Upright Vacuum
NV180 Series
OWNER’S GUIDE
Navigator
3sharkclean.co.uk 2 sharkclean.co.uk
CONTENTS
Important Safety Instrustions .......................................4
Getting to know your Shark Lift Away ................................6
Assembly .........................................................8
Power cord ...................................................... 9
Settings .........................................................10
Emptying the Dust Cup ............................................12
Cleaning the Filters ...............................................13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Checking for Blockages ............................................15
Available Accessories .............................................16
Trouble Shooting .................................................17
Guarantee ........................................................18
Notes ............................................................19
This marking indicates that this product should not be disposed of with
other household wastes throughout the UK. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material sources. To return
your used device, please use the return and collection systems or contact
the retailer where this product was purchased. They can take this product
for environmentally safe recycling.
TIP: You can find
the model and serial
numbers on the QR
code label on the
bottom of the back of
the vacuum pod.
REGISTER YOUR PURCHASE
TO BENEFIT FROM YOUR PRODUCT'S EXTENDED
GUARANTEE, SIMPLY REGISTER YOUR PURCHASE AT:
sharkclean.co.uk/register-guarantee
0800 862 0453
Scan QR code using mobile device
Please note, products purchased directly from Shark®
are automatically registered.
Benefits of registering your product and creating
an account:
• Get easier, faster product support and access to
guarantee information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product
promotions
RECORD THIS INFORMATION
Model Number: �������������������������������
Serial Number ��������������������������������
Date of Purchase (Keep receipt): �����������������
Store of Purchase: �����������������������������
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50-60Hz
Watts: 600W
O mode consumption: 0.0W
THANK YOU
for purchasing the Shark Navigator Corded Upright Vacuum
PLEASE READ CAREFULLY
AND KEEP FOR FUTURE REFERENCE.
This instruction manual is designed to help you get a
complete understanding of your new Shark Navigator
Corded Upright Vacuum.
If you have any questions, please call the customer
service line on 0800 862 0453.
5sharkclean.co.uk 4 sharkclean.co.uk
READ ALL INSTRUCTIONS BEFORE
USING THIS VACUUM
1. Inspect power cord and plug for any
damage before use. DO NOT use
vacuum cleaner with a damaged
cord or plug. Turn off all controls
before plugging in or unplugging
the vacuum cleaner. Store your
vacuum cleaner with the power cord
secured around the two cord hooks.
To minimize the risk of power cord
damage, do not allow the motorized
brush roll to ingest the cord. If this
occurs, immediately shut off power
to the vacuum and remove the cord.
2. This appliance has a polarized plug,
if the plug does not fit fully into the
outlet, reverse the plug (one blade is
wider than the other). If it still does
not fit, contact a qualified electrician.
DO NOT force into outlet or try to
modify to fit.
3. Your vacuum cleaner may consist of
a motorized nozzle, wand, hose, and/
or vacuum pod. This device contains
electrical connections, electrical
wiring, and moving parts that
potentially present risk to the user.
4. Use only identical replacement parts.
5. Carefully observe and follow the
instructions provided below to avoid
improper use of the appliance.
DO NOT use the vacuum for any
purpose other than those described
in this manual.
6. Before use, carefully inspect all parts
for any damage. DO NOT use if any
parts are damaged.
7. The use of an extension cord is
NOT recommended.
8. This vacuum cleaner contains
no serviceable parts.
9. This appliance can be used by
persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Cleaning and user maintenance
shall not be made by children. Keep
the appliance and its cord out of
reach of children. DO NOT allow the
appliance to be used by children. DO
NOT allow to be used as a toy. Close
supervision is necessary when used
near children.
10. Always turn off the vacuum cleaner
before connecting or disconnecting
any motorized nozzles or other
accessories.
11. DO NOT handle plug or vacuum
cleaner with wet hands.
12. DO NOT use without filters in place.
13. Only use Shark® branded filters
and accessories.
14. DO NOT damage the power cord:
a) DO NOT pull or carry vacuum
cleaner by the cord or use the
cord as a handle.
b) DO NOT unplug by pulling on
cord. Grasp the plug, not the cord.
c) DO NOT run the vacuum cleaner
over the power cord, close a door
on the cord, pull the cord around
sharp corners, or leave the cord
near heated surfaces.
