Read all instructions and explanations for
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
appliance is sold or passed on, ensure
that the new owner always receives this operation instructions.
delete installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
product is sold or passed on then ensure
that the new owner always receives this
manual.
EN
TUMBLE DRYER
Dryer
MODEL:
MD110H80D/W-UK
CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions ..................................................
INSTALLATION
Product Description ................................................
Installation ...........................................................
OPERATION
Quick Start .............................................................
Before Each Drying ..................................................
Control Panel .........................................................
Option....................................................................
Display....................................................................
Programmes............................................................
Drying Programmes Table ........................................
Consumption Data...................................................
MAINTENANCE
Cleaning and Care .................................................
Trouble Shooting ....................................................
Technical Specifications .........................................
Product Fiche..........................................................
2
9
9
12
13
15
16
18
19
20
21
22
25
27
28
1
DANGER
This symbol indicates that there are dangers to the life and health of persons due to extremely
flammable gas.
SAFETY INSTRUCTIONS
Safety Instructions
2
Warning!
！
To prevent any damages to your and others' life or
property, you have to follow the safety notes.
This heat pump dryer is intended for drying typical
amounts of household laundry, which have been washed
with water. It has been designed solely for private use
and is not suitable for commercial or shared use (i.e. by
several families in an apartment building).
• Use this appliance only as described in this user manual.
• This appliance is for indoor use only.
• Any other use is deemed improper and may result in
damage to property or even personal injury.
• The manufacturer accepts no liability for damage caused
by improper use.
•
Safety Instructions
•
only be connected to a plug with a protective conductor
that has been installed properly. When connecting the
appliance to the mains, make sure that the mains voltage
is correct. You can find more information about this on
the rating plate.
The appliance corresponds to protection class I and may
Intended use
CAUTION: RISK OF FIRE !
SAFETY INSTRUCTIONS
3
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
Warning!
！
Electric shock hazard
•
connection parameter on the rating plate (fuse rating,
voltage and frequency) match the mains electricity supply.
If in any doubt, consult a qualified electrician.
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
• Do not pull the power cord forcefully. Please grasp the
mains plug instead
• Do not plug/draw the mains plug with wet hands.
• Do not bend, clamp or damage the power cord and the
power plug.
• If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Before connecting the tumble dryer, ensure that the
SAFETY INSTRUCTIONS
4
•
external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by a utility.
• Do not connect the appliance to the mains electricity
supply by an extension lead, multi-socket adapter or similar.
• The accessibility of the plug must always be ensured, in
order to disconnect the tumble dryer from the mains.
• If the appliance appear high temperature abnormally,
please draw the mail plug immediately.
Warning: The appliance must not be supplied through an
Injury danger
•
a sliding door or a door with a hinge on the opposite side
to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
• Do not disassemble or install the dryer without any
instruction or supervision.
• Do not stack this dryer on washing machine without
stacking kits. (If you want to stack this dryer on a washing
machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service
agent or similarly qualified persons to avoid any hazards.)
• Do not lean on the opened door of the dryer.
• Condensed water is not drinking water. It can cause
health problems in both people and animals if consumed.
The appliance must not be installed behind a lockable door,
Damage danger
•
See the related chapter in the user manual.
Do not put more load than rated in this user manual.
SAFETY INSTRUCTIONS
5
• Do not operate the dryer without the door filter.
• Do not dry the clothes before being spun.
• Do not expose the dryer directly under the sun.
• Do not install the dryer in humid and drenching environment.
• While cleaning and maintenance, please do remember to
pull out the power plug and do not directly spray the dryer
with water.
• The appliance should not be overturned during normal use
or maintenance.
CAUTION: RISK OF FIRE !
Explosion & Fire danger
•
substances such as kerosene or alcohol. Otherwise, there
may be explosion.
• The appliance contains an environmentally friendly but
flammable R290 refrigerant. Keep away from open flame
and other sources of ignition.
