User Guide
BE3600 Dual-Band Wi-Fi 7 Wireless USB Adapter
Archer TBE3600U
Contents
About This Guide 1
Chapter 1 Get to Know About Your Adapter 3
1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1. 2. LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2 Connect to a Computer 6
Chapter 3 Use the Adapter 8
3. 1. Install Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. 2. Join a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. 3. Uninstall Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Appendix: Troubleshooting 10
1
About This Guide
This guide is a complement to Quick Installation Guide. The Quick Installation
Guide instructs you on quick installation, and this guide provides the product
overview and detailed instructions for each steps.
When using this guide, please notice that features available of the adapter may
vary by model and software version. It may also vary by region or ISP. All images,
steps, and descriptions in this guide are only examples and may not reflect your
actual experience.
Conventions
In this guide, the following conventions are used:
Convention
Description
Underlined
Underlined words or phrases are hyperlinks. You can click to redirect to a
website or a specific section.
Teal
Contents to be emphasized and texts on the web page are in teal, including
the menus, items, buttons, etc.
Note:
Ignoring this type of note might result in a malfunction or damage to the
device.
Tips:
Indicates important information that helps you make better use of your
device.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11
specifications. Actual wireless data throughput and wireless coverage, and number of connected
devices are not guaranteed and will vary as a result of network conditions, AP limitations, and
environmental factors, including building materials, obstacles, volume and density of traffic, and
AP location.
**Use of Wi-Fi 7(802.11be), Wi-Fi 6(802.11ax), Wi-Fi 6E(802.11ax), and other features including
MLO, 160 MHZ Bandwidth, 4K-QAM, Multi-RUs, OFDMA, MU-MIMO, and BSS Color requires the
AP and PC OS also to support the corresponding features. The MLO is still being developed on
some Wi-Fi 7 models and will be supported in subsequent driver updates.
†Use of WPA3 requires APs also to support the corresponding feature.
‡The number is based on testing conducted by the USB-IF and your computers are required to
also support USB 3.0.
△To ensure compatibility, you may need to update the adapter’s drivers after an OS update, you
can find our latest drivers in the download center at tp-link.com/en/download-center.
Actual network speed may be limited by the rate of the product’s USB port, PCI Express Interface,
Ethernet WAN or LAN port, the rate supported by the network cable, internet service provider
factors, and other environmental conditions.
More Info
• The latest driver can be found at Download Center
at https://www.tp-link.com/support.
2
• The Quick Installation Guide can be found where you find this guide or inside
the package of the router.
• Specifications can be found on the product page at https://www.tp-link.com.
• A TP-Link Community is provided for you to discuss our products at
https://community.tp-link.com.
• Our Technical Support contact information can be found at the Contact
Technical Support page at https://www.tp-link.com/support.
4
Chapter 1
Get to Know about Your Adapter
1 1 Product Overview
Archer TBE3600U redefines Wi-Fi 7: Dual band ensures smooth connections,
MLO enables seamless switching between bands for uninterrupted speed,
4096-QAM delivers 20% more data per signal, and multi-RUs let your whole
family stream, game, and download simultaneously—all without lag.**
• 3.6 Gbps Dual Band Wi-Fi 7 - Ultra-fast speeds up to 2882 Mbps (5 GHz) + 688
Mbps (2.4 GHz).*
• Multi-Link Operation (MLO) - Enable devices to use multi-link seamless
dynamic switching to achieve lower latency, lag-free gaming and streaming.**
• Broader Coverage - Connect to your WiFi from wherever in your home with
high-performance antennas and Beamforming.
1 2 LED Status
You can check the adapter’s working status by following the LED explanation
table.
Status
Indication
On The driver has been installed successfully.
Off
The driver is not installed.
The adapter is not detected.
Tips:
If the LED is off, try these troubleshooting tips:
1. Check if the adapter is recognized and enabled or not. Refer to Appendix: Troubleshooting for detailed
instructions.
2. Remove and reinsert the adapter.
3. Reinstall the driver, if necessary.
Chapter 2
Connect to a Computer
This chapter introduces how to connect the adapter to your computer.
6
Chapter 2
Connect to a Computer
Before You Start:
• Make sure your Router or Access Point supports the Wi-Fi 7 standard.
• It is recommended to use the adapter on Windows 11 (64-bit) or above.
Note:
It is recommended to connect the adapter to a USB 3.0 ( ) port.
Insert the adapter into a USB port on your computer directly.
* The image is for demonstration only.
Chapter 3
Use the Adapter
This chapter introduces how to install your adapter’s driver, use your adapter
to join a wireless network, and uninstall your adapter in a Windows system.
The adapter is equipped with a Setup Wizard, which can guide you through the
installation process.
This chapter includes the following sections:
• Install Driver
• Join a Wireless Network
• Uninstall Driver
8
Chapter 3 Use the Adapter
3 1 Install Driver
1 Go to My Computer or This PC.
2 Double click the CD Drive then run SetupInstall.exe to install the driver.
Note:
1. If you cannot find the setup program, please download the driver at www.tp-link.com/support.
2. If an unknown publisher message pops up, select Yes to continue.
3. If Windows User Account Control requires admin credentials, type user name and password of
your Windows administrator account. .
