Mounting Adapter
Selection Guide
Normally Used By A B
ISE Ring
Adaptor #
Special Information
ISE, Waste King, Toledo, National 4 ½" 5 1/8" 11327A Discard previous adaptor parts.
Bus Boy 6" 6 7/8" 11327K Discard previous adaptor parts
(has 3-piece split ring).
ISE, Toledo 6" 7 3/16" 11327B Discard previous adaptor parts.
Standard ISE mounting 6 5/8" 7 1/8" 11599E Discard previous adaptor parts.
National, Hobart, Toledo 7" 7 3/8" 11327G Discard previous adaptor parts.
National mounting has ten
bolt circle on split ring.
Salvajor 7" 7 ¾" 11599A Discard previous adaptor parts
(split ring supplied).
ISE, Toledo 8" 9 ¼" 11327 Discard previous adaptor parts
(split ring supplied).
A – Diameter (sink or bowl opening)
B – Diameter (outside flange)
A
B
FLANGE
SINK MOUNT
1
Normally Used By A B E
No. of
Bolt Holes
ISE Ring
Adaptor #
Special Information
Waste King, Red Goat 4 1/2" 6 1/2" 5 1/2" 6 11599 Discard previous
adaptor parts. Use
existing bolt holes.
American Delphi, Atomic 6" 7 1/2" 6 7/8" 6 11378D Discard previous
adaptor parts. Use
existing bolt holes.
National, Hobart 7" 8 1/2" 8 1/16" 10 11599B Discard previous
adaptor parts.
A – Diameter (sink or bowl opening)
B – Diameter (outside flange)
E – Diameter (bolt hole circle)
A
E
B
2
Normally Used By A B
ISE Ring
Adaptor #
Special Information
Waste King 6" 6 1/2" 11327D Loose ring on sink not used with this adaptor
(O.D. of loose ring is 7 ½" with six bolts – 7" bolt
hole circle diameter).
A – Diameter (sink or bowl opening)
B – Diameter (outside flange)
A
B
BOLT
HOLES IN
UNATTACHED
RING
3
Adaptability is one of our best features.
Our disposers include two types of stainless steel collar adaptors and a sink ange
adaptor to accommodate any size sink opening. Customize your disposer and clean
up operation by choosing from a variety of bowl sink assemblies designed for dish
tables or drainboards.
Follow these steps and use the chart to select the correct InSinkErator Mounting Adaptor
STEP 1: Disconnect existing disposer from sink bowl or cone.
STEP 2: Find the diagram that matches the shape of your sink bowl or cone.
STEP 3: Measure the A and B dimensions (also C, D and E if indicated).
STEP 4: Match the manufacturer and dimensions to find the adaptor number to order.
Normally Used By A C
ISE Ring
Adaptor #
Special Information
Waste King, Bus Boy 5 7/8" 6 1/2" 11327H Re-use existing clamping ring.
Waste King, Bus Boy 5 7/8" 6 7/8" 11327H
A – Diameter (sink or bowl opening)
C – Diameter (inside bend)
LOOSE RING (RE-USE)
MEASURE
FROM ABOVE
(INSIDE BEND)
A
C
4
Normally Used By A C E
No. of
Bolt Holes
ISE Ring
Adaptor #
Special Information
Hobart 4 1/2" 6 7/8" 5 1/2" 6 11327H Discard previous
adaptor parts.
A – Diameter (sink or bowl opening)
C – Diameter (inside bend)
E – Diameter (bolt hole circle)
MEASURE
FROM ABOVE
(INSIDE BEND)
A
C
E
5
Normally Used By A D
ISE Ring
Adaptor #
Special Information
Red Goat, Insinger 4 ½" 1 1/8" 11378C 4 3/4" rubber connection sleeve and
clamping bands. Support legs required.
Waste King 6" 1 1/8" 11378A 6 ¼" rubber connection sleeve and
clamping bands. Support legs required.
