www.PyleUSA.com
PLBNPS28 - PLBNPS21 - PLBNPS22
Dual Subwoofer Box System
Rear Vented Design
with Built-in Illuminating LED Lights
WIRING CONNECTION
Power amplier for schematic diagram.
Connect the power amplier to the positive
and negative terminals accordingly as shown.
REMOTE CONTROL FEATURES
1. Turn ON/Standby: Press this key to turn on LEDs or switch to standby mode.
2/9. Dynamic Mode button: Switch from dynamic mode to color mode or
switch between dynamic modes.
3/8. Dynamic Mode Speed button: Use these buttons to adjust dynamic mode
speed. If the unit is in static mode, pressing these buttons will switch unit to
dynamic mode.
4/5. Static Color Adjust button: Use this button to swit h between static colors.
Pressing these keys while in dynamic mode will switch the unit to static mode.
6/7. Brightness Adjust button: Pressing these buttons will adjust brightness
while in static mode. If these buttons are pressed while unit is in dynamic mode,
it will switch to static mode.
10. Demo Mode button: This button will switch the unit into demo mode.
While in demo mode, unit will loop through 9 of the dynamic modes with each repeating 3 times.
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]om
www.PyleUSA.com
PLBNPS28
8'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• External Material: Articial Leather
• Power Rating: 2x400 Watts Max Power
• Voice Coil: 1.5''
• Impedance: 4 Ohms
• Magnet: 2x30 Oz
• Sensitivity: 89 dB
• Frequency Response: 45-800 Hz
• Remote Control Battery Operated, Requires (1) x ‘CR2025’ Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H): 25.6'' x 11.0'' x 11.0'' -inches
PLBNPS21
10'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• External Material: Articial Leather
• Power Rating: 2x500 Watts Max Power
• Voice Coil: 2.0''
• Impedance: 4 Ohms
• Magnet: 2x40 Oz
• Sensitivity: 90 dB
• Frequency Response: 35-500 Hz
• Remote Control Battery Operated, Requires (1) x ‘CR2025’ Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H):28.3'' x 13.8'' x 13.0'' -inches
PLBNPS22
12'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• External Material: Articial Leather
• Power Rating: 2x600 Watts Max Power
• Voice Coil: 2.0''
• Impedance: 4 Ohms
• Magnet: 2x50 Oz
• Sensitivity: 91 dB
• Frequency Response: 25-300 Hz
• Remote Control Battery Operated, Requires (1) x ‘CR2025’ Batteries
• Battery Type: 3V Lithium Battery
• Battery Life: Up to 2+ Hours
• Product Dimensions (L x W x H): 30.9'' x 15.7'' x 15.1'' -inches
Features:
• Rear Vented Design
• High Powered Woofers
with a Silver Paper Cone
• Rubber Edge Suspension
• Smooth Articial Leather Finish
• 4 Layer Dual Voice Coil
• Binding Post Connectors
• Perfect for Truck and Behind the Seat
• High-Quality Construction
What's in the Box:
• Subwoofer Box
• LED Remote Control
