Frequency Baby unit: 2402 - 2480 MHz (WiFi, FHSS, BLE )
Max Transmit power is 10mW (WiFi, FHSS, BLE )
Parent unit: 2406 - 2475 Mhz
Max Transmit power is 100mW
LCD 5’’ Color LCD (IPS 1280x720 pixels)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may
vary according to environmental conditions at the time of use.
Power requirement Baby unit power adapter: Output: 5V DC, 1.5A.
Parent unit power adapter: Output: 5V DC, 2A.
Parent unit battery: 3.7V 5000mAh, 18.5Wh Lithium-ion battery
Specifications are subject to change without notice.
© 2024 VTech Communications, Inc.
All rights reserved. 10/24. RM901HD-X_Gen 2_US_QSG_V1
Technical specications
VM901HD
VM901-2HD
Wi-Fi 1080p
Pan & Tilt Video Monitor
Quick start guide
Disclaimer and Limitation of Liability
VTech Communications, Inc. and its suppliers assume no responsibility for any damage or loss resulting
from the use of this user’s manual. VTech Communications, Inc. and its suppliers assume no responsibility
for any loss or claims by third parties that may arise through the use of this product.
Company: VTech Communications, Inc.
Address: 9020 SW Washington Square Road - Ste 555 Tigard, OR 97223, United States
Phone: 1 (800) 595-9511 in the U.S. or 1 (800) 267-7377 in Canada
UL STD.
62368-1
CERTIFIED TO
CSA STD.
C22.2 NO.62368-1
CONFORMS TO
Android
TM
and Google Play
TM
are trademarks of Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
Go to www.vtechbabycare.com
to register your product for
enhanced warranty support and
latest VTech product news.
S
m
Congratulations
on purchasing your new VTech product.
Before using this baby monitor, please read the Important safety instructions.
What’s in the box
x 2
x 2
Quick start guide
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs to be at least three feet
away from the child at all times. Do not
use with an extension cord. Do not
remove this tag.
Éloignez ce cordon des enfants. Le
cordon doit se trouver à au moins trois
pieds d’un enfant et ce, en tout temps.
N’utilisez pas de rallonge. Ne retirez pas
cette étiquette.
Mantenga este cable fuera de la alcance
de los niños. Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
CABLE MANAGEMENT
1 2 3
VM901HD
VM901-2HD
1 set for VM901HD
2 sets for VM901-2HD
Strangulation
Hazard
Keep this cord out of reach of children.
The cord needs to be at least three feet
away from the child at all times. Do not
use with an extension cord. Do not
remove this tag.
Éloignez ce cordon des enfants. Le
cordon doit se trouver à au moins trois
pieds d’un enfant et ce, en tout temps.
N’utilisez pas de rallonge. Ne retirez pas
cette étiquette.
Mantenga este cable fuera de la alcance
de los niños. Este cable debe estar por
lo menos tres pies fuera de la alcance
del niño en todo momento. No lo use
con una extensión inalámbrica. No quite
esta etiqueta.
Risque
d’étranglement
Riesgo de
estrangulación
For more support, email
support@vtechbabycare.com
or scan the QR code below for
product information.
Parent unit icons
Status icons
Direct mode
Parent unit and baby unit are connected to
each other directly.
Signal strength is indicated by the signal icon(s)
on the right.
The red bar(s) indicates no connection.
Wi-Fi mode
The signal icon(s) on the left indicate the baby
unit is connected to a home Wi-Fi network.
The red icon(s) indicates no connection.
Status icons
Baby unit 1 and 2 are being viewed in Patrol
mode (For VM901-2HD only).
Baby unit 1 and 2 are being viewed in Split
mode (For VM901-2HD only).
Night vision is turned on.
Motion detection alert is turned on.
Melodies and soothing sounds are playing.
Temperature alert is turned on.
Parent unit is muted.
Temperature measured at baby unit.
Main
Menu
Sub-
menu
Options
Monitoring mode (For VM901-2HD only)
• View baby units in Single mode.
• View baby units in Patrol mode
(switch view every 10 seconds).
• View baby units in Split screen.
Melodies and soothing sounds
Play/Stop
• Toggle between play and stop.
Library
• Select to play all melodies, or play one
of the five melodies or five soothing
sounds.
Camera Volume
• Adjusts baby unit speaker volume.
Timer
• Set the timer to stop playing after 15, 30
or 60 minutes, or play non-stop.
General settings
Connect to Mobile App
• Instructions for adding baby unit to
mobile app.
Camera Volume
• Adjusts baby unit speaker volume.
Screen Brightness
• Adjusts parent unit screen brightness.
Screen Off Timer
• Turn the screen off timer OFF, or set
the screen to turn off after 1, 3 or 5
minutes when no sound is detected.
