GB
Instruction manual
Heated Underblanket Single Size HU 674
Device and controls
Do not use the heated underblanket
when it is folded!
Do not puncture the heated under-
blanket!
Not suitable for children under 3 years!
Only use the heated underblanket in-
doors!
The heated underblanket can be
cleaned in a gentle wash cycle at max.
30°C!
Do not bleach!
Do not dry the heated underblanket in
a tumble drier!
Do not iron the heated underblanket!
Do not dry clean!
IMPORTANT!
Non-observance of these instructions
can result in serious injury or damage
to the device.
WARNING
These warning notes must be observed
to prevent any injury to the user.
CAUTION
These notes must be observed to pre
-
vent any damage to the device..
NOTE
These notes provide useful additional
information on the installation or
operation.
Protection category II
LOT number
Manufacturer
Recycling symbols/codes: These are
used to provide information about the
material and its proper use and recycling.
Explanation of symbols
Important instructions. Retain for future use.
GB Safety instructions
Technical specications
Name and model: medisana Heated Underblanket
Single Size HU 674
Power supply: 220-240V~, 50/60Hz
Power output: 100 watts
Automatic switch-off: after approx. 180 minutes
Dimensions approx.: 150 x 80 cm
Weight approx.: 1.2 kg
Operating conditions: Only use in dry rooms according to
this user manual
Storage conditions: clean and dry
Art. number: 48905
EAN number: 40155 88 48905 1
In accordance with our policy of continual product
improvement, we reserve the right for technical
and design changes without notice.
Warranty and repair terms
Your statutory warranty rights are not restricted by our
guarantee below. Please contact your dealer or the service
centre in case of a claim under the warranty. If you have to
return the unit, please enclose a copy of your receipt and
state what the defect is.
The following warranty terms apply:
1. The warranty period for medisana products is one year
from date of purchase. In case of a warranty claim, the
date of purchase has to be proven by means of the sales
receipt or invoice.
2. Defects in material or workmanship will be removed free
of charge within the warranty period.
3. Repairs under warranty do not extend the warranty period
either for the unit or for the replacement parts.
4. The following is excluded under the warranty:
a. All damage which has arisen due to improper
treatment, e.g. non-observance of the user instructions.
b. All damage which is due to repairs or tampering by the
customer or unauthorised third parties.
c. Damage which has arisen during transport from the
manufacturer to the consumer or during transport to
the service centre.
d. Accessories which are subject to normal wear and
tear.
5. Liability for direct or indirect consequential losses caused
by the unit are excluded even if the damage to the unit is
accepted as a warranty claim.
medisana GmbH
Carl-Schurz-Str. 2, 41460 NEUSS, GERMANY
1
2
48905_HU 674_manual_GB(VT)_202310_L1
Power supply
• Before connecting the device to your power supply, please
ensure that the supply voltage stated on the rating plate is
compatible with your mains supply.
• The control switch should not be covered or placed on or
below the pad while the unit is in operation.
• Keep the mains lead away from hot surfaces.
• Never carry, pull or turn the heated underblanket by the
mains lead and do not let the lead get tangled.
• Never touch a device that has fallen into water. Unplug the
unit from the mains outlet immediately.
• The controls and leads must not be exposed to any kind of
moisture.
• The heated underblanket may only be operated with the
control unit (HU 674) supplied.
For special people
• This appliance must not be used by persons insensitive to
heat and other very vulnerable persons who are unable to
react to overheating.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
• Children below the age of 3 years are not allowed to use this
device, because they are not able to react on overheating.
• The heated underblanket must not be used by young
children over the age of 3 years, unless the control unit has
been adjusted accordingly by its parents or legal guardians
and unless the child has been well instructed how to use
the control unit properly.
• Should you have any concerns about health issues, consult
your doctor before using the device.
• Should you experience persistent pains in the muscles and
joints, please inform your doctor. Persistent pains can be a
symptom of serious illness.
• If you wear a pacemaker, please be aware that the
electromagnetic elds emanating from this electric product
may, under certain circumstances, interfere with the
functions of your pacemaker. Therefore, ask your doctor
and the manufacturer of the pacemaker for advice before
using this product.
• If you experience any pain or discomfort while using the
unit, stop using it immediately.
• Do not crease the appliance by placing items on top of it
during storage.
• Examine the appliance frequently for signs of wear or
damage. If there are such signs, if the appliance has been
misused or does not work, return it to the supplier before
switching it on again.
• The appliance can be used by children older than 3 years
and younger than 8 years under supervision and with the
control always set to minimum temperature value.
• The cable and control unit of the appliance can give rise
to risks of entanglement, strangulation, tripping or treading
if not correctly arranged. The user shall make sure that
excess ties and electric cords shall be arranged in a safe
way.
Operating the device
• Only use the device for its intended use as in the instruction
manual.
• If misused, all guarantee rights shall become null and void.