• The tumble dryer is not to be used if industrial chemicals
have been used for cleaning.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
Please do not dry the clothes with any flammable
SAFETY INSTRUCTIONS
6
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
• Fabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
• Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat
from escaping and so create a fire hazard.
• Remove all objects from pockets such as lighters and
matches.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products be placed in a tumble dryer they should first be
washed in hot water with extra detergent. This will reduce,
but not eliminate, the hazard.
• WARNING: Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Openings must not be obstructed.
• The lint trap has to be cleaned frequently.
• Lint must not to be allowed to accumulate around the
tumble dryer.
• WARNING: In the appliance enclosure or in the built-in
structure, keep ventilation openings clear of obstruction.
• WARNING: Do not damage the refrigerant circuit.
Safety with children
SAFETY INSTRUCTIONS
7
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by
children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Always close the door after use. In this way you will avoid
the danger of:
1. Children climbing onto or into the dryer or hiding things
in it.
2. Pets or other small animals climbing into it.
SAFETY INSTRUCTIONS
8
Model
Rated capacity
8.0kg
The packaging is designed to protect the appliance from
damage during transportation. The packaging materials
are environmentally friendly and should be recycled.
Recycling the packaging can reduce the use of raw
materials in the manufacturing process and the amount
of waste in landfill sites.
•
Disposal of packaging material
Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
Dispose of the appliance in accordance with local
requirements for the disposal of Waste Electrical
and Electronic Equipment.
The appliance contains flammable gas (R290).
Contact your municipal authority for information
on how to discard the appliance correctly.
MD110H80D/W-UK
INSTALLATION
9
Product Description
Installation
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves to them
as per the instruction below .
install
Note: The actual model you purchased might differ. Please see the product you purchased in kind prevail.
Connector
Power cord
Door filter
Water container
Door
Control panel
Air inlet
Maintenance cover
Drum
Top board
Pull out the upper drain hose
Put the external drain hose into the
floor drain(be careful not to bend the
external drain hose)
Drain hose
X
Overflow hose
Drain hose
Put the hose holder in the washing
basin or any other sink.
Max.120cm
20
0cm
x
10
INSTALLATION
Installation Position
Transport
Move cautiously. Do not grasp any salient parts of machine. The machine door cannot
be used as the handle for transport. If the dryer can't be transported erectly, the dryer
can be tilted to right less than 30°.
Risk of injury and damage!
Improper handling of the appliance may result in injury.
• The appliance is very heavy. Never transport or carry the appliance alone; always
with the assistance of another person.
• Remove all obstacles on the transport route and from the installation location, e.g.
open doors and clear away objects lying on the floor.
• Do not use the open door as a handhold.
• Remove all package material before using the appliance.
• Before setting up the tumble dryer, check it for any externally visible damage.
Do not install or use a damaged tumble dryer.
• Do not install the tumble dryer in a room where there is a risk of frost occurring.
At temperatures around freezing point the tumble dryer may not be able to operate
properly. There is a risk of damage if the condensed water is allowed to freeze in the
pump and hoses.
Warning!
！
• Children can become entangled in the packaging film or swallow small parts and s
uffocate. Do not allow children to play with the packaging.
• The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to that of the tumble dryer, in such a way that a
full opening of the tumble dryer door is restricted.
• Do not restrict the floor clearance through deep pile carpets, strips of wood or
similar. This might cause heat built-up which would interfere with the operation of
the appliance.
1. It is recommended that, for your convenience, the machine is positioned close to
your washing machine.
2. Do not stack this dryer on washing machine without stacking kits. (If you want to
stack this dryer on a washing machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service agent or similarly qualified
persons to avoid any hazards.)
3. The tumble dryer must be installed in a clean place, where dirt does not accumulate.
Air must be able to circulate freely around the appliance. Do not obstruct the front
air inlet or the air intake grilles at the back of the machine.
11
INSTALLATION
Level Adjusting
Once in its permanent operating position, check that
the dryer is absolutely level with the aid of a spirit level.
If it is not, adjust the feet by hand or using a tool.
