OSCILLATING DIGITAL
CERAMIC TOWER HEATER
WITH REMOTE
23" | 1500W / 750W
MODEL 2VAHCT23
OWNER’S MANUAL
2
CONTENTS
(Continued)
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual.
Also, write the store name/location and date purchased below:
Store Name: ___________________________________________________________
Location: ______________________________________________________________
Date Purchased: _______________________________________________________
FEATURES
• Three Heat Settings:
- Energy Save Mode
- High - 1,500W (5,120 BTU)
- Low - 750W
• Timer and Digital Thermostat
• Top Mounted Control Panel
• 70° Oscillation for Wide Coverage
• Full Function Remote Control
• Safety Overheat Protection
• Safety Tip-Over Switch
• Stay Cool Carry Handle
• 120V AC, 60Hz, 12.5A
3
CONTENTS
Safety Guidelines ........................................................................................4
Usage ...........................................................................................................8
Care and Maintenance ..............................................................................11
Important Safety Features ........................................................................12
Changing the Battery ................................................................................12
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference.
Illustrations in this manual are for explanatory purposes only, your actual
product may look slightly dierent.
4
INTENDED USE
This product is intended for indoor residential and oce use only, not for
industrial or other commercial applications. Use only with electrical wiring
that is in good working order and that meets applicable codes and ordinances.
This heater must be plugged into a 120 Volt AC, 15 AMP (or larger) circuit. Do
not plug anything additional into the same circuit. If you have any questions
whether your wiring is adequate, consult a qualied electrician. Risk of re,
overheating, malfunction, property damage, injury or even death may result if
not adhered to.
Use your heater only with a working smoke detector located in the vicinity of
your heater.
While using your heater, you should follow the IMPORTANT INSTRUCTIONS
listed below. As part of those instructions, we have used the word “WARNING”
to indicate the level of hazard: WARNING indicates a hazard which, if not
avoided, could result in injury or death.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of electric shock, re, or injury to persons, including
the following precautions:
• Read all the instructions before using this heater.
• This heater is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. Use provided handle when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers, clothes and curtains at
least 3 ft. (1m) from the front of the heater and keep them away from the sides
and rear.
• Do not use heater unattended. Use of extreme caution is necessary when any
heater is used by or near children, invalids, disabled persons or pets.
• Do not operate the heater with a damaged power cord or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater
to authorized service facility for examination, electrical or mechanical
adjustment or repair.
• Do not use heater outdoors.
SAFETY GUIDELINES
5
SAFETY GUIDELINES
• Use your heater only in dry environments. This heater is not intended for
use in a bathroom, laundry area, or similar locations, or near sinks, washing
machines, swimming pools or other sources of water. Never locate heater
where it may fall into a bathtub or other water container. Do not use in damp
environments such as ooded basements.
• Do not place the heater on a small, unleveled, uneven or any surface which
might allow heater to tip or fall.
• For proper operation, heater should be placed on a smooth, non-combustible
surface. Do not place on rugs, carpet, vinyl ooring or other plastic surfaces.
Not for use outdoors or in wet areas.
• This heater is not designed as a primary heat source.
• Always plug heaters directly into a wall outlet / receptacle. Never use with an
extension cord or relocatable power tap (outlet / power strip). Always unplug
heater when not in use.
• Do not run power cord under carpeting. Do not cover cord with throw rugs,
runners or similar coverings. Arrange cord away from trac area where it will
not be tripped over.
• To disconnect heater, turn controls o then remove plug from outlet.
• Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re or damage the heater.
• To prevent a possible re, do not block air intakes or exhaust in any manner.
Do not use on soft surfaces like a bed, where openings may become blocked.
• A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint or ammable liquids are used or stored.
• Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause re, electric shock or injury to
persons or property.
• Hyperthermia can result in death. Symptoms of hyperthermia include high
body temperature, headache, nausea, vomiting, tiredness, dizziness, fainting,
and rapid pulse. If you begin to experience symptoms related to hyperthermia,
turn o the heater and seek medical attention.
• To avoid excessive room temperatures which can cause hyperthermia: DO
NOT leave product running unattended in a conned space around infants, or
individuals with reduced physical, sensory, or mental capabilities.
(Continued)
6
HEADLINE
(Continued)SAFETY GUIDELINES
a) Remove and immediately recycle or dispose of used batteries according to
local regulations and keep away from children. DO NOT dispose of batteries
in household trash or incinerate.
b) Even used batteries may cause sever injury or death.
c) Call a local poison control center for treatment information
d) Always use the same size and grade battery as CR2025 for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat above 104°F or
incinerate. Doing so may result in injury due to venting, leakage or explosion
due to chemical burns.
h) Ensure the batteries are installed correctly according to polarity (+ and -).
i) Do not mix old and new batteries, dierent brands or types of batteries,
such as alkaline, carbon-zinc, or rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries from Equipment
not used for an extended period of time according to local regulations.
k) Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and keep them away from children.