15. DO NOT put any objects into nozzle
or accessory openings. DO NOT use
with any opening blocked; keep free
of dust, lint, hair, and anything that
may reduce airflow.
16. DO NOT use if nozzle or accessory
airflow is restricted. If the air paths or
the motorized floor nozzle become
blocked, turn the vacuum cleaner
off and unplug from electrical outlet.
Remove all obstructions before you
plug in and turn on the unit again.
17. Keep nozzle and all vacuum openings
away from hair, face, fingers,
uncovered feet, or loose clothing.
18. DO NOT use if vacuum cleaner is
not working as it should, or has been
dropped, damaged, left outdoors, or
dropped into water.
19. Use extra care when cleaning
on stairs.
20. DO NOT leave the vacuum cleaner
unattended while plugged in.
21. When powered on, keep the
vacuum cleaner moving over the
carpet surface at all times to avoid
damaging the carpet fibers.
22. DO NOT place vacuum cleaner
on unstable surfaces such as chairs
or tables.
23. Your Shark® vacuum may not
be designed to stand up on its own.
When taking a break from cleaning,
you may need to lean it against
furniture or a wall, or lay it flat
on the floor. Using the vacuum
for an application where the unit
lacks stability may result in
personal injury.
24. DO NOT use to pick up:
a) Liquids
b) Large objects
c) Hard or sharp objects
(glass, nails, screws, or coins)
d) Large quantities of dust (drywall
dust, fireplace ash, or embers).
DO NOT use as an attachment to
power tools for dust collection.
e) Smoking or burning objects
(hot coals, cigarette butts,
or matches)
f) Flammable or combustible
materials (lighter fluid, gasoline,
or kerosene)
g) Toxic materials (chlorine bleach,
ammonia, or drain cleaner)
25. DO NOT use in the following areas:
a) Poorly lit areas
b) Wet or damp surfaces
c) Outdoor areas
d) Spaces that are enclosed and may
contain explosive or toxic fumes
or vapors (lighter fluid, gasoline,
kerosene, paint, paint thinners,
mothproofing substances, or
flammable dust)
26. Turn off all controls before plugging
in or unplugging the vacuum.
27. Unplug from electrical outlet
when not in use and before
any maintenance or cleaning.
28. Hand wash with water only.
Washing with cleaning chemicals
could damage the unit.
29. During cleaning or routine
maintenance, DO NOT cut anything
other than hair, fibers, or string
wrapped around the brushroll.
30. Allow all filters to air-dry completely
before replacing in the vacuum to
prevent liquid from being drawn
into electric parts.
31. Make sure the dust cup and all
filters are in place after routine
maintenance.
32. If provided, secure the power
cord around the two cord hooks
during storage.
WARNING
To reduce the risk of fire, electric shock, injury, or property damage, when using
an electrical appliance, basic precautions should always be followed, including
the following:
IMPORTANT SAFETY INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
7sharkclean.co.uk 6 sharkclean.co.uk
NOTE: The dust cup has to be removed to ccess the filter.
GETTING TO KNOW YOUR SHARK NAVIGATOR CORDED UPRIGHT VACUUM
WELCOME!
Congratulations
on your purchase.
Use this instruction
manual to learn about
your new vacuum’s
great features. From
assembly to use to
maintenance, you will
find it all in here.
MAIN UNIT
A Suction Control Slider
B Handle
C Hose
D Handle Release Button
E Power Switch
F Power cord
G Wand
H Wand Release Button
I Dust-Cup
J Dust-Cup Release Latch
K Filter Cover
L Headlights
M Brush-Roll
Wand
Release
B
F
I
C
D
G
H
J
K
L
M
E
A
9sharkclean.co.uk 8 sharkclean.co.uk
ASSEMBLY ASSEMBLY
POWER CORD
For cord access, rotate upper hook
down and remove cord.
Use cord holder on the side of wand to
hold cord in place while vacuuming.