Power Supply Connection
4. To keep vibration and noise within minimum level when the dryer is in use, it must
be placed on a firm and level surface.
5. The feet must never be removed.
1.Make sure that the voltage of the power supply is the same as the electric specification.
2.Do not connect the dryer with the power connection board, a universal plug or socket,
do not use multi-plug adapters and extension cables.
6.Place the product with its back surface to the wall (for heater models).
OPERATION
12
After Drying
Drying
Buzzer beep and "End"on display.
1 2 3 4
open the door and
take out laundry
pull out the
container
pour out
condensate water
clean the filter power off
Quick Start
Before using, make sure the tumble dryer is installed correctly.
Note!
plug in
2
load
3
close the door
start
select program
select function
or default
• If the socket with a switch is used, please press the switch to turn off the power
directly.
Note!
Before Drying
5
1
13
OPERATION
Before Each Drying
• Leave it to stand for 2 hours after transporting. Before first use, please use
the soft fabric to clean the inside drum.
1. Put some clean rags into the drum.
2.Plug the power, rotate the knob button.
3. Select the 【AIRFRESH】 Programme, press 【 】 button.
4. After finishing this programme, please follow the “cleaning and care ”
(refer to page ) to clean the door filter.
• During drying, the compressor and the water will generate some noise
which is entirely normal.
22
Note!
1.Before drying, thoroughly spin the laundry in washing machine. High spin speed
shortens the drying time and saves energy.
2.For uniform drying result, sort the laundry according to fabric type and select the
appropriate drying programme.
3.Before drying, please close zips, hooks and eyelets, button, tie fabric belts, etc.
4.Remove all objects from pockets such as lighters and matches.
5.Sew in or remove underwiring from bras.
6.Close duvet covers and pillow cases to prevent small items from being rolled up
inside them.
7.Leave jackets open and undo any long zips so that textiles dry evenly.
8.Do not over dry the clothes, because over dried clothes can easily get creases.
9.Do not dry the articles containing rubber or similar elastic materials.
10.Keep the area around the tumble dryer clean. Coal dust or flour may cause an
explosion.
11.The door shall be opened only after the programme of the tumble dryer is finished
to avoid being scalded by hot steam or over heated drying machine.
12.Clean the lint filter and empty water container after each use to avoid extension of
drying time and increase of energy consumption.
13.Do not dry clothes after dry-clean process.
14
OPERATION
Do not put more load than rated.
• Do not dry dripping wet laundry. The dryer might get damaged
•
Note!
The reference weight of dry clothes (weight per item)
Sweater
(mixed 800g)
Jacket
( cotton 800g )
Jeans
(800g)
Bath Towel
(cotton 900g )
Single bedsheet
(cotton 600g )
T-Shirt
(cotton 180g )
Work clothes
( 1120g)
Underwear
(cotton 70g )
Pyjamas
( 200g)
Socks
(mixed-weave 50g )
Shirt
(cotton 300g )
Only dry laundry suitable for tumble drying. Regard the laundry care labels:
Suitable for tumble drying
Normal drying process: Drying in the tumbler is possible under normal load and
temperature 80°C.
Mild drying process: Caution is appropriate when tumble drying. Select mild
process with reduced thermal action.
Do not tumble dry: Articles unsuitable for drying in the tumbler.
15
OPERATION
Control Panel
Off
Product is switched off.
1
1
Start/Pause
the button to start or pause the
drying cycle.
Press
1
2
Option
These buttons are used for setting
additional functions.
3
Display
The display shows the setting, estimated
program time remaining and status messages
of your dryer.
4
Programmes
Different drying cycles can be selected
according to the users need and the type of
laundry to be dried.
5
1
2
3
5
4
16
OPERATION
Option
TIME+/
When the【 AIRFRESH】or programme is selected, the 【TIME+】
【TIME-】button can be used to adjust the drying time in 10 min. steps.
TIME
【 TIME DRY】 ,
-
DELAY END
This function is used for delaying the end of the drying programme up to 24 hours.
