User Guide
BE6500 Wi-Fi 7 High Gain Wireless USB Adapter
Archer TBE400UH / Archer TBE6500UH
Contents
About This Guide 1
Chapter 1 Get to Know About Your Adapter 3
1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1. 2. LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2 Connect to a Computer 6
Chapter 3 Use the Adapter 8
3. 1. Install Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. 2. Join a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. 3. Uninstall Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Appendix: Troubleshooting 10
1
About This Guide
This guide is a complement to Quick Installation Guide. The Quick Installation
Guide instructs you on quick installation, and this guide provides the product
overview and detailed instructions for each steps.
When using this guide, please notice that features available of the adapter may
vary by model and software version. It may also vary by region or ISP. All images,
steps, and descriptions in this guide are only examples and may not reflect your
actual experience.
Conventions
In this guide, the following conventions are used:
Convention
Description
Underlined
Underlined words or phrases are hyperlinks. You can click to redirect to a
website or a specific section.
Teal
Contents to be emphasized and texts on the web page are in teal, including
the menus, items, buttons, etc.
Note:
Ignoring this type of note might result in a malfunction or damage to the
device.
Tips:
Indicates important information that helps you make better use of your
device.
†
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications.
Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of
network conditions, AP limitations, and environmental factors, including building materials, obstacles,
volume and density of traffic, and AP location.
‡
Use of Wi-Fi 7 (802.11be), Wi-Fi 6/6E (802.11ax), and other features, including 4096-QAM, Multi-RUs,
OFDMA, and MU-MIMO, requires the AP and PC OS to also support the corresponding features. Please
try to update the device’s driver for feature compatibility.
§The adapter supports 6 GHz on Windows 10 21H2 and later versions, though functionality and
performance may be limited.
△Use of WPA3 requires APs to also support the corresponding feature.
*802.11be 4096-QAM enables maximum theoretical data rates, which are 1.2× faster than 802.11ax
1024-QAM as per IEEE 802.11 specifications. This requires the use of compatible 802.11be routers.
**Actual network speed may be limited by the rate of the product’s USB port, PCI Express Interface,
Ethernet WAN or LAN port, the rate supported by the network cable, internet service provider factors,
and other environmental conditions.
More Info
• The latest driver can be found at Download Center
at https://www.tp-link.com/support.
• The Quick Installation Guide can be found where you find this guide or inside
the package of the router.
• Specifications can be found on the product page at https://www.tp-link.com.
4
Chapter 1
Get to Know about Your Adapter
1 1 Product Overview
Wi-Fi 7 offers the forefront of technology to maximize the 6 GHz band. With
4096-QAM, the adapter delivers peak rates 1.2× faster than Wi-Fi 6/6E
adapters, ensuring a seamless network experience.
‡
*
Two bifurcated high-gain antennas and a detachable cradle with a 1.2-meter
cable combine with beamforming technology to concentrate Wi-Fi signals
toward your router for enhanced reception and reliable connections from a
distance.
•Ultra-Low Latency – The revolutionary combo of OFDMA and MU-MIMO
ensures the most efficient Wi-Fi connection for your PC, reducing latency for
faster speeds.
‡
• Tri-Band Wireless – 2.4 GHz, 5 GHz and 6 GHz bands for flexible connectivity.
• Supports WEP, WPA/WPA2/WPA3, WPA-PSK/ WPA2-PSK*.
• Supports Windows 10(32-bit), Windows 10/11(64-bit)*.
1 2 LED Status
You can check the adapter’s working status by following the LED explanation
table.
Status
Indication
On The driver has been installed successfully.
5
Chapter 1
Get to Know about Your Adapter
Status
Indication
Off
The driver is not installed.
The adapter is not detected.
Tips:
If the LED is off, try these troubleshooting tips:
1. Check if the adapter is recognized and enabled or not. Refer to Appendix: Troubleshooting for detailed
instructions.
2. Remove and reinsert the adapter.
3. Reinstall the driver, if necessary.
Chapter 2
Connect to a Computer
This chapter introduces how to connect the adapter to your computer.
