Model - SDC 760
STEAM DRYER CLOSET
STOP
DO NOT RETURN TO STORE!
HAVE QUESTIONS OR NEED SERVICE?
1-800-776-3538
Read the instructions carefully and keep for
future reference. Information maybe updated
from time to time so please refer to the
website for the latest version of the manual.
1. Scan Chat-AI
Open Smart Phone
Open Camera
Click the Link
2. Register online at ApplianceDesk.com/Warranty
3. Chat-AI is also used to obtain Product Information,
Manuals and Updates
Congratulations on your new Steam Dryer Closet!
All-in-one steaming, ironing and drying
Refresh feature
Fewer or no trips to the dry cleaner
No more ironing
Sanitizes and deodorizes
Easy to use and maintain
In addition to its contemporary design, this is a highly sophisticated
engineered product that will give you many years of satisfaction.
Here are some of the best reasons for buying your appliance for the
ultimate laundry experience:
Safety
Keep air outlet clear of obstructions and do not touch this area as the high
temperature could cause burns.
When positioning the appliance, ensure the electrical cord is not trapped,
damaged or near water.
Do not place multiple portable socket-outlets at the rear of the appliance.
Never unplug the appliance by pulling on the power cord. Grip the plug firmly
and pull straight out to remove from wall socket.
Do not use a damaged power cord.
Do not use an extension cord.
Do not open the appliance when it is operating, as the high temperature
may cause burns or injuries.
Children should be supervised to ensure that they do not climb in or play
with the appliance.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction.
Safe Disposal
Before discarding the appliance, remove the door in order to prevent
risk of child entrapment.
Please dispose of this appliance in accordance with local regulations.
WARNING: This product contains chemical known to the State of California
to cause cancer and birth defects or other reproductive harm.
California Proposition 65
1
Place indoors in a dry place.
Place the appliance away from sources of heat and high humidity, and also
away from areas or moisture and exposure to cold temperatures.
Ensure the appliance is placed on a flat, level surface. The feet of the
appliance can be adjusted to make it level.
Plug the appliance into a dedicated, properly installed-grounded wall outlet.
Check the plug and cable before you connect the power and make sure of
the correct 110 voltage.
Ensure that the plug is accessible.
Before use, clean the outside and inside surfaces with a soft damp cloth.
Installation
The Steam Dryer Closet is a perfect addition to use along with the washer and
dryer. It is used instead of an iron to prevent and remove wrinkles from clothing.
It is used for drying, steaming and sterilizing washed clothing. Items that can
be steamed or dried include: pants, jeans, shirts, tops, scarves,
jackets (cloth - not leather).
Description
Advantages of the Steam Dryer Closet:
An improvement on hand-held steamers
Eliminates wrinkles, so no ironing is needed
Alternative to dry cleaning (but may not replace it completely)
Steam and UV light sanitizes, eliminates germs and odors
Freshens and deodorizes clothes
Please do not use for drying shoes, fur, leather, sprayed fabrics, plastics,
or other non-cloth materials.
Note: If a clothing care label specifically states “Dry Clean Only” then
this item should be taken to a professional dry cleaner and should not
be treated in this appliance.
2
P3 – Chat-AI should be QR-Code. In 2 places.
P6. Advantage of the Steam Dryer Closet – It a title, so Bold or Italics
P7/8 - @Arti. Change Perfume to Fragrance or Aroma?
P7 - Hangars = Hangers (2 places)
P9 – Enlarge control panel to full widthof page so it is easily readable
Fill water icon decription is missing
P12 - Leave the door open so the water can evaporate and prevent mold
(Use Italics for all such instructions to draw attention to it)
P14 – Environmental Protection List – is is nececcary to provide this?
Remove unless ETL tells us to include
nd rd
P15 – In 2 and 3 sentences, only Our Missiona dn Our Vision are in Bold.
Preparing to use the Steam Dryer Closet
This appliance is intended for household use.
This appliance is to be used only for drying, steaming and sterilizing
washed clothing.
Hangers - The Steam Dryer Closet comes equipped with 4 hangers. Hang the
clothes, smooth the surfaces and ensure that the 4 hangers are placed in the
grooves on the hanging rod. This allows for adequate spacing between the
hanging clothes to achieve the best ironing and drying results. Do not add
extra hangers with more clothes.
Hanging Rod - The mechanism in the hanging rod swings the clothes in an
oscillating back and forth motion to achieve the effect of ironing clothes.
Vents - The vents at the base produce steam.
UV Light - The Ultraviolet (UV) Light at the top of the appliance sanitizes
the clothes.