UPPER CORD HOOK CORD HOLDER
1
(Click)
2
(Click)
1. Insert the Wand into the Pod.
2. Insert the Handle into the top of the wand.
3. Connect the Hose to the back of the pod.
4. Insert the C-clip into the back of the pod.
5. Insert the hose into the C-clip and the hose holder.
6. Store Accessories on the Tool Storage Posts.
For proper operation, ensure all parts are firmly clicked into place.
3
(Click)
4
(Click)
5(Click)
6
11sharkclean.co.uk 10 sharkclean.co.uk
NOTE: All accessories are compatible with both the wand and the handle.NOTE: For deep carpet cleaning, set to MAX suction and use setting II, Carpet.
WHOLE-HOME CLEANING
CLEANING MODES
To engage Brushroll, turn on the power, step
on the floor nozzle, and tilt handle back.
Select surface setting:
O O
I Hard Floor
For bare floors and area rugs. The
brushrolls will spin slowly in this mode.
II Carpet
For carpets. The brushrolls spin quickly in
this mode.
WHAT DOES THE BRUSHROLL INDICATOR LIGHT MEAN?
Solid Green: The brushroll is spinning and working as intended.
Solid Red: There is a jam in the brushroll area. Turn o and unplug the vacuum and remove any
blockages in the nozzle.
Flashing Red: The motorised floor nozzle is overheating. Turn the vacuum o and wait a minimum
of 60 minutes for the unit to cool down. See Troubleshooting section for more information.
Press the Wand Release button and pull
up on the wand to detach it from the
pod. Attach an accessory to the wand.
Press the Handle Release button and
pull up on the handle to detach it
from the wand. Attach an accessory
to the handle.
ABOVE-FLOOR—WANDABOVE-FLOOR—HANDLE
WHOLE-HOME CLEANING
SETTINGS
BRUSHROLL INDICATOR LIGHT
UPRIGHT MODE
INDICATOR LIGHT
POWER/SURFACE SWITCH
The Suction Control Slider located on the
handle allows you to adjust the suction
depending on the floor type.
MIN: to reduce suction and increase
maneuverability on carpets.
MAX: to increase suction on bare floors.
SUCTION CONTROL
13sharkclean.co.uk 12 sharkclean.co.uk
EMPTYING THE DUST CUP
To remove Dust Cup, slide up the release button
on the dust cup handle. Tilt dust cup forward,
then lift to remove.
To reinstall, place the bottom of dust cup
onto the pod and then tilt until it clicks into
place.
Press the release button to open bottom of
dust cup.
To remove collected debris from Lint Screen,
press the top release button and lift the
handle to open the dust cup. Gently brush
lint screen toclean.
RINSE POST-MOTOR FILTER
EVERY YEAR
Remove dust cup, tilt Filter Door and firmly
pull it o. Press tab at top of Post-Motor
Filter and pull out filter. To reinstall, insert
filter into unit and replace the filter door.
RINSE PRE-MOTOR FILTERS
EVERY MONTH
Remove Dust Cup, then lift out Filters.
Regularly rinse and replace the filters to maintain your vacuum's suction power.
To prevent damage from cleaning chemicals, rinse filters with cold water only. Allow all filters
to air-dry for at least 24 hours before reinstalling them to prevent liquid from being drawn into
electronicparts.
CLEANING AND REPLACING THE FILTERS
CLEANING FILTERS
IMPORTANT: DO NOT use soap when cleaning the filters.
IMPORTANT: Unplug the power cord before performing any maintenance.
Empty the dust cup each time you vacuum and periodically during cleaning, when debris in the
dust cup reaches the MAX fill line.
Post-Motor
Filter
Foam
Felt
Filter
Door
NOTE: To order replacement parts and filters, visit sharkclean.co.uk/shark-parts-accessories/shark-vacuum-cleaner-parts-accessories/
Replacement
Pre-Motor Foam &
Felt Filter Kit
Replacement
Post-Motor Filter
Follow the previous instructions for removing filters. The Pre-Motor Filter should be replaced
every month. The Filter should be replaced every year.
REPLACING FILTERS
15sharkclean.co.uk 14 sharkclean.co.uk
CLEANING THE BRUSHROLL
MAINTENANCE
CHECKING FOR BLOCKAGES
Detach hose from vacuum pod,
and check hose and opening on
back of pod for blockages.