• Select Auto to set the Sound
Sensitivity level for the screen to
auto turn on when a sound level is
detected that is higher than the set
level. The screen will turn off after 50
seconds of no sound detection.
Main
Menu
Sub-
menu
Options
Temperature Format
• Set the temperature display format
between Celsius or Fahrenheit.
Other
• Time Settings (Toggle Time Display
on Live View; 24-Hour Format; Set the
Time Zone), Reset Settings, Software
Update.
Alerts Settings
• Adjusts the alert tone volume level.
Motion Detect
• Turn the motion detection alert on/off.
• Adjust Motion Sensitivity level for
waking the parent unit screen.
Low Medium High
Temperature
• Turn the temperature alert on/off.
• Select the temperature alert maximum
and minimum temperature limits.
Low Battery
• Toggle the low battery alert on or off.
Lost Link
• Toggle the lost link alert on or off.
Help and info
Help
• Support Information
How-to Video
• Support video
System Info
• System Information
VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of industry-
recommended best practices to help keep your wireless connection private and your devices
protected when online. We recommend you carefully review and consider complying with the
following tips.
Ensure your wireless connection is secure.
• Before installing a device, ensure your router’s wireless signal is encrypted by selecting the
“WPA2-PSK with AES” setting in your router’s wireless security menu.
Change default settings.
• Change your wireless router’s default wireless network name (SSID) to something unique.
• Change default passwords to unique, strong passwords. A strong password:
- Is at least 10 characters long.
- Is complex.
- Does not contain dictionary words or personal information.
- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.
Keep your devices up to date.
• Download security patches from manufacturers as soon as they become available. This will
ensure you always have the latest security updates.
• If the feature is available, enable automatic updates for future releases.
Disable Universal Plug and Play (UPnP) on your router.
• UPnP enabled on a router can limit the effectiveness of your firewall by allowing other network
devices to open inbound ports without any intervention or approval from you. A virus or other
malware program could use this function to compromise security for the entire network.
For more information on wireless connections and protecting your data, please review the
following resources from industry experts:
1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips –
www.fcc.gov/consumers/guides/how-protect-yourself-online.
2. U.S. Department of Homeland Security: Before You Connect a New Computer to the Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3. Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4. Wi-Fi Alliance: Discover Wi-Fi Security –
http://www.wi-fi.org/discover-wi-fi/security.
Protect your privacy and online security
Download app for mobile access
Use the MyVTech Baby Plus on your mobile phone to monitor your baby
remotely. Follow the instructions below to set up and pair your baby monitor
with the app.
1. Scan the QR code to download the free MyVTech Baby Plus mobile app,
or search “MyVTech Baby Plus” on App Store or Google Play Store. If you
have previously installed the app, ensure that you have the latest version.
2. Tap
P
L
U
S
P
L
U
S
to launch the mobile app on your device and create an account.
3. We recommend that you use common webmail services, such as Google Gmail, to
register your user account. Check your email (including the Spam folder) and activate
your new account by entering the email verification code. Then, sign in to your account.
4. Ensure that you are connected to a 2.4GHz Wi-Fi network and have enabled Bluetooth
and Location Service on your device.
5. After signing in to the app, select Camera(s) with Parent unit and scan the QR code
displayed on the parent unit. To find the QR code, press the MENU/SELECT button and
go to > Connect to Mobile App.
6. Input the Wi-Fi password.
7. Press and hold the pair key on the baby unit for 3 seconds until you hear the beep
sound to enter pairing mode.
8. Select the camera model that appears in the app and wait for the camera to connect.
Once connected, it will display a live view preview.
9. Select “Continue” and create a profile for your baby (Optional). Now you can start
monitoring! (For models with 2 cameras, a pop-up will ask if you wish connect another
camera. Repeat steps 7-9 for the second camera.)
P
L
U
S
P
L
U
S
• Make sure your mobile phone meets the
minimum requirement for the mobile app.
Minimum requirement
The mobile app is compatible with:
• Android
TM
9.0 or later (Android devices with
32-bit system are not compatible); and
• iOS 14 or later.
Use Camera Sharing to instantly share access to the camera. Follow these steps:
1. Go to Menu and select Camera Sharing.
2. Choose “Invite People” and enter the name and email address of the family member’s app
account.
3. The family member will receive a pop-up notification in the app and can accept the
invitation to access the camera(s).
Direct mode
Your baby monitor parent unit and baby unit connect to each other in Direct mode by default,
which allows you to immediately stream video out of the box.
You may experience reduced signal
strength if your parent unit and baby unit
are far apart, or there are obstructing
factors, such as internal walls between
them. Move the parent unit closer to the
baby unit to improve the signal strength.
Ensure the parent unit antenna is raised
for optimum reception.
