NOTESNOTE
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the baby monitor is not connected to a switch-controlled electric outlet.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of baby monitor, so do not connect them to any ceiling, under-the-table,
or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby units and the power adapter cords are out of reach of children.
Long press
Power off
Specifications are subject to change without notice.
© 2020 VTech Communications, Inc. All rights reserved.
07/20. VM5463-X_QSG_V5.
Quick start guide
VM5463
VM5463-2
Full Color Pan and Tilt
Video Monitor
Go to www.vtechphones.com
to register your product for
enhanced warranty support and
the latest VTech product news.
1
Connect the baby monitor
2
Power on or off the baby monitor
Slide the switch to power on or off your baby unit.
Press and hold POWER to power on or off your parent unit.
What’s in the box
4
Status check
Once you power on both your
baby unit and parent unit, your
parent unit displays image from
the baby unit, and the LINK LED
light turns on.
The ON LED light of baby unit
turns on.
3
Positioning the baby monitor
Caution
• The default volume of your parent unit is level
4, and the maximum volume is level 7. If you
experience high-pitched screeching noise from
your baby monitor while positioning:
- Make sure your baby unit and parent unit are
more than 3 feet (1 meter) apart, OR
- Lower the volume of your parent unit.
Note
• To avoid interference from other electronic
devices, place your baby monitor at least 3 feet
(1 meter) away from devices such as wireless
routers, microwaves, cell phones and computers.
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
th
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
i
l
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
le
a
s
t
t
h
r
e
e
f
e
e
t
a
w
a
y
f
ro
m
th
e
c
h
i
ld
a
t
a
ll
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
ta
g
.
É
l
o
ig
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
fa
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
ro
u
v
e
r
à
a
u
m
o
in
s
t
r
o
is
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
t
o
u
t
t
e
m
p
s
.
N
’u
t
il
is
e
z
p
a
s
d
e
ra
l
lo
n
g
e
.
N
e
r
e
t
i
r
e
z
p
a
s
ce
t
t
e
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
ra
d
e
la
a
l
c
a
n
c
e
d
e
l
o
s
n
i
ñ
o
s
.
E
s
te
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
re
s
p
ie
s
fu
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
to
d
o
m
o
m
e
n
t
o
.
N
o
lo
u
s
e
c
o
n
u
n
a
e
x
t
e
n
s
ió
n
in
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
t
a
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
ió
n
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
t
h
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
il
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
l
e
a
s
t
t
h
r
e
e
fe
e
t
a
w
a
y
f
r
o
m
t
h
e
c
h
il
d
a
t
a
l
l
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
t
a
g
.
É
l
o
i
g
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
f
a
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
r
o
u
v
e
r
à
a
u
m
o
i
n
s
t
r
o
i
s
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
to
u
t
t
e
m
p
s
.
N
’
u
t
i
l
is
e
z
p
a
s
d
e
r
a
l
lo
n
g
e
.
N
e
r
e
t
ir
e
z
p
a
s
c
e
t
te
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
lo
s
n
i
ñ
o
s
.
E
s
t
e
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
r
e
s
p
i
e
s
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
t
o
d
o
m
o
m
e
n
to
.
N
o
l
o
u
s
e
c
o
n
u
n
a
e
x
t
e
n
si
ó
n
i
n
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
ta
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
i
ó
n
Quick start guide
Frequency control Crystal controlled PLL synthesizer
Transmit frequency Baby unit: 2405 - 2475 MHz
Parent unit: 2405 - 2475 MHz
Channels 32
LCD 5” Color LCD
(WQVGA 480x272 pixel)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range
may vary according to environmental conditions at the time of use.
Power requirements Parent unit: 3.6V Ni-MH battery
Baby unit power adapter: Output: 5V DC @ 1A
Parent unit power adapter: Output: 5V DC @ 1A
Technical specifications
Credits:
The Background Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Stream Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Crickets At Night sound file was created by Mike Koenig, and is used under the Creative Commons license.
The Heart Beat sound file was created by Zarabadeu, and is used under the Creative Commons license.
The applied nameplate is located at the bottom of the
baby unit’s base.
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on the
product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height
above 2 meters.
4. This product is not a substitute for adult supervision of the
infant. Supervising the infant is the parent’s or caregiver’s
responsibility. This product could cease operating, and
therefore you should not assume it will continue working
properly for any given period of time. Further, this is not
a medical device and should not be used as such. This
product is intended to assist you in supervising your baby.
5. Do not use this product near water. For example, do
not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement
or shower.
6.
CAUTION: Use only the battery provided.
There may be a risk of explosion if a wrong type of battery
is used for the parent unit. The battery cannot be subjected
to high or low extreme temperature and low air pressure at
high altitude during use, storage or transportation. Disposal
of battery into fire or a hot oven, or mechanically crushing
or cutting or the battery can result in an explosion. Leaving
the battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of
flammable liquid of gas. Battery subjected to extremely
low air pressure may result in an explosion or the leakage of
flammable liquid or gas. Dispose of used battery according
to the information in The RBRC
®
seal.
7. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Baby unit power adapter: Output: 5V DC 1A;
Parent unit power adapter: Output: 5V DC 1A.
8. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place if it
is plugged into a ceiling, under-the-table or cabinet
outlet.
9. For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
10. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth
for cleaning.
11. Do not cut off the power adapters to replace them with
other plugs, as this causes a hazardous situation.
12. Do not allow anything to rest on the power cords. Do
not install this product where the cords may be walked
on or crimped.
13. This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or local power company.
14. Do not overload wall outlets or use an extension cord.
15. Do not place this product on an unstable table, shelf,
stand or other unstable surfaces.
16. This product should not be placed in any area where
proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for
ventilation. To protect them from overheating, these
openings must not be blocked by placing the product
on a soft surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat
register.
17. Never push objects of any kind into this product
through the slots because they may touch dangerous
voltage points or create a short circuit. Never spill liquid
of any kind on the product.
18. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specified access doors may
expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock
when the product is subsequently used.
19. You should test the sound reception every time you
turn on the units or move one of the components.
20. Periodically examine all components for damage.
21. Be aware of possible loss of privacy while using public
airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
22. Children should be supervised to ensure that they do
not play with the product.
23. The product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature between
32
o
F and 104
o
F.
2. Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to a
heating source.
3. Batteries should not be exposed to
excessive heat such as bright sunshine
or fire.
4. Make sure the baby unit(s) and the
adapter cord(s) are always out of reach
of the baby, at least 3 feet away from
the baby or crib, to avoid a possible strangulation
hazar d.
5. Never place the baby unit(s) inside the baby’s crib or
playpen. Never cover the baby unit(s) or parent unit
with anything such as a towel or a blanket.
6. Other electronic products may cause interference
with your baby monitor. Try installing your baby
monitor as far away from these electronic devices
as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and
implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians
that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned
ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and
according to the instructions in this user’s manual, the
product is safe to be used based on scientific evidence
available today.
Important safety instructions
Stra
ngula
ti
o
n
Haza
rd
K
eep thi
s cor
d ou
t of re
ach o
f chi
ldren
.
The co
rd ne
eds
to be
at le
ast t
hree f
eet
away
from
the
child
at al
l time
s. Do
not
us
e wit
h an e
xtens
ion c
ord.
Do no
t
remov
e thi
s tag.
Él
oigne
z ce
cordo
n des
enfa
nts. L
e
cord
on do
it se tro
uve
r à a
u mo
ins tro
is
pie
ds d’u
n en
fant e
t ce, e
n tou
t tem
ps.
N
’utilise
z pa
s de ra
llon
ge. Ne
reti
rez pa
s
cette
étiqu
ette.
Ma
nten
ga e
ste ca
ble
fu
era de
la a
lcanc
e
de lo
s niño
s. Est
e ca
ble de
be
estar p
or
lo
meno
s tre
s pie
s fu
era de
la alc
ance
del
niño e
n to
do m
ome
nto. N
o lo
use
c
on u
na ex
tensió
n in
alám
brica
. No q
uite
esta
etiqu
eta.
Ri
sq
ue
d’ét
rangl
eme
n
t
Rie
sgo
de
e
strang
ulaci
ón
Str
angul
atio
n
Ha
za
rd
Ke
ep th
is
cord
out
of rea
ch
of
childr
en
.
The
co
rd
nee
ds
t
o be
at
leas
t
th
ree
feet
awa
y
f
rom
the
child
at al
l time
s. D
o n
ot
use
wi
th
an
exten
si
on
co
rd
. Do
not
re
mo
ve th
i
s ta
g.
É
loign
ez
ce c
o
rdo
n d
es en
fant
s.
Le
cordo
n
do
it se
trou
ver
à au
mo
in
s tro
is
pi
ed
s d
’un en
fan
t e
t ce,
en t
out
tem
p
s.
N’u
tilisez
p
as
de
rallo
nge
. Ne
retir
ez p
as
ce
tt
e ét
iqu
ette.
M
a
nten
ga es
te
cab
le fu
era
de
la al
can
ce
de
los n
iños
. E
ste c
abl
e de
be
es
ta
r po
r
lo
men
os
tres
pies
fuer
a
de la
alc
ance
de
l niñ
o
en
t
odo
mo
men
to. N
o
lo u
se
c
on u
na
ext
ensi
ón
inalá
mbr
ic
a. No q
u
ite
esta
eti
que
ta.
Ri
squ
e
d’
ét
ran
gle
ment
Ries
go
de
estr
ang
ulaci
ó
n
Power on
Power off
>
<
3ft (1m)
3ft (1m)
6
3
63
> 3ft (1m)
x 2
x 2
1 set for VM5463
2 sets for VM5463-2
≥
<
3ft (1m)
3ft (1m)
63
Long press
Power on
NOTESNOTE
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the baby monitor is not connected to a switch-controlled electric outlet.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of baby monitor, so do not connect them to any ceiling, under-the-table,
or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby units and the power adapter cords are out of reach of children.
Long press
Power off
Specifications are subject to change without notice.
© 2020 VTech Communications, Inc. All rights reserved.
07/20. VM5463-X_QSG_V5.
Quick start guide
VM5463
VM5463-2
Full Color Pan and Tilt
Video Monitor
Go to www.vtechphones.com
to register your product for
enhanced warranty support and
the latest VTech product news.
1
Connect the baby monitor
2
Power on or off the baby monitor
Slide the switch to power on or off your baby unit.
Press and hold POWER to power on or off your parent unit.
What’s in the box
4
Status check
Once you power on both your
baby unit and parent unit, your
parent unit displays image from
the baby unit, and the LINK LED
light turns on.
The ON LED light of baby unit
turns on.
3
Positioning the baby monitor
Caution
• The default volume of your parent unit is level
4, and the maximum volume is level 7. If you
experience high-pitched screeching noise from
your baby monitor while positioning:
- Make sure your baby unit and parent unit are
more than 3 feet (1 meter) apart, OR
- Lower the volume of your parent unit.
Note
• To avoid interference from other electronic
devices, place your baby monitor at least 3 feet
(1 meter) away from devices such as wireless
routers, microwaves, cell phones and computers.
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
th
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
i
l
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
le
a
s
t
t
h
r
e
e
f
e
e
t
a
w
a
y
f
ro
m
th
e
c
h
i
ld
a
t
a
ll
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
ta
g
.
É
l
o
ig
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
fa
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
ro
u
v
e
r
à
a
u
m
o
in
s
t
r
o
is
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
t
o
u
t
t
e
m
p
s
.
N
’u
t
il
is
e
z
p
a
s
d
e
ra
l
lo
n
g
e
.
N
e
r
e
t
i
r
e
z
p
a
s
ce
t
t
e
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
ra
d
e
la
a
l
c
a
n
c
e
d
e
l
o
s
n
i
ñ
o
s
.
E
s
te
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
re
s
p
ie
s
fu
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
to
d
o
m
o
m
e
n
t
o
.
N
o
lo
u
s
e
c
o
n
u
n
a
e
x
t
e
n
s
ió
n
in
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
t
a
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
ió
n
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
t
h
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
il
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
l
e
a
s
t
t
h
r
e
e
fe
e
t
a
w
a
y
f
r
o
m
t
h
e
c
h
il
d
a
t
a
l
l
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
t
a
g
.
É
l
o
i
g
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
f
a
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
r
o
u
v
e
r
à
a
u
m
o
i
n
s
t
r
o
i
s
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
to
u
t
t
e
m
p
s
.
N
’
u
t
i
l
is
e
z
p
a
s
d
e
r
a
l
lo
n
g
e
.
N
e
r
e
t
ir
e
z
p
a
s
c
e
t
te
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
lo
s
n
i
ñ
o
s
.
E
s
t
e
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
r
e
s
p
i
e
s
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
t
o
d
o
m
o
m
e
n
to
.