Hanging Rod
Hangers (4)
Vents
Clamps (6)
Adjustable Feet
Air Vent
Fragrance Bottle
Water Tank
3
P3 – Chat-AI should be QR-Code. In 2 places.
P6. Advantage of the Steam Dryer Closet – It a title, so Bold or Italics
P7/8 - @Arti. Change Perfume to Fragrance or Aroma?
P7 - Hangars = Hangers (2 places)
P9 – Enlarge control panel to full widthof page so it is easily readable
Fill water icon decription is missing
P12 - Leave the door open so the water can evaporate and prevent mold
(Use Italics for all such instructions to draw attention to it)
P14 – Environmental Protection List – is is nececcary to provide this?
Remove unless ETL tells us to include
nd rd
P15 – In 2 and 3 sentences, only Our Missiona dn Our Vision are in Bold.
Fragrance Bottle - optional (dilute fragrance with water)
Lift out the bottle.
Remove the diffuser wick.
Add fragrance and water mixture to the bottle. Mixture should be 1 measure
of fragrance to 9 measures of water.
Insert the diffuser wick into the bottle.
Place the bottle into the opening of the Water Tank Cover.
Note: The clothes must be spun completely in the washer or if hand washed,
the clothes must be wrung out thoroughly so that there is minimal moisture.
This will increase the efficiency and time required to dry the clothes.
A fragrance bottle is included for the option of adding a fragrance to the
clothes being steamed and dried. The bottle is in the Water Tank Cover.
Water Tank - The steaming process uses water from the Water Tank, located
at the base of the appliance.
No plumbing is needed.
The Water Tank must always be filled prior to using the appliance. Lift the
cover and pour water at least half full into the Water Tank, and then
replace the cover.
If the Water Tank is not full, “Fill Water” will illuminate on the Control Panel.
4
Clamps - There are 6 clamps attached to stretchable cords at the base of the
appliance. These clamps can be pulled up and clamped onto the clothes,
allowing the material to be stretched so that it can be steamed evenly to
prevent wrinkles.
5
Use the Control Panel on the door of the Steam Dryer Closet to select the
steaming, drying or sanitizing cycle.
Control Panel
Heavy
Normal
Light
PROGRAM
Extra
Normal
Damp
On/O ffPower icon - Powers on the Steam Dryer Closet. All the
selections on the Control Panel illuminate.
Program - Steam dries clothes. Select Heavy, Normal or Light cycle. The
selected program will illuminate.
Refresh - Quickly steams and sanitizes dry clothes.
Dry - Dries washed wet clothes. Select the dry level: Extra, Normal or
Damp Dry.
Sanitize - The UV light sanitizes clothes.
Delay - If you want to start the cycle at a later time use Delay. After selecting
Program, Refresh, Dry, or Sanitize, you have the option of delaying when the
steaming/drying begins. Each time you press Delay, the time increases in
one-hour increments from 1 hour to 8 hours.
Start icon - Begins the steaming/drying process. You may pause the
cycle by pressing this icon . Then press again to restart.
Fill Water - Fill Water will illuminate if there is no water in the Water Tank.
The appliance will not operate and an error of Er3 will display on the
Control Panel. Fill the Water Tank with water to resume operation.
P3 – Chat-AI should be QR-Code. In 2 places.
P6. Advantage of the Steam Dryer Closet – It a title, so Bold or Italics
P7/8 - @Arti. Change Perfume to Fragrance or Aroma?
P7 - Hangars = Hangers (2 places)
P9 – Enlarge control panel to full widthof page so it is easily readable
Fill water icon decription is missing
P12 - Leave the door open so the water can evaporate and prevent mold
(Use Italics for all such instructions to draw attention to it)
P14 – Environmental Protection List – is is nececcary to provide this?
Remove unless ETL tells us to include
nd rd
P15 – In 2 and 3 sentences, only Our Missiona dn Our Vision are in Bold.
6
Operation
This program first has high temperature steam, followed by drying and
finally UV to sanitize.
1. Hang up damp or dry clothes
2. Press and hold the Power icon
3. Press Program to select Heavy, Normal or Light depending on the material
to be steamed and dried. Each time you press Program, it illuminates Heavy,
Normal or Light. Press Program until the selected program illuminates.
4. Press Start
The Program selection remains illuminated, and you can hear the
steam starting.
The Display Panel shows the time for the program selected and then counts
down the minutes until the end, when it goes o ffand the program is no
longer illuminated.
Heavy - 60 minutes
Normal - 50 minutes
Light - 40 minutes
1. Hang up dry clothes
2. Press and hold the Power icon
3. Press Refresh
4. Press Start
Refresh
This is a quick 20 minutes cycle which uses steam, drying and UV light. This is
recommended for clean clothes that are hanging in the closet which need a
refresh and light ironing.