Wi-Fi mode
To enhance your experience and enjoy
seamless live video streaming via your
mobile app, and to receive product
software updates (when available), we
highly recommend setting up your
monitor’s Wi-Fi connection.
It uses your 2.4GHz home Wi-Fi network to
connect your video monitor and supports
live video streaming through the mobile
app.
To stream live video remotely with your
mobile phone, download and install the
MyVTech Baby Plus mobile app. With the
mobile app, your Wi-Fi router (not included) provides Internet connectivity to your HD video
monitor system. It serves as a communication channel between your baby unit and mobile
phone, allowing you to monitor and/or control your baby unit wherever you are. For more
details, see Download app for mobile access section in this quick start guide.
How the system works
To receive product rmware updates, this baby monitor requires connecting to
a 2.4GHz home Wi-Fi network.
Local access
63
o
F
FHSS link
63ē
Mobile access
Local access
FHSS link
Overview
Baby unit overview
1 Microphone
2 Camera lens
3 Light sensor
4 LED indicators
Set to off by default. You can turn it on using
the app (Setting > Camera Setting > LED
status).
In direct mode:
• Orange is steadily on when the baby unit
is connecting to the parent unit.
• Orange flashes slowly during video
streaming.
In Wi-Fi mode:
• Green is steadily on when the baby unit is
connected to Wi-Fi.
• Green flashes slowly during video
streaming to Wi-Fi.
5 Infrared LEDs
• Allow you to see clearly in a dark environment.
6
ON/OFF switch
7 Antenna
8 Speaker
9 Temperature sensor
10 Power jack
11 Wall mount slots
12 Pair/Reset button
• To enter pairing mode, press and hold
the PAIR key for three seconds until you
hear a beep sound. Then follow the app
instructions to connect the camera to a
2.4GHz Wi-Fi network.
• To reset the baby unit, press and hold
the PAIR key until you hear a beep
sound. Release the PAIR key and then
press and release a further five times
until you hear another beep sound. The
baby unit will emit another beep when
the reset is complete. After the beep
sound, the baby unit will reboot itself.
12
11
1
6
10
2
3
5
7
8
9
4
Parent unit overview
1
LED light
• On when the parent unit is connected
to AC power, or the battery is charging.
• Flashes when the parent unit battery is
low and needs to be charged.
• Off when the parent unit is
disconnected from AC power.
2 LINK LED light
• On when the parent unit is linked to the
baby unit.
• Flashes when the link to the baby unit
is lost.
3
LED light
• On when the parent unit speaker
volume is set to off.
• On when the parent unit is talking to
the baby unit.
4 TALK LED light
• On when the parent unit is talking to
the baby unit.
5 LCD display
6 Microphone
7 LCD ON/OFF
8 POWER
9
Lullaby
• Press to directly enter the lullaby menu.
10
TALK/
• Press and hold to talk to the baby unit.
is displayed on screen while the
button is pressed.
• While in a submenu, press to exit.
11 Arrow keys
, , or
• Press to navigate leftward, upward,
rightward or downward, within the
main menu and sub-menus.
• Press to move the baby unit camera
leftward, rightward , upward or
downward.
12 MENU/SELECT
• Press to enter the main menu.
• While in a menu, press to confirm a
selection, or save a setting.
13
Zoom in / Zoom out
• Press to zoom in/out to different levels.
14 - VOL/ VOL +
• Increase, decrease or mute the parent
unit volume.
15 Speaker
16 Power jack
17 Antenna
18 RESET
• Force reboot the parent unit.
19 Stand
18
19
16
15
11
12
13
14
10
8
9
7
6
2
3
4
5
1
17
The applied nameplate is located at the bottom of the baby unit base.
When in use, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and injury, including the
following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height above 6.5 feet
(2 meters).
4. This product is intended as an aid. It is not a substitute for
responsible and proper adult supervision and should not be
used as such.
5. This product is not intended for use as a medical monitor.
6. Do not use this product near water, for example, near to a bath,
sink, swimming pool or shower.
7. CAUTION: Use only the internal, non-user replaceable battery
fitted to the parent unit. There may be a risk of explosion if a
wrong type of battery is used for the parent unit. The battery
cannot be subjected to high or low extreme temperature
and low air pressure at high altitude during use, storage or
transportation. Disposal of batteries in fire or a hot oven,
mechanically crushing or cutting the battery can result in an
explosion. Subjecting products or batteries to an extremely high
temperature environment can result in explosion or leakage of
flammable liquids, or gas. Products or batteries subjected to
extremely low air pressures may result in explosion or leakage of
flammable liquids, or gas. Dispose of used batteries according
to the information in The RBRC seal.
8. Use only the power adapters supplied with this product.
Incorrect power adapter polarity or voltage can seriously
damage the product.