• Carefully check the heated underblanket before each use,
if you notice wear or damage.
• Do not use if you notice wear, damage or signs of improper
use on the heated underblanket, the switch or the cables or
if the device is not working.
• The heated underblanket may not be operated while folded,
creased, wrapped in a cover or placed around the mattress.
• Neither pierce the blanket with, nor attach safety pins or
other spiky or sharp objects to the device.
• Never use the device unsupervised.
• The device is only for private use and is not to be used in
hospitals.
• Do not fall asleep while the device is switched on. Pro-
longed use of the device at a high setting could lead to skin
burns.
• If the appliance is used on an adjustable bed, check that
the blanket and cord do not become trapped or rucked, for
example in hinges.
• Do not use the device when wet and only use it in dry
environments (not in the bathroom or similar environments).
Maintenance and cleaning
• You are only permitted to clean the unit. To avoid hazards,
never repair the device yourself. Contact the customer
service.
• Cleaning and user maintenance shall not be made by
children without supervision.
• If the power supply cable is damaged, it may only be
replaced by medisana, an authorised dealer or by qualied
personnel in order to avoid hazards.
• A damaged power supply cable must be replaced with a
power cable of the same type.
• If a fault occurs, do not attempt to repair the unit yourself.
Repairs must only be carried out by an authorized specialist
dealer or other suitably qualied personnel.
• Let the heated underblanket cool down completely before
folding and storing it. Do not fold it too tight.
• Do not store the device with any objects covering or resting
on top of it in order to avoid sharp crinkles.
Scope of supply
Please check rst of all that the device is complete and is not
damaged in any way. In case of doubt, do not use the it and
contact your dealer or your service centre.
The following parts are included:
• 1 medisana Heated underblanket single size
• 1 Detachable slider control
• 1 Instruction manual
If you notice any transport damage during unpacking, please
contact your dealer without delay.
Operating
Spread the blanket out at on top of the mattress. There are four
rubber bands sewn onto the heated underblanket. Use these
bands to tighten the heated underblanket over the corners
of the mattress. Make sure that the electric underblanket is
rmly strapped to the mattress in both directions and that
it will not crease while it is being used. Spread a bedsheet
on top of it. This allows the underblanket to release its heat
in the best way possible. Check it is in the correct position
before going to bed!
Make sure, the connection cable of the control unit is properly
connected to the plug of the heated underblanket. Plug the
unit into the mains outlet and move the slider control
2
from
position 0 to position 1. The power LED
1
will light up in
green.
After a few minutes you will be able to feel the heated
underblanket getting noticeably warmer. If you require
a higher temperature setting, move the switch to the next
positions 2 or 3 or the maximum heat setting, position 4.
If the heated underblanket gets too hot for you, move the
slider back to position 3, 2 or 1. After a short time, the heated
underblanket will cool down.
The heated underblanket may cool down after a short period
of time. This is normal. The fast re-heating according to the
setting will follow immediately.
To switch the unit off, move the switch back to position 0. The
power LED
1
will go out, indicating that the unit is switched
off. Unplug the unit from the mains outlet.
Move the switch to position 1 for any continuous use. The
heated underblanket will switch off automatically after approx.
180 minutes of continuous use.
To switch it back on again, move the slider switch to position
0 and then back to the desired heat setting.
Unplug the unit from the mains outlet once you have nished
using it.
Troubleshooting
If there is no function at all after switching on the heated
underblanket (power LED
1
shows no light), please check if
the mains plug is correctly plugged in the mains outlet. If this
is the case, the heated underblanket is defect. Please do not
use the heated underblanket and contact the service center.
Cleaning and maintenance
• Before cleaning the heated underblanket, unplug it from the
mains outlet and let it cool down for at least ten minutes.
• The heated underblanket is equipped with a removable
control unit (HU 674).
• Unplug the control unit from the heated underblanket by
pulling out the connection cable from the plug on the heated
underblanket.
• The heated underblanket can be cleaned dry (with a soft
brush) or as described in the instructions on the product
label.
• Never use strong detergents or hard brushes.
• To dry, lay the heated underblanket at on a moisture-
absorbent towel or mat.
• Only use the heated underblanket again once it is completely
dry.
• Reconnect the control unit to the heated underblanket in
the correct manner.
• You should untangle the cable from time to time.
• Let the heated underblanket cool down completely before
folding and storing it.
• Do not fold it too tightly. Ideally, you should store the
underblanket folded in its original carton in a clean and dry
place.
Disposal
This product must not be disposed of together with
domestic waste.
All users are obliged to hand in all electrical or
electronic devices, regardless of whether or not
they contain toxic substances, at a municipal or
commercial collection point so that they can be
disposed of in an environmentally acceptable
manner. Consult your municipal authority or your
dealer for information about disposal.
WARNING
Please ensure that the polythene packing is kept
away from the reach of children!
Risk of suffocation!
1
Power LED
2
Slider control
