Series 9 Contemporary Tall
Built-in Dishwasher
Contemporary
A tall built-under dishwasher with considered detailing and
seamless integration, oering increased internal height for larger
cookware and entertaining essentials. Telescopic slide racking
supports exible loading, complemented by interior illumination
for improved visibility throughout. Auto sensing technology
adjusts water and wash intensity automatically, and quiet
performance suits open plan living.
Auto sensing wash adjusts water and wash intensity to suit each
load
Designed to maximize usable space, with pitch-adjustable tines
for deeper dishes and bowls
Auto Door Open Dry releases excess steam, while an Air Curtain
directs it away from surrounding cabinetry
Wi-Fi enabled and works with the SmartHQ™ app for remote
control and notications
DIMENSIONS
Height 33 3/4 - 36 1/8 "
Width 23 1/2 "
Depth 22 13/16 "
SPECIFICATIONS
Accessories (included)
Cutlery basket •
Kickstrip true
Capacity and loading
Accommodates round plates up to (lower
basket)
12 3/4"
Accommodates round plates up to (top
basket)
9 13/16"
Adjustable height, foldable cupracks •
Easy lift adjustable upper basket •
Fold down tines •
Full width cutlery/utensil tray •
Large crockery insert in lower basket •
Pitch adjustable tines •
Place settings 16
Place settings 16
Telescopic slides •
Wine glass supports with stemware grippers •
Connected Features
Alerts and notications •
Education and onboarding •
Energy consumption monitoring •
Monitoring •
Remote operation •
Software updates •
Consumption
Energy rating Energy star Most
ecient
Energy usage 210kWh/year
In-use energy carbon emissions estimate 74.1kgCO2e/year
Water usage (per wash cycle) 3.2 gal
Controls
Energy saving delay start option of up to
24 hours
•
Floor light cycle feedback •
Internal light •
Internal wash selector •
Keylock •
Rinse aid indicator light •
Smart appliance •
QUICK REFERENCE GUIDE > DW24UDT4X4 Date: 04.03.2026 > 1
Features
Air curtain for bench protection •
Auto Door Open Dry •
Fan assisted drying •
Flood protection •
Fully independent spray arms •
Half load option •
Internal tub material Stainless Steel
Motor type BLDC
Three-stage ltration system •
Variable wash pressure technology •
Performance
Noise emissions 42 dBA
Power Requirements
Amperage 10A
Supply frequency 60Hz
Supply voltage 100 - 120V
Product Dimensions
Depth 22 13/16 "
Height 33 3/4 - 36 1/8 "
Width 23 1/2 "
Wash Program Modiers
Dry + •
Half load •
Intensive •
Sanitise •
Wash modiers 4
Wash Programs
60 min •
Auto •
Eco •
Glassware •
Heavy •
Light •
Medium •
Rinse •
Wash programs 8
Water connection
Water pressure 30kPa - 1000 kPa
SKU 85994
The product dimensions and specications in this page apply to the specic
product and model. Under our policy of continuous improvement, these
dimensions and specications may change at any time. You should therefore
check with Fisher & Paykel's Customer Care Centre to ensure this page
correctly describes the model currently available. © Fisher & Paykel
Appliances Ltd 2020
Other product downloads available at sherpaykel.com
Where applicable:
All appliances use energy, and energy usage typically generates
carbon emissions. Fisher & Paykel Appliances’ In-use Energy
Carbon Emissions Estimate indicates carbon emissions from a
product’s in-use energy. This is calculated either annually or per
cycle, using the product’s market-specic energy label energy
consumption data multiplied by the carbon emissions factor for
energy in your country or region.
Our In-use Energy Carbon Emissions Estimate is designed to assist
customers in making informed purchasing decisions when
comparing dierent Fisher & Paykel products. For example, a heat
pump dryer typically has a lower In-use Energy Carbon Emissions
Estimate than a vented dryer.
