BN68-25147A-00
1
1
2
3
Unpacking and
Installation Guide
Scan this QR code
with your smart
phone to see
helpful videos.
85″
85″
75″
75″
43″- 58″
43″- 75″
43″- 70″
65″- 75″
Power Cable
Remote Control /
Battery (AAA) x2
Simple User Guide /
Remote control guide /
Regulatory Guide
3
4 5
43U8***H
37.7 inches
(957.8 mm)
22.0 inches
(558.8 mm)
3.0 inches
(76.3 mm)
24.0 inches
(609.0 mm)
6.2 inches
(157.0 mm)
42.5 inches
14.3 lbs
(6.5 kg)
14.8 lbs
(6.7 kg)
50U8***H
43.7 inches
(1110.8 mm)
25.3 inches
(643.8 mm)
3.0 inches
(76.4 mm)
27.4 inches
(696.0 mm)
7.8 inches
(199.0 mm)
49.5 inches
18.5 lbs
(8.4 kg)
19.2 lbs
(8.7 kg)
55U8***H
48.2 inches
(1224.6 mm)
27.9 inches
(707.8 mm)
3.0 inches
(76.6 mm)
29.9 inches
(760.0 mm)
7.8 inches
(199.0 mm)
54.6 inches
21.8 lbs
(9.9 kg)
22.5 lbs
(10.2 kg)
58U8***H
50.6 inches
(1285.7 mm)
29.5 inches
(749.0 mm)
3.0 inches
(76.8 mm)
31.5 inches
(800.2 mm)
8.7 inches
(222.0 mm)
57.5 inches
25.6 lbs
(11.6 kg)
26.2 lbs
(11.9 kg)
65U8***H
56.9 inches
(1444.1 mm)
32.7 inches
(831.2 mm)
3.0 inches
(76.8 mm)
34.7 inches
(882.2 mm)
8.7 inches
(222.0 mm)
64.5 inches
31.1 lbs
(14.1 kg)
31.7 lbs
(14.4 kg)
70U8***H
61.7 inches
(1567.2 mm)
34.5 inches
(875.5 mm)
3.0 inches
(77.2 mm)
36.5 inches
(926.6 mm)
11.0 inches
(280.0 mm)
69.5 inches
41.9 lbs
(19.0 kg)
42.8 lbs
(19.4 kg)
75U8***H
65.7 inches
(1668.1 mm)
37.7 inches
(957.8 mm)
3.0 inches
(77.0 mm)
39.7 inches
(1007.9 mm)
11.0 inches
(280.0 mm)
74.5 inches
47.6 lbs
(21.6 kg)
48.5 lbs
(22.0 kg)
85U8***H
74.4 inches
(1889.9 mm)
42.7 inches
(1083.5 mm)
3.0 inches
(77.0 mm)
44.6 inches
(1132.8 mm)
12.8 inches
(326.0 mm)
84.5 inches
62.6 lbs
(28.4 kg)
63.7 lbs
(28.9 kg)
* : 0~9, A~Z
VESA
x (mm) (mm) x 4 (mm)
(inches)
(inches)
(inches)
43U8***H 200 x 200
23-25
+
M8 1.25 5.7 14.9 8.4
50U8***H 200 x 200
23-25
+
M8 1.25 8.3 17.9 9.2
55U8***H 200 x 200
23-25
+
M8 1.25 10.8 20.2 9.2
58U8***H 200 x 200
23-25
+
M8 1.25 12.3 21.6 9.3
65U8***H 200 x 200
23-25
+
M8 1.25 15.7 24.5 9.2
70U8***H 400 x 300
10-12
+
M8 1.25 14.4 23.0 8.3
75U8***H 400 x 300
10-12
+
M8 1.25 17.6 25.0 8.3
85U8***H 400 x 300
10-12
+
M8 1.25 22.6 29.3 8.3
* : 0~9, A~Z
: Wall-Mount Bracket
The length of the screw protruding
past the bracket must be between
10 to 12 mm, the total length of the
screw will depend on the depth of
the bracket used.
70inch