(Continued)
7
SAFETY GUIDELINES
READ AND SAVE THESE INSTRUCTIONS
WARNING SHOCK HAZARD
Use your heater only in dry environments. This heater is not intended for use in
a bathroom, laundry area, or similar locations, or near sinks, washing machines,
swimming pools or other sources of water. Never locate heater where it may fall
into a bathtub or other water container. Do not use heater outdoors. Do not use
in damp environments such as ooded basements.
WARNING: HOT SURFACES
Do not touch body of heater when in use. This heater is hot when in use, to
avoid burns, do not let bare skin touch hot surfaces. If provided, use handles
when moving this heater.
WARNING: FIRE HAZARD
Heater has hot and arcing or sparking parts inside. Do not use near combustible
materials or ammable gases or sources of heat. DO NOT USE in areas where
gasoline, paint or ammable materials are used or stored. Keep combustible
materials such as furniture, pillows, bedding, papers, clothes and curtains at least
3 ft. (1m) from the front of the heater and keep them away from the sides and rear.
To prevent a possible re, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked. Do not
insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock, re, or damage the heater.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate electrical system
that is up to code.
CAUTION: TO PREVENT ELECTRIC SHOCK
This product has a polarized two prong plug (one blade is wider than the other)
that must be fully inserted into a matching properly grounded outlet. This plug
is designed to t a polarized outlet only one way. If the plug does not t fully
into the outlet, reverse the plug. If the plug still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
DO NOT operate any heater with a damaged cord or plug or after heater
malfunctions, has been dropped or damaged in any manner. Do not
operate heater with a broken heating element or ceramic cone or any visual
imperfections. Disconnect power before servicing.
(Continued)
8
USAGE
THE PLUG NEEDS TO BE INSTALLED DIRECTLY INTO A WALL OUTLET. NEVER
USE AN EXTENSION CORD OR ANY TYPE OF ADAPTER. THE HEATER SHOULD
NEVER SHARE A WALL OUTLET WITH ANOTHER APPLIANCE, NO MATTER
HOW SMALL.
PET OWNERS NOTE:
The health of birds and some small pets are extremely sensitive to the fumes
given o during the initial use of many appliances. Although these fumes are
not harmful to humans, it is recommended that this heater not be used around
birds and small pets during its initial use until the manufacturing corrosion
coatings burn o.
WARNING: LITHIUM BATTERY COIN CELL SAFETY
Keep lithium coin batteries out of the reach of small children; coin cell batteries
can be accidentally ingested. If ingested, these batteries may leak harmful
contents causing chemical burns, perforation of soft tissue, and in severe
cases may cause death. Lithium coin batteries must be removed immediately if
swallowed. Seek medical attention immediately. If you or your doctor suspects
that a battery has been ingested for assistance in the US call the NATIONAL
BATTERY INGESTION HOT LINE any time at (202) 625-3333: in Canada call
416-813-5900.
USAGE
HEATER OPERATION
Always operate the heater in the upright position following all instructions and
recommendations listed in this manual.
HEATER LOCATION
Position the heater in the coldest area of the room.
HEATER CONNECTION
Plug heater directly into 120 Volt AC, 60Hz wall outlet. Be sure plug ts tightly
in outlet. A loose connection may cause overheating and damage to the plug
or heater.
NOTE: To prevent overloading a circuit, do not plug the heater into a circuit
that is servicing other electrical needs.
9
USAGE
TURNING HEATER ON
To begin using the heater:
1. Plug the heater directly into a wall outlet—never use any type of extension
cord or adapter. The Power Indicator light will illuminate, indicating power
availability.
2. Press the POWER
button to switch the heater on. By default, it will be
in Fan-only setting. The fan indicator will light up, and the LED display will
show the default temperature setting of 95°F.
During the initial use of the heater, you may notice a slight odor or smoke. This
is normal and results from the heating element lubrication “burning o.” It will
dissipate after a few minutes of operation.
POWER LEVEL SWITCH
This heater has 1 fan-only setting and 3 heat settings: FAN, LOW, HIGH and
ENERGY SAVE. Select the heat setting that best meets your heating needs.
The ENERGY SAVE setting provides comfortable heating in most rooms, while
saving you money on energy costs.
HEAT/FAN SETTING
To adjust the heat settings:
(Continued)
PULL
PUSH
CONTROL PANEL
Mode Button
Power Button
Oscillation Function
Thermostat
Adjustment
Energy Save
Mode
Timer
Function
High Heat Indicator
Low Heat Indicator
Fan Indicator
10
Press the MODE button once for LOW Heat (750W). The low heat indicator
will illuminate.