When the delayed programme starts, the time starts to countdown on the display and
the delay icon illuminate.
1.Load your laundry and make sure the machine door is closed.
2.Rotate the knob button, then use the programme selector knob to select
the desired programme.
3.Press the【DELAY END】 button.
4.Repeatedly to press the 【 】button to select the desired delay time.
5.After the 【 】 button is pressed, the Dryer is at the running condition.
The drying procedure will be automatically performed when the delay time is over.
6.If you press the【 】button again, the delay function will be paused.
7.If you want to cancel the “ ” function, please .
DELAY END
DELAY END rotate the knob button to off
DRY LEVEL
You can adjust the dryness level of the laundry by pressing the【 】button.
There are three grades, please refer to icons table on page 18.
1.The function can be activated only before the programme starts.
2.Press the【DRY LEVEL】button repeatedly to increase the drying grade.
3.Except the【 ECO】,【 AIRFRESH】,【QUICK 35'】, 【TIME DRY】, 【WOOL REFRESH】,
and【HEALTH GUARD】, all the other programmes can be adjusted
with the【DRY LEVEL】function.
DRY LEVEL
dry level
Signal
Set the buzzer on or off. In default
condition, the buzzer is on.
When the buzzer is on:
1.The dryer will affirm pressed function button by a sound.
2.If the programme knob is rotated during the dryer is running, the buzzer will remind the user
that this is an invalid operation.
3. When the drying programme is done, the buzzer will beep.
Press the【Lamp】button for 3 seconds to activate signal.
17
OPERATION
ANTI-CREASE
This function prevents the laundry from creases.
The laundry can be removed during the anti-crease phase.
Except【WOOL 】 all the other programmes have this function.
At the end of the drying cycle, a 30 minutes anti-crease function is active as default
seeting. The time for the function can be adjusted to 30-60-90-120minutes.
REFRESH ,
CHILD LOCK
1.This machine incorporates a special child safety lock, which can prevent children from
carelessly pressing buttons or making the faulty operation.
2.When the dryer is running , pausing or stand by, press the【TIME-】button for 3 seconds
activate child lock.
3.When child lock function is set, the display will show Child lock icon and all button are
deactivated, except
4.To deactivate the child lock function, the button shall be pressed for 3 seconds.
to
when the【TIME-】button is pressed for 3 seconds.
【TIME-】
LAMP
The drum light will be on for 1 minute when the button is pressed or 1 minute when the door
is open.
OPERATION
Display
18
Delay End
Anti-crease
Lamp
Empty water container (warning)
Clean filters (warning)
Child lock
Dry level ( extra dry, cupboard dry, iron dry )
Remaining Time indicator/Error message
19
OPERATION
Programmes
Programme selector
1.When the LED display screen brightens up, rotate the programme knob to select the
desired programme.
2.Select the【DELAY END】,【TIME+】,【TIME-】,【DRY LEVEL】,【ANTI-CREASE】,
【LAMP】 functions for additional options.
3.Press the【 】button.
4.Rotate the knob to the 【OFF】after the programme has completed.
Programme start
Programme end
The drum will rotate after the programme starts. The remaining programme time will
be displayed.
1.The drum will stop rotating after the programme ends. The display will show "End".
The dryer will start Anti-crease function if user doesn't remove the load.
Please Rotate the knob to the 【OFF】 after unloading the tumble dryer to cut
off power and pull out the plug.
2.Deal with the problems according to “Trouble Shooting” section, if there is an
unexpected stop during the drying procedure or the dryer shows an Error Code (Refer
to page 25).
20
OPERATION
Max
Load
Application/Properties
DELAY
END
TIME
3.5kg
For mixed fabrics from cotton and synthetics.
Y
N
To dry thin synthetic textiles, which are not ironed,
such as easy care shirts, baby cloths or socks.
To dry individual items or complete the drying
multi-layer fabrics with different drying behavior,
such as jackets,pillows or voluminous items. Min
10 min. to max. 150min.(in 10 min. steps)
Y
JEANS
4.0kg
To dry jeans or leisure clothes that are spun at high
speed in the washing machine.