Detach wand from pod and handle,
and check both ends for blockages.
Detach wand from pod, and
check opening for blockages.
Detach handle from wand and
hose from the vacuum pod, and
check openings for blockages.
Detach dust cup from vacuum
pod. Empty dust cup, remove
debris from lint screen, and check
for blockages.
HOSE BLOCKAGES WAND BLOCKAGES
POD BLOCKAGES HANDLE/HOSE BLOCKAGES
DUST CUP BLOCKAGES
To minimize the risk of power cord damage,
DO NOT run the vacuum over the power cord.
If this occurs, immediately shut o power to
the vacuum and remove the cord from the
brushroll or nozzle.
1. DO NOT pull or carry vacuum cleaner by
the cord or use cord as a handle.
2. DO NOT unplug by pulling on the cord.
Grasp the plug, not the cord.
3. DO NOT close the door on the cord.
4. DO NOT pull the cord around sharp
corners.
5. DO NOT leave the cord near heated
surfaces.
CORD MAINTENANCE
Clean o any debris on the bristles. Carefully use scissors within
the brush-roll groove to cut away any hair or debris wrapped
around the brush-roll.
DEBRIS WRAPPED
AROUND BRUSH-ROLL
17sharkclean.co.uk 16 sharkclean.co.uk
AVAILABLE ACCESSORIES
B
F
G H
I
E
D
A
Crevice Tool
This slender tool oers extended reach to
access corners, baseboards, tight spaces,
and ceilings.
B
Upholstery Tool
Picks up hair, dust, and large debris from
mattresses, couches, curtains, lampshades,
and other delicate upholstered fabrics.
C
Pet Power Brush
The turbine brush loosens and removes
pet hair and debris from carpets, and
powerfully deep-cleans dander out of
upholstery and other surfaces.
D
Duster Crevice Tool
Two cleaning tools in one. The crevice tool
gives you extended reach to clean in tight
spaces, while the soft brush is ideal for
dusting delicate surfaces.
E
Pet Multi-Tool
A single convertible tool for cleaning tough
pet messes two ways: use the sti bristle
brush to clean stuck-on debris, or take o
the bristles to reveal an upholstery tool
perfect for removing stubborn pet hair and
large piles of debris.
F
Under-Appliance Wand
Clean under and behind hard-to-move
appliances and furniture with this adjustable
36” tool. Flip the extension piece over to
clean the underside of appliances.
G
Anti-Allergen Dust Brush
This brush features nylon fiber bristles
specifically designed for removing fine
dust and allergen particles from the most
delicate surfaces.
H
Home & Car Detail Kit
Deep-clean your car like a professional
detailer, or clean hard-to-reach areas in
your home. Micro-sized tools let you clean
around delicate objects and access the
tightest spaces like car vents and computer
keyboards.
I
Accessory Bag
This convenient accessory storage bag
measures 32 cm x 70 cm and fits the Under-
Appliance Wand. Smaller size available at
sharkaccessories.com.
A
C
NOTE: Not all accessories come with all units. For a list of the accessories included with this model, see the top inside flap
of the box. To order additional accessories, visit sharkclean.co.uk/shark-parts-accessories.
TROUBLESHOOTING
Power cord caught in brushroll or floor nozzle.
• To minimize the risk of power cord damage, DO NOT run the vacuum over the power cord.
If this occurs, immediately shut o power to the vacuum and remove the cord from the
brushroll or nozzle.
• Inspect power cord and plug for any damage before use. DO NOT use vacuum cleaner with
a damaged cord or plug. Turn o all controls before plugging in or unplugging the vacuum
cleaner. Store your vacuum cleaner with the power cord secured around the two cord hooks.
Vacuum is not picking up debris. No suction or light suction.
• Check filters to see if they need cleaning. Follow instructions for rinsing and air-drying the
filters before reinstalling.
• Dust cup may be full; empty dust cup.
• Clear any blockages in the hose, hose connections, nozzle, wand, pod, or accessories. See
Checking for Blockages section for more information.
Vacuum lifts area rugs.
• Make sure Power/Surface switch is set to Hard Floor (setting I).
• Suction is powerful. Take care when vacuuming area rugs or rugs with delicately sewn edges.
