48-59-2012
USB PORTABLE POWER SOURCE AND CHARGER
Apr. 2019
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 31-12-0640 Charger Cap (1)
2 48-11-2130 REDLITHIUM
®
USB Battery (Optional) (1)
3 44-66-1215 Wall Plug and 2 ft. USB Cable (Optional) (1)
4 12-20-2013 Service Nameplate (Not Shown) (1)
FIG. NOTES
4 A clean, dry surface is essential for proper performance
for any adhesive system. The area intended for application
of any adhesive label or nameplate must be prepared by
cleaning with isopropyl alcohol. The solvent is to be applied
with a clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
54-04-2000
REVISED BULLETIN
SERVICE PARTS
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
0
00
K67A
2
3
1
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. Lisbon Road, Brookeld, Wisc. 53005
Drwg. 1