N
Programme
8.0kg
For single or multi-layer cotton laundry to be dried
completely for direct storage.
Y
Drying Programmes Table
MIX
TIME DRY
For single or multi-layer cotton laundry to be dried
completely for direct wear.
COTTON
SYNTHETICS
SPORTS
3.0kg
To dry sportswear and thin fabrics from polyesther,
which arenot ironed.
Y N
1.0kg
Y N
WOOL REFRESH
For wool clothes that have been stored and need to be
refreshed, reheat them again.
HEALTH GUARD
Sterilize and dry heat-resistant clothing.
Y N
•
1.The ECO programme in accordance with Regulation 392/2012/EU for energy labelling, measured in accordance
with EN 61121 and suitable for drying normal cotton load at rated load capacity.
2.The ECO programme used at full and partial load is the standard drying programme to which the information in
the label and the fiche relates. This programme is suitable for drying normal wet cotton laundry and it is the most
efficient programme in terms of energy consumption for cotton.
Note for Test Institutes:
8.0kg
3.5kg
ECO
AIRFRESH
For clothes that have been stored and need to be
refreshed, and the timing can be
adjusted between 20 to 180 minutes.
reheat them again,
_
1.0kg
Y
SHIRTS
Place clothes loosely in the dryer. Once dried,
and hang it on a clothes ha
minimize the
ironing effort. It is recommended to put shirts of the same
material when selecting the shirts program.
remove quickly
nger. Easy care laundry(small
amount of thin synthetics), such as shirts and blouses
equipped with anti-crease functionality to
4.0kg
BED LINEN
To dry bed linen, bed sheets or other large items.
Y N
For thick or multi-layer synthetic fabrics to be dried
completely.
TOWEL
3.0kg
DELICATE
1.0kg
Suitable for fine small items made of underwear and
silk materials
NY
QUICK 35'
0.5kg
NY
Y
Y
N
N
N
Y
Y
Y
NY
NY
_
Suitable for synthetics textile like light sportswear set,
single pieces of light cotton wear or small quantity
mix of synthetics with light cotton. Do not overload
maximum capacity of this programme. For textiles like
towels, bathrobes or bathroom rugs please use Towel
programme.
4.0kg
21
OPERATION
Consumption Data
1
1
Note!
• Thick or multi-layered fabrics, e.g. jackets etc., are not easy to dry. You had better
choose Cotton programme.
• Please follow instructions at page 16 to change dryness level.
• As uneven material, thick and multi-layered clothes are not easy to dry, it is better
to choose the appropriate time drying programme to completely dry them if some
parts of the clothes are still damp after programme finishes.
• Loading the household tumble dryer up to the maximum capacity for the respective
programmes will contribute to energy savings.
All data are measured in accordance with EN 61121.
The values given for programmes other than the eco programme are indicative only;
The actual consumption may differ from the values given in the table,
depending on the amount of the laundry, type of fabric, residual moisture and
any additional functions selected.
1
1
MD110H80D/W-UK
Model
Program
Capacity
Final
moisture
content
Drying
Time
[h:min]
Energy
Consumption
ECO
8.0kg
3.5kg
4.0kg
1.0kg
1.0kg
0%
0%
3:30
1:40
2:10
0:25
1:25
1.74kWh
0.80kWh
1.02kWh
0.20kWh
0.65kWh
0%
0%
WOOL REFRESH
DELICATE
3.5kg
2%
1:30
0.70kWh
SYNTHETICS
*Acoustic airborne noise emission of the ECO programme at full load is 66dB.