N
o
l
o
u
s
e
c
o
n
u
n
a
e
x
t
e
n
si
ó
n
i
n
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
ta
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
i
ó
n
Quick start guide
Frequency control Crystal controlled PLL synthesizer
Transmit frequency Baby unit: 2405 - 2475 MHz
Parent unit: 2405 - 2475 MHz
Channels 32
LCD 5” Color LCD
(WQVGA 480x272 pixel)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range
may vary according to environmental conditions at the time of use.
Power requirements Parent unit: 3.6V Ni-MH battery
Baby unit power adapter: Output: 5V DC @ 1A
Parent unit power adapter: Output: 5V DC @ 1A
Technical specifications
Credits:
The Background Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Stream Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Crickets At Night sound file was created by Mike Koenig, and is used under the Creative Commons license.
The Heart Beat sound file was created by Zarabadeu, and is used under the Creative Commons license.
The applied nameplate is located at the bottom of the
baby unit’s base.
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on the
product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height
above 2 meters.
4. This product is not a substitute for adult supervision of the
infant. Supervising the infant is the parent’s or caregiver’s
responsibility. This product could cease operating, and
therefore you should not assume it will continue working
properly for any given period of time. Further, this is not
a medical device and should not be used as such. This
product is intended to assist you in supervising your baby.
5. Do not use this product near water. For example, do
not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement
or shower.
6.
CAUTION: Use only the battery provided.
There may be a risk of explosion if a wrong type of battery
is used for the parent unit. The battery cannot be subjected
to high or low extreme temperature and low air pressure at
high altitude during use, storage or transportation. Disposal
of battery into fire or a hot oven, or mechanically crushing
or cutting or the battery can result in an explosion. Leaving
the battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of
flammable liquid of gas. Battery subjected to extremely
low air pressure may result in an explosion or the leakage of
flammable liquid or gas. Dispose of used battery according
to the information in The RBRC
®
seal.
7. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Baby unit power adapter: Output: 5V DC 1A;
Parent unit power adapter: Output: 5V DC 1A.
8. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place if it
is plugged into a ceiling, under-the-table or cabinet
outlet.
9. For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
10. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth
for cleaning.
11. Do not cut off the power adapters to replace them with
other plugs, as this causes a hazardous situation.
12. Do not allow anything to rest on the power cords. Do
not install this product where the cords may be walked
on or crimped.
13. This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or local power company.
14. Do not overload wall outlets or use an extension cord.
15. Do not place this product on an unstable table, shelf,
stand or other unstable surfaces.
16. This product should not be placed in any area where
proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for
ventilation. To protect them from overheating, these
openings must not be blocked by placing the product
on a soft surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat
register.
17. Never push objects of any kind into this product
through the slots because they may touch dangerous
voltage points or create a short circuit. Never spill liquid
of any kind on the product.
18. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specified access doors may
expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock
when the product is subsequently used.
19. You should test the sound reception every time you
turn on the units or move one of the components.
20. Periodically examine all components for damage.
21. Be aware of possible loss of privacy while using public
airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
22. Children should be supervised to ensure that they do
not play with the product.
23. The product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature between
32
o
F and 104
o
F.
2. Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to a
heating source.
3. Batteries should not be exposed to
excessive heat such as bright sunshine
or fire.
4. Make sure the baby unit(s) and the
adapter cord(s) are always out of reach
of the baby, at least 3 feet away from
the baby or crib, to avoid a possible strangulation
hazar d.
5. Never place the baby unit(s) inside the baby’s crib or
playpen. Never cover the baby unit(s) or parent unit
with anything such as a towel or a blanket.
6. Other electronic products may cause interference
with your baby monitor. Try installing your baby
monitor as far away from these electronic devices
as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and
implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians
that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned
ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and
according to the instructions in this user’s manual, the
product is safe to be used based on scientific evidence
available today.
Important safety instructions
Stra
ngula
ti
o
n
Haza
rd
K
eep thi
s cor
d ou
t of re
ach o
f chi
ldren
.
The co
rd ne
eds
to be
at le
ast t
hree f
eet
away
from
the
child
at al
l time
s. Do
not
us
e wit
h an e
xtens
ion c
ord.
Do no
t
remov
e thi
s tag.
Él
oigne
z ce
cordo
n des
enfa
nts. L
e
cord
on do
it se tro
uve
r à a
u mo
ins tro
is
pie
ds d’u
n en
fant e
t ce, e
n tou
t tem
ps.
N
’utilise
z pa
s de ra
llon
ge. Ne
reti
rez pa
s
cette
étiqu
ette.
Ma
nten
ga e
ste ca
ble
fu
era de
la a
lcanc
e
de lo
s niño
s. Est
e ca
ble de
be
estar p
or
lo
meno
s tre
s pie
s fu
era de
la alc
ance
del
niño e
n to
do m
ome
nto. N
o lo
use
c
on u
na ex
tensió
n in
alám
brica
. No q
uite
esta
etiqu
eta.
Ri
sq
ue
d’ét
rangl
eme
n
t
Rie
sgo
de
e
strang
ulaci
ón
Str
angul
atio
n
Ha
za
rd
Ke
ep th
is
cord
out
of rea
ch
of
childr
en
.
The
co
rd
nee
ds
t
o be
at
leas
t
th
ree
feet
awa
y
f
rom
the
child
at al
l time
s. D
o n
ot
use
wi
th
an
exten
si
on
co
rd
. Do
not
re
mo
ve th
i
s ta
g.
É
loign
ez
ce c
o
rdo
n d
es en
fant
s.
Le
cordo
n
do
it se
trou
ver
à au
mo
in
s tro
is
pi
ed
s d
’un en
fan
t e
t ce,
en t
out
tem
p
s.
N’u
tilisez
p
as
de
rallo
nge
. Ne
retir
ez p
as
ce
tt
e ét
iqu
ette.
M
a
nten
ga es
te
cab
le fu
era
de
la al
can
ce
de
los n
iños
. E
ste c
abl
e de
be
es
ta
r po
r
lo
men
os
tres
pies
fuer
a
de la
alc
ance
de
l niñ
o
en
t
odo
mo
men
to. N
o
lo u
se
c
on u
na
ext
ensi
ón
inalá
mbr
ic
a. No q
u
ite
esta
eti
que
ta.
Ri
squ
e
d’
ét
ran
gle
ment
Ries
go
de
estr
ang
ulaci
ó
n
Power on
Power off
>
<
3ft (1m)
3ft (1m)
6
3
63
> 3ft (1m)
x 2
x 2
1 set for VM5463
2 sets for VM5463-2
≥
<
3ft (1m)
3ft (1m)
63
Long press
Power on
NOTESNOTE
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the baby monitor is not connected to a switch-controlled electric outlet.
• Connect the power adapters in a vertical or floor mount position only. The adapters’ prongs are not
designed to hold the weight of baby monitor, so do not connect them to any ceiling, under-the-table,
or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby units and the power adapter cords are out of reach of children.
Long press
Power off
Specifications are subject to change without notice.
© 2020 VTech Communications, Inc. All rights reserved.
07/20. VM5463-X_QSG_V5.
Quick start guide
VM5463
VM5463-2
Full Color Pan and Tilt
Video Monitor
Go to www.vtechphones.com
to register your product for
enhanced warranty support and
the latest VTech product news.
1
Connect the baby monitor
2
Power on or off the baby monitor
Slide the switch to power on or off your baby unit.
Press and hold POWER to power on or off your parent unit.
What’s in the box
4
Status check
Once you power on both your
baby unit and parent unit, your
parent unit displays image from
the baby unit, and the LINK LED
light turns on.
The ON LED light of baby unit
turns on.
3
Positioning the baby monitor
Caution
• The default volume of your parent unit is level
4, and the maximum volume is level 7. If you
experience high-pitched screeching noise from
your baby monitor while positioning:
- Make sure your baby unit and parent unit are
more than 3 feet (1 meter) apart, OR
- Lower the volume of your parent unit.
Note
• To avoid interference from other electronic
devices, place your baby monitor at least 3 feet
(1 meter) away from devices such as wireless
routers, microwaves, cell phones and computers.
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
th
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
i
l
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
le
a
s
t
t
h
r
e
e
f
e
e
t
a
w
a
y
f
ro
m
th
e
c
h
i
ld
a
t
a
ll
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
ta
g
.
É
l
o
ig
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
fa
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
ro
u
v
e
r
à
a
u
m
o
in
s
t
r
o
is
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
t
o
u
t
t
e
m
p
s
.
N
’u
t
il
is
e
z
p
a
s
d
e
ra
l
lo
n
g
e
.
N
e
r
e
t
i
r
e
z
p
a
s
ce
t
t
e
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
ra
d
e
la
a
l
c
a
n
c
e
d
e
l
o
s
n
i
ñ
o
s
.
E
s
te
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
re
s
p
ie
s
fu
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
to
d
o
m
o
m
e
n
t
o
.
N
o
lo
u
s
e
c
o
n
u
n
a
e
x
t
e
n
s
ió
n
in
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
t
a
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
ió
n
S
t
r
a
n
g
u
l
a
t
i
o
n
H
a
z
a
r
d
K
e
e
p
t
h
i
s
c
o
r
d
o
u
t
o
f
r
e
a
c
h
o
f
c
h
il
d
r
e
n
.
T
h
e
c
o
r
d
n
e
e
d
s
t
o
b
e
a
t
l
e
a
s
t
t
h
r
e
e
fe
e
t
a
w
a
y
f
r
o
m
t
h
e
c
h
il
d
a
t
a
l
l
t
im
e
s
.
D
o
n
o
t
u
s
e
w
i
t
h
a
n
e
x
t
e
n
s
i
o
n
c
o
r
d
.
D
o
n
o
t
r
e
m
o
v
e
t
h
i
s
t
a
g
.
É
l
o
i
g
n
e
z
c
e
c
o
r
d
o
n
d
e
s
e
n
f
a
n
t
s
.
L
e
c
o
r
d
o
n
d
o
i
t
s
e
t
r
o
u
v
e
r
à
a
u
m
o
i
n
s
t
r
o
i
s
p
ie
d
s
d
’
u
n
e
n
f
a
n
t
e
t
c
e
,
e
n
to
u
t
t
e
m
p
s
.
N
’
u
t
i
l
is
e
z
p
a
s
d
e
r
a
l
lo
n
g
e
.
N
e
r
e
t
ir
e
z
p
a
s
c
e
t
te
é
t
iq
u
e
t
t
e
.
M
a
n
t
e
n
g
a
e
s
t
e
c
a
b
l
e
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
lo
s
n
i
ñ
o
s
.
E
s
t
e
c
a
b
le
d
e
b
e
e
s
ta
r
p
o
r
lo
m
e
n
o
s
t
r
e
s
p
i
e
s
f
u
e
r
a
d
e
l
a
a
l
c
a
n
c
e
d
e
l
n
iñ
o
e
n
t
o
d
o
m
o
m
e
n
to
.
N
o
l
o
u
s
e
c
o
n
u
n
a
e
x
t
e
n
si
ó
n
i
n
a
lá
m
b
r
i
c
a
.
N
o
q
u
i
t
e
e
s
t
a
e
ti
q
u
e
ta
.
R
i
s
q
u
e
d
’
é
t
r
a
n
g
l
e
m
e
n
t
R
i
e
s
g
o
d
e
e
s
t
r
a
n
g
u
l
a
c
i
ó
n
Quick start guide
Frequency control Crystal controlled PLL synthesizer
Transmit frequency Baby unit: 2405 - 2475 MHz
Parent unit: 2405 - 2475 MHz
Channels 32
LCD 5” Color LCD
(WQVGA 480x272 pixel)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range
may vary according to environmental conditions at the time of use.
Power requirements Parent unit: 3.6V Ni-MH battery
Baby unit power adapter: Output: 5V DC @ 1A
Parent unit power adapter: Output: 5V DC @ 1A
Technical specifications
Credits:
The Background Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Stream Noise sound file was created by Caroline Ford, and is used under the Creative Commons license.
The Crickets At Night sound file was created by Mike Koenig, and is used under the Creative Commons license.
The Heart Beat sound file was created by Zarabadeu, and is used under the Creative Commons license.
The applied nameplate is located at the bottom of the
baby unit’s base.
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on the
product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height
above 2 meters.
4. This product is not a substitute for adult supervision of the
infant. Supervising the infant is the parent’s or caregiver’s
responsibility. This product could cease operating, and
therefore you should not assume it will continue working
properly for any given period of time. Further, this is not
a medical device and should not be used as such. This
product is intended to assist you in supervising your baby.
5. Do not use this product near water. For example, do
not use it next to a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet basement
or shower.
6.
CAUTION: Use only the battery provided.
