exhibits reduced range from the transmitter.
- Make certain there is no outside radio interference in your area. The best way to test this is to take
the vehicle as far away from radio towers, electrical lines or tall buildings as possible to ensure no
further radio interference wil occur.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This transmitter is equipped with 2.4GH technology which allows up to 6 vehicles to be raced at the
same time.
Before first use and after any time the batteries are replaced, the transmitter must be paited to the
vehicle.
To sync transmitter and vehicle, follow the steps below:
1. Correctly install batteries in the transmitter.
2. Place vehicle upside down, and turn Vehicle ON/OFF switch to the ON position. The Vehicle is only
in sync mode for 30 seconds.
3. Immediately press and hold the Forward/Reverse joystick on the transmitter. Keep holding until
wheels move (up to 30 sec.).
AGES
6+
WARNING:
CHOKING HAZARD – Small Parts.
Not for children under 3 years of age.
© 2025 MerchSource, LLC. Irvine, CA 92618. All rights reserved.
Official licensed product of Polaris Industries Inc., all rights reserved.
POLARIS and the POLARIS Logos are trademarks of Polaris Industries Inc.
Model No.: 1019461
Printed in China
SCAN TO
UNLOCK
OFF-ROAD
ACTION!
* If vehicle pulls to the left or right during forward driving the Wheel Alignment may need to be
adjusted. The Wheel Alignment Dial is located on bottom of chassis between the front wheels.
1. Locate the ON/OFF switch and USB cord on the under-side of the vehicle.
2. Turn the ON/OFF switch to the "OFF" position.
3. Open Storage Compartment cover.
4. Remove USB cable from the Storage Compartment. (Use care when extending cord as it is
attached to inside internal battery). Cord can be plugged into any 5V DC computer or 5V DC USB
outlet brick (not included).
5. While charging, the LED under the vehicle will be on. Once fully charged the LED will turn off.
Charging is completed in approximately 1.5 hours. Return cord and secure storage lid before
operating the vehicle.
After Pairing successfully, the RGB LED and the 2 light bars will be on in red color.
• Press the light button of remote once every time，the RGB LED and the 2 light bars will change the
RGB LED color in turns: Red – Green – Blue.
• Press and hold the light button of the remote for 2 seconds，they will start flashing rapidly. Press
and hold for 2 seconds again, they will be off. Press and hold for 2 seconds once more, they will be
on again.
Section 1: Table of Contents
Section 2: Cautions
Component Checklist
Section 3: Features and Functions (Vehicle)
Section 4: Charging the Battery
Section 5: Battery Installation
Features and Functions (Transmitter)
Section 6: Precautions and Care
Section 7: Troubleshooting and Support
• Do not mix old and new batteries.(if more than one batteries are used).
• Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.
• Alkaline batteries are recommended. Use only the specified voltage.
• Insert batteries using the correct polarity. Always use, replace, and recharge (if applicable)
batteries under adult supervision.
• Do not attempt to charge non-rechargeable batteries.
• Do not short-circuit the battery supply terminals.
• Do not dispose of batteries in fire: batteries may explode or leak.
• Remove batteries before storing.
• Recycle or dispose of batteries according to federal, state, and local laws.
• Keep these instructions for future reference.
BATTERY WARNINGS
• This product contains batteries that are non-replaceable.
• There is a risk of fire and personal injury if battery is punctured, damaged, or misused.
• Do not dismantle, crush, incinerate or short-circuit battery.
• Never expose battery to extreme temperatures or moisture.
• Keep away from flammable materials and direct sunlight.
• Only charge using the provided charger, cable, and/or adapters.
• Rechargeable battery is only to be charged by an adult.
• Adult supervision is required while charging the battery.
• Allow battery to cool to room temperature before charging.
• Charge on a non-flammable surface and keep away from flammable products.
• Discontinue charging if battery becomes hot, swells, smokes, or gives off a strong odor.
• Battery chargers used with the product are to be regularly examined for damage to the cord, plug,
enclosure, and other parts. In the event of such damage, chargers must not be used until the
damage has been repaired.
• Recycle or dispose of battery according to federal, state, and local laws.
• Keep these instructions for future reference.
Safety Warning: Rechargable/non-repleaceable
• 1 RC Vehicle With USB Cord
• 1 Transmitter
• 2 AA 1.5V Carbon-zinc Batteries
This vehicle is equipped with a 7.4V 800mAh internal Lithium-lon battery that is recharged via USB.
ON/OFF Switch must be in the OFF position prior to charging.
