Slimline 5000mAh 20W PD Aluminum Power Bank
INSTRUCTION MANUAL
EPB-SL26
READ ALL INSTRUCTIONS CAREFULLY BEFORE USE.
IN THE BOX
EPB-SL26 Slimline 5000mAh 20W PD Aluminum Power Bank (x1)
Charging Cable (x1)
SAFETY PRECAUTIONS
This product is NOT a toy, keep away from children and pets.
Only use the product according to the instructions in this manual. Never use the
product for anything other than its intended purpose.
Do not open this product or attempt to repair the unit yourself if it is not working
properly. Doing so risks re, shock or injury.
When not in use, the product should be stored in a dry, cool location, away from
sources of water or heat.
Do not expose product or charging cable to extreme temperatures (heat or
cold), open flames, humid or wet conditions.
Do not submerge in water. Do not use in a location where the product or
charging cable could fall into liquid.
Unplug the charging cable when not in use. Do not pull the charging cable to
disconnect, or use the cable as a handle.
Do not use if the product or charging cable is damaged. If the product or
charging cable is damaged, it MUST be serviced or replaced by the
manufacturer or its service agent before using again.
Do not over charge battery.
This product contains a built-in battery and should not be disposed of with
regular household waste. Please consult the local authorities on the correct way
to dispose of this product.
Attachments on the back of your device can impede effectiveness of the
wireless charger, and lead to overheating. Remove attachments from your
device before charging on this wireless charger.
The strong magnetic elds of neodymium magnets can damage items, such as
television, computers, computer monitors, credit cards, bank cards, diskettes
and other data carriers, video tapes, mechanical watches, hearing aids, loud
speakers and VCRs. Pace-makers may be damaged or switched to “test mode”
in the presence of a strong magnetic force, if pace-maker or other electronical
body implant is in use. Keep a minimum of 3 feet distance.
- 1 -
PRODUCT DIAGRAMS
INSTRUCTIONS
Charge the power bank fully before using for the rst time.
CHARGING THE POWER BANK
Plug the small connector of the included charging cable into the USB
-
C port on the
power bank.
Plug the other end of the cable into a USB power source, such as the USB port on a
computer or into a certied USB adapter (not included), and plug into a wall socket.
The LED indicator will flash WHITE while
the
power bank is in charging and stop
flashing when the power bank is fully charged.
CHARGING ELECTRONIC DEVICES WITH THE POWER BANK
Using the cable of the device you wish to charge, connect the charging cable to your
device with the appropriate connector.
Connect the other end of the cable
to the
USB
-
C port
of the power bank.
The power bank will begin to charge automatically.
The LED indicator will illuminate WHITE when charging.
Remove the cable from your mobile device when it is fully charged.
USING WIRELESS CHARGING
Place a wireless charging enabled mobile device on the wireless charging surface,
the mobile device will begin to charge automatically. The rst LED indicator
on the
right near the power button
will
illuminate GREEN
to indicate that your device is
charging properly.
If your device does not begin to charge, try repositioning your device on the
wireless charging surface. You may need to remove the case of your device to
charge properly.
Remove your device from the wireless charging surface when it is fully charged.
- 2 -
Magnetic Surface
Wireless Charging
Surface
[Power] Button
Phone Stand
USB-C Input & Output
LED Indicator
Note:
WIRELESS CHARGING WITH MAGNETIC ATTACHMENT
If the charged device supports MagSafe Charger, simply place the device against the
magnetic surface of the power bank, the device will begin to charge automatically.
The perfectly aligned magnets in the wireless charging surface will attach to the
charged device and provide more secure wireless charging.
The rst LED indicator on the right near the power button will illuminate GREEN to
indicate that your device is charging properly.
Remove your device from the wireless charging surface when it is fully charged.
NOTE ON SAFETY FEATURES:
The wireless charging will automatically power OFF when the wireless charging
surface is overheated or when a metal object, such as a coin, is placed on the
wireless charging surface. The rst LED indicator on the right near the power button
will flash GREEN to warn of automatic shutoff.
TECH SPECIFICATIONS
Battery Capacity: 5000mAh/3.85V/19.25Wh
USB-C Input: DC 5V/3A, 9V/2A, 12V/1.5A (18W Max.)
USB-C Output: DC 5V/3A, 9V/2.22A, 12V/1.67A (20W Max.)
Wireless Charging Output: 5W/7.5W/10W/15W
Working Temperature: 14°F ~ 113°F (-10°C ~ 45°C)
- 3 -
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
FCC ID: 2A9Q9-EPB-SL26
Made in China
- 4 -
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