7
Chapter 2
Connect to a Computer
Before You Start:
• Make sure your Router or Access Point supports the Wi-Fi 7 standard.
• It is recommended to use the adapter on Windows 11 (64-bit) or above.
Note:
It is recommended to connect the adapter to a USB 3.0 ( ) port.
Option 1:
Insert the adapter into a USB port on your computer directly.
* The image is for demonstration only.
Option 2: Via the USB Extension Cable
Note:
For optimal performance, it is recommended to use the provided USB extension cable.
* The image is for demonstration only.
Chapter 3
Use the Adapter
This chapter introduces how to install your adapter’s driver, use your adapter
to join a wireless network, and uninstall your adapter in a Windows system.
This chapter will use TBE400UH as an example to demonstrate how to use the
adapter. The adapter is equipped with a Setup Wizard, which can guide you
through the installation process.
This chapter includes the following sections:
• Install Driver
• Join a Wireless Network
• Uninstall Driver
9
Chapter 3 Use the Adapter
3 1 Install Driver
1 Go to My Computer or This PC.
2 Double click the CD Drive then run SetupInstall.exe to install the driver.
Note:
1. If you cannot find the setup program, please download the driver at www.tp-link.com/support.
2. If an unknown publisher message pops up, select Yes to continue.
3. If Windows User Account Control requires admin credentials, type user name and password of
your Windows administrator account. .
3 2 Join a Wireless Network
You can join a wireless network via Windows built-in wireless utility. Follow the
instructions below to use your computer system’s built-in wireless utility:
Click the Network icon on the taskbar (the icon might look like one of these: ,
, , or ). Select the Wi-Fi network you want to join, and click Connect.
Enter the network password when prompted.
3 3 Uninstall Driver
The software uninstallation steps vary a bit from different systems. Here we take
the instructions for Windows 10 as an example.
Go to Contol Pannel > Programs, click Uninstall a program, then double-click
TP-Link Archer TBE400UH Driver, then follow the on-screen instructions to
complete the uninstallation.
SetupInstall.exe
10
Appendix: Troubleshooting
T1 What should I do if the adapter is not detected?
• Make sure the adapter is securely connected to the computer.
• Make sure you meet the minimum system requirements for the adapter and that the
latest Windows and system updates are installed on your computer.
• Make sure you use the latest driver for your specific adapter. The latest drivers can
be found at https://www.tp-link.com/download-center.
• Try a different USB port on the computer.
• Try restarting the computer or try using the adapter on a different computer.
T2 How to check if I have installed the driver for my adapter successfully
or not?
1 On your computer, please right click Computer icon and go to Manage;
2 Open the Device Manager and go to Network adapters, and then find the
corresponding TP-Link adapter, right click it and then go to Properties;
11
3 If you can see “This device is working properly.” in the red box, you have already
installed the driver successfully.
T3 What should I do if can’t connect to the Wi-Fi after installing the
driver?
• Refer to T2 to check if you have installed the driver for your adapter successfully .
• Make sure the adapter is securely connected to the computer.
• Disable the antivirus software and firewall, then try again.
• Try a different USB port on the computer.
• Restart your computer and try again.
12
• Re-install the driver and try again.
T4 How to find the hardware version of the adapter?
• The hardware version is printed on the product label on the package or the adapter.
There is a character string “Ver:X.Y” (for example, Ver:2.0) in the Serial Number field,
and the number X is the hardware version of the adapter.
• Visit https://www.tp-link.com/faq-46.html and follow the second method to find the
hardware version of the adapter.
T5 How do I update my operating system?
• Refer to the official website to download Win 11:
https://www.microsoft.com/software-download/windows11/
For more detailed instructions:
• Can’t find the hardware version of the adapter: https://www.tp-link.com/faq-46.html
• Can’t find or join the wireless networks: https://www.tp-link.com/faq-2253.html
• Can’t install the driver: https://www.tp-link.com/faq-2252.html
FCC compliance information statement
Product Name: BE6500 Wi-Fi 7 High Gain Wireless USB Adapter
Model Number: Archer TBE400UH/ Archer TBE6500UH
Responsible party:
TP-Link Systems Inc
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]om
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1 ) This device may not cause harmful interference.
