PL26BSL - PL28BSL - PL210BSL
Dual Subwoofer Box System
Rear Vented Design
with Built-in Illuminating LED Lights
WIRING CONNECTION
Power amplier for schematic diagram.
Features:
• Rear Vented Design
• Rubber Edge Suspension
• Two 4” Tweeters
• Smooth Carpet Finish
• 4 Layer Dual Voice Coil
• Binding Post Connectors
• Perfect for Truck and Behind the Seat
• High-Quality Construction
What's in the Box:
• Subwoofer Box
Connect the power amplier to the positive
and negative terminals accordingly as shown.
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]om
•
•
www.PyleUSA.com
PL26BSL
6'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• Power Rating: 2 x 200 Watts Max Power
• Voice Coil: 1.0''
• Impedance: 4 Ohms
• Magnet: 2 x 20 Oz
• Sensitivity: 90 dB
• Frequency Response: 65-18000 Hz
• Product Dimensions (L x W x H): 20.5'' x 4.7'' x 8.5'' -inches
PL28BSL
8'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• Power Rating: 2 x 300 Watts Max Power
• Voice Coil: 1.5''
• Impedance: 4 Ohms
• Magnet: 2 x 24 Oz
• Sensitivity: 91 dB
• Frequency Response: 50-18000 Hz
• Product Dimensions (L x W x H): 27.5'' x 6.3'' x 11.0'' -inches
PL210BSL
10'' Dual Series Vented Subwoofer Enclosure
Rear Vented Design with Built-in Illuminating LED Lights
Technical Specs:
• Construction Materials: 15mm Particle Board + Multilayer Board
• Power Rating: 2 x 400 Watts Max Power
• Voice Coil: 2.0''
• Impedance: 4 Ohms
• Magnet: 2 x 30 Oz
• Sensitivity: 91 dB
• Frequency Response: 40-18000 Hz
• Product Dimensions (L x W x H): 29.9'' x 7.0'' x 13.0'' -inches