Power adapter information:
Baby Unit Output: 5V DC 1.5A
VTech Telecommunications Ltd.
Model: VT07EUS05150 -OR-
Jiangxi Jian Aohai Technology Co., Ltd.
Model: A938-050150W-US1
Parent Unit Output: 5V DC 2A
VTech Telecommunications Ltd.
Model: VT07EUS05200 -OR-
Jiangxi Jian Aohai Technology Co., Ltd.
Model: A938-050200W-US1
Rechargeable battery information:
3.7V 5000mAh, 18.5Wh Lithium-ion battery
Zhuhai Great Power Energy Co., Ltd.
Model: GSP806090-5Ah-3.7V-1S1P
9. The power adapter is intended to be correctly oriented in a
vertical or floor mount position. The prongs are not designed to
hold the plug in place if it is plugged into a ceiling, under-the-
table or cabinet outlet.
10. For pluggable equipment, the socket-outlet (power adapter)
should be installed near the equipment and should be easily
accessible.
11. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth for
cleaning.
12. Do not modify the power adapters or replace with other third-
party adapters.
13. Do not allow anything to rest on the power cords. Do not install
this product where the cords may be walked on or damaged.
14. The product should only be operated from a power source
indicated on the power adapter label or marking. If you are
unsure of the type of power supply in your home, consult your
dealer or electricity supply provider.
15. Do not overload wall outlets or use an extension cord.
16. Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
17. This product should not be placed in any area where proper
ventilation is not provided. Any slots or openings in the back or
bottom of this product are provided for ventilation. To protect
from overheating, openings must not be blocked by placing
the product on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator or heat
source.
18. Never insert any objects through any apertures or slots in the
product as this can be dangerous and cause damage to the battery
or other internal parts. Never spill any liquids on the product.
19. To reduce the risk of electric shock, do not disassemble
this product, but take it to an authorized service facility.
Disassembling or removing parts of the product other than
battery replacement via a battery door (if applicable) may
expose dangerous voltages or other risks.
20. You should test the sound reception every time you turn on the
units or move one of the components.
21. Periodically examine all components for damage.
22. There is a very low risk of privacy loss when using certain
electronic devices, such as baby monitors, cordless telephones,
etc. To protect your privacy, make sure the product has
never been used before purchase, reset the baby monitor
periodically by powering off and then powering on the units,
and power off the baby monitor if you are not intending to use
it for some time.
23. Children should be supervised to ensure that they do not play
with the product.
24. The small parts of this monitor can be swallowed by babies or
small children. Keep these parts out of reach of children.
25. The product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 32
o
F (0
o
C)
and 104
o
F (40
o
C).
• Mishandling batteries can cause burn, fire or explosion hazards.
• Batteries should not be exposed to excessive heat such as bright
sunshine or fire.
• Do not expose the product to extreme cold, heat or direct
sunlight. Do not place the product close to a heating source.
• Warning—Strangulation Hazard—Children
have STRANGLED in cords. Keep this cord out of the
reach of children (more than 3 ft (0.9m) away). Do not
remove warning label on the adapter cord.
• Never place the camera unit(s) inside the baby’s crib or playpen.
Never cover the camera unit(s) or parent unit with anything such
as a towel or a blanket.
• Other electronic products can cause interference to your parent
unit and baby unit. Try installing your baby unit as far away
as possible from the following electronic devices: wireless
routers, radios, mobile telephones, intercoms, room monitors,
televisions, personal computers, kitchen appliances (e.g.
microwave ovens) and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted
cardiac pacemakers. Supported by the U.S. Food and Drug
Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the pacemaker,
such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic elds (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and according to
the instructions in this user’s manual, the product is safe to be used
based on scientific evidence available today.
Important safety instructions
Connect, charge and power on the baby
monitor
Connect the parent unit and baby unit to the supplied adapter and mains supply.
The parent unit turns on automatically after connecting to the power socket, and the
welcome screen appears. You can press and hold
POWER
to turn it on or off.
1
For optimum reception,
always raise the parent unit
antenna.
Slide the ON/OFF switch to the left
to power on your baby unit.
2
3
WARM
WARM
• Please peel off the lens/screen protector before use.
• Charge the parent unit battery before use.
• When powering up, the baby unit’s orange status LED turns on. It will
turn off after a while and remain off if the status LED is set to off.
• The status LED is set to off by default. You can turn it on using the app
(Setting > Camera Setting > LED status).
• The baby unit may get warm during use. This is normal.
Status icons
01:54 PM
01:54 PM
Time display
Battery level indicator
Low battery indicator
6-level sound indicator
•
indicates low sound level detected by
the baby unit.
• indicates moderate sound level
detected by the baby unit.
• indicates high sound level detected
by the baby unit.
Low Medium High
ON
OFF
Product Recycling
Recycle this product when you are done with it.
