2.0.0
SENA
QUICK START GUIDE
ENGLISH
MOTORCYCLE MESH COMMUNICATION SYSTEM
SENA Technologies, Inc.
Customer Support: sena.com
Downloadable Sena Software
Download the SENA MOTORCYCLES App at Google Play
Store or App Store.
SENA MOTORCYCLES
Download the following items at sena.com.
Firmware
Sena Device Manager
• Firmware upgrade
• Device configuration setting
Quick Start Guide,
User’s Guide
Follow us on Facebook, YouTube, Twitter and Instagram to check
the latest information and helpful tips.
Product Details
Mesh Intercom Button
Mesh Intercom Antenna
Status LED
Phone Button
Jog Dial
DC Power
Charging &
Firmware
Upgrade Port
Speaker and
Microphone Port
Charging LED
Installation
• For more information about installation, refer to the User’s Guide.
Using the Clamp Unit
1 2
Using the Glued Surface Mounting Plate
1 2
3
Installing the Speakers
1
2
Installing the Wired Boom Microphone
1
1
2
2
3
1
2
Installing the Wired Microphone
1
1
2
2
3
1
2
Mesh Intercom Antenna
Pull the Mesh Intercom Antenna
outwards slightly to unfold it.
1
2
NOTICE
• This Quick Start Guide (Version 2.0) explains how to operate
the SPIDER ST1 with firmware version 2.0 or higher.
• For the operation of the SPIDER ST1 with a firmware version
lower than 2.0, refer to the SPIDER ST1 Quick Start Guide
(Version 1.1.0) or lower.
Icon Legend
1x
TAP
Tap button/Jog Dial the
specified number of times
10s
HOLD
Press and Hold button/Jog
Dial for the specified amount
of time
ROTATE
L
ROTATE
R
ROTATE
Rotate Jog Dial clockwise (right) or
counterclockwise (left).
ROTATE
L
ROTATE
R
ROTATE
Rotate while Pressing Jog Dial clockwise (right) or
counterclockwise (left).
“Hello” Audible prompt
Basic Operations
Powering On
1s
HOLD
Volume Up
ROTATE
R
Powering Off
1x
TAP
Volume Down
ROTATE
L
Checking the Battery Level
Powering On
=
=
=
Phone Pairing
①
5s
HOLD
Blinking
“Phone pairing”
②
Select SPIDER ST1 in the list of
Bluetooth devices detected.
Device B
Pi
Bluetooth
SPIDER ST1
• For more information on phone pairing, refer to the User’s Guide.
Using the Phone
Answer a Call
1x
TAP
Reject a Call
2s
HOLD
End a Call
1x
TAP
Voice Dial
1x
TAP
in
stand-by
mode
Music Control
Play/Pause
1s
HOLD
Track Forward
ROTATE
R
Track Backward
ROTATE
L
Mesh Intercom™
Open Mesh™: communication within the same channel.
Group Mesh™: communication within the same private group.
• For more information on Mesh Intercom, refer to the User’s Guide.
Mesh Intercom On
1x
TAP
Blinking
“ Mesh intercom on,
Open Mesh, channel 1”
Mesh Intercom Off
1x
TAP
“ Mesh intercom off”
Note: When Mesh Intercom is on, the SPIDER ST1 will
automatically connect to nearby SPIDER ST1 users and the
headset will be in Open Mesh (default: channel 1) initially.
Open Mesh
Channel Setting (Default: channel 1) in Open Mesh
Using the Button
①
Enter into the Channel Setting.
2x
TAP
“ Channel setting, 1”
②
Navigate between channels.
(1
2 ••• 8 9 Exit 1 •••)
ROTATE
R
or
ROTATE
L
“ #”
③
Save the channel.
1x
TAP
“ Channel is set,
channel #”
Using the SENA MOTORCYCLES App
You can select the channel through the SENA MOTORCYCLES App.
Group Mesh
Group Mesh is a closed group intercom function that allows users to
join, leave, or rejoin a group intercom conversation without pairing
each headset.
1) Creating a Group Mesh
Creating a Group Mesh requires two or more Open Mesh users.
Open Mesh Group Mesh
You
B
C
You
B C
①
Users (You, B, and C) enter into Mesh Grouping to create a
Group Mesh.
5s
HOLD
“ Mesh grouping”
②
When Mesh Grouping is completed, the users (You, B and C) will
hear a voice prompt on their headset as Open Mesh switches to
Group Mesh.
You
B C
“ Group Mesh”
2) Joining an Existing Group Mesh
One of the current users in an Existing Group Mesh can allow new
users (one or more) in Open Mesh to join the Existing Group Mesh.
Existing
Group Mesh Open Mesh Existing Group Mesh
F
D
You
B
C
You
D
B
F
C
①
One (You) of the current users in the Existing Group Mesh and
new users (D and F) in Open Mesh enter into Mesh Grouping to
join the Existing Group Mesh.
5s
HOLD
“ Mesh grouping”
②
When Mesh Grouping is completed, the new users (D and F) will
hear a voice prompt on their headset as Open Mesh switches to
Group Mesh.
D F
“ Group Mesh”
Enable/Disable Mic (Default: Enable)
Users can enable/disable the microphone when communicating in a
Mesh Intercom.
1s
HOLD
Reset Mesh
If a headset in an Open Mesh or Group Mesh resets the Mesh, it will
automatically return to Open Mesh (default: channel 1).
8s
HOLD
Configuration Menu
Accessing the Configuration Menu
5s
HOLD
“ Configuration menu”
Navigating Between Menu Options
ROTATE
R
or
ROTATE
L
Execute Menu Options
1x
TAP
Troubleshooting
Factory Reset
①
10s
HOLD
“ Factory reset”
②
1x
TAP
“ Headset reset,
good-bye”
Fault Reset
Note: Fault Reset will not restore the headset to the factory
default settings.
Quick Reference
TYPE OPERATION BUTTON COMMANDS
Basic
Operations
Power on /
Power off
1s
HOLD
1x
TAP
Volume up / Volume down
ROTATE
R
or
ROTATE
L
Mobile
Phone
Answer phone call
1x
TAP
End phone call
1x
TAP
Reject phone call
2s
HOLD
Voice Dial
1x
TAP
Music
Play/Pause music
1s
HOLD
Track forward
ROTATE
R
Track backward
ROTATE
L
TYPE OPERATION BUTTON COMMANDS
Mesh
Intercom™
Mesh Intercom on/off
1x
TAP
Channel setting
2x
TAP
Mesh Grouping
5s
HOLD
Reset Mesh
8s
HOLD
Enable/Disable Mic
1s
HOLD
2.0.0_EN_March2022