2 ) This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must not
be co-located or operating in conjunction with any other antenna or transmitter.
This equipment has been SAR-evaluated for use in hand. SAR measurements
are based on a 5mm spacing from the body and that compliance is achieved at
that distance.
Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control
of or communications with unmanned aircraft systems.
We, TP-Link Systems Inc , has determined that the equipment shown as above
has been shown to comply with the applicable technical standards, FCC part 15.
There is no unauthorized change is made in the equipment and the equipment is
properly maintained and operated.
Issue Date: 25/03/28
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.
OPERATING FREQUENCY(the maximum transmitted power)
2400MHz-2483.5MHz(20dBm)
5150MHz-5250MHz(23dBm)
5250MHz-5350MHz(23dBm)
5470MHz-5725MHz(23dBm)
5945MHz-6425MHz(23dBm)
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directives 2014/53/EU, 2011
/65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found
at https://www.tp-link.com/en/support/ce/
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of the Radio Equipment Regulations
2017.
The original UK declaration of conformity may be found at https://www.tp-link.
com/support/ukca/
RF Exposure Information
This device meets the EU requirements (2014/53/EU Article 3.1a) on the
limitation of exposure of the general public to electromagnetic fields by way of
health protection.
This device has been tested and meets the ICNIRP exposure guidelines and
the European Standard EN 62209-2. SAR is measured with this device at a
separation of 0.5 cm to the body, while transmitting at the highest certified
output power level in all frequency bands of this device. Carry this device at
least 0.5 cm away from your body to ensure exposure levels remain at or below
the as-tested levels.
Frequency band: 5150 - 5250 MHz:
Indoor use: Inside buildings only. Installations and use inside road vehicles
and train carriages are not permitted. Limited outdoor use: If used outdoors,
equipment shall not be attached to a fixed installation or to the external body
of road vehicles, a fixed infrastructure or a fixed outdoor antenna. Use by
unmanned aircraft systems (UAS) is limited to within the 5170 - 5250 MHz
band.
Frequency band: 5250 - 5350 MHz:
Indoor use: Inside buildings only. Installations and use in road vehicles, trains
and aircraft are not permitted. Outdoor use is not permitted.
Frequency band: 5470 - 5725 MHz:
Installations and use in road vehicles, trains and aircraft and use for unmanned
aircraft systems (UAS) are not permitted.
Frequency band: 5945-6425MHz:
Restricted to indoor use, including in trains with metal-coated windows and
aircraft. Outdoor use, including in road vehicles, is not permitted.
AT BE BG CH CY CZ DE DK
EE EL ES FI FR HR HU IE
IS IT LI LT LU LV MT NL
NO PL PT RO SE SI SK UK(NI)
UK
Attention: This device may only be used indoors in Great Britain.
Canadian Compliance Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
Caution: The device for operation in the band 5150–5250 MHz is only for
indoor use to reduce the potential for harmful interference to co-channel mobile
satellite systems.
DFS (Dynamic Frequency Selection) products that operate in the bands 5250-
5350 MHz, 5470-5600MHz, and 5650-5725MHz.
Avertissement: Le dispositif fonctionnant dans la bande 5150-5250 MHz est
réservé uniquement pour une utilisation à l’intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes
canaux;
Les produits utilisant la technique d’atténuation DFS (sélection dynamique des
fréquences) sur les bandes 5250- 5350 MHz, 5470-5600MHz et 5650-5725MHz.
Devices shall not be used for control of or communications with unmanned
aircraft systems.
Les appareils ne doivent pas être utilisés pour le contrôle ou la communication
avec des systèmes d’aéronefs sans pilote.
Radiation Exposure Statement:
This EUT is compliance with SAR for general population/uncontrolled exposure
limits in RSS-102 and had been tested in accordance with the measurement
methods and procedures specified in IEEE 1528 and IEC 62209. This equipment
should be installed and operated with minimum distance 0.5 cm between the
radiator and your body. This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or transmitter.