There may be a risk of explosion if a wrong type of battery
is used for the parent unit. The battery cannot be subjected
to high or low extreme temperature and low air pressure at
high altitude during use, storage or transportation. Disposal
of battery into fire or a hot oven, or mechanically crushing
or cutting or the battery can result in an explosion. Leaving
the battery in an extremely high temperature surrounding
environment can result in an explosion or the leakage of
flammable liquid of gas. Battery subjected to extremely
low air pressure may result in an explosion or the leakage of
flammable liquid or gas. Dispose of used battery according
to the information in The RBRC
®
seal.
7. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can seriously
damage the product.
Baby unit power adapter: Output: 5V DC 1A;
Parent unit power adapter: Output: 5V DC 1A.
8. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place if it
is plugged into a ceiling, under-the-table or cabinet
outlet.
9. For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
10. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth
for cleaning.
11. Do not cut off the power adapters to replace them with
other plugs, as this causes a hazardous situation.
12. Do not allow anything to rest on the power cords. Do
not install this product where the cords may be walked
on or crimped.
13. This product should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supply in your home,
consult your dealer or local power company.
14. Do not overload wall outlets or use an extension cord.
15. Do not place this product on an unstable table, shelf,
stand or other unstable surfaces.
16. This product should not be placed in any area where
proper ventilation is not provided. Slots and openings
in the back or bottom of this product are provided for
ventilation. To protect them from overheating, these
openings must not be blocked by placing the product
on a soft surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat
register.
17. Never push objects of any kind into this product
through the slots because they may touch dangerous
voltage points or create a short circuit. Never spill liquid
of any kind on the product.
18. To reduce the risk of electric shock, do not
disassemble this product, but take it to an authorized
service facility. Opening or removing parts of the
product other than specified access doors may
expose you to dangerous voltages or other risks.
Incorrect reassembling can cause electric shock
when the product is subsequently used.
19. You should test the sound reception every time you
turn on the units or move one of the components.
20. Periodically examine all components for damage.
21. Be aware of possible loss of privacy while using public
airwaves. Conversations may be picked up by other
nursery monitors, cordless phones, scanners, etc.
22. Children should be supervised to ensure that they do
not play with the product.
23. The product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature between
32
o
F and 104
o
F.
2. Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to a
heating source.
3. Batteries should not be exposed to
excessive heat such as bright sunshine
or fire.
4. Make sure the baby unit(s) and the
adapter cord(s) are always out of reach
of the baby, at least 3 feet away from
the baby or crib, to avoid a possible strangulation
hazar d.
5. Never place the baby unit(s) inside the baby’s crib or
playpen. Never cover the baby unit(s) or parent unit
with anything such as a towel or a blanket.
6. Other electronic products may cause interference
with your baby monitor. Try installing your baby
monitor as far away from these electronic devices
as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and
implanted cardiac pacemakers. Supported by the U.S. Food
and Drug Administration, WTR recommends to physicians
that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned
ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and
according to the instructions in this user’s manual, the
product is safe to be used based on scientific evidence
available today.
Important safety instructions
Stra
ngula
ti
o
n
Haza
rd
K
eep thi
s cor
d ou
t of re
ach o
f chi
ldren
.
The co
rd ne
eds
to be
at le
ast t
hree f
eet
away
from
the
child
at al
l time
s. Do
not
us
e wit
h an e
xtens
ion c
ord.
Do no
t
remov
e thi
s tag.
Él
oigne
z ce
cordo
n des
enfa
nts. L
e
cord
on do
it se tro
uve
r à a
u mo
ins tro
is
pie
ds d’u
n en
fant e
t ce, e
n tou
t tem
ps.
N
’utilise
z pa
s de ra
llon
ge. Ne
reti
rez pa
s
cette
étiqu
ette.
Ma
nten
ga e
ste ca
ble
fu
era de
la a
lcanc
e
de lo
s niño
s. Est
e ca
ble de
be
estar p
or
lo
meno
s tre
s pie
s fu
era de
la alc
ance
del
niño e
n to
do m
ome
nto. N
o lo
use
c
on u
na ex
tensió
n in
alám
brica
. No q
uite
esta
etiqu
eta.
Ri
sq
ue
d’ét
rangl
eme
n
t
Rie
sgo
de
e
strang
ulaci
ón
Str
angul
atio
n
Ha
za
rd
Ke
ep th
is
cord
out
of rea
ch
of
childr
en
.
The
co
rd
nee
ds
t
o be
at
leas
t
th
ree
feet
awa
y
f
rom
the
child
at al
l time
s. D
o n
ot
use
wi
th
an
exten
si
on
co
rd
. Do
not
re
mo
ve th
i
s ta
g.
É
loign
ez
ce c
o
rdo
n d
es en
fant
s.
Le
cordo
n
do
it se
trou
ver
à au
mo
in
s tro
is
pi
ed
s d
’un en
fan
t e
t ce,
en t
out
tem
p
s.
N’u
tilisez
p
as
de
rallo
nge
. Ne
retir
ez p
as
ce
tt
e ét
iqu
ette.
M
a
nten
ga es
te
cab
le fu
era
de
la al
can
ce
de
los n
iños
. E
ste c
abl
e de
be
es
ta
r po
r
lo
men
os
tres
pies
fuer
a
de la
alc
ance
de
l niñ
o
en
t
odo
mo
men
to. N
o
lo u
se
c
on u
na
ext
ensi
ón
inalá
mbr
ic
a. No q
u
ite
esta
eti
que
ta.
Ri
squ
e
d’
ét
ran
gle
ment
Ries
go
de
estr
ang
ulaci
ó
n
Power on
Power off
>
<
3ft (1m)
3ft (1m)
6
3
63
> 3ft (1m)
x 2
x 2
1 set for VM5463
2 sets for VM5463-2
≥
<
3ft (1m)
3ft (1m)
63
Long press
Power on
For operations and guides to help you using your video monitor,
and for latest information and supports, go and check the online
help topics and online FAQs.
Use your smartphone or mobile device to access our online help.
• Go to
https://help.vtechphones.com/vm5463
or
https://help.vtechphones.com/vm5463-2
; OR
• Scan the QR code on the right. Launch the camera app or QR code scanner app
on your smartphone or tablet. Hold the device’s camera up to the QR code and
frame it. Tap the notification to trigger the redirection of the online help.
- If the QR code is not clearly displayed, adjust your camera’s focus by moving
your device closer or further away until it is clear.
You can also call our Customer Support at 1 (800) 595-9511 [in US] or
1 (800) 267-7377 [in Canada] for help.
14
11
12
13
1
2
4
5
6
7
8
3
10
9
Adjust speaker volume
Press
/
to adjust your parent unit
speaker volume.
Zoom
Press to zoom in or out.
Talk to your baby unit
Press and hold TALK and speak to your
parent unit. Your voice is transmitted to
the baby unit. Release TALK when finish
talking and hear your baby again.
Use the menu
Press to enter the menu, choose a menu item,
or save a setting. You can use the parent unit for
advanced settings or operations, such as to play
or stop the baby unit lullaby, or to adjust the baby
unit sound sensitivity.
While in the menu:
• Press or to scroll among the menu options.
• Press to select an item, or to save a setting.
• Press or to scroll among the sub-menus,
or to adjust a setting.
• Press to return to the previous menu options
without changing the current setting.
• Press /EXIT to return to live video.
Basic operation - Parent unit
Turn off the screen
Press and hold LCD ON/OFF to switch off
the screen. You can still hear sound from the
baby unit.
Tip
• Press any keys on the parent unit to turn on
the screen again.
Overview - Parent unit
Overview - Baby unit
6
3
6
3
6
3
Press and hold
Long press
5
3
4
2
1
6
7
8
9
12
10
11
13
1 LED lights
2 LCD display
3 Microphone
4 POWER
5 TALK
6 MENU/SELECT
7 Arrow keys
8
Volume
9 VIEW /LCD ON/OFF
10 /EXIT
11 Antenna
12 RESET
13 Stand
14 Power jack
1 Light sensor
2 Camera lens
3 Microphone
4 Night light
5 On/Off switch
6 On/Off LED light
• On when the baby unit is
turned on and is paired to the
parent unit.
• Flashes when the baby unit is
not being viewed;
or when the link to the parent
unit is lost.
7 Light projection
8 Speaker
9
Projection light on/off key
10
Night light on/off key
11 Power jack
12 Temperature sensor
13 Slots for wall mounting
Need help?
Parent unit icons
Main
menu
Sub-menu
Brightness
• Adjust the parent unit’s LCD
brightness.
Camera settings
Monitoring mode (For VM5463-2 only)
• Single mode
• Split mode
• Patrol mode
Baby unit speaker volume
• Adjust the baby unit’s
speaker volume.
Lullaby
/
Play/Stop lullaby
• Select one of the soothing sounds,
or white noise.
• Select one of the five melodies.
• Play all melodies.
• Set timer to stop playing the
selected melody or soothing sound.
Main
menu
Sub-menu
Night light
/
Turn on/off night light
•
Select one of the night light colors.
• Set timer to turn the night light off.
• Set to auto turn on the night light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Projection light
/
Turn on/off projection light
• Set timer to turn the projection light
off.
• Set to auto turn on the projection light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Temperature
/
• Turn on/off temperature alert tone.
• Set the parent unit to beeps
whenever the room temperature
detected by the baby unit falls
outside of the set temperature range.
• Set the minimum temperature.
• Set the maximum temperature.
• Set temperature display in
Fahrenheit (
o
F) or Celsius (
o
C)
Main
menu
Sub-menu
Alert tones
• Set the parent unit to beep when the
battery is low.
• Set the parent unit to beep when the
link between the parent unit and the
baby unit is lost.
• Set the confirmation tone on or off
when selecting an option in the
menus.
• Set the parent unit to beep when the
baby unit detects sounds while in
Split mode (For VM5463-2 only).
Sound activation - screen and audio
/
Turn on/off sound activation
• Set sound activation on or off.
• When it is on, and the baby unit
detects no sound, the parent unit
screen stays off to save power. Once
a sound is detected, the parent
unit screen and speaker turns on
automatically, and you can see and
hear your baby. The parent unit will
then turn off again after 50 seconds
of no sound detection.
NONO
Note
• When the parent unit screen is off
and it receives alerts, for example,
link lost between parent unit and
baby unit, or battery is low, the
parent unit screen and speaker will
turn on for 10 seconds.
VOX (Voice Activated Alert) Sensitivity
• You can set VOX sensitivity level
to activate parent unit screen and
sound when baby unit detects
sounds that exceed certain levels.
See Sound sensitivity and sound
activation section.
Main menu icons
VM5463
VM5463-2
For operations and guides to help you using your video monitor,
and for latest information and supports, go and check the online
help topics and online FAQs.
Use your smartphone or mobile device to access our online help.
• Go to
https://help.vtechphones.com/vm5463
or
https://help.vtechphones.com/vm5463-2
; OR
• Scan the QR code on the right. Launch the camera app or QR code scanner app
on your smartphone or tablet. Hold the device’s camera up to the QR code and
frame it. Tap the notification to trigger the redirection of the online help.
- If the QR code is not clearly displayed, adjust your camera’s focus by moving
your device closer or further away until it is clear.
You can also call our Customer Support at 1 (800) 595-9511 [in US] or
1 (800) 267-7377 [in Canada] for help.
14
11
12
13
1
2
4
5
6
7
8
3
10
9
Adjust speaker volume
Press
/
to adjust your parent unit
speaker volume.
Zoom
Press to zoom in or out.
Talk to your baby unit
Press and hold TALK and speak to your
parent unit. Your voice is transmitted to
the baby unit. Release TALK when finish
talking and hear your baby again.
Use the menu
Press to enter the menu, choose a menu item,
or save a setting. You can use the parent unit for
advanced settings or operations, such as to play
or stop the baby unit lullaby, or to adjust the baby
unit sound sensitivity.
While in the menu:
• Press or to scroll among the menu options.
• Press to select an item, or to save a setting.
• Press or to scroll among the sub-menus,
or to adjust a setting.
• Press to return to the previous menu options
without changing the current setting.
• Press /EXIT to return to live video.
Basic operation - Parent unit
Turn off the screen
Press and hold LCD ON/OFF to switch off
the screen. You can still hear sound from the
baby unit.
Tip
• Press any keys on the parent unit to turn on
the screen again.
Overview - Parent unit
Overview - Baby unit
6
3
6
3
6
3
Press and hold
Long press
5
3
4
2
1
6
7
8
9
12
10
11
13
1 LED lights
2 LCD display
3 Microphone
4 POWER
5 TALK
6 MENU/SELECT
7 Arrow keys
8
Volume
9 VIEW /LCD ON/OFF
10 /EXIT
11 Antenna
12 RESET
13 Stand
14 Power jack
1 Light sensor
2 Camera lens
3 Microphone
4 Night light
5 On/Off switch
6 On/Off LED light
• On when the baby unit is
turned on and is paired to the
parent unit.
• Flashes when the baby unit is
not being viewed;
or when the link to the parent
unit is lost.
