360° U型自动声波牙刷
使用说明书
Ｖ１．０３
包装清单：
①
②
④
⑤
③
① 刷头（尼龙植毛 ／ 硅胶） ×１
② 主机×１
③ ＵＳＢ Ｔｙｐｅ－Ｃ 充电线×１
④ 充电底座×１
⑤ 说明书×１
备注：① 不同型号配置可能不同，可选尼龙植毛 ／ 硅胶刷头
１
产品功能：
无线感应充电
３小时充电，续航１５天，方便快捷
强劲声波马达
宽幅高频震动，配合高品质尼龙或硅胶刷头，
带来深层清洁体验
防水设计
支持全身冲洗，无惧进水损坏，清洁更方便
五档清洁模式
敏感、清洁、美白、抛光、按摩
４５秒全口洁牙
３６０°包覆式刷牙，４５秒完成全口清洁
２
使用步骤：
③ 将刷头放入口腔，轻轻咬合
上下牙齿，让牙齿包裹在刷
头的Ｕ型槽中。
④ 按下开关键启动清洁。
② 将本产品专用泡沫牙膏注入
牙刷头；使用普通牙膏，先
淋湿牙刷头，将牙膏涂抹于
刷头两侧。
① 将牙刷头与机身平行，刷头
孔对准机身动力轴，插入并
安装到位。
３
备注：硅胶刷头可根据个人口腔大小适当修剪。
充电步骤：
① 将 ＵＳＢ Ｔｙｐｅ－Ｃ 插头插入充电底座接口，
Ｔｙｐｅ－Ａ 插头 接入 ５Ｖ ＵＳＢ 电源。
② 充电底座指示灯点亮，表示电源已接通。
③ 将主机垂直放置在底座凹槽上，顶部 ＲＧＢ 灯渐亮闪烁表示正
在充电，充满电时 ＲＧＢ 灯常亮。
⑤ 轻轻左右摇动手柄，使牙齿
清洁更彻底。
⑥ 使用后清水冲洗刷头并晾干；
机身请用干布擦拭
并保持干燥。
４
产品参数：
５
• 规格型号：ＪＳ５０８
• 电机：磁悬浮宽摆声波电机（专为Ｕ型牙刷设计）
• 振动：可调，４８００－３６０００次／分钟
• 模式：５种模式
• 红蓝光保健：４８０ｎｍ蓝光抗菌＋６４０ｎｍ红光修复护理
• 氛围灯：ＲＧＢ幻彩氛围灯
• 电池：３．７Ｖ 动力锂电池
• 续航：１５－２０天（不同模式）
• 防水：ＩＰＸ７级
• 主机尺寸：６．２ ｘ ６．８ ｘ ２．９ｃｍ （带刷头６．２ ｘ １１ ｘ ２．９ｃｍ）
• 定时：４５秒
• 表面材质：硅胶＋喷涂
• 刷头适配：多种硅胶刷头／尼龙毛刷头
主机
安全＆使用说明：
６
①.产品正常工作温度为０℃ － ５０℃。
②.请在常温下充电，保持主机和充电座干燥。
③.产品存放在干燥、阴凉处、避免阳光照射。
④.刷牙完成后，请用湿布擦去机身上的水和污渍，避免用水浸泡。
⑤.本牙刷采用全密封防水设计。连续使用可能会导致硅胶外壳轻微发热和膨
胀，这是正常现象。请在连续使用三次后放置产品 １－２ 分钟，以防止电
机过热，损坏产品。
• 充电：感应充电座（４小时充满）
• 额定电源：５Ｖ ／ ２．５Ｗ
• 防水等级：ＩＰＸ１（不防水）
充电座
７
⑥.长期不使用时，每３个月需充放电一次。
⑦.充电时远离水源，勿将充电底座浸入水中或放置在多灰尘环境中。
⑧.请仅使用 ＤＣ ５Ｖ １Ａ 适配器（如 ＵＳＢ Ｔｙｐｅ－Ａ 电源），避免使用快充或不
适配电源，以免损坏设备或引发危险。
⑨.充电时勿在底座上放置金属物品，以免导致危险。
⑩.如果刷头不易取下，请将刷头和手柄的连接处浸泡
在５０－７０°热水中加热，３０秒后尝试取下，
注意：请不要激烈扭动刷头，以防止产品损坏。
⑪.本产品非玩具，儿童需在成人监护下使用；如有口腔疾病
或医生特别建议，请遵循医嘱使用。
360° U-Shaped Automatic
Sonic Toothbrush
V1.03
User Manual
Package Contents：
①
②
④
⑤
③
① Brush head × 1
② Handle × 1
③ USB Type-C charging cable × 1
④ Charging base × 1
⑤ User manual × 1
Note:
① Brush head type may vary by model. Available in nylon bristle or
silicone. Please refer to the actual product received.
