HCF200FI
Chest Freezer
USER & INSTALLATION GUIDE NZ AU
HCF300FI
2
3
WARNING!
This appliance contains flammable
refrigerant isobutane (R600a).
READ AND SAVE THIS GUIDE
SAFETY AND WARNINGS
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
Children shall not play with the appliance.
Children must not clean or maintain the appliance without supervision.
Cleaning and user maintenance shall not be made by children without supervision.
The appliance must be positioned so that the plug is accessible.
lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
WARNING: Keep ventilation openings, in the appliance enclosure or in the built in structure, clear
of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
This chest freezer is suitable for unheated rooms and outbuildings, provided temperatures do not
fall below -15°C.
instructions. Contact a professional or our after-sales service for disposal.
The thermal insulation foam in this appliance may contain flammable insulation blowing gases, any
Regulations require this appliance to be earthed.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket outlets or portable power supplies at the rear
of the appliance.
Children aged 3 to 8 may load and unload the appliance only under supervision.
exposed foam may be highly flammable and must be carefully treated during disposal.
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
4
farm houses and by clients in hotels, motels and other residential type environments;
bed and breakfast type environments;
catering and similar non retail applications.
To avoid food contamination, follow these instructions:
Avoid keeping the lid open for long periods, as this raises the internal temperature.
Regularly clean surfaces that come into contact with food.
Store raw meat and fish in sealed containers to prevent contact with or dripping onto other food.
If the appliance will be unused for a long time, switch it off, defrost, clean, dry, and leave the door
open to prevent mould growth.
This refrigerating appliance is not intended to be used as a built in appliance.
It is hazardous for anyone other than an Authorised Service Person to service this appliance. In
Queensland – the authorized Service Person MUST hold a Gas Work Authorisation for hydrocarbon
refrigerants, to carry out Servicing or repairs which involve the removal of covers.
WARNING: Risk of child entrapment. Before you throw away your old refrigerator or freezer, the doors
and panels should be removed and the racks left in place so that children may not easily climb inside
SAFETY AND WARNINGS
Before Use
This appliance is intended strictly for household use, for storing food only.
If the appliance is damaged when unpacked, please contact your dealer.
Declaration of Conformity
The manufacturer of the product/s described herein, to which this description refers, declares on its
sole responsibility that the product/s meet the relevant fundamental safety, health and protection
requirements of the relevant UK and EU requirements and that the corresponding test reports are
available for examination by the relevant authorities and can be requested from the seller of the
appliance, especially with regard to CE Declaration of Conformity issued by the manufacturer or with the
manufacturer’s approval.
Moreover, the manufacturer declares that the parts of the appliance described in this user manual, which
come into contact with fresh food, do not contain any toxic substances.
The manufacturer works constantly at the further development of all products. Please therefore bear this
in mind as the form, set up and technology are subject to change, without prior notice.
For further
information about the product, please consult https://eprel.ec.europa.eu/ or scan the QR on
the energy label supplied with the appliance.
This appliance is intended to be used in household and similar applications such as:
staff kitchen areas in shops, offices and other working environments;
5
OVERVIEW
A Lid
B Gasket
C Basket
D Cabinet
E Storage compartment
F Foot or Caster
G Control panel
H Caster
I Ventilation grille
A
B
C
D
E
G H
F
Control Panel
Product Overview
I
E
6
INSTALLATION
Fully unpack the appliance and remove all packaging materials. Dispose of packaging safely and keep it
out of reach of children.
Install the appliance in a dry, well-ventilated area. Avoid direct sunlight and keep it away
from heat sources.
The electricity supply must match the rating plate and comply with local regulations.
Wait at least two hours after installation before switching on the appliance. This allows the refrigerant
circuit to stabilise.
Install the appliance in a location with an ambient temperature matching the climate class shown on
the rating plate.
Insert the plug in the socket. Wait
until all indicators light up and
then be displayed.
Allow two hours for the internal
temperature to stabilise before
placing food inside.
Climate Class
Ambient Temperature
SN
+10 ºC to 32ºC
N
+16 ºC to 32ºC
ST
+16 ºC to 38ºC
T
+16 ºC
to 43ºC
Dimensions
HCF200FI
MM
A Height 865
B Width 940
C Depth 565
D Overall height (lid open) 1375
E Clearances (front, rear, sides, top of lid when open) 50
Freezers with installed casters are designed exclusively for short-distance repositioning.
Long-distance or movement over uneven surfaces is strictly prohibited.
The appliance has adjustable feet, which can be lifted and lowered to ensure the product remains stable.
A
B C
D
E E E
E
foot
caster
lowerrise
Fully retract all adjustable feet of freezer to clear ground contact before moving the machine.
HCF300FI
MM
865
1205
620
1430
50
7
FIRST USE
Guidance on Freezing Food
Wrap or seal food in aluminium foil, airtight containers, or freezer-safe storage bags before freezing.