7 Light projection
8 Speaker
9
Projection light on/off key
10
Night light on/off key
11 Power jack
12 Temperature sensor
13 Slots for wall mounting
Need help?
Parent unit icons
Main
menu
Sub-menu
Brightness
• Adjust the parent unit’s LCD
brightness.
Camera settings
Monitoring mode (For VM5463-2 only)
• Single mode
• Split mode
• Patrol mode
Baby unit speaker volume
• Adjust the baby unit’s
speaker volume.
Lullaby
/
Play/Stop lullaby
• Select one of the soothing sounds,
or white noise.
• Select one of the five melodies.
• Play all melodies.
• Set timer to stop playing the
selected melody or soothing sound.
Main
menu
Sub-menu
Night light
/
Turn on/off night light
•
Select one of the night light colors.
• Set timer to turn the night light off.
• Set to auto turn on the night light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Projection light
/
Turn on/off projection light
• Set timer to turn the projection light
off.
• Set to auto turn on the projection light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Temperature
/
• Turn on/off temperature alert tone.
• Set the parent unit to beeps
whenever the room temperature
detected by the baby unit falls
outside of the set temperature range.
• Set the minimum temperature.
• Set the maximum temperature.
• Set temperature display in
Fahrenheit (
o
F) or Celsius (
o
C)
Main
menu
Sub-menu
Alert tones
• Set the parent unit to beep when the
battery is low.
• Set the parent unit to beep when the
link between the parent unit and the
baby unit is lost.
• Set the confirmation tone on or off
when selecting an option in the
menus.
• Set the parent unit to beep when the
baby unit detects sounds while in
Split mode (For VM5463-2 only).
Sound activation - screen and audio
/
Turn on/off sound activation
• Set sound activation on or off.
• When it is on, and the baby unit
detects no sound, the parent unit
screen stays off to save power. Once
a sound is detected, the parent
unit screen and speaker turns on
automatically, and you can see and
hear your baby. The parent unit will
then turn off again after 50 seconds
of no sound detection.
NONO
Note
• When the parent unit screen is off
and it receives alerts, for example,
link lost between parent unit and
baby unit, or battery is low, the
parent unit screen and speaker will
turn on for 10 seconds.
VOX (Voice Activated Alert) Sensitivity
• You can set VOX sensitivity level
to activate parent unit screen and
sound when baby unit detects
sounds that exceed certain levels.
See Sound sensitivity and sound
activation section.
Main menu icons
VM5463
VM5463-2
For operations and guides to help you using your video monitor,
and for latest information and supports, go and check the online
help topics and online FAQs.
Use your smartphone or mobile device to access our online help.
• Go to
https://help.vtechphones.com/vm5463
or
https://help.vtechphones.com/vm5463-2
; OR
• Scan the QR code on the right. Launch the camera app or QR code scanner app
on your smartphone or tablet. Hold the device’s camera up to the QR code and
frame it. Tap the notification to trigger the redirection of the online help.
- If the QR code is not clearly displayed, adjust your camera’s focus by moving
your device closer or further away until it is clear.
You can also call our Customer Support at 1 (800) 595-9511 [in US] or
1 (800) 267-7377 [in Canada] for help.
14
11
12
13
1
2
4
5
6
7
8
3
10
9
Adjust speaker volume
Press
/
to adjust your parent unit
speaker volume.
Zoom
Press to zoom in or out.
Talk to your baby unit
Press and hold TALK and speak to your
parent unit. Your voice is transmitted to
the baby unit. Release TALK when finish
talking and hear your baby again.
Use the menu
Press to enter the menu, choose a menu item,
or save a setting. You can use the parent unit for
advanced settings or operations, such as to play
or stop the baby unit lullaby, or to adjust the baby
unit sound sensitivity.
While in the menu:
• Press or to scroll among the menu options.
• Press to select an item, or to save a setting.
• Press or to scroll among the sub-menus,
or to adjust a setting.
• Press to return to the previous menu options
without changing the current setting.
• Press /EXIT to return to live video.
Basic operation - Parent unit
Turn off the screen
Press and hold LCD ON/OFF to switch off
the screen. You can still hear sound from the
baby unit.
Tip
• Press any keys on the parent unit to turn on
the screen again.
Overview - Parent unit
Overview - Baby unit
6
3
6
3
6
3
Press and hold
Long press
5
3
4
2
1
6
7
8
9
12
10
11
13
1 LED lights
2 LCD display
3 Microphone
4 POWER
5 TALK
6 MENU/SELECT
7 Arrow keys
8
Volume
9 VIEW /LCD ON/OFF
10 /EXIT
11 Antenna
12 RESET
13 Stand
14 Power jack
1 Light sensor
2 Camera lens
3 Microphone
4 Night light
5 On/Off switch
6 On/Off LED light
• On when the baby unit is
turned on and is paired to the
parent unit.
• Flashes when the baby unit is
not being viewed;
or when the link to the parent
unit is lost.
7 Light projection
8 Speaker
9
Projection light on/off key
10
Night light on/off key
11 Power jack
12 Temperature sensor
13 Slots for wall mounting
Need help?
Parent unit icons
Main
menu
Sub-menu
Brightness
• Adjust the parent unit’s LCD
brightness.
Camera settings
Monitoring mode (For VM5463-2 only)
• Single mode
• Split mode
• Patrol mode
Baby unit speaker volume
• Adjust the baby unit’s
speaker volume.
Lullaby
/
Play/Stop lullaby
• Select one of the soothing sounds,
or white noise.
• Select one of the five melodies.
• Play all melodies.
• Set timer to stop playing the
selected melody or soothing sound.
Main
menu
Sub-menu
Night light
/
Turn on/off night light
•
Select one of the night light colors.
• Set timer to turn the night light off.
• Set to auto turn on the night light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Projection light
/
Turn on/off projection light
• Set timer to turn the projection light
off.
• Set to auto turn on the projection light
when baby unit detects sound. It will
turn off after 15 minutes of no sound
detection. You can set VOX sensitivity
level to detect sounds that exceed
certain levels. See Sound sensitivity
and sound activation section.
Temperature
/
• Turn on/off temperature alert tone.
• Set the parent unit to beeps
whenever the room temperature
detected by the baby unit falls
outside of the set temperature range.
• Set the minimum temperature.
• Set the maximum temperature.
• Set temperature display in
Fahrenheit (
o
F) or Celsius (
o
C)
Main
menu
Sub-menu
Alert tones
• Set the parent unit to beep when the
battery is low.
• Set the parent unit to beep when the
link between the parent unit and the
baby unit is lost.
• Set the confirmation tone on or off
when selecting an option in the
menus.
• Set the parent unit to beep when the
baby unit detects sounds while in
Split mode (For VM5463-2 only).
Sound activation - screen and audio
/
Turn on/off sound activation
• Set sound activation on or off.
• When it is on, and the baby unit
detects no sound, the parent unit
screen stays off to save power. Once
a sound is detected, the parent
unit screen and speaker turns on
automatically, and you can see and
hear your baby. The parent unit will
then turn off again after 50 seconds
of no sound detection.
NONO
Note
• When the parent unit screen is off
and it receives alerts, for example,
link lost between parent unit and
baby unit, or battery is low, the
parent unit screen and speaker will
turn on for 10 seconds.
VOX (Voice Activated Alert) Sensitivity
• You can set VOX sensitivity level
to activate parent unit screen and
sound when baby unit detects
sounds that exceed certain levels.
See Sound sensitivity and sound
activation section.
Main menu icons
VM5463
VM5463-2
Night vision
The baby unit has infrared LEDs that
allow you to see your baby clearly at
night or in a dark room. When the baby
unit being viewed detects low light
levels, the infrared LEDs are switched
on automatically. The images from the
baby unit are in black and white, and
appears on the screen.
Notes
• It is normal if you see a short white glare on
your parent unit screen as the baby unit is
adapting to the dark environment.
• When the infrared LEDs are on, the images
are in black and white. This is normal.
Tip
• Depending on the surroundings and other
interfering factors, like lightings, objects,
colors and backgrounds, the video quality
may vary. Adjust the baby unit’s angle or
place the baby unit at a higher level to
prevent glare and blurry display.
For VM5463-2 only
If you are viewing baby unit , the
POWER LED light of baby unit
turns on. As baby unit is not being
viewed, its POWER LED light flashes.
NONO
Note
• If you power on only one baby unit, you may see the parent unit displaying and then , and
the LINK LED light flashing.
• Press VIEW in Single CAM or Patrol mode to switch to the baby unit you have powered on.
Status check - Two baby units
Select Patrol as your monitoring mode to
alternately view the image from baby units
and every 10 seconds.
Change different views - Patrol
10s
Select Split as your monitoring
mode to view the images from both
baby units at once.
Change different views - Split
In Single CAM or
Patrol mode, press
VIEW to switch
between the image
of baby units
and .
Change different views - Single CAM
Sound sensitivity and sound activation
Sound activated screen and audioAdjust sound detection sensitivity
When Sound activation is on, the parent unit screen stays off
to save power when the baby unit detects no sound.
Once the baby unit detects sounds that are louder than the
chosen sound sensitivity level, the parent unit screen and
speaker turn on automatically. The parent unit will then turn
off again after 50 seconds of no sound detection.
Note
• If you have muted the parent unit speaker, only the parent unit
screen will turn on when a sound is detected.
You can turn on Sound activation and adjust
the VOX sensitivity to detect sounds and
turn on the parent unit while its screen is
switched off or dimmed.
When the baby unit detects sounds that
exceed certain levels, the parent unit
screen will turn on and the baby unit starts
transmitting the sounds to the parent unit,
and you can see and hear your baby. If you
have turned on the Night light Auto-on and
the Projection light Auto-on feature, they
will turn on automatically to sooth your baby.
If you turn off Sound activation, you will hear
sounds from the baby unit all the time, even
when the parent unit screen is switched off.
If you have turned on sound alert, the parent
unit beeps when the baby unit detect sounds
while in Split mode (*For VM5463-2 only).
Press VIEW
Parent unit icons (Cont’d)
VOX
Sensitivity
level
Level 5
(Highest)
Level 4
(High)
Level 3
(Medium)
Level 2
(Low)
Level 1
(Lowest)
Description
(Default setting)
The parent unit
screen and
speaker turn
on for very
small sounds,
including
background
noises from your
baby’s room.
The parent
unit screen
and speaker
turn on for soft
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby sleeps
soundly.
The parent unit
screen and
speaker turns
on for loud
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby makes
soft sounds.
The parent
unit screen
and speaker
turn on
for crying
and louder
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
The parent
unit screen
and speaker
turn on for
loud crying
or screeching
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
Status icons
Connection status
• - Strong signal strength.
• - Moderate signal
strength.
• - Low signal strength.
• - Weak signal strength.
Split mode
(*For VM5463-2 only)
Patrol mode
(*For VM5463-2 only)
Current view status
• The baby unit number that is
being viewed when in:
- Single CAM mode.
- Patrol mode
(*For VM5463-2 only).
- Split mode
(*For VM5463-2 only).
Night vision - On
Zoom - On
Lullaby - On
Night light - On
Night light - Auto-on
• Color icon indicates the night
light is set to auto-on, and is
currently turned on by sound
activation.
• Gray icon indicates the night
light is currently off but is set
to auto-on. Night light will turn
on when sound is detected by
the baby unit.
Status icons
Projection light - On
Projection light - Auto on
• Color icon indicates the
projection light is set to auto-
on, and is currently turned on
by sound activation.
• Gray icon indicates the
projection light is currently off
but is set to auto-on. Projection
light will turn on when sound is
detected by the baby unit.
o
F or
o
C
Real-time temperature
• Real-time temperature
detected by the baby unit in
Fahrenheit (
o
F) or Celsius (
o
C)
(e.g. 57
o
F or 14
o
C).
Temperature alert tone - On
9-level sound indicator
•
indicates low sound level
detected by the baby unit.
• indicates moderate
sound level detected by the
baby unit.
• indicates high
sound level detected by the
baby unit.
Mute alert
• Displays when the parent unit
speaker volume is set to off.
• Displays when the parent unit
is talking to the baby unit.
Battery status
•
animates
when the battery is charging.
• - battery is fully charged.
•
- battery is low and needs
charging.
Speaker volume - displays the
parent unit speaker volume level
while adjusting.
Alert icons
• Displays when parent unit’s battery is low and needs charging.
• Displays when connection between parent unit and baby unit is lost.
• Displays when sound is detected at a baby unit when in Split view.
(For VM5463-2 only)
• Baby unit detects temperature reaches or exceeds the set maximum.
• Baby unit detects temperature is at or is lower than the set minimum.
The parent unit display will dim to conserve energy after 10 minutes of inactivity, in
which there is neither key pressed nor alert received from the baby unit.
