ELECTRIC FIREPLACE
HEATER
23" | 1500W / 750W
MODEL 1VAHFP21
OWNER’S MANUAL
2 3
CONTENTSCONTENTS
(Continued)
Safety Guidelines ........................................................................................4
Usage ...........................................................................................................6
Overheating Safety .....................................................................................7
Cleaning Your Fan Heater ............................................................................7
Disposal of Electrical and Electronic Equipment .......................................7
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference.
Illustrations in this manual are for explanatory purposes only, your actual
product may look slightly dierent.
CONSUMER PRODUCT INFORMATION
For your own records, please attach a copy of your sales receipt to this manual.
Also, write the store name/location and date purchased below:
Store Name: ___________________________________________________________
Location: ______________________________________________________________
Date Purchased: _______________________________________________________
4 5
SAFETY GUIDELINES
IMPORTANT SAFEGUARDS
When using any electrical appliance basic precautions should be followed.
Please read the following instructions as they are for your benet and safety:
1. Make sure the power supply used corresponds to the rating label.
2. Never obstruct or block any openings of the heater.
3. Use the heater only on a at surface.
4. Always disconnect the appliance from the main power supply when not in
use and when cleaning.
5. Do not leave the heater “ON” unattended.
6. Never cover the heater as this may lead to risk of re.
7. Keep the appliance a distance of at least 90 cm from any combustible
material such as furniture, curtains, bedding, clothes or papers.
8. Do not use this heater in the immediate surrounding of a bath, a shower or
a swimming pool.
9. Do not immerse the heater in water or allow for water to come into contact
with the plug or control device.
10. Keep this heater clean. Do not allow objects to enter the ventilation
opening as this may cause electric shock, re of damage to the heater.
11. Close supervision is require when any appliance is used near or by children.
12. Never allow the cord to touch wet or hot surfaces, become twisted or be
within the reach of children.
13. Do not use outdoors
14. Do not place on or near a hot gas electric burner.
15. If the supply cord is damaged, it must be replaced the manufacture or its
service agent or a similarly qualied person must replace it in order to
avoid a hazard.
16. Do not use the appliance for other than its intended use as described in
this instruction book.
17. Do not place the heater immediately below a socket outlet.
18. This appliance is intended for household use only.
19. Do not leave the heater on overnight.
SAFETY GUIDELINES
20. While cleaning, make sure not to use a wet cloth or use water on any part of
the unit, as this may cause a short circuit or electrical shock.
21. Do not use this unit in any area where water present.
22. Make sure the power cord is placed at the back away from the front panel
of the heater.
23. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
24. Children should be supervised to ensure that they do not play with the
appliance.
25. Caution: Do not cover anything on your heater when in use.
26. The heater must not be placed near a socket and the following hint: This
fan-heater must not be used near a bath, shower or swimming pool.
27. This heater is not equipped with a device to control the room temperature.
Do not use this heater in small rooms when they are occupied by persons
not capable of leaving the room on their own, unless constant supervision
is provided.
28. NOTE: It is normal when the heaters are turned on for the rst time or when
they are turned on after having not been used for a long period of time,
the heaters may emit some smell and fumes. This will disappear when the
heater has been on a short while.
29. Hyperthermia can result in death. Symptoms of hyperthermia include
high body temperature, headache, nausea, vomiting, tiredness, dizziness,
fainting, and rapid pulse. If you begin to experience symptoms related to
hyperthermia, turn o the heater and seek medical attention.
30. To avoid excessive room temperatures which can cause hyperthermia: DO
NOT leave product running unattended in a conned space around infants,
or individuals with reduced physical, sensory, or mental capabilities.
(Continued)
6 7
HEADLINE
(Continued)
SAFETY, CLEANING, DISPOSAL
USAGE
HOW TO OPERATE
THE PLUG NEEDS TO BE INSTALLED DIRECTLY INTO A
WALL OUTLET, NEVER USE AN EXTENSION CORD OR
ANY TYPE OF ADAPTER. THE HEATER SHOULD NEVER
SHARE A WALL OUTLET WITH ANOTHER APPLIANCE.
Turn on the ON/OFF main switch, which is located
on the back bottom corner of the replace.
FLAME
Press the left button
to start the ame eect.
Press it again to turn o the ame.
HEAT SETTING
Press the right button
to start the heating mode.
Press once for low heat; press twice for high heat; press again to turn the heat
and ame eect o. The fan will run for 30 seconds before powering o.
TEMPERATURE
Press the button
to adjust the temperature from 59-100°F (15-38°C).
TIMER
Press the button
to set the timer for up to 12 hours.
REMOTE CONTROL
The remote requires a line-of-sight path to allow for the signal to be received by
the unit. Position the unit so the receiver lens is visible from the remote control.
The symbols on the remote correspond to the symbols on the main unit, you
can use it to get corresponding function.
The remote control uses one button cells, model No. CR2025 (3V). We
recommend the use of Lithium type battery for longer use.
Note: Please follow battery disposal instruction on battery packaging, or
contact your local councils for safely disposal of batteries.
OVERHEATING SAFETY DEVICE
The heater is tted with a safety device. If the heater overheats, it will stop
working. Please turn the heater o and inspect of blockage of inlet or outlet.
The safety device will restart the heater after several minutes.
If the safety device fails to restart the heater again, contact customer service
for troubleshooting.
CLEANING YOUR FAN HEATER
1. Always disconnect the appliance from the main supply before cleaning.
2. Clean the outside of the heater by wiping with damp cloth and bu with a
dry cloth.
3. Do not use Benzine or any other detergents / solvents or chemical agents
to clean the heater.
DISPOSAL OF ELECTRICAL AND
ELECTRONIC EQUIPMENT
To protect our environment and to recycle the raw materials
used as completely as possible, the consumer is asked to return
unserviceable equipment to the public collection system for
electrical and electronic. The symbol of the crossed indicates
that this product must be returned to the collection point for
electronic waste to feed it by recycling the best possible raw
material recycling.
By ensuring this product you will prevent possible negative eects on the
environment and human health, which could otherwise be caused due to
improper disposal of that product. The recycling of materials from this product
will help to preserve a healthy environment and natural resources.