For more information, scan the QR code
or visit www.vtechbabycare.com.
Test the sound level and position the baby monitor
test the location for the baby unit
Testing the sound level of the baby monitor
• This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should
not be used as such.
• For hearing protection, make sure the parent unit is more than 10 feet away from the baby
unit. If you hear any feedback noise from the parent unit, move the parent unit further until
the noise stops. You can also press on the parent unit to lower or mute the noise.
• Increase the parent unit speaker volume if you cannot hear the sounds transmitted from the baby unit.
2. Adjust the angle of the baby unit to aim
the camera at your baby.
1. Place the baby unit more than 3 feet away
from your baby.
3. To avoid causing feedback noise from your baby monitor:
• Make sure your baby unit and parent unit are more than 10 feet apart; OR
• Turn down the volume of your parent unit.
Positioning the baby monitor
• Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s
crib or playpen.
• Excessive downward camera tilt may impair night vision and sound reception. If so, please adjust the tilt
slightly upwards.
If you plan to install your baby unit in a designated
location, and use your home Wi-Fi network to
connect your video monitor, you need to test
which of your selected monitoring areas within
the house have good Wi-Fi signal strength. After
you have powered on your parent unit, you can
use your parent unit’s Wi-Fi signal icon(s) to assist
in checking. Once you have identified the suitable
location, you can install your baby unit. Adjust the
distance between your baby unit and the Wi-Fi
router if needed.
• Surroundings and obstructing factors, such as large
metallic objects, filing cabinets, long distances,
electrical appliances, and internal walls, may reduce
Wi-Fi signal.
>
10ft (3m)
> 10ft (3m)
> 3ft (1m)
> 3ft (1m)
>
10ft (3m)
<
10ft (3m)
> 10ft (3m)
< 10ft (3m)
Frequently asked questions
General product care
Storage
FCC and IC regulations
FCC Part 15
NOTE: This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of
the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a
user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC
criteria. The baby unit shall be installed and used such that parts of all persons’ body are maintained at a distance of approximately 8 in
(20 cm) or more. The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s
licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must
accept any interference, including interference that may cause undesired operation of the device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
RF radiation exposure statement
The product complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The baby unit should be
installed and operated with a minimum distance of 8 in (20 cm) between the baby unit and all persons’ body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines. This equipment complies also with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
La plaque signalétique appliquée est située au bas du socle de l’unité
du bébé.
Lorsque vous utilisez votre appareil, vous devriez toujours suivre
certaines mesures de précaution de base afin de réduire les risques
d’incendie, d’électrocution et de blessures corporelles, dont ceux qui
suivent:
1. Observez toutes les instructions et mises en garde inscrites sur
l’appareil.
2. L’installation par un adulte est requise.
3. MISE EN GARDE: N’installez pas l’unité du bébé à une hauteur
supérieure à 2 mètres.
4. Ce produit a été conçu pour être un dispositif d’appoint
seulement. Il n’est pas le remplacement d’une supervision
responsable et adéquate par un adulte et ne devrait pas être
utilisé comme telle.
5. Ce produit n’est pas conçu pour être utilisé en tant que moniteur
médical.
6. N’utilisez pas cet appareil près de l’eau ni de toute autre source
d’humidité, par exemple, près d’une baignoire, cuve à lessive,
évier de cuisine, dans un sous-sol humide ni près d’une piscine,
dans un soussol humide ou une douche.
7. MISE EN GARDE: N’utilisez que la pile fournie. Il peut y avoir
un risque d’explosion si un mauvais type de pile est utilisé
pour le dispositif apaisant. La pile ne peut pas être soumise a
des températures extrêmes élevées ou basses et a une faible
pression atmosphérique a haute altitude pendant son utilisation,
son entreposage ou son transport. Le fait de jeter la pile dans
au feu ou dans un four chaud, ou d’écraser ou de couper
mécaniquement la pile peut entrainer une explosion. Le fait de
laisser la pile dans un environnement a température extrêmement
élevée peut entrainer une explosion ou une fuite de liquide
ou de gaz inflammable. Une pile soumise a une pression d’air
extrêmement basse peut provoquer une explosion ou une fuite
de liquide ou de gaz inflammable. Mettez au rebut la pile usagée
conformément aux informations figurant dans la section Le sceau
RBRC.
8. N’utilisez que les adaptateurs inclus avec ce produit. L’utilisation
d’un adaptateur dont la polarité ou la tension serait inadéquate
risque d’endommager sérieusement le produit et mettre votre
sécurité en péril.
Informations sur les adaptateurs électriques :
Sortie : 5 V CC 1,5A
VTech Telecommunications Ltd.
Modèle : VT07EUS05150 -OU-
Jiangxi Jian Aohai Technology Co., Ltd.