Dim mode
10 min inactivity
Press any buttons
Optimal position
Projection light
Tip
• The projection light located on the top of the baby unit projects a starry soft night light scene onto
the ceiling with a tilting angle. Adjust your baby unit’s position with the projection light to help
sooth your baby to sleep. For optimal performance, place the baby unit in upright position.
or
Night vision
The baby unit has infrared LEDs that
allow you to see your baby clearly at
night or in a dark room. When the baby
unit being viewed detects low light
levels, the infrared LEDs are switched
on automatically. The images from the
baby unit are in black and white, and
appears on the screen.
Notes
• It is normal if you see a short white glare on
your parent unit screen as the baby unit is
adapting to the dark environment.
• When the infrared LEDs are on, the images
are in black and white. This is normal.
Tip
• Depending on the surroundings and other
interfering factors, like lightings, objects,
colors and backgrounds, the video quality
may vary. Adjust the baby unit’s angle or
place the baby unit at a higher level to
prevent glare and blurry display.
For VM5463-2 only
If you are viewing baby unit , the
POWER LED light of baby unit
turns on. As baby unit is not being
viewed, its POWER LED light flashes.
NONO
Note
• If you power on only one baby unit, you may see the parent unit displaying and then , and
the LINK LED light flashing.
• Press VIEW in Single CAM or Patrol mode to switch to the baby unit you have powered on.
Status check - Two baby units
Select Patrol as your monitoring mode to
alternately view the image from baby units
and every 10 seconds.
Change different views - Patrol
10s
Select Split as your monitoring
mode to view the images from both
baby units at once.
Change different views - Split
In Single CAM or
Patrol mode, press
VIEW to switch
between the image
of baby units
and .
Change different views - Single CAM
Sound sensitivity and sound activation
Sound activated screen and audioAdjust sound detection sensitivity
When Sound activation is on, the parent unit screen stays off
to save power when the baby unit detects no sound.
Once the baby unit detects sounds that are louder than the
chosen sound sensitivity level, the parent unit screen and
speaker turn on automatically. The parent unit will then turn
off again after 50 seconds of no sound detection.
Note
• If you have muted the parent unit speaker, only the parent unit
screen will turn on when a sound is detected.
You can turn on Sound activation and adjust
the VOX sensitivity to detect sounds and
turn on the parent unit while its screen is
switched off or dimmed.
When the baby unit detects sounds that
exceed certain levels, the parent unit
screen will turn on and the baby unit starts
transmitting the sounds to the parent unit,
and you can see and hear your baby. If you
have turned on the Night light Auto-on and
the Projection light Auto-on feature, they
will turn on automatically to sooth your baby.
If you turn off Sound activation, you will hear
sounds from the baby unit all the time, even
when the parent unit screen is switched off.
If you have turned on sound alert, the parent
unit beeps when the baby unit detect sounds
while in Split mode (*For VM5463-2 only).
Press VIEW
Parent unit icons (Cont’d)
VOX
Sensitivity
level
Level 5
(Highest)
Level 4
(High)
Level 3
(Medium)
Level 2
(Low)
Level 1
(Lowest)
Description
(Default setting)
The parent unit
screen and
speaker turn
on for very
small sounds,
including
background
noises from your
baby’s room.
The parent
unit screen
and speaker
turn on for soft
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby sleeps
soundly.
The parent unit
screen and
speaker turns
on for loud
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby makes
soft sounds.
The parent
unit screen
and speaker
turn on
for crying
and louder
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
The parent
unit screen
and speaker
turn on for
loud crying
or screeching
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
Status icons
Connection status
• - Strong signal strength.
• - Moderate signal
strength.
• - Low signal strength.
• - Weak signal strength.
Split mode
(*For VM5463-2 only)
Patrol mode
(*For VM5463-2 only)
Current view status
• The baby unit number that is
being viewed when in:
- Single CAM mode.
- Patrol mode
(*For VM5463-2 only).
- Split mode
(*For VM5463-2 only).
Night vision - On
Zoom - On
Lullaby - On
Night light - On
Night light - Auto-on
• Color icon indicates the night
light is set to auto-on, and is
currently turned on by sound
activation.
• Gray icon indicates the night
light is currently off but is set
to auto-on. Night light will turn
on when sound is detected by
the baby unit.
Status icons
Projection light - On
Projection light - Auto on
• Color icon indicates the
projection light is set to auto-
on, and is currently turned on
by sound activation.
• Gray icon indicates the
projection light is currently off
but is set to auto-on. Projection
light will turn on when sound is
detected by the baby unit.
o
F or
o
C
Real-time temperature
• Real-time temperature
detected by the baby unit in
Fahrenheit (
o
F) or Celsius (
o
C)
(e.g. 57
o
F or 14
o
C).
Temperature alert tone - On
9-level sound indicator
•
indicates low sound level
detected by the baby unit.
• indicates moderate
sound level detected by the
baby unit.
• indicates high
sound level detected by the
baby unit.
Mute alert
• Displays when the parent unit
speaker volume is set to off.
• Displays when the parent unit
is talking to the baby unit.
Battery status
•
animates
when the battery is charging.
• - battery is fully charged.
•
- battery is low and needs
charging.
Speaker volume - displays the
parent unit speaker volume level
while adjusting.
Alert icons
• Displays when parent unit’s battery is low and needs charging.
• Displays when connection between parent unit and baby unit is lost.
• Displays when sound is detected at a baby unit when in Split view.
(For VM5463-2 only)
• Baby unit detects temperature reaches or exceeds the set maximum.
• Baby unit detects temperature is at or is lower than the set minimum.
The parent unit display will dim to conserve energy after 10 minutes of inactivity, in
which there is neither key pressed nor alert received from the baby unit.
Dim mode
10 min inactivity
Press any buttons
Optimal position
Projection light
Tip
• The projection light located on the top of the baby unit projects a starry soft night light scene onto
the ceiling with a tilting angle. Adjust your baby unit’s position with the projection light to help
sooth your baby to sleep. For optimal performance, place the baby unit in upright position.
or
Night vision
The baby unit has infrared LEDs that
allow you to see your baby clearly at
night or in a dark room. When the baby
unit being viewed detects low light
levels, the infrared LEDs are switched
on automatically. The images from the
baby unit are in black and white, and
appears on the screen.
Notes
• It is normal if you see a short white glare on
your parent unit screen as the baby unit is
adapting to the dark environment.
• When the infrared LEDs are on, the images
are in black and white. This is normal.
Tip
• Depending on the surroundings and other
interfering factors, like lightings, objects,
colors and backgrounds, the video quality
may vary. Adjust the baby unit’s angle or
place the baby unit at a higher level to
prevent glare and blurry display.
For VM5463-2 only
If you are viewing baby unit , the
POWER LED light of baby unit
turns on. As baby unit is not being
viewed, its POWER LED light flashes.
NONO
Note
• If you power on only one baby unit, you may see the parent unit displaying and then , and
the LINK LED light flashing.
• Press VIEW in Single CAM or Patrol mode to switch to the baby unit you have powered on.
Status check - Two baby units
Select Patrol as your monitoring mode to
alternately view the image from baby units
and every 10 seconds.
Change different views - Patrol
10s
Select Split as your monitoring
mode to view the images from both
baby units at once.
Change different views - Split
In Single CAM or
Patrol mode, press
VIEW to switch
between the image
of baby units
and .
Change different views - Single CAM
Sound sensitivity and sound activation
Sound activated screen and audioAdjust sound detection sensitivity
When Sound activation is on, the parent unit screen stays off
to save power when the baby unit detects no sound.
Once the baby unit detects sounds that are louder than the
chosen sound sensitivity level, the parent unit screen and
speaker turn on automatically. The parent unit will then turn
off again after 50 seconds of no sound detection.
Note
• If you have muted the parent unit speaker, only the parent unit
screen will turn on when a sound is detected.
You can turn on Sound activation and adjust
the VOX sensitivity to detect sounds and
turn on the parent unit while its screen is
switched off or dimmed.
When the baby unit detects sounds that
exceed certain levels, the parent unit
screen will turn on and the baby unit starts
transmitting the sounds to the parent unit,
and you can see and hear your baby. If you
have turned on the Night light Auto-on and
the Projection light Auto-on feature, they
will turn on automatically to sooth your baby.
If you turn off Sound activation, you will hear
sounds from the baby unit all the time, even
when the parent unit screen is switched off.
If you have turned on sound alert, the parent
unit beeps when the baby unit detect sounds
while in Split mode (*For VM5463-2 only).
Press VIEW
Parent unit icons (Cont’d)
VOX
Sensitivity
level
Level 5
(Highest)
Level 4
(High)
Level 3
(Medium)
Level 2
(Low)
Level 1
(Lowest)
Description
(Default setting)
The parent unit
screen and
speaker turn
on for very
small sounds,
including
background
noises from your
baby’s room.
The parent
unit screen
and speaker
turn on for soft
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby sleeps
soundly.
The parent unit
screen and
speaker turns
on for loud
babbling and
louder sounds
from your baby.
The parent unit
remains quiet
when your
baby makes
soft sounds.
The parent
unit screen
and speaker
turn on
for crying
and louder
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
The parent
unit screen
and speaker
turn on for
loud crying
or screeching
sounds from
your baby.
The parent
unit remains
quiet when
your baby
makes soft
sounds.
Status icons
Connection status
• - Strong signal strength.
• - Moderate signal
strength.
• - Low signal strength.
• - Weak signal strength.
Split mode
(*For VM5463-2 only)
Patrol mode
(*For VM5463-2 only)
Current view status
• The baby unit number that is
being viewed when in:
- Single CAM mode.
- Patrol mode
(*For VM5463-2 only).
- Split mode
(*For VM5463-2 only).
Night vision - On
Zoom - On
Lullaby - On
Night light - On
Night light - Auto-on
• Color icon indicates the night
light is set to auto-on, and is
currently turned on by sound
activation.
• Gray icon indicates the night
light is currently off but is set
to auto-on. Night light will turn
on when sound is detected by
the baby unit.
Status icons
Projection light - On
Projection light - Auto on
• Color icon indicates the
projection light is set to auto-
on, and is currently turned on
by sound activation.
• Gray icon indicates the
projection light is currently off
but is set to auto-on. Projection
light will turn on when sound is
detected by the baby unit.
o
F or
o
C
Real-time temperature
• Real-time temperature
detected by the baby unit in
Fahrenheit (
o
F) or Celsius (
o
C)
(e.g. 57
o
F or 14
o
C).
Temperature alert tone - On
9-level sound indicator
•
indicates low sound level
detected by the baby unit.
• indicates moderate
sound level detected by the
baby unit.
• indicates high
sound level detected by the
baby unit.
Mute alert
• Displays when the parent unit
speaker volume is set to off.
• Displays when the parent unit
is talking to the baby unit.
Battery status
•
animates
when the battery is charging.
• - battery is fully charged.
•
- battery is low and needs
charging.
Speaker volume - displays the
parent unit speaker volume level
while adjusting.
Alert icons
• Displays when parent unit’s battery is low and needs charging.
• Displays when connection between parent unit and baby unit is lost.
• Displays when sound is detected at a baby unit when in Split view.
(For VM5463-2 only)
• Baby unit detects temperature reaches or exceeds the set maximum.
• Baby unit detects temperature is at or is lower than the set minimum.
The parent unit display will dim to conserve energy after 10 minutes of inactivity, in
which there is neither key pressed nor alert received from the baby unit.
Dim mode
10 min inactivity
Press any buttons
Optimal position
Projection light
Tip
• The projection light located on the top of the baby unit projects a starry soft night light scene onto
the ceiling with a tilting angle. Adjust your baby unit’s position with the projection light to help
sooth your baby to sleep. For optimal performance, place the baby unit in upright position.
or
Mount the baby unit on dry wall (optional)
The RBRC
®
seal on the Ni-MH battery indicates that VTech Communications, Inc. is voluntarily participating
in an industry program to collect and recycle these batteri es at the end of their useful lives, when taken out
of service within the United States and Canada.
The RBRC
®
program provides a convenient alternative to placing used Ni-MH batteries into the trash or
municipal waste, which may be illegal in your area.
VTech’s participation in RBRC
®
makes it easy for you to drop off the spent battery at local retailers participating in the RBRC
®
program or at authorized VTech product service centers. Please call
1 (800) 8 BATTERY
®
for information on Ni-MH battery recycling and dis posal bans/restrictions in your area. VTech’s
involvement in this program is par t of its commitment to protecting our environment and conserving natural resources.
RBRC® and 1 (800) 8 BATTERY® are registered trademarks of the Rechargeable Battery Recycling Corporation.
Mesures de sécurité importantes
La plaque signalétique appliquée est située au bas du socle
de l’unité du bébé.
Lorsque vous utilisez votre appareil, vous devriez toujours suivre
certaines mesures de précaution de base afin de réduire les
risques d’incendie, d’électrocution et de blessures corporelles,
dont ceux qui suivent :
1. Observez toutes les instructions et mises en garde inscrites
sur l’appareil.