3 2 Join a Wireless Network
You can join a wireless network via Windows built-in wireless utility. Follow the
instructions below to use your computer system’s built-in wireless utility:
Click the Network icon on the taskbar (the icon might look like one of these: ,
, , or ). Select the Wi-Fi network you want to join, and click Connect.
Enter the network password when prompted.
3 3 Uninstall Driver
The software uninstallation steps vary a bit from different systems. Here we take
the instructions for Windows 10 as an example.
Go to Contol Pannel > Programs, click Uninstall a program, then double-click
TP-Link Wi-Fi 7 Wireless USB Adapter, then follow the on-screen instructions to
complete the uninstallation.
SetupInstall.exe
9
Appendix: Troubleshooting
T1 What should I do if the adapter is not detected?
• Make sure the adapter is securely connected to the computer.
• Make sure you meet the minimum system requirements for the adapter and that the
latest Windows and system updates are installed on your computer.
• Make sure you use the latest driver for your specific adapter. The latest drivers can
be found at https://www.tp-link.com/download-center.
• Try a different USB port on the computer.
• Try restarting the computer or try using the adapter on a different computer.
T2 How to check if I have installed the driver for my adapter successfully
or not?
1 On your computer, please right click Computer icon and go to Manage;
2 Open the Device Manager and go to Network adapters, and then find the
corresponding TP-Link adapter, right click it and then go to Properties;
10
3 If you can see “This device is working properly.” in the red box, you have already
installed the driver successfully.
T3 What should I do if can’t connect to the Wi-Fi after installing the
driver?
• Refer to T2 to check if you have installed the driver for your adapter successfully .
• Make sure the adapter is securely connected to the computer.
• Disable the antivirus software and firewall, then try again.
• Try a different USB port on the computer.
• Restart your computer and try again.
11
• Re-install the driver and try again.
T4 How to find the hardware version of the adapter?
• The hardware version is printed on the product label on the package or the adapter.
There is a character string “Ver:X.Y” (for example, Ver:2.0) in the Serial Number field,
and the number X is the hardware version of the adapter.
• Visit https://www.tp-link.com/faq-46.html and follow the second method to find the
hardware version of the adapter.
T5 How do I update my operating system?
• Refer to the official website to download Win 11:
https://www.microsoft.com/software-download/windows11/
For more detailed instructions:
• Can’t find the hardware version of the adapter: https://www.tp-link.com/faq-46.html
• Can’t find or join the wireless networks: https://www.tp-link.com/faq-2253.html
• Can’t install the driver: https://www.tp-link.com/faq-2252.html
FCC compliance information statement
Product Name: BE3600 Dual-Band Wi-Fi 7 Wireless USB Adapter
Model Number: Archer TBE3600U
Responsible party:
TP-Link Systems Inc
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]om
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1 ) This device may not cause harmful interference.
2 ) This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must not
be co-located or operating in conjunction with any other antenna or transmitter.
This equipment has been SAR-evaluated for use in hand. SAR measurements
are based on a 5mm spacing from the body and that compliance is achieved at
that distance.
We, TP-Link Systems Inc , has determined that the equipment shown as above
has been shown to comply with the applicable technical standards, FCC part 15.
There is no unauthorized change is made in the equipment and the equipment is
properly maintained and operated.
Issue Date: 25/05/09
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service,
please contact us.
• Do not use the device where wireless devices are not allowed.
• This equipment can be powered only by equipments that comply with Power
Source Class 2 (PS2) or Limited Power Source (LPS) defined in the standard of
IEC 62368-1.
• This product uses radios and other components that emit electromagnetic fields.
Electromagnetic fields and magnets may interfere with pacemakers and other
implanted medical devices. Always keep the product and its power adapter more
than 15 cm (6 inches) away from any pacemakers or other implanted medical
devices. If you suspect your product is interfering with your pacemaker or any
other implanted medical device, turn off your product and consult your physician
for information specific to your medical device.
Operating Temperature: 0℃~40℃ (32°F~104°F)
Please read and follow the above safety information when operating the device.
We cannot guarantee that no accidents or damage will occur due to improper use
of the device. Please use this product with care and operate at your own risk.
Explanation of the symbols on the product label
Symbols may vary from products.
Symbol
Explanation
Class II equipment
Class II equipment with functional earthing
Alternating current
Direct current
Polarity of d.c. power connector
For indoor use only
Dangerous voltage
Caution, risk of electric shock
Energy efficiency Marking
Protective earth
Earth
Frame or chassis
Functional earthing
Caution, hot surface
Caution
Operator’s manual
Stand-by
“ON”/”OFF” (push-push)
Fuse
Fuse is used in neutral N
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic
equipment (WEEE). This means that this product must be handled pursuant to
European directive 2012/19/EU in order to be recycled or dismantled to minimize
its impact on the environment.
User has the choice to give his product to a competent recycling organization or to
the retailer when he buys a new electrical or electronic equipment.
Caution, avoid listening at high volume levels for long periods
Disconnection, all power plugs
m
Switch of mini-gap construction
µ
Switch of micro-gap construction (for US version)
Switch of micro-gap / micro-disconnection construction (for other versions except
US)
ε Switch without contact gap (Semiconductor switching device)