Refresh remains illuminated and you can hear the steam starting.
Display Panel shows 20 minutes, and then counts down the minutes until the
end, when it goes o ffand Refresh is no longer illuminated.
Program
Once the clothes have been hung up in the Steam Dryer Closet, close the door
firmly and select the cycle on the Control Panel.
Dry
This cycle has only the drying function and is recommended for shirts, jeans
and pants that would normally get wrinkled in the dryer. The Steam Dryer
Closet will dry evenly and reduce or eliminate wrinkles.
1. Hang up wet clothes
2. Press and hold the Power icon
3. Press Dry to select the level of dry: Extra, Normal or Damp
4. Press Start
The Dry level selected will illuminate and you can hear the appliance is on.
7
Sanitize
Only the UV light functions in this program to sterilize clothes.
1. Hang up dry clothes
2. Press and hold the Power icon
3. Press Sanitize
4. Press Start
Sanitize will illuminate and you can hear the appliance is on.
The Display Panel shows the minutes based on the dry level selected, and
then counts down the minutes until the end, when it goes o ffand the dry
level is no longer illuminated.
The Display Panel shows 10 minutes, and then counts down the minutes until
the end, when it goes o ffand Sanitize is no longer illuminated.
Extra - 120 minutes
Normal - 90 minutes
Damp - 60 minutes
The Delay function can be used with any of the 4 selections: Program, Refresh,
Dry and Sanitize.
After you have pressed the Power Icon and one of the cycles, but before you
press Start, you can press Delay to set a desired amount of time before the
cycle begins.
Press Delay repeatedly to increase the time in 1-hour increments up to 8 hours.
After the delay time is selected, remember to press Start.
The Display Panel shows the delay time selected, and then counts down until
the time has elapsed. At this point, Delay goes o ffand the selected cycle begins.
The selected cycle remains illuminated, and the Display Panel shows
the time for the selected cycle.
Delay
8
After the cycle ends, there may be residual water produced by the steam that
remains at the base of the appliance.
Leave the door open so the water can evaporate and prevent mold.
You can also use a cloth to wipe away the water.
Clean the outside and inside of the appliance regularly, using water and
mild detergent.
The Water Tank is built into the base of the appliance. In order to clean it,
lift the cover and empty the tank by scooping out as much water as possible.
Then wipe it dry with a towel. If needed, apply mild detergent and wipe the
inside of the Water Tank.
Maintenance
Troubleshooting
Problem Possible Cause Solution
Does not work Power is not on or the unit is
not connected to power
source.
Check fuse and Power socket.
Connect to Power
Plug in correctly
Control Panel does
not work
The Control Panel is wet or
dirty
Clean and dry the
Control Panel
Cycle is complete
but clothes are not
dry
Clothes are heavy or thick
Dry clothes partially in a
dryer and then use the
Dry cycle
There is no steam
Water Tank is empty
Fill the Water Tank
The outside of the
appliance is hot
When drying, heat may build
up in the appliance
This is normal
In most cases, when your Steam Dryer Closet fails to work, the problems
arising can be easily solved without having to call for a technician. Before
calling for assistance, always check these points. Repairs should only be
done by an authorized service agent.
Error Codes
9
Error Codes Possible Cause Solution
Er 1 Error in Control Board Call for service
Er 2 The door is open
Faulty door sensor If error remains, call for service
Close the door
Er 3 Water Tank does not have
enough water
Fill water in Water Tank
10
Environmental Protection List
Component
Name
Toxic and Harmful Substances or Elements
(Pb)
Lead Mercury
(Hg)
(Cd)
Cadmium
chromium
Hexavalent
(Cr/VI)
(PBB)
biphenyls
Polybrominated
ethers (PBDE)
diphenyl
Polybrominated
Upper cover
assembly
o o o o o o
assembly
Upper-level o o o o o o
Housing o o o o o o
Liner assembly o o o o o o
Fan assembly o o o o o o
PTC assembly o o o o o o
Bottom cover o o o o o o
Electrical
components
x o o o x x
PCB board
assembly
x o x o x x
x: means that content of this hazardous substance exceeds the specified range of GB/T 26572 in
all homogeneous materials of this component.
o: means that content of this hazardous substance in all homogeneous materials of this
component is within the specified range of GB/T 26572.
This table is prepared in accordance with the relevant stipulations in SJ/T11364.
Specifications Table
Model
Total Hanging Capacity
Rated Power
Net Weight
Power Cord Length
SDC 760
4 pcs / <33lbs (15kg)
1500W
137 lbs
6 feet (1.8m)
Product Dimensions HxWxD (inches)
60 x 16 x 22
Electrical
110V / 60Hz