2. L’installation par un adulte est requise.
3. MISE EN GARDE: N’installez pas l’unité du bébé à une
hauteur supérieure à 2 mètres.
4. Ce produit ne remplace pas la surveillance adulte du
nourrisson. La supervision du nourrisson est la responsabilité
du parent ou de la personne qui s’occupe de l’enfant. Ce
produit pourrait cesser de fonctionner et, par conséquent,
vous ne devriez pas présumer qu’il continuera de fonctionner
correctement pendant une période de temps donnée. De
plus, il ne s’agit pas d’un instrument médical et ne devrait pas
être utilisé comme tel. Ce produit est destiné à vous aider à
superviser votre bébé.
5. N’utilisez pas cet appareil près de l’eau ni de toute autre
source d’humidité, par exemple, près d’une baignoire,
cuve à lessive, évier de cuisine, dans un sous-sol humide
ni près d’une piscine, dans un soussol humide ou une
douche.
6.
MISE EN GARDE: Utilisez uniquement les piles
fournies. Il existe un risque d’explosion si un autre type de
batterie est utilisé pour l’unité Parents. N’incinérez pas les
piles. Celles-ci risqueraient d’exploser. Jetez les piles usées
selon les renseignements suivant le sceau du RBRC
®
.
7. N’utilisez que les adaptateurs inclus avec ce produit.
L’utilisation d’un adaptateur dont la polarité ou la tension
serait inadéquate risque d’endommager sérieusement le
produit et mettre votre sécurité en péril.
Adaptateur de l’unité du bébé : Sortie : 5V CC 1A
Adaptateur de l’unité du parent : Sortie : 5V CC 1A
8. Lorsqu’ils sont branchés dans une prise de courant, les
adaptateurs secteur ont été conçus pour être orientés
correctement, soit à la verticale ou au plancher. Les broches
n’ont pas été conçues pour supporter le poids du bloc
d’alimentation et le maintenir en place si celuici est branché
dans une prise au plafond, sous une table ou dans un
meuble.
9. Pour les PRODUITS À BRANCHER À UNE PRISE DE
COURANT, la prise de courant doit être installée près du
produit, afin d’assurer une accessibilité sécuritaire à la prise
de courant.
10. Débranchez ce produit de la prise de courant avant de
procéder au nettoyage. N’utilisez pas de nettoyants en
aérosols. Utilisez un chiffon humide pour le nettoyer.
11. Débranchez les cordons d’alimentation avant de remplacer
le bloc-piles.
12. Ne coupez pas les cordons d’alimentation pour remplacer
les fiches, car ceci peut présenter un danger potentiel.
13. Ne laissez aucun objet reposer ni appuyer sur le cordon
d’alimentation. N’installez pas cet appareil dans un endroit
où l’on risque d’écraser le cordon d’alimentation ou de le
piétiner.
14. Ne faites fonctionner cet appareil qu’avec le type
d’alimentation indiqué sur l’étiquette. Si vous ne connaissez
pas le type d’alimentation que vous possédez à votre
domicile, consultez votre marchand ou votre compagnie
locale d’électricité.
15. Ne surchargez pas les prises de courant murales ni les
rallonges électriques.
16. Ne placez pas cet appareil sur un chariot, meuble, trépied,
support de montage ni table chancelants.
17. Les trous et ouvertures du boîtier, situés à l’arrière de
l’appareil ou sous celui-ci, servent à aérer l’appareil.
Pour l’empêcher de surchauffer, ne bloquez sous aucun
prétexte ces ouvertures et n’empêchez pas l’aération
adéquate de l’appareil en le plaçant sur un lit, divan,
tapis ou toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une source de
chaleur ou d’un calorifère. De plus, ne placez pas l’appareil
dans un endroit avant de vous assurer qu’il y ait une bonne
circulation d’air.
18. N’enfoncez jamais d’objets à travers les ouvertures de
cet appareil, car ils pourraient entrer en contact avec
des points de tension dangereux ou causer des courts-
circuits qui peuvent dégénérer en incendies ou en risques
d’électrocution. Ne renversez jamais de liquide dans ce
produit.
19. Afin de réduire les risques d’électrocution, ne démontez
pas cet appareil, mais apportez-le dans un centre de service
autorisé. L’ouverture du boîtier ou le retrait de toutes pièces
que contient cet appareil, à l’exception de l’accès autorisé
à certaines portes ou ouvertures, risque de vous exposer à
des points de tension dangereux ou d’autres dangers. Un
remontage incorrect peut par la suite présenter des risques
d’électrocution.
20. Vous devriez tester la réception chaque fois que vous
mettez l’appareil en fonction.
21. Examinez les composantes afin de vérifier si celles-ci ne
sont pas endommagées.
22. Soyez avisé de la perte de la confidentialité lorsque vous
utilisez les ondes publiques. Les conversations peuvent
être entendues par d’autres moniteurs de bébé, des
téléphones sans fil, des scanneurs, etc.
23. Les enfants devraient être supervisés afin de vous assurer
qu’ils ne jouent pas avec l’appareil.
24. Le produit n’est pas conçu pour être utilisé par des
personnes (incluant des enfants) aux capacités physiques,
sensorielles ou mentales réduites ou qui manquent
d’expérience et de connaissances, à moins qu’on leur
ait donné suffisamment de supervision ou d’instructions
relativement à l’utilisation de l’appareil par une personne
responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
1. Utilisez et entreposez le produit à une température entre
0˚ C (32˚F) et 40˚C (104˚ F).
2. N’exposez pas cet appareil à des froids ou des chaleurs
extrêmes, ainsi qu’à la lumière directe du soleil. Ne
l’installez pas près d’une source de
chauffage.
3. Le bloc-piles ne doit pas être exposé à la
chaleur excessive telle que la lumière du
soleil ou au feu.
4. Assurez-vous que le moniteur et le cordon
de l’adaptateur sont toujours hors de portée des enfants,
àau moins 1 mètre (3 pieds) de l’enfant ou du berceau, pour
éviter tout risque de strangulation.
5. Ne jamais placer le moniteur à l’intérieur du berceau
ou du parc de bébé. Ne jamais couvrir le moniteur ou
l’unité (s) portative avec un article tel une serviette ou une
couverture.
6. D’autres équipements électroniques peuvent produire des
interférences sur votre moniteur vidéo et audio. Tentez
d’installer votre moniteur vidéo ou audio à l’écart des
appareils électroniques tels que des routeurs sans fil, radios,
téléphones cellulaires, interphones, moniteurs, téléphones,
ordinateurs personnels, électroménagers et téléphones
sans fil.
Stimulateurs cardiaques implantés dans l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux dispositifs
numériques sans fil) :
L’organisme ‘Wireless Technology Research, LLC (WTR)’, une
firme de recherche indépendante, a mené une évaluation
pluridisciplinaire des interférences entre les téléphones sans
fil portatifs et les stimulateurs cardiaques implantés dans
l’organisme. Appuyée par l’Administration des aliments et
drogues (FDA) des États-Unis, la firme WTR recommande aux
médecins:
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil à au moins six
pouces du simulateur cardiaque.
• Ils ne doivent PAS placer le téléphone sans fil directement
sur le stimulateur cardiaque, tel que dans une poche de
chemise, lorsque celui-ci est en marche.
L’étude effectuée par l’organisme WRS n’a pas identifié de
risque pour les détenteurs de simulateurs cardiaques causés par
les gens qui utilisent dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes les normes se
rapportant aux champs électromagnétiques (EMF) standard. Si
vous le manipulez correctement en suivant les instructions de ce
guide, son utilisation sera sécuritaire pendant de nombreuses
années, selon les meilleures évidences scientifiques dont nous
disposons aujourd’hui.
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized
service representative will repair or replace at VTech’s option,
without charge, a Materially Defective Product. If we repair
the Product, we may use new or refurbished replacement
parts. If we choose to replace the Product, we may replace
it with a new or refurbished Product of the same or
similar design. We will retain defective parts, modules,
or equipment. Repair or replacement of the Product, at
VTech’s option, is your exclusive remedy. VTech will return
the repaired or replacement Products to you in working
condition. You should expect the repair or replacement to
take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for
ONE (1) YEAR from the date of purchase. If VTech repairs or
replaces a Materially Defective Product under the terms of
this limited warranty, this limited warranty also applies to the
repaired or replacement Product for a period of either (a)
90 days from the date the repaired or replacement Product
is shipped to you or (b) the time remaining on the original
one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 below); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our
website at www.vtechphones.com or call 1 (800) 595-9511.
In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return repaired or replaced Product under this limited
warranty. Transportation, delivery or handling charges are
prepaid. VTech assumes no risk for damage or loss of the
Product in transit. If the Product failure is not covered by
this limited warranty, or proof of purchase does not meet
the terms of this limited warranty, VTech will notify you and
will request that you authorize the cost of repair prior to any
further repair activity. You must pay for the cost of repair and
return shipping costs for the repair of Products that are not
covered by this limited warranty.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the
Product. There are no other express warranties. No one is
authorized to make modifications to this limited warranty and
you should not rely on any such modification. State/Provincial
Law Rights: This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state
or province to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof
of purchase.
This baby monitor meets the California Energy Commission (CEC) regulations for energy consumption. Your baby monitor
is set up to comply with the energy-conserving standards right out of the box. Follow the instructions to install and charge
the battery. The CEC battery charging testing mode is activated while charging. Even if the parent unit is paired to baby
units, the CEC battery charging testing mode is ac tivated while it is powered off and charging.
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed
by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with
the FCC criteria. The baby unit shall be installed and used such that parts of all persons’ body are maintained at a distance of
approximately 8 in (20 cm) or more. The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your
face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that may cause undesired operation of the
device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were
met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
RF radiation exposure statement
The baby unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The baby unit should
be installed and operated with a minimum distance of 8 in (20 cm) between the baby unit and all persons’ body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter. This equipment complies also with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
The RBRC® seal For cETL compliance only Limited warranty
California Energy Commission battery
charging testing mode
FCC and IC regulations
1. Place the wall mount bracket on a
wall and then use a pencil to mark
two holes in parallel. Remove the
wall mount bracket and drill two
holes in the wall (7/32 inch drill bit).
NONO
Notes
• Check for reception strength and
camera angle before drilling the holes.
• The types of screws and anchors you
need depend on the composition of
the wall. You may need to purchase the
screws and anchors separately to mount
your camera units.
2. If you drill the holes into a stud, go
to step 3.
• If you drill the holes into an
object other than a stud, insert
the wall anchors into the holes.
Tap gently on the ends with a
hammer until the wall anchors
are flush with the wall.
3. Align the wall mount bracket and screws with
the holes in the wall as shown. Tighten the screw
in the middle hole first, so that the wall mount
bracket position is fixed. You can tighten the
other screw in the top hole.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Place the camera unit on the wall
mount bracket, and then slide it
forward until it locks into place. Align
the holes on the wall mount bracket
with the screws on the wall, and slide
the wall mount bracket down until it
locks into place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the
joint and secure the angle.
OR
4. Place the camera unit on the wall mount
bracket, and then slide it forward until
it locks into place. Connect the power
adapter to the camera unit and a power
supply not controlled by a wall switch.
2
1
Mount the baby unit on dry wall (optional)
The RBRC
®
seal on the Ni-MH battery indicates that VTech Communications, Inc. is voluntarily participating
in an industry program to collect and recycle these batteri es at the end of their useful lives, when taken out
of service within the United States and Canada.
The RBRC
®
program provides a convenient alternative to placing used Ni-MH batteries into the trash or
municipal waste, which may be illegal in your area.
VTech’s participation in RBRC
®
makes it easy for you to drop off the spent battery at local retailers participating in the RBRC
®
program or at authorized VTech product service centers. Please call
1 (800) 8 BATTERY
®
for information on Ni-MH battery recycling and dis posal bans/restrictions in your area. VTech’s
involvement in this program is par t of its commitment to protecting our environment and conserving natural resources.
RBRC® and 1 (800) 8 BATTERY® are registered trademarks of the Rechargeable Battery Recycling Corporation.
Mesures de sécurité importantes
La plaque signalétique appliquée est située au bas du socle
de l’unité du bébé.
Lorsque vous utilisez votre appareil, vous devriez toujours suivre
certaines mesures de précaution de base afin de réduire les
risques d’incendie, d’électrocution et de blessures corporelles,
dont ceux qui suivent :
1. Observez toutes les instructions et mises en garde inscrites
sur l’appareil.
2. L’installation par un adulte est requise.
3. MISE EN GARDE: N’installez pas l’unité du bébé à une
hauteur supérieure à 2 mètres.