Spin
Speed
1000rpm
1000rpm
800rpm
800rpm
/
800rpm
/
SYNTHETICS EXTRA
( + )SYNTHETICS
SYNTHETICS IRON
( + )SYNTHETICS
COTTON EXTRA
COTTON
COTTON IRON
8.0kg
8.0kg
8.0kg
4.0kg
4.0kg
4.0kg
-3%
0%
12%
4:00
3:50
3:00
2:50
2:40
1:50
1.95kWh
1.80kWh
1.50kWh
1.20kWh
1.10kWh
0.80kWh
-3%
0%
12%
1000rpm
1000rpm
1000rpm
1000rpm
1000rpm
1000rpm
3.5kg
1:20
0.60kWh
12%
800rpm
( + )COTTON
( + )COTTON
MAINTENANCE
22
Empty the water container
1. Pull out and hold the water container
with two hands.
2. Tilt the water container, pour out the
condensate water into the basin.
3. Install the water container.
Cleaning and Care
• Empty the water container after each use. Once the water container is filled
completely, the programme will be paused and the " " will light up and flash
on the display. After the container is emptied, the dryer can be restarted by
pressing【 】button.
• Do not drink the condensate water.
• Do not use the dryer without the water container.
Warning!
！
Clean the filter door
Clean the filters
This dryer has a primary door lint filter.
Make sure you clean the door filter after each cycle
to avoid increased energy consumption and cycle time.
1. Open the door.
2. Take out the door filter.
3. Open the filter and remove the fluff on the filter screen.
You can use a vacuum cleaner to remove the lint or clean
it by hand.
4. Throw lint in the garbage bin and do not wash it down
the drain to avoid micro plastics in the used water system.
• Take notice of the correct orientation before to insert the door filter.
Note!
•
be closed smoothly , the arrows at both
ends need to be aligned, and the middle
slot and the rib need to be aligned.
To ensure the double-layer filter can
Note!
Door Filter
MAINTENANCE
23
As necessary, approx. once every 3 months, remove the fluff from the heat
exchanger using a vacuum cleaner with a dusting brush attached.
• Clean the heat exchanger without applying any pressure. Otherwise the heat
exchanger could be damaged. The dryer will not dry
if the cooling fins are damaged or bent.
•
Clean the heat exchanger
Warning!
！
Do not touch the heat exchanger with your hand,
which may cause an injury.
Foreign objects removal
•
filter, open the heat exchanger area compartment and remove the foreign object
making sure not to touch the heat exchanger with bare hands to avoid injuries.
In case of foreign objects fall inside below the filter compartment, remove the
MAINTENANCE
24
Clean Tumble dryer
Warning!
！
• Disconnect the power cord before cleaning!
• Clean the dryer with a wet cloth which is only damped
by clean water.
• Do not use solvents, abrasive cleaners, glass cleaners
or all-purpose cleaners. These could damage plastic
surfaces and other parts.
• Please wear gloves when cleaning.
After each use:
• Prepare a wet cloth damped by clean water.
• Clean the door, especially the inside window.
• Clean the sealing around the door opening.
• Clean the humidity sensor inside the drum.
• Take out all the filters, clean the sealing and air flow openings.
• Before starting the dryer, dry all parts with a soft cloth.
MAINTENANCE
25
Trouble Shooting
Many malfunctions and faults that might occur in daily operation can be easily
remedied. Time and money will be saved because a service call won't be needed.
The following guide may help you to find the reason for a malfunction and correct it.
“ ”E33
Display
Reason
Solutions
Temperature sensor error
Please contact your local
problem occurs.
service center if the
“ ”E82
PCB communication error
• Self-repair or non-professional repair may create safety risk and cease the
guarantee.
• If the LED displays other prompt and the dryer does not work, pull out the
plug from the socket, please call the service.
WARNING!
！
Note!
unit of present model on the market.
Spare parts are available for a minimum time of 10 years after placing the last
Container is full
Water pump failure or water
level sensor failure
Empty water container
26
MAINTENANCE
If you cannot deal with the problems by yourself and need help:
• .
• Pull out the mains plug and call the service.
Rotate the knob to the 【OFF】
Warning!
！
• Clean lint filter and .
• Empty the water container.
• Check the drain hose.
• Check installation place is appropriate.
• Keep the air inlet clean.
• Use higher drying intensity level programme or
time programme.
heat exchanger
Problem
Solution
•Display is not
on
• Check if the power supply works.