Allow hot food to cool prior to placing it in the appliance.
Smaller portions freeze faster. The recommended maximum portion size is 2.5 kg.
Avoid placing warm food directly against frozen items. This could cause defrosting and reduce shelf life.
The capacity of the appliance, as shown on the rating plate, should not be exceeded.
When freezing large amounts of fresh food, activate the Super Freeze function (if available) at least 24
hours in advance.
Storage times for frozen products vary by type and packaging. Always follow the instructions on the label.
Temperature setting
Press “+” or “-” to adjust temperature(Control Panel).It's suggested to set the temperature at -18°C.
mode
Temperature setting range
Refrigerating
+10°C to 0°C
Freezing -1°C to -26°C
Function setting
Light activated in freezing mode (with Super Freeze mode) and remains off in refrigerating mode.
:
Light activated in Freezer /Super Freeze mode.
:
Light activated in Super Freeze mode.
:
Light activated in Refrigerator mode.
:
Light activated in locked status.
:
Press 3s to lock/unlock the control panel, quick press to turn Super Freeze on/off while
:
Quick press to switch between Frz and Ref modes directly.(Note: Invalid when in Super
:
unlock status.
Freeze mode; system responds with a flashing alert)
Attention
Energy consumption will increase when this function is on.The Super Freeze function will be
:
cooling outlet
air inlet
WARNING: When loading food items, maintain clearance from all air ducts inside the cabinet to ensure
optimal cooling performance. The return air cover forms part of the airflow tunnel. DO NOT remove it
under any circumstances! If there is any outside object entry air outlet, please consult and contact
after-service immediately, DO NOT disassemble if contamination occurs.
Attention
Before changing storage mode, we recommend removing all contents from the product.
:
switched off automatically after 56 hours to save energy.During the Super Freeze function,
temperature in the freezer will be -26°C.
Set the required temperature, keep the lid closed, and allow a day for the internal
temperature to stabilise, prior to putting in contents to be stored at the new temperature.
8
CLEANING AND MAINTENANCE
Cleaning
If the appliance will be unused for a long time, leave the door open to prevent unpleasant odours.
To ensure food safety, use and clean the freezer regularly as described below.
Clean the inside of your freezer at least once a year.
Use warm water and baking soda solution about a tablespoon of baking soda to litre/quart of water.
Rinse thoroughly with water and wipe dry.
Do not use cleaning powders or other abrasive cleaners.
Do not wash removable parts in a dishwasher.
Do not use harsh chemicals, abrasives, ammonia, chlorine bleach, concentrated detergents, solvents, or
metal scouring pads. These may damage or discolour the freezer.
Never use metallic scouring pads, brushes, abrasive cleaners, or alkaline solutions on any surface.
Clean the door gasket every three months with the baking soda solution as above. Keep it clean and
brushes to clean. If needed, removable shelves, trays, drawers, and similar accessories can be taken out
and washed in the sink.
9
TROUBLESHOOTING
Is the door difficult to open?
the seal is functioning properly. Wait a few minutes, and the door will open easily.
Appliance not operating (not running or cooling)
Is there a power failure.
Appliance isn’t cooling properly / 'HH' appears on display
Is the door of the appliance closed properly?
Is the appliance exposed to direct sunlight or heat?
Has too much warm food been placed in the appliance?
temperatures suitable for proper operation.
The appliance makes noise
This sound comes from the compressor motor and refrigerant moving through the system. These
noises are normal.
Condensation builds up on the outer walls
Under certain atmospheric conditions, condensation can form on the appliance’s outer walls. This is
Climate Class
Ambient Temperature
SN
+10 ºC to 32ºC
N
+16 ºC to 32ºC
ST
+16 ºC to 38ºC
T
+16 ºC to 43ºC
Auto Defrosting
Under conditions of heavy ambient humidity(e.g., rainy weather, humid air) or frequent door openings,
frost may form on door seals or side liner on the cabinet which is normal. The frost will automatically
dissipate after maintaining door closure for a while.
Freezing in refrigerator mode
If you encounter freezing of drinks in the base of the product when it is in refrigerator mode, move drinks
to be stored in the upper section of the freezer. You may need to store drinks on top of other solid items
or in the baskets.
10
CUSTOMER SERVICE
We recommend our Haier Customer Service and the use of original spare parts.
If you have a problem with your appliance, please first check the Troubleshooting section. If you cannot find
a solution there, please contact:
z
Your local dealer
z
The Service & Support area at
www.haier.com.au or
www.haier.co.nz
where you can activate the service claim and also find FAQs.
To contact our Service, ensure that you have the following data available.
The information can be found on the rating plate at the door.
Model
Serial No.
Complete and keep for safe reference:
Model
Serial No.
Purchase Date
Purchaser
Dealer
Suburb
To w n
Country
0070520819 2025.07.07