4. Ce produit ne remplace pas la surveillance adulte du
nourrisson. La supervision du nourrisson est la responsabilité
du parent ou de la personne qui s’occupe de l’enfant. Ce
produit pourrait cesser de fonctionner et, par conséquent,
vous ne devriez pas présumer qu’il continuera de fonctionner
correctement pendant une période de temps donnée. De
plus, il ne s’agit pas d’un instrument médical et ne devrait pas
être utilisé comme tel. Ce produit est destiné à vous aider à
superviser votre bébé.
5. N’utilisez pas cet appareil près de l’eau ni de toute autre
source d’humidité, par exemple, près d’une baignoire,
cuve à lessive, évier de cuisine, dans un sous-sol humide
ni près d’une piscine, dans un soussol humide ou une
douche.
6.
MISE EN GARDE: Utilisez uniquement les piles
fournies. Il existe un risque d’explosion si un autre type de
batterie est utilisé pour l’unité Parents. N’incinérez pas les
piles. Celles-ci risqueraient d’exploser. Jetez les piles usées
selon les renseignements suivant le sceau du RBRC
®
.
7. N’utilisez que les adaptateurs inclus avec ce produit.
L’utilisation d’un adaptateur dont la polarité ou la tension
serait inadéquate risque d’endommager sérieusement le
produit et mettre votre sécurité en péril.
Adaptateur de l’unité du bébé : Sortie : 5V CC 1A
Adaptateur de l’unité du parent : Sortie : 5V CC 1A
8. Lorsqu’ils sont branchés dans une prise de courant, les
adaptateurs secteur ont été conçus pour être orientés
correctement, soit à la verticale ou au plancher. Les broches
n’ont pas été conçues pour supporter le poids du bloc
d’alimentation et le maintenir en place si celuici est branché
dans une prise au plafond, sous une table ou dans un
meuble.
9. Pour les PRODUITS À BRANCHER À UNE PRISE DE
COURANT, la prise de courant doit être installée près du
produit, afin d’assurer une accessibilité sécuritaire à la prise
de courant.
10. Débranchez ce produit de la prise de courant avant de
procéder au nettoyage. N’utilisez pas de nettoyants en
aérosols. Utilisez un chiffon humide pour le nettoyer.
11. Débranchez les cordons d’alimentation avant de remplacer
le bloc-piles.
12. Ne coupez pas les cordons d’alimentation pour remplacer
les fiches, car ceci peut présenter un danger potentiel.
13. Ne laissez aucun objet reposer ni appuyer sur le cordon
d’alimentation. N’installez pas cet appareil dans un endroit
où l’on risque d’écraser le cordon d’alimentation ou de le
piétiner.
14. Ne faites fonctionner cet appareil qu’avec le type
d’alimentation indiqué sur l’étiquette. Si vous ne connaissez
pas le type d’alimentation que vous possédez à votre
domicile, consultez votre marchand ou votre compagnie
locale d’électricité.
15. Ne surchargez pas les prises de courant murales ni les
rallonges électriques.
16. Ne placez pas cet appareil sur un chariot, meuble, trépied,
support de montage ni table chancelants.
17. Les trous et ouvertures du boîtier, situés à l’arrière de
l’appareil ou sous celui-ci, servent à aérer l’appareil.
Pour l’empêcher de surchauffer, ne bloquez sous aucun
prétexte ces ouvertures et n’empêchez pas l’aération
adéquate de l’appareil en le plaçant sur un lit, divan,
tapis ou toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une source de
chaleur ou d’un calorifère. De plus, ne placez pas l’appareil
dans un endroit avant de vous assurer qu’il y ait une bonne
circulation d’air.
18. N’enfoncez jamais d’objets à travers les ouvertures de
cet appareil, car ils pourraient entrer en contact avec
des points de tension dangereux ou causer des courts-
circuits qui peuvent dégénérer en incendies ou en risques
d’électrocution. Ne renversez jamais de liquide dans ce
produit.
19. Afin de réduire les risques d’électrocution, ne démontez
pas cet appareil, mais apportez-le dans un centre de service
autorisé. L’ouverture du boîtier ou le retrait de toutes pièces
que contient cet appareil, à l’exception de l’accès autorisé
à certaines portes ou ouvertures, risque de vous exposer à
des points de tension dangereux ou d’autres dangers. Un
remontage incorrect peut par la suite présenter des risques
d’électrocution.
20. Vous devriez tester la réception chaque fois que vous
mettez l’appareil en fonction.
21. Examinez les composantes afin de vérifier si celles-ci ne
sont pas endommagées.
22. Soyez avisé de la perte de la confidentialité lorsque vous
utilisez les ondes publiques. Les conversations peuvent
être entendues par d’autres moniteurs de bébé, des
téléphones sans fil, des scanneurs, etc.
23. Les enfants devraient être supervisés afin de vous assurer
qu’ils ne jouent pas avec l’appareil.
24. Le produit n’est pas conçu pour être utilisé par des
personnes (incluant des enfants) aux capacités physiques,
sensorielles ou mentales réduites ou qui manquent
d’expérience et de connaissances, à moins qu’on leur
ait donné suffisamment de supervision ou d’instructions
relativement à l’utilisation de l’appareil par une personne
responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
1. Utilisez et entreposez le produit à une température entre
0˚ C (32˚F) et 40˚C (104˚ F).
2. N’exposez pas cet appareil à des froids ou des chaleurs
extrêmes, ainsi qu’à la lumière directe du soleil. Ne
l’installez pas près d’une source de
chauffage.
3. Le bloc-piles ne doit pas être exposé à la
chaleur excessive telle que la lumière du
soleil ou au feu.
4. Assurez-vous que le moniteur et le cordon
de l’adaptateur sont toujours hors de portée des enfants,
àau moins 1 mètre (3 pieds) de l’enfant ou du berceau, pour
éviter tout risque de strangulation.
5. Ne jamais placer le moniteur à l’intérieur du berceau
ou du parc de bébé. Ne jamais couvrir le moniteur ou
l’unité (s) portative avec un article tel une serviette ou une
couverture.
6. D’autres équipements électroniques peuvent produire des
interférences sur votre moniteur vidéo et audio. Tentez
d’installer votre moniteur vidéo ou audio à l’écart des
appareils électroniques tels que des routeurs sans fil, radios,
téléphones cellulaires, interphones, moniteurs, téléphones,
ordinateurs personnels, électroménagers et téléphones
sans fil.
Stimulateurs cardiaques implantés dans l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux dispositifs
numériques sans fil) :
L’organisme ‘Wireless Technology Research, LLC (WTR)’, une
firme de recherche indépendante, a mené une évaluation
pluridisciplinaire des interférences entre les téléphones sans
fil portatifs et les stimulateurs cardiaques implantés dans
l’organisme. Appuyée par l’Administration des aliments et
drogues (FDA) des États-Unis, la firme WTR recommande aux
médecins:
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil à au moins six
pouces du simulateur cardiaque.
• Ils ne doivent PAS placer le téléphone sans fil directement
sur le stimulateur cardiaque, tel que dans une poche de
chemise, lorsque celui-ci est en marche.
L’étude effectuée par l’organisme WRS n’a pas identifié de
risque pour les détenteurs de simulateurs cardiaques causés par
les gens qui utilisent dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes les normes se
rapportant aux champs électromagnétiques (EMF) standard. Si
vous le manipulez correctement en suivant les instructions de ce
guide, son utilisation sera sécuritaire pendant de nombreuses
années, selon les meilleures évidences scientifiques dont nous
disposons aujourd’hui.
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized
service representative will repair or replace at VTech’s option,
without charge, a Materially Defective Product. If we repair
the Product, we may use new or refurbished replacement
parts. If we choose to replace the Product, we may replace
it with a new or refurbished Product of the same or
similar design. We will retain defective parts, modules,
or equipment. Repair or replacement of the Product, at
VTech’s option, is your exclusive remedy. VTech will return
the repaired or replacement Products to you in working
condition. You should expect the repair or replacement to
take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for
ONE (1) YEAR from the date of purchase. If VTech repairs or
replaces a Materially Defective Product under the terms of
this limited warranty, this limited warranty also applies to the
repaired or replacement Product for a period of either (a)
90 days from the date the repaired or replacement Product
is shipped to you or (b) the time remaining on the original
one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 below); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our
website at www.vtechphones.com or call 1 (800) 595-9511.
In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return repaired or replaced Product under this limited
warranty. Transportation, delivery or handling charges are
prepaid. VTech assumes no risk for damage or loss of the
Product in transit. If the Product failure is not covered by
this limited warranty, or proof of purchase does not meet
the terms of this limited warranty, VTech will notify you and
will request that you authorize the cost of repair prior to any
further repair activity. You must pay for the cost of repair and
return shipping costs for the repair of Products that are not
covered by this limited warranty.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the
Product. There are no other express warranties. No one is
authorized to make modifications to this limited warranty and
you should not rely on any such modification. State/Provincial
Law Rights: This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state
or province to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof
of purchase.
This baby monitor meets the California Energy Commission (CEC) regulations for energy consumption. Your baby monitor
is set up to comply with the energy-conserving standards right out of the box. Follow the instructions to install and charge
the battery. The CEC battery charging testing mode is activated while charging. Even if the parent unit is paired to baby
units, the CEC battery charging testing mode is ac tivated while it is powered off and charging.
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed
by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with
the FCC criteria. The baby unit shall be installed and used such that parts of all persons’ body are maintained at a distance of
approximately 8 in (20 cm) or more. The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your
face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that may cause undesired operation of the
device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were
met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
RF radiation exposure statement
The baby unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The baby unit should
be installed and operated with a minimum distance of 8 in (20 cm) between the baby unit and all persons’ body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter. This equipment complies also with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
The RBRC® seal For cETL compliance only Limited warranty
California Energy Commission battery
charging testing mode
FCC and IC regulations
1. Place the wall mount bracket on a
wall and then use a pencil to mark
two holes in parallel. Remove the
wall mount bracket and drill two
holes in the wall (7/32 inch drill bit).
NONO
Notes
• Check for reception strength and
camera angle before drilling the holes.
• The types of screws and anchors you
need depend on the composition of
the wall. You may need to purchase the
screws and anchors separately to mount
your camera units.
2. If you drill the holes into a stud, go
to step 3.
• If you drill the holes into an
object other than a stud, insert
the wall anchors into the holes.
Tap gently on the ends with a
hammer until the wall anchors
are flush with the wall.
3. Align the wall mount bracket and screws with
the holes in the wall as shown. Tighten the screw
in the middle hole first, so that the wall mount
bracket position is fixed. You can tighten the
other screw in the top hole.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Place the camera unit on the wall
mount bracket, and then slide it
forward until it locks into place. Align
the holes on the wall mount bracket
with the screws on the wall, and slide
the wall mount bracket down until it
locks into place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the
joint and secure the angle.
OR
4. Place the camera unit on the wall mount
bracket, and then slide it forward until
it locks into place. Connect the power
adapter to the camera unit and a power
supply not controlled by a wall switch.
2
1
Mount the baby unit on dry wall (optional)
The RBRC
®
seal on the Ni-MH battery indicates that VTech Communications, Inc. is voluntarily participating
in an industry program to collect and recycle these batteri es at the end of their useful lives, when taken out
of service within the United States and Canada.
The RBRC
®
program provides a convenient alternative to placing used Ni-MH batteries into the trash or
municipal waste, which may be illegal in your area.
VTech’s participation in RBRC
®
makes it easy for you to drop off the spent battery at local retailers participating in the RBRC
®
program or at authorized VTech product service centers. Please call
1 (800) 8 BATTERY
®
for information on Ni-MH battery recycling and dis posal bans/restrictions in your area. VTech’s
involvement in this program is par t of its commitment to protecting our environment and conserving natural resources.
RBRC® and 1 (800) 8 BATTERY® are registered trademarks of the Rechargeable Battery Recycling Corporation.
Mesures de sécurité importantes
La plaque signalétique appliquée est située au bas du socle
de l’unité du bébé.
Lorsque vous utilisez votre appareil, vous devriez toujours suivre
certaines mesures de précaution de base afin de réduire les
risques d’incendie, d’électrocution et de blessures corporelles,
dont ceux qui suivent :
1. Observez toutes les instructions et mises en garde inscrites
sur l’appareil.
2. L’installation par un adulte est requise.
3. MISE EN GARDE: N’installez pas l’unité du bébé à une
hauteur supérieure à 2 mètres.
4. Ce produit ne remplace pas la surveillance adulte du
nourrisson. La supervision du nourrisson est la responsabilité
du parent ou de la personne qui s’occupe de l’enfant. Ce
produit pourrait cesser de fonctionner et, par conséquent,
vous ne devriez pas présumer qu’il continuera de fonctionner
correctement pendant une période de temps donnée. De
plus, il ne s’agit pas d’un instrument médical et ne devrait pas
être utilisé comme tel. Ce produit est destiné à vous aider à
superviser votre bébé.