Modèle : A938-050150W-US1
Sortie : 5 V CC 2A
VTech Telecommunications Ltd.
Modèle : VT07EUS05200 -OU-
Jiangxi Jian Aohai Technology Co., Ltd.
Modèle : A938-050200W-US1
Informations sur les piles rechargeables :
3,7V 5000mAh, 18,5Wh Lithium-ion batterie
Zhuhai Great Power Energy Co., Ltd.
Modèle : GSP806090-5Ah-3.7V-1S1P
9. Lorsqu’ils sont branchés dans une prise de courant, les adaptateurs
secteur ont été conçus pour être orientés correctement, soit à la
verticale ou au plancher. Les broches n’ont pas été conçues pour
supporter le poids du bloc d’alimentation et le maintenir en place
si celuici est branché dans une prise au plafond, sous une table ou
dans un meuble.
10. Pour les appareils raccordés, la prise de courant (de l’adaptateur
secteur) doit être installée près de l’équipement et doit être
facilement accessible.
11. Débranchez ce produit de la prise de courant avant de procéder
au nettoyage. N’utilisez pas de nettoyants en aérosols. Utilisez un
chiffon humide pour le nettoyer.
12. Ne coupez pas les cordons d’alimentation pour remplacer les
fiches, car ceci peut présenter un danger potentiel.
13. Ne laissez aucun objet reposer ni appuyer sur le cordon
d’alimentation. N’installez pas cet appareil dans un endroit où l’on
risque d’écraser le cordon d’alimentation ou de le piétiner.
14. Ne faites fonctionner cet appareil qu’avec le type d’alimentation
indiqué sur l’étiquette. Si vous ne connaissez pas le type
d’alimentation que vous possédez à votre domicile, consultez
votre marchand ou votre compagnie locale d’électricité.
15. L’équipement doit être fourni à partir d’un acquiescement gauche
identifié d’USB aux conditions de la source d’énergie limitée.
16. Ne surchargez pas les prises de courant murales ni les rallonges
électriques.
17. Ne placez pas cet appareil sur un chariot, meuble, trépied,
support de montage ni table chancelants.
18. Les trous et ouvertures du boîtier, situés à l’arrière de l’appareil
ou sous celui-ci, servent à aérer l’appareil. Pour l’empêcher de
surchauffer, ne bloquez sous aucun prétexte ces ouvertures et
n’empêchez pas l’aération adéquate de l’appareil en le plaçant sur
un lit, divan, tapis ou toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une source de chaleur
ou d’un calorifère. De plus, ne placez pas l’appareil dans un
endroit avant de vous assurer qu’il y ait une bonne circulation d’air.
19. N’enfoncez jamais d’objets à travers les ouvertures de cet appareil,
car ils pourraient entrer en contact avec des points de tension
dangereux ou causer des courts-circuits qui peuvent dégénérer
en incendies ou en risques d’électrocution. Ne renversez jamais de
liquide dans ce produit.
20. Afin de réduire les risques d’électrocution, ne démontez pas cet
appareil, mais apportez-le dans un centre de service autorisé.
L’ouverture du boîtier ou le retrait de toutes pièces que contient
cet appareil, à l’exception de l’accès autorisé à certaines portes
ou ouvertures, risque de vous exposer à des points de tension
dangereux ou d’autres dangers. Un remontage incorrect peut par
la suite présenter des risques d’électrocution.
21. Vous devriez tester la réception chaque fois que vous mettez
l’appareil en fonction.
22. Examinez les composantes afin de vérifier si celles-ci ne sont pas
endommagées.
23. Il existe un très faible risque de perte de confidentialité avec
certains appareils électroniques (autres écoute-bébés, téléphones
sans fils etc.). Pour l’éviter, s’assurer que le produit n’a jamais
été utilisé avant l’achat, réinitialiser l’unité de façon périodique,
éteindre l’écoute-bébé quand il n’est pas en cours d’utilisation.
24. Les enfants devraient être supervisés afin de vous assurer qu’ils ne
jouent pas avec l’appareil.
25. Les petites pièces de ce moniteur peuvent être avalées par les
bébés ou les petits enfants. Veuillez tenir ces pièces hors de
portée des enfants.
26. Le produit n’est pas conçu pour être utilisé par des personnes
(incluant des enfants) aux capacités physiques, sensorielles
ou mentales réduites ou qui manquent d’expérience et de
connaissances, à moins qu’on leur ait donné suffisamment
de supervision ou d’instructions relativement à l’utilisation de
l’appareil par une personne responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
• Utilisez et entreposez le produit à une température entre 0˚ C
(32˚F) et 40˚C (104˚ F).
• Risque de brûlure, risque d’incendie, risque d’explosion associé à
une mauvaise manipulation de la batterie.