Press the MODE button
a second time for HIGH Heat (1,500W). The high
heat indicator will illuminate.
Press the MODE button
a third time for FAN-ONLY setting.
ENERGY SAVE MODE
Provides comfortable heating in most rooms, while saving you money on
energy costs.
1. Press the ENERGY SAVE button
to activate Energy Save mode.
2. The ENERGY SAVE indicator light will turn on, and the LED display will
turn OFF.
3. The thermostat temperature will automatically adjust to 68°F.
• If the room temperature falls BELOW 60°F, the heater will activate in
HIGH heat mode.
• If the room temperature is between 60°F and 68°F, the heater will
activate in LOW heat mode.
• If the room temperature is ABOVE 68°F, the heater will enter STANDBY
mode. In STANDBY mode, the fan and heating elements will turn OFF.
The heater will exit STANDBY mode only if the room temperature drops
BELOW 68°F.
THERMOSTAT ADJUSTMENT
When the heater is in LOW or HIGH heat mode:
Press the THERMOSTAT button
until your desired temperature is
illuminated. You can adjust the temperature between 60°F and 95°F. It’s typical
for the heating element and fan to cycle on and o automatically to maintain
the desired temperature setting. Please allow for a margin of dierence
between the set temperature and the actual room temperature for the heating
element’s cycling.
If the room temperature is BELOW the thermostat setting, the heater will turn
ON at the selected heat setting.
USAGE
(Continued)
11
If the room temperature is ABOVE the thermostat setting, the heater will enter
STANDBY mode and the power light will ash.
NOTE: It is normal for the heater unit to cycle heating On and heating O as
it maintains the set temperature.
OSCILLATION FUNCTION
The oscillation function will work in any mode. Press the OSCILLATION button
to oscillate the heater from left to right at a 70° angle. To turn the oscillation
function OFF, press the OSCILLATION button
again.
TIMER FUNCTION
The TIMER function operates in any mode, with the timer indicator lighting up
when active:
Set the length of operation from 1 to 9 hours by pressing the TIMER button
Each press increases the operation time by 1 hour, displaying the time set on
the LED display.
To disable the timer function, continuously press the TIMER button
until
the LED display shows 0H.
NOTE: The timer function is not an excuse to leave the heater unattended.
TURNING OFF
To turn the heater OFF, press the POWER button
.
NOTE: When the unit is powered o, the fan may continue to run for a while
to cool o the ceramic elements and dispense any retained heat. The unit
will then shut o automatically. Heater should be unplugged when not in use.
CARE AND MAINTENANCE
12
SAFETY GUIDELINES
IMPORTANT SAFETY FEATURES
The heater is equipped with an automatic overheat protection device located
inside the body of the heater. If the heater grille is obstructed, or if the heater
gets too hot for any reason, the automatic overheat protection device will turn
the heater o. To reset the heater, simply turn power o and unplug the heater
for 10 minutes until it cools down and then you may plug the heater in and
restart. Be sure that the heater is on a smooth level surface with no obstructions.
The heater is also equipped with a safety tip-over switch to turn power o to
the heater when the heater tips over. To resume heater functions simply stand
heater upright.
CHANGING THE REMOTE BATTERY
Remove clear insulating lm from
remote control battery before
remote control use.
To replace remote control battery,
insert 1 pc CR2025 battery.
Remote Control Clear Insulating Film
PULL
PUSH
Remote Control Battery Cover CR2025 Battery
13
SAFETY GUIDELINES
(Continued)
CARE AND MAINTENANCE
WARNING
ALWAYS UNPLUG THE CORD BEFORE MOVING OR SERVICING. Do not use harsh
chemical or abrasive cleaners. DO NOT IMMERSE THE HEATER IN WATER. Allow
heater to dry completely before use.
CLEANING
IMPORTANT! DO NOT IMMERSE HEATER IN WATER! Clean the heater grille
with the vacuum brush attachment on your vacuum cleaner. This will remove lint
and dirt from inside the heater. DO NOT ATTEMPT TO TAKE APART THE HEATER.
DO NOT REMOVE THE HEATER GRILLE. Clean the body of the heater with a
soft cloth.
CAUTION
Do not use gasoline, benzene, paint thinner, harsh cleaners, etc. as they will
damage the heater. NEVER USE ALCOHOL OR SOLVENTS.
REPAIR
DO NOT OPERATE THE HEATER WITHOUT THE GRILLE IN PLACE. DO NOT USE
THE HEATER IF IT HAS MALFUNCTIONED OR BECOME DAMAGED IN ANY WAY.
STORAGE
Keep original carton for storage of the heater. Coil and tie the power cord to
avoid damage during storage.
833-950-1185 | support@visionairproducts.com
www.visionairproducts.com
4560 W. 160th Street
Cleveland, OH 44135
Printed in China | 0424_M020
