Hearth&HomeTechnologies•DM6036/DM8042GlassDoors•33797RevG•05/01/14
1
tm
Models:
DM6036
DM8042
Glass Doors
Installation
Instructions
Thesebi-foldglassdoorshavebeentestedforusewithspecicHearth&HomeTechnologiesproducts.Checkwithyour
localbuildingcodeagencybeforeyoubegininstallationtoensurecompliancewithlocalcodes,includingtheneedforper-
mitsandfollow-upinspections.Ifyouencounteranyproblemsregardingcodeapprovals,orifyouneedclaricationofany
oftheinstructionscontainedhere,contactyourHearth&HomeTechnologiesdealer.Forthedealernearestyou,please
visitwww.hearthnhome.com.
Note: Anarrow()foundinthetextsignieschangeincontent.
WARNING
Hot screen/mesh and glass doors will cause burns.
• Donottouchscreen/meshorglassdoorsuntilcooled
• NEVERallowchildrentotouchscreen/meshorglass
doors
• Keepchildrenaway
• CAREFULLY SUPERVISEchildren in sameroomas
replace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keepclothing,furniture,draperiesandotherflammable
materialsaway.
HOT SURFACES!
Screen/mesh,glassdoorsand
othersurfacesarehotduring
operationANDcooldown.
CAUTION! Risk of Cuts/Abrasions. Wear protective
gloves and safety glasses during installation. Sheet metal
edges are sharp.
• Startingwiththeleftsidegoinginrst,slipthebottom
doortrackalongthefrontedgeofthehearthrefractory
andlineitupendtoend.SeeFigures1-2.
• Removethetwoscrewsoneachendofthetopfrontface
forthetopdoortrack.SeeFigure3.
• Installthetopdoortrackbehindthefrontface.Secure
thetrackinplacewithonescrewinthecenter.
• Oneachendofthetopdoortrack,replacethetwoscrews
removedinStep2,addingaspringcliptoeachendof
thedoortrack.SeeFigure3.
Figure 1 - Install the Door Track
Figure 2 - Installed Door Track
Hearth & Home Technologies • DM6036/DM8042 Glass Doors • 33797 Rev G • 05/01/14
2
• InstalltheSideFillers
a.Pushthescreenstothecenterofthereplace
opening.
b.Slipthesidellerinfrontofthesideregractorywith
thenotchtothebottomandthetabstothefront.
SeeFigure4.
Figure 4 - Slide the Side Filler In
SPRING CLIPS
TOP DOOR
TRACK PLACED
BEHIND THE
FRONT FACE
(FRONT FACE)
TOP DOOR TRACK
ADJUSTMENT
SCREWS
1 Screw
Figure 3 - Spring Clip Placement
Figure 5 - Fastening the Side Filler
Note: Iftherearenoholesinthesidecolumn,
usethesidellerasatemplateanddrillholes
inthecolumn.Fastenllertocolumn.
c.Fastenthesidellertothecorrespondingholesin
thecolumn.SeeFigure5.
d.Repeatfortheotherside.
• Fold up one door (handles at the bottom) and set the
bottompin intotheholein thebottomdoortrack.See
Figure6.
Notch
• Slidethetoppinsonthedoorintothetopdoortrack.Slide
thedooroveruntilthepivotpinsnapsintothespringclip.
SeeFigure7.
• RepeatSteps6-7fortheotherside.
• To adjust the dooralignment,loosenthescrewsatthe
topspringclip,slidingdoorsinorout,thentighteningthe
screws.
Figure 6 - Bottom Pin/Door Track
Figure 7 - Pivot Pins/Top Door Track