Red Goat, Insinger 7" 1 1/8" 11378B 7 ¼" rubber connection sleeve and
clamping bands. Support legs required.
Master 8" 1" 11599K 8 ¼" rubber connection sleeve and
clamping bands. Support legs required.
A – Diameter (sink or bowl opening)
D – Diameter
NO FLANGE
MOUNT
A
D
7
Normally Used By A D
ISE Ring
Adaptor #
Special Information
Salvajor 4 7/16" 1" 11599N
Has raised bead on outside of sink throat.
Support legs required.
Salvajor 6 5/8" 1" 11599H
A – Diameter (sink or bowl opening)
D – Diameter
RAISED
BEAD
A
D
8
6
Normally Used By A C
Hobart 5" 5 7/8"
GE 6" 6 3/8"
A – Diameter (sink or bowl opening)
C – Diameter (inside bend)
SNAP-
RING
GROOVE
MEASURE
FROM ABOVE
(INSIDE BEND)
C
A
Discontinued
Five Stainless Steel Models from 1 HP to 10 HP in three sizes:
InSinkErator Commercial Disposer Sizing Chart
6
5
/
8
"
6
13
/
16
"
4
7
/
8
"
1
1
/
2
"
3
3
/
8
"
7
11
/
16
"
6
5
/
8
"
7
3
/
4
"
2
3
/
4
"
2"
6
13
/16"
7
3
/8"
6
3
/8"
6
5
/8"
7"
7
1
/
8
"
13"
3"
8
3
/4"
8
3
/4"
23
3
/
4
"
(603.25 mm)
TO
31
1
/
8
"
(790.58 mm)
External Electrical ConnectionsExternal Electrical ConnectionsExternal Electrical Connections
N.P. T.
Waste
Outlet
N.P. T.
Waste
Outlet
½ – 14 N.P. T.
Water Inlet
½ – 14 N.P. T.
Water Inlet
½ – 14 N.P. T.
Water Inlet
17"
(431.8 mm)
1 Phase
18.25"
(463.55 mm)
3 Phase
18
7
/
16
"
(468.31 mm)
1 Phase
19.25"
(488.95 mm)
3 Phase
Small Capacity
1 HP
Medium Capacity
2 HP
Large Capacity
3, 5, & 10 HP
Trusted by foodservice consultants and equipment dealers.
Whether you serve 25 or 2,500 people, there is an InSinkErator disposer that’s right for you.
To determine the proper size disposer, use this recommended sizing chart. Sizing recommendations are given in
general terms; actual capacities vary depending on the volume and type of food waste. LC-50 model available for
light duty commercial applications, such as coee shops, convenience stores, or quick service restaurants.
For questions or special applications, contact your Foodservice Consultant or InSinkErator.
From food waste disposers and reduction systems to hot water dispensers and water saving systems,
InSinkErator has a commercial equipment solution to enhance your day-to-day foodservice operations.
KITCHEN BETTER
™
1250 International Drive, Mount Pleasant, WI 53177
T: 800-845-8345
www.insinkerator.com/foodservice
F188-23D-95-85
InSinkErator® may make improvements and/or changes in the specification
at any time, in its sole discretion, without notice or obligation and further
reserves the right to change or discontinue models.
©2023 InSinkErator All rights reserved.
SS-300 SS-300/500 SS-500 SS-500/1000
SS-500/1000
SS-200 SS-300 SS-300/500 SS-500
SS-500/1000
SS-100 SS-200 SS-300 SS-300/500 SS-500
SS-100 SS-100 SS-200 SS-300 SS-300/500
Light
Majority Fruits & Vegetables
Medium
50/50 Mixture
Heavy
Majority Meats & Seafood
Food Waste Composition
Volume Processed
High
Government
Medium
Full Service
Restaurant
Low
Limited Service
Restaurant/Café/
Fast Casual
100
MEALS
2,500
MEALS
