20" BOX FAN
MODEL 2VAFBX20
OWNER’S MANUAL
2
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
CONTENTS
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference. Illustrations in this manual are
for explanatory purposes only, your actual product may look slightly dierent.
INTENDED USE ................................................................................................................................................................. 3
IMPORTANT INSTRUCTIONS ....................................................................................................................................... 3
ASSEMBLY INSTRUCTIONS ......................................................................................................................................... 5
USAGE .................................................................................................................................................................................. 5
CONTROL PANEL ............................................................................................................................................................ 5
FUSE REPLACEMENT ..................................................................................................................................................... 5
CLEANING AND MAINTENANCE ................................................................................................................................ 6
REPAIR ................................................................................................................................................................................. 6
STORAGE ........................................................................................................................................................................... 6
CONSUMER PRODUCT INFORMATION ................................................................................................................... 7
3
SAFETY INFORMATION
INTENDED USE
This product is intended for indoor residential
and oce use only, not for industrial or other
commercial applications. Use only with electrical
wiring that is in good working order and that meets
applicable codes and ordinances. If you have
any questions whether your wiring is adequate,
consult a qualied electrician.
While using your fan, you should follow the
IMPORTANT INSTRUCTIONS listed below. As
part of those instructions, we have used the
word
“WARNING” to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided,
could result in injury or death.
IMPORTANT INSTRUCTIONS
As with all electrical appliances, basic safety
precautions should always be followed to reduce
the risk of electric shock, re, or injury to persons,
including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual.
Any other use not recommended by the
manufacturer may cause electrical shock,
re or injury to persons.
• Do not operate the fan with a damaged power
cord or after the fan malfunctions or has been
dropped in any manner.
• Use of extreme caution is necessary when
any fan is used by or near children, disabled
persons or pets and whenever the fan is left
operating unattended.
• Do not place the fan on a small, unlevel,
uneven or any surface which might allow
fan to tip or fall.
• For proper operation, fan should be placed on
a smooth, non‑combustible, level surface.
• Always unplug fan when not in use, when
moving from place to place, when assembling
or disassembling parts, and before cleaning.
• The use of attachments, not recommended or
sold by the manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause
electrical hazard (for non‑window models).
• Do not operate the fan with blade guards or
any safety device removed.
• Avoid the use of extension cords due to
risk of re.
• Do not run power cord under carpeting. Do not
cover cord with throw rugs, runners or the like.
Arrange cord away from trac area where it
will not be tripped over.
• Do not insert or allow any object to enter any
openings on the fan. Doing so may cause
electric shock and/or re hazard. Avoid contact
with moving parts.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure they
do not play with the appliance.
4
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
(Continued)
SAFETY INFORMATION
READ & SAVE THESE INSTRUCTIONS!
WARNING SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended for use in a bathroom, laundry area,
or similar locations, or near sinks, washing machines, swimming pools or other sources of water.
Never locate fan where it may fall into a bathtub or other water receptacle. Do not use in damp
environments such as ooded basements.
WARNING HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in use, to avoid burns,
do not let bare skin touch hot surfaces.
WARNING FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near combustible materials or ammable gases
or sources of heat. Do not use in areas where gasoline, paint or ammable materials are used or stored.
To prevent a possible re, do not block air intakes or exhaust in any manner. Do not insert or allow
foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock, re,
or damage the fan.
WARNING ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate electrical system that is up to code.
CAUTION TO PREVENT ELECTRIC SHOCK, this product has a polarized two prong plug
(one blade is wider than the other) that must be fully inserted in to a matching properly grounded
outlet. This plug is designed to t a polarized outlet only one way. If the plug does not t fully into
the outlet, reverse the plug. If the plug still does not t, contact a qualied electrician. Do not attempt
to defeat this safety feature.
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, do not use this
product with any solid‑state speed control device.
DO NOT operate any fan with a damaged cord or plug or after fan malfunctions, has been dropped
or damaged in any manner. Do not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs covered under warranty, see warranty
statement. For all other repairs contact Customer Service by telephone for information and assistance.
DO NOT run power cord under carpeting. Do not cover cord with throw rugs, runners or the like.
Arrange cord away from trac area where it will not be tripped over. Avoid the use of extension cords
due to risk of re. Do not use an extension cord unless the plug can be completely inserted into its
receptacle. Unplug the fan when not in use. Do not operate fan with its ventilation obstructed.
5
USAGE AND CONTROL PANEL
ASSEMBLY INSTRUCTIONS
Turn the feet clock/unclock according to arrow to
the right place.
USAGE
FAN OPERATION
Always operate the fan in the upright position
following all instructions and recommendations
listed in this manual.
FAN LOCATION
Place the fan in the area of the room that will provide
proper circulation such as by a window, doorway, or
towards the middle of the room.
FAN CONNECTION
Plug fan directly into 120 volt A.C., 60 Hz wall outlet.
Be sure plug ts tightly in outlet. A loose connection
may cause overheating and damage to the plug
or fan. Avoid the use of extension cords due to risk
of re.
NOTE: To prevent overloading a circuit, do not
plug the fan into a circuit that is servicing other
electrical needs.
Stabilizing Feet
CONTROL PANEL
TURNING FAN ON/OFF
Place fan on stable level
surface. Plug fan into
properly grounded outlet.
To start the fan, turn
rotary dial on Control Panel:
1 ‑ LOW, 2 ‑ MED, 3 ‑ HIGH.
Press 0 ‑ OFF to discontinue use.
Unplug fan when not in use.
Control Panel
1
2
3
4
FUSE REPLACEMENT
1. Grasp plug and remove from the receptacle or
other outlet device. Do not unplug by pulling on
cord. See Fig. 1
2. Open fuse cover by sliding open fuse access
cover on top of attachment plug towards blades.
See Fig. 2
3. Remove fuse carefully. Use a small tool to pry the
end of the fuse from holder cavity. Be careful not
to break glass window. See Fig. 3
4. Replace fuse.
WARNING Risk of re.
Replace fuse only with identical 2.5 or 5.0 Amp,
125 Volt fuse (3.6mm x 10mm). Be sure fuse is
properly seated within its cavity.
5. Close fuse cover by sliding it back to its original
closed position. See Fig. 1
6
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
CARE AND MAINTENANCE
CLEANING AND MAINTENANCE
• Always unplug fan before cleaning.
• Clean with a soft, damp cloth. Use a mild soap solution as needed.
• DO NOT ALLOW WATER TO DRIP ONTO THE MOTOR HOUSING, MOTOR, OR ELECTRICAL COMPONENTS.
• Do not use any solvents or harsh chemicals.
• When not using for extended periods, store the fan in a clean, dry location away from dust and debris.
It is recommended to store the fan inside its box.
REPAIR
DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN PLACE. DO NOT USE THE FAN IF IT HAS
MALFUNCTIONED OR BECOME DAMAGED IN ANY WAY.
STORAGE
Keep original carton for storage of the fan. Coil and tie the power cord to avoid damage during storage.
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual.
Also, write the store name/location and date purchased below:
Store Name: _______________________________________________________________
Location: __________________________________________________________________
Date Purchased: ____________________________________________________________
NOTE: As a result of continual improvements, the design and specications of the
product within may dier slightly to the unit illustrated on the packaging.
NOTE: Proof of purchase is required for all warranty claims.
Printed in China | 0924_M145
833‑950‑1185 | support@visionairproducts.com | www.visionairproducts.com