１
Product Features：
Wireless Inductive Charging
3-hour charging,15-day battery life for convenient use
Powerful Sonic Motor
Wide swing vibration with high-quality nylon or silicone
bristle brush heads for a deep cleaning experience
IPX7 Waterproof
Safe for rinsing under water. Easy to clean without fear
of water damage
Five Cleaning Modes
Gentle, Clean, Whitening, Polish and Massage
45-Second Full-Mouth Cleaning
360°coverage. Completes a full brushing cycle in just
45 seconds
２
① Align the brush head hole with
the motor shaft and insert until
securely in place.
② Use special foaming toothpaste;
if using regular toothpaste,
dampen the brush
head first, then apply
toothpaste to both
sides of the brush
head
How To Use：
④ Press the power button to
start cleaning.
③ Place the brush in your mouth
and gently bite down
so that the upper
and lower teeth fit
into the mouthpiece.
３
Note：
Silicone brush heads can be trimmed to suit
individual mouth size.
How To Charge:
① Insert the USB Type-C plug into the charging base,
and connect the Type-A end to a 5V USB power
source.
② The indicator light on the charging base will turn on,
showing the power is connected.
③ Place the handle vertically on the base slot. The RGB light on the handle
will pulse while charging and remain solid when fully charged.
⑤ Gently move the handle left
and right to allow
deeper cleaning.
⑥ Rinse the brush head with clean
water after use and allow
it to air dry. Wipe the
handle with a dry
cloth and keep it
dry.
４
Specifications：
U-Shaped Automatic Sonic Toothbrush
• Model: JS508
• Motor: Wide-swing sonic motor
• Vibration: Adjustable, 4,800–36,000 VPM
• Modes: 5 modes
• Additional features: 480nm blue light for antibacterial care
+ 640nm red light for restorative care
• Ambient Light: RGB color-changing ambient lights
• Battery: 3.7V lithium battery
• Battery Life: 15–20 days
• Waterproof rating: IPX7
• Size: 6.2 × 6.8 × 2.9 cm, 6.2 × 11 × 2.9 cm (with brush head)
• Timer: 45 seconds
• Surface Material: Silicone + Spray Coating
• Brush Head: Various silicone brush heads / nylon bristle brush heads
５
Safety Instructions:
６
① Operating temperature range: 0℃ – 50℃.
② Charge at room temperature. Keep both the handle and charging
base dry.
③ Store in a cool, dry place away from direct sunlight.
④ After each use, wipe the handle clean. Do not soak in water.
⑤ This toothbrush has a fully sealed waterproof design. Continuous
use may cause slight heating and minor expansion of the silicone
sleeve, which is normal.For best performance, let the product rest
for 1–2 minutes after three consecutive uses to prevent the motor
from overheating and damaging the product.
⑥ If not used for an extended period, charge and discharge the
product once every 3 months.
Wireless Charging Dock
• Charging: Inductive charging dock (fully charged in 4 hours)
• Input power: 5V / 2.5W
• Waterproof rating: IPX1 (not waterproof)
７
⑦ Keep the charging base away from water. Do not immerse it or
place it in dusty environments.
⑧ Use only a DC 5V 1A adapter (e.g., USB Type-A power supply).
Avoid incompatible fast chargers, which may damage the product
or pose safety risks.
⑨ Do not place metal objects on the charging base while charging,
to avoid potential hazards.
⑩
If the brush head is difficult to remove, soak
the connection between the brush head and the
handle in hot water at 50–70°C and heat for
30 seconds, then try to remove it. Do not
twist the brush head forcefully, as this may
cause damage to the product.
⑪ This is not a toy. Children must use under adult supervision. If you
have oral conditions or medical restrictions, please follow your
doctor’s advice.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
-This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