• Check if the mains plug is inserted.
• Check the selected programme .
• Rotate the knob to the【OFF】.
• Clean the lint filter.
• When the dryer is powered on standby, the " "icon will
flash for 10 seconds to remind the user to clean the filter.
After 10 seconds, the " "icon will always on. After
startup, the" " icon will disappear.
•Dryer does not start
•
• Turn on the tumble dryer.
• Check the the door is closed.
• Check the programme is set.
• Press the【 】button.
Connect the tumble dryer to the mains.
•Degree of dryness was
reached or drying time too
long
not
•There are humming noises
• The compressor is operating. These noises are
quite normal and do not indicate a fault.
•The dryer switches off at
the end of the programme
• The dryer switches off automatically for energy
saving. This is not an error but a normal function.
• “ ”is lighting
•“ ”is inglight
•
the condensate water and restart the dryer.
• If the container is not full, please restart the dryer
directly.
• If the “ “ icon is still lighting after you have
finished the first two steps, please call the service.
Check the water container. If it's full, please pour out
•
When the dryer is powered on standby, the" "icon will
always on to remind the user to pour out the condensate
water. After startup, the" " icon will disappear.
MAINTENANCE
27
• The rated capacity is the maximum capacity to be dried at one time. Make sure that
the dry clothes which are loaded into the appliance do not exceed the rated capacity.
• Do not install the tumble dryer in a room when there is a risk of frost occurring. At
temperatures around freezing point the tumble dryer may not be able to operate
properly.
• There is a risk of damage if the condensate water is allowed to freeze in the pump,
hoses and / or condensate water container.
Technical Specifications
Rated capacity
Rated frequency
Dimension(L*W*H)
Rated input power
Rated voltage
Weight of product
Model
Parameter
Ambient temperature
+2°C ~ +35°C
220-240V~
600*595*850(mm)
800W
44kg
50Hz
Note!
Refrigerant
R290
8.0kg
GWP
CO - eq
2
Quantity of refrigerant
3
0.00t
120g
MD110H80D/W-UK
How to find Energy related information on the public database of European Commission
EPREL:
1.Open the EPREL database hompage
https://eprel.ec.europa.eu/screen/product/tumbledriers
2.Search for the model
Model ID: MD110H80D/W-UK
Note!
MAINTENANCE
28
Product Fiche
MD110H80D/W-UK
8.0kg
Condenser
A++
217.0kWh/year
Automatic
N/A
1.33kWh
1.74kWh
1.02kWh
0.5W
0.8 W
10 min
165min
210min
130min
B
82%
82%
82%
66dB
Model
Rated Capacity
Dryer Type
Energy efficiency class
Weighted annual energy consumption (AE )
Automatic or non-automatic
EU Ecolabel
Energy consumption of the ECO programme
Weighted energy consumption of the ECO programme at full and partial load
Energy consumption of the ECO programme at full load
Energy consumption of the ECO programme at partial load
Power consumption of the off-mode (Po)
Power consumption of the left-on mode (Pl)
Duration of the left-on mode
Programme time of the ECO programme
Weighted programme time of the ECO programme at full and partial load
Programme time of the ECO programme at full load
Programme time of the ECO programme at partial load
Condensation efficiency class A (most efficient) to G (least efficient)
Average condensation efficiency of the ECO programme at full load
Average condensation efficiency of the ECO programme at partial load
Weighted condensation efficiency for the ECO programme at full and partial load
Sound power level for the ECO programme at full load
❶
c
❶
Energy consumption per year, based on 160 drying cycles of the programme
at full and partial load, and the consumption of the low-power modes. Actual energy
consumption per cycle will depend on how the appliance is used. The ECO programme
used at full and partial load is the standard cotton programme to which the information
in the label and the fiche relates. Measured according to EN 61121 and EU Regulation
392/2012. Energy efficiency class on a scale from A+++ (more efficient) to D (least
efficient).
ECO
Remarks:
16138200A22350
V1.0