• N’exposez pas cet appareil à des froids ou des chaleurs extrêmes,
ainsi qu’à la lumière directe du soleil. Ne l’installez pas près d’une
source de chauffage.
• Avertissement - Risque de strangulation -
Les enfants se sont ÉTRANGLÉS dans des cordons.
Gardez ce cordon hors de portée des enfants (à
plus de 0,9 m). N’enlevez pas cette étiquette.
• Ne jamais placer le moniteur à l’intérieur du berceau ou du parc
de bébé. Ne jamais couvrir le moniteur ou l’unité (s) portative avec
un article tel une serviette ou une couverture.
• D’autres produits électroniques peuvent causer des interférences
auprès de votre caméra IP. Essayez d’installer votre caméra IP
le plus loin possible de ces dispositifs électroniques : routeurs
sans fil, radios, téléphones cellulaires, interphones, moniteurs de
pièces, téléviseurs, ordinateurs personnels, appareils électriques
de cuisine et téléphones sans fil.
Stimulateurs cardiaques implantés dans l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux dispositifs
numériques sans fil):
L’organisme ‘Wireless Technology Research, LLC (WTR)’, une firme de
recherche indépendante, a mené une évaluation pluridisciplinaire des
interférences entre les téléphones sans fil portatifs et les stimulateurs
cardiaques implantés dans l’organisme. Appuyée par l’Administration
des aliments et drogues (FDA) des États-Unis, la firme WTR
recommande aux médecins:
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil à au moins six pouces
du simulateur cardiaque.
• Ils ne doivent PAS placer le téléphone sans fil directement sur
le stimulateur cardiaque, tel que dans une poche de chemise,
lorsque celui-ci est en marche.
L’étude effectuée par l’organisme WRS n’a pas identifié de risque
pour les détenteurs de simulateurs cardiaques causés par les gens qui
utilisent dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes les normes se rapportant
aux champs électromagnétiques (EMF) standard. Si vous le manipulez
correctement en suivant les instructions de ce guide, son utilisation
sera sécuritaire pendant de nombreuses années, selon les meilleures
évidences scientifiques dont nous disposons aujourd’hui.
California Energy Commission battery
charging testing mode
This video monitor meets the California Energy Commission (CEC) regulations for energy consumption. Your video monitor is set up to
comply with the energy-conserving standards right out of the box.
Follow the instructions to install and charge the battery. The CEC battery charging testing mode is activated while charging.
Even if the parent unit is paired to camera units, the CEC battery charging testing mode is activated while it is powered off and
charging.
For cETL compliance only
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized service
representative will replace at VTech’s option, without charge,
a Materially Defective Product. If we choose to replace
the Product, we may replace it with a new or refurbished
Product of the same or similar design. We will retain
defective parts, modules, or equipment. Replacement of the
Product, at VTech’s option, is your exclusive remedy. VTech
will return the replacement Products to you in working
condition. You should expect the replacement to take
approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for ONE
(1) YEAR from the date of purchase (90 days on products
purchased as Refurbished*). This limited warranty also
applies to the replacement Product for a period of either (a)
90 days from the date the replacement Product is shipped
to you or (b) the time remaining on the original one-year
warranty (90-day limited warranty on products that are
purchased as Refurbished*); whichever is longer.
*Refurbished products purchased from our online store
carry a 90-day replacement warranty.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation, fire,
water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 below); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our
website at www.vtechbabycare.com or call 1 (800) 595-
9511. In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return replaced Product under this limited warranty.
Transportation, delivery or handling charges are prepaid.
VTech assumes no risk for damage or loss of the Product in
transit.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the Product.
There are no other express warranties. No one is authorized
to make modifications to this limited warranty and you should
not rely on any such modification. State/Provincial Law Rights:
This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state or province
to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof
of purchase.
Limited warranty
The RBRC seal on the lithium-ion battery indicates that VTech Communications, Inc. is voluntarily participating in an
industry program to collect and recycle these batteries at the end of their useful lives, when taken out of service within
the United States and Canada. The program provides a convenient alternative to placing used lithium-ion batteries into
the trash or municipal waste, which may be illegal in your area.
VTech’s participation makes it easy for you to drop off the spent product at local retailers participating in the program
or at authorized VTech product service centers. Please call 1 (800) 8 BATTERY
®
for information on Li-ion battery recycling and disposal
bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and
conserving natural resources.
The RBRC Seal and 1 (800) 8 BATTERY
®
are registered trademarks of Call2recycle, Inc.
The RBRC seal
To keep this product working well and looking good, follow these guidelines:
• Avoid placing near heating appliances and devices that generate electrical noise (for example, motors
or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft damp cloth.
• DO NOT immerse the parent unit or the baby unit in water and do not clean under running water.