Déclaration d’exposition aux radiations :
Cet adaptateur est conforme au SAR pour la population générale/limites
d’exposition non contrôlées dans RSS-102 et a été testé conformément aux
méthodes et procédures de mesure spécifiées dans IEEE 1528 et CEI 62209.
Cet équipement doit être installé et utilisé avec une distance minimale de 5 mm
entre le radiateur et votre corps. Cet appareil et ses antennes ne doivent pas
être situés ou fonctionner en conjonction avec une autre antenne ou un autre
émetteur.
Industry Canada Statement
CAN ICES-003 (B)/NMB-003(B)
Korea Warning Statements
당해 무선설비는 운용중 전파혼신 가능성이 있음.
NCC Notice
注意！
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變
更頻率、加大功率或變更原設計之特性及功能。
低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象
時，應立即停用，並改善至無干擾時方得繼續使用。
前述合法通信，指依電信管理法規定作業之無線電通信。
低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
應避免影響附近雷達系統之操作。
BSMI Notice
安全諮詢及注意事項
• 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
• 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
• 注意防潮，請勿將水或其他液體潑灑到本產品上。
• 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋
開口。
• 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位
置中。
•不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。
限用物質含有情況標示聲明書
設備名稱：BE6500Wi-Fi7HighGainWireless
USBAdapter
Equipmentname
型號（型式）：ArcherTBE400UH/
TBE6500UH
Typedesignation(Type)
產品元件
名稱
限用物質及其化學符號
鉛
Pb
鎘
Cd
汞
Hg
六價鉻
Cr
+6
多溴聯苯
PBB
多溴二苯醚
PBDE
PCB ○ ○ ○ ○ ○ ○
天線 ○ ○ ○ ○ ○ ○
外殼 ○ ○ ○ ○ ○ ○
其他及其
配件
一 ○ ○ ○ ○ ○
備考1.“超出0.1wt%”及“超出0.01wt%”系指限用物質之百分比含量超出百分比含量基準
值。
備考2.“○”系指該項限用物質之百分比含量未超出百分比含量基準值。
Продукт сертифіковано згідно с правилами системи УкрСЕПРО
на відповідність вимогам нормативних документів та вимогам, що
передбачені чинними законодавчими актами України.
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service,
please contact us.
• Do not use the device where wireless devices are not allowed.
• This equipment can be powered only by equipments that comply with Power
Source Class 2 (PS2) or Limited Power Source (LPS) defined in the standard of
IEC 62368-1.
• This product uses radios and other components that emit electromagnetic fields.
Electromagnetic fields and magnets may interfere with pacemakers and other
implanted medical devices. Always keep the product and its power adapter more
than 15 cm (6 inches) away from any pacemakers or other implanted medical
devices. If you suspect your product is interfering with your pacemaker or any
other implanted medical device, turn off your product and consult your physician
for information specific to your medical device.
Operating Temperature:0℃~40℃ (32°F~104°F)
Please read and follow the above safety information when operating the device.
We cannot guarantee that no accidents or damage will occur due to improper use
of the device. Please use this product with care and operate at your own risk.
Explanation of the symbols on the product label
Symbols may vary from products.
Symbol
Explanation
Class II equipment
Class II equipment with functional earthing
Alternating current
Direct current
Polarity of d.c. power connector
For indoor use only
Dangerous voltage
Caution, risk of electric shock
Energy efficiency Marking
Protective earth
Earth
Frame or chassis
Functional earthing
Caution, hot surface
Caution
Operator’s manual
Stand-by
“ON”/”OFF” (push-push)
Fuse
Fuse is used in neutral N
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic
equipment (WEEE). This means that this product must be handled pursuant to
European directive 2012/19/EU in order to be recycled or dismantled to minimize
its impact on the environment.
User has the choice to give his product to a competent recycling organization or to
the retailer when he buys a new electrical or electronic equipment.
Caution, avoid listening at high volume levels for long periods
Disconnection, all power plugs
m
Switch of mini-gap construction
µ
Switch of micro-gap construction (for US version)
Switch of micro-gap / micro-disconnection construction (for other versions except
US)
ε Switch without contact gap (Semiconductor switching device)