5. N’utilisez pas cet appareil près de l’eau ni de toute autre
source d’humidité, par exemple, près d’une baignoire,
cuve à lessive, évier de cuisine, dans un sous-sol humide
ni près d’une piscine, dans un soussol humide ou une
douche.
6.
MISE EN GARDE: Utilisez uniquement les piles
fournies. Il existe un risque d’explosion si un autre type de
batterie est utilisé pour l’unité Parents. N’incinérez pas les
piles. Celles-ci risqueraient d’exploser. Jetez les piles usées
selon les renseignements suivant le sceau du RBRC
®
.
7. N’utilisez que les adaptateurs inclus avec ce produit.
L’utilisation d’un adaptateur dont la polarité ou la tension
serait inadéquate risque d’endommager sérieusement le
produit et mettre votre sécurité en péril.
Adaptateur de l’unité du bébé : Sortie : 5V CC 1A
Adaptateur de l’unité du parent : Sortie : 5V CC 1A
8. Lorsqu’ils sont branchés dans une prise de courant, les
adaptateurs secteur ont été conçus pour être orientés
correctement, soit à la verticale ou au plancher. Les broches
n’ont pas été conçues pour supporter le poids du bloc
d’alimentation et le maintenir en place si celuici est branché
dans une prise au plafond, sous une table ou dans un
meuble.
9. Pour les PRODUITS À BRANCHER À UNE PRISE DE
COURANT, la prise de courant doit être installée près du
produit, afin d’assurer une accessibilité sécuritaire à la prise
de courant.
10. Débranchez ce produit de la prise de courant avant de
procéder au nettoyage. N’utilisez pas de nettoyants en
aérosols. Utilisez un chiffon humide pour le nettoyer.
11. Débranchez les cordons d’alimentation avant de remplacer
le bloc-piles.
12. Ne coupez pas les cordons d’alimentation pour remplacer
les fiches, car ceci peut présenter un danger potentiel.
13. Ne laissez aucun objet reposer ni appuyer sur le cordon
d’alimentation. N’installez pas cet appareil dans un endroit
où l’on risque d’écraser le cordon d’alimentation ou de le
piétiner.
14. Ne faites fonctionner cet appareil qu’avec le type
d’alimentation indiqué sur l’étiquette. Si vous ne connaissez
pas le type d’alimentation que vous possédez à votre
domicile, consultez votre marchand ou votre compagnie
locale d’électricité.
15. Ne surchargez pas les prises de courant murales ni les
rallonges électriques.
16. Ne placez pas cet appareil sur un chariot, meuble, trépied,
support de montage ni table chancelants.
17. Les trous et ouvertures du boîtier, situés à l’arrière de
l’appareil ou sous celui-ci, servent à aérer l’appareil.
Pour l’empêcher de surchauffer, ne bloquez sous aucun
prétexte ces ouvertures et n’empêchez pas l’aération
adéquate de l’appareil en le plaçant sur un lit, divan,
tapis ou toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une source de
chaleur ou d’un calorifère. De plus, ne placez pas l’appareil
dans un endroit avant de vous assurer qu’il y ait une bonne
circulation d’air.
18. N’enfoncez jamais d’objets à travers les ouvertures de
cet appareil, car ils pourraient entrer en contact avec
des points de tension dangereux ou causer des courts-
circuits qui peuvent dégénérer en incendies ou en risques
d’électrocution. Ne renversez jamais de liquide dans ce
produit.
19. Afin de réduire les risques d’électrocution, ne démontez
pas cet appareil, mais apportez-le dans un centre de service
autorisé. L’ouverture du boîtier ou le retrait de toutes pièces
que contient cet appareil, à l’exception de l’accès autorisé
à certaines portes ou ouvertures, risque de vous exposer à
des points de tension dangereux ou d’autres dangers. Un
remontage incorrect peut par la suite présenter des risques
d’électrocution.
20. Vous devriez tester la réception chaque fois que vous
mettez l’appareil en fonction.
21. Examinez les composantes afin de vérifier si celles-ci ne
sont pas endommagées.
22. Soyez avisé de la perte de la confidentialité lorsque vous
utilisez les ondes publiques. Les conversations peuvent
être entendues par d’autres moniteurs de bébé, des
téléphones sans fil, des scanneurs, etc.
23. Les enfants devraient être supervisés afin de vous assurer
qu’ils ne jouent pas avec l’appareil.
24. Le produit n’est pas conçu pour être utilisé par des
personnes (incluant des enfants) aux capacités physiques,
sensorielles ou mentales réduites ou qui manquent
d’expérience et de connaissances, à moins qu’on leur
ait donné suffisamment de supervision ou d’instructions
relativement à l’utilisation de l’appareil par une personne
responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
1. Utilisez et entreposez le produit à une température entre
0˚ C (32˚F) et 40˚C (104˚ F).
2. N’exposez pas cet appareil à des froids ou des chaleurs
extrêmes, ainsi qu’à la lumière directe du soleil. Ne
l’installez pas près d’une source de
chauffage.
3. Le bloc-piles ne doit pas être exposé à la
chaleur excessive telle que la lumière du
soleil ou au feu.
4. Assurez-vous que le moniteur et le cordon
de l’adaptateur sont toujours hors de portée des enfants,
àau moins 1 mètre (3 pieds) de l’enfant ou du berceau, pour
éviter tout risque de strangulation.
5. Ne jamais placer le moniteur à l’intérieur du berceau
ou du parc de bébé. Ne jamais couvrir le moniteur ou
l’unité (s) portative avec un article tel une serviette ou une
couverture.
6. D’autres équipements électroniques peuvent produire des
interférences sur votre moniteur vidéo et audio. Tentez
d’installer votre moniteur vidéo ou audio à l’écart des
appareils électroniques tels que des routeurs sans fil, radios,
téléphones cellulaires, interphones, moniteurs, téléphones,
ordinateurs personnels, électroménagers et téléphones
sans fil.
Stimulateurs cardiaques implantés dans l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux dispositifs
numériques sans fil) :
L’organisme ‘Wireless Technology Research, LLC (WTR)’, une
firme de recherche indépendante, a mené une évaluation
pluridisciplinaire des interférences entre les téléphones sans
fil portatifs et les stimulateurs cardiaques implantés dans
l’organisme. Appuyée par l’Administration des aliments et
drogues (FDA) des États-Unis, la firme WTR recommande aux
médecins:
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil à au moins six
pouces du simulateur cardiaque.
• Ils ne doivent PAS placer le téléphone sans fil directement
sur le stimulateur cardiaque, tel que dans une poche de
chemise, lorsque celui-ci est en marche.
L’étude effectuée par l’organisme WRS n’a pas identifié de
risque pour les détenteurs de simulateurs cardiaques causés par
les gens qui utilisent dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes les normes se
rapportant aux champs électromagnétiques (EMF) standard. Si
vous le manipulez correctement en suivant les instructions de ce
guide, son utilisation sera sécuritaire pendant de nombreuses
années, selon les meilleures évidences scientifiques dont nous
disposons aujourd’hui.
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the
holder of a valid proof of purchase (“Consumer” or “you”)
that the Product and all accessories provided in the sales
package (“Product”) are free from defects in material
and workmanship, pursuant to the following terms and
conditions, when installed and used normally and in
accordance with the Product operating instructions. This
limited warranty extends only to the Consumer for Products
purchased and used in the United States of America and
Canada.
What will VTech do if the Product is not free from defects
in materials and workmanship during the limited warranty
period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized
service representative will repair or replace at VTech’s option,
without charge, a Materially Defective Product. If we repair
the Product, we may use new or refurbished replacement
parts. If we choose to replace the Product, we may replace
it with a new or refurbished Product of the same or
similar design. We will retain defective parts, modules,
or equipment. Repair or replacement of the Product, at
VTech’s option, is your exclusive remedy. VTech will return
the repaired or replacement Products to you in working
condition. You should expect the repair or replacement to
take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for
ONE (1) YEAR from the date of purchase. If VTech repairs or
replaces a Materially Defective Product under the terms of
this limited warranty, this limited warranty also applies to the
repaired or replacement Product for a period of either (a)
90 days from the date the repaired or replacement Product
is shipped to you or (b) the time remaining on the original
one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse, accident,
shipping or other physical damage, improper installation,
abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due to repair, alteration
or modification by anyone other than an authorized
service representative of VTech; or
3. Product to the extent that the problem experienced is
caused by signal conditions, network reliability, or cable or
antenna systems; or
4. Product to the extent that the problem is caused by use
with non-VTech accessories; or
5. Product whose warranty/quality stickers, product serial
number plates or electronic serial numbers have been
removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for repair
from outside the United States of America or Canada, or
used for commercial or institutional purposes (including
but not limited to Products used for rental purposes); or
7. Product returned without a valid proof of purchase (see
item 2 below); or
8. Charges for installation or set up, adjustment of customer
controls, and installation or repair of systems outside the
unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our
website at www.vtechphones.com or call 1 (800) 595-9511.
In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
NOTE: Before calling for service, please review the user’s
manual - a check of the Product’s controls and features may
save you a service call.
Except as provided by applicable law, you assume the risk
of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the
transport of the Product(s) to the service location. VTech
will return repaired or replaced Product under this limited
warranty. Transportation, delivery or handling charges are
prepaid. VTech assumes no risk for damage or loss of the
Product in transit. If the Product failure is not covered by
this limited warranty, or proof of purchase does not meet
the terms of this limited warranty, VTech will notify you and
will request that you authorize the cost of repair prior to any
further repair activity. You must pay for the cost of repair and
return shipping costs for the repair of Products that are not
covered by this limited warranty.
What must you return with the Product to get warranty
service?
1. Return the entire original package and contents including
the Product to the VTech service location along with a
description of the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model) and
the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other written or
oral communications related to this Product. VTech provides
no other warranties for this Product. The warranty exclusively
describes all of VTech’s responsibilities regarding the
Product. There are no other express warranties. No one is
authorized to make modifications to this limited warranty and
you should not rely on any such modification. State/Provincial
Law Rights: This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state
or province to province.
Limitations: Implied warranties, including those of fitness
for a particular purpose and merchantability (an unwritten
warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/
provinces do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
In no event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages (including,
but not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost of
substitute equipment, and claims by third parties) resulting
from the use of this Product. Some states/provinces
do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as proof
of purchase.
This baby monitor meets the California Energy Commission (CEC) regulations for energy consumption. Your baby monitor
is set up to comply with the energy-conserving standards right out of the box. Follow the instructions to install and charge
the battery. The CEC battery charging testing mode is activated while charging. Even if the parent unit is paired to baby
units, the CEC battery charging testing mode is ac tivated while it is powered off and charging.
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the
Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed
by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with
the FCC criteria. The baby unit shall be installed and used such that parts of all persons’ body are maintained at a distance of
approximately 8 in (20 cm) or more. The transmitter and antenna of the parent unit shall be held at least 1 in (2.5 cm) from your
face.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that may cause undesired operation of the
device.
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were
met.
This product meets the applicable Innovation, Science and Economic Development Canada technical specifications.
RF radiation exposure statement
The baby unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. The baby unit should
be installed and operated with a minimum distance of 8 in (20 cm) between the baby unit and all persons’ body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter. This equipment complies also with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of Humans to RF Fields.
The RBRC® seal For cETL compliance only Limited warranty
California Energy Commission battery
charging testing mode
FCC and IC regulations
1. Place the wall mount bracket on a
wall and then use a pencil to mark
two holes in parallel. Remove the
wall mount bracket and drill two
holes in the wall (7/32 inch drill bit).
NONO
Notes
• Check for reception strength and
camera angle before drilling the holes.
• The types of screws and anchors you
need depend on the composition of
the wall. You may need to purchase the
screws and anchors separately to mount
your camera units.
2. If you drill the holes into a stud, go
to step 3.
• If you drill the holes into an
object other than a stud, insert
the wall anchors into the holes.
Tap gently on the ends with a
hammer until the wall anchors
are flush with the wall.
3. Align the wall mount bracket and screws with
the holes in the wall as shown. Tighten the screw
in the middle hole first, so that the wall mount
bracket position is fixed. You can tighten the
other screw in the top hole.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Place the camera unit on the wall
mount bracket, and then slide it
forward until it locks into place. Align
the holes on the wall mount bracket
with the screws on the wall, and slide
the wall mount bracket down until it
locks into place.
5. You can maximize your camera unit’s viewing angles by tilting the wall mount bracket.
Hold the camera unit, and then rotate the knob in anticlockwise direction. This will loosen the joint of the wall mount bracket.
Tilt your camera unit up or down to adjust to your preferred angle. Then, rotate the knob in clockwise direction to tighten the
joint and secure the angle.
OR
4. Place the camera unit on the wall mount
bracket, and then slide it forward until
it locks into place. Connect the power
adapter to the camera unit and a power
supply not controlled by a wall switch.
2
1