• DO NOT use solvents, household cleaning sprays, or liquid cleaners.
• Make sure the parent unit and the baby unit are dry before reconnecting to the mains supply.
When you are not going to use the video monitor for some time, store the parent unit, the baby unit
and the adapters in a cool, dry place.
Below are the questions most frequently asked about the video monitor.
Can I turn the parent
unit display screen
off but keep hearing
sounds from the baby
unit?
Yes, press POWER
|
LCD ON/OFF on the parent unit to turn off the screen. You
will still be able to hear all sounds from the baby unit.
Press any key to turn the screen back on.
Why is the baby
unit not responding
normally?
Try the following (in the order listed) for a common cure:
1. Disconnect the power to the baby unit.
2. Wait a few minutes before connecting power back to the baby unit.
3. Reboot the parent unit.
Why is my screen in
black and white?
The baby unit has a light sensor that measures ambient light. When the
ambient light is dim, such as during night time or in a dark room, the baby unit
activates its infrared LEDs, and displays the camera images in black and white
night vision.
Why does my baby unit
show offline? Why is the
connection lost every
now and then?
The baby unit may have lost connection to the Wi-Fi router. Check your
network and router settings.
Other electronic products may cause interference with your baby unit. Try
installing your baby unit as far away from these electronic devices as possible.
Why can’t I hear a
sound/Why can’t I hear
my baby crying?
The parent unit speaker volume may be too low. Press on the parent unit
to increase the volume.
mount the baby unit (optional)
1. Place the wall mount bracket on a
wall and then use a pencil to mark
two holes in parallel. Remove the
wall mount bracket and drill two
holes in the wall (7/32 inch drill bit).
NOTESNOTE
Notes
Check the reception strength and baby unit
camera angle before drilling any holes:
• The types of screws and anchors you
need depend on the composition of
the wall. You may need to purchase the
screws and anchors separately to mount
your baby units.
2. If you drill the holes into a stud, go
to step 3.
• If you drill the holes into an
object other than a stud, insert
the anchors into the holes.
Tap gently on the ends with a
hammer until the anchors are
flush with the wall.
3. Align the wall mount bracket and screws with
the holes in the wall as shown. Tighten the screw
in the middle hole first, so that the wall mount
bracket position is fixed. You can tighten the
other screw in the top hole.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Place the baby unit on the wall
mount bracket, and then slide it
forward until it locks into place. Align
the holes on the wall mount bracket
with the screws on the wall, and slide
the wall mount bracket down until it
locks into place.
5. You can maximize your baby unit viewing angle by tilting the wall mount bracket.
Hold the baby unit, and then rotate the knob in an anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your baby unit up or down to adjust to your preferred angle. Then, rotate the knob in a clockwise direction to tighten the
joint and secure the angle.
OR
4. Place the baby unit on the wall mount bracket,
and then slide it forward until it locks into place.
Connect the power adapter to the baby unit
and a power supply.
1
2
Need help?
S
m
For instructions and guides to make the best use of your baby
monitor, and for the latest information and support, check out our
online help topics and FAQs. The online help page will also be
updated periodically to reflect product system updates.
Use your smartphone or mobile phone to access our online help.
• Go to https://help.vtechphones.com/vm901hd or
https://help.vtechphones.com/vm901-2hd; OR
• Scan the QR code on the right. Launch the camera app or QR code
scanner app on your smartphone or tablet. Hold the device’s
camera up to the QR code and frame it. Tap the notification to be
redirected to the online help page.
- If the QR code is not clearly displayed, adjust your camera’s
focus by moving your device closer or further away until the
image is clear.
If you would like to contact us, visit
https://help.vtechphones.com/cs.
You can also call our Customer Support at 1 (800) 595-9511 [in US] or
1 (800) 267-7377 [in Canada] for help.
VM901HD online help
VM901-2HD online help
Night vision
Notes
• A click sound from the baby unit is normal and occurs when your unit adapts to the
environment lighting conditions.
• To achieve accurate and high quality video feeds, your baby unit is equipped with an
Infrared Cut-off Filter lens that optimizes color accuracy in bright, day-time environments.
When the environment turns dark at night, this filter lens is withdrawn to enhance
night vision quality. The brief click sound you hear is from the filter lens activating and
withdrawing as the unit switches from day to night vision (and vice versa).
Tip
• Depending on the surroundings and other interfering factors, for example, lighting, objects,
colors and backgrounds, the image quality may vary. Adjust the baby unit angle or place the
baby unit at a higher location to prevent glare and a blurred display.
The baby unit has infrared LEDs that allow you to see your baby clearly at night or in a
dark room. When the baby unit detects low light levels, the infrared LEDs are switched
on automatically. The images from the baby unit are in black and white, and appears
on the parent unit screen.