• To minimize suction, set the suction control slider to MIN. See the Suction Control section
for more information.
Brushroll does not spin.
• If the brushroll indicator light turns red, immediately turn o and unplug the vacuum.
Remove the wand from the pod and clear any blockages. Reconnect wand, plug in vacuum,
and turn on power.
• With the power on, recline the handle, which will automatically turn on the brushroll.
• Check hose, hose connections, nozzle, wand, pod, and accessories for blockages. Clear any
blockages found.
(Refer to Checking for Blockages section for more information.)
Vacuum turns o on its own or indicator light flashes red.
If your vacuum overheats, the thermostat will automatically turn o the motor. Follow these
steps to restart:
1. Turn vacuum o and unplug it.
2. Empty dust cup and clean filters (see Emptying the Dust Cup and Cleaning the Filters).
3. Check for blockages in hose, wand, nozzle, accessories, and inlet openings.
4. Allow unit to cool for a minimum of 60 minutes.
5. Plug in vacuum and turn it on.
For all other issues, please visit our website at sharkclean.co.uk/support.
19sharkclean.co.uk 18 sharkclean.co.uk
When a consumer buys a product in the UK, they get the benefit of legal rights relating to the quality of the
product (your “statutory rights”). You can enforce these rights against your retailer. However, at Shark® we are
so confident about the quality of our products that we give you an additional manufacturer’s warranty of up to
five years (one year as standard, plus a further four years upon registration with Shark®). Oer valid only in
United Kingdom and Republic of Ireland. These terms and conditions relate to our manufacturer’s guarantee
only – your statutory rights are unaected.
The conditions below describe the prerequisites and scope of our guarantee.
Shark
®
Guarantees
A household appliance like a vacuum cleaner constitutes a sizeable investment. Your new machine needs
to work properly for as long as possible. The guarantee it comes with is an important consideration - and
reflects how much confidence the manufacturer has in its product and manufacturing quality.
Every Shark® machine comes with a free parts and labour guarantee. Our customer service helpline
(0800 862 0453) is open from 9.00am to 6.00pm Monday - Friday. It’s free to call, and you’ll be put straight
through to a Shark® representative. You’ll also find online support at sharkclean.co.uk.
How do I register my extended Shark
®
guarantee?
If you have purchased your vacuum directly from sharkclean.co.uk your guarantee is registered automatically.
You can also register your guarantee at sharkclean.co.uk within 28 days of purchase. To save time, you’ll need
the following information about your machine:
• Date you purchased the machine (receipt or delivery note)
• Model Number
IMPORTANT
• Your guarantee will only cover your product from the date of purchase.
• Please keep your receipt at all times. Should you need to use your guarantee we will need your receipt
to verify the information you have supplied to us is correct. The inability to produce a valid receipt may
invalidate your ability to claim against your guarantee.
What are the benefits of registering my free Shark
®
guarantee?
When you register your guarantee we’ll have your details to hand if we ever need to get in touch. You can also
receive tips and advice on how to get the best out of your Shark® vacuum and hear the latest news about new
Shark
®
technology and launches.
If you register your guarantee online, you’ll get instant confirmation that we’ve received your details.
How long are new Shark
®
machines guaranteed for?
Our confidence in our design and quality control means that your new Shark® vacuum cleaner is guaranteed
for a total of up to five years (1 year plus an extended guarantee of 4 years on registration).
What is covered by the free Shark
®
guarantee?
At Shark’s discretion repair or replacement of your Shark® machine, including all parts and labour. A Shark®
guarantee is in addition to your legal rights as a consumer.
What is not covered by the free Shark
®
guarantee?
• Blockages – for details of how to unblock your vacuum cleaner, please refer to the Operating Manual.
• Normal wear and tear such as brush bar, fuse, belt etc.
• Accidental damage, faults caused by negligent use or care, misuse, neglect, careless operation or
handling of the vacuum cleaner which is not in accordance with the Shark® Operating Manual supplied
with your machine.
• Use of the vacuum cleaner for anything other than normal domestic household purposes.
• Use of parts not assembled or installed in accordance with the operating instructions.
• Use of parts and accessories which are not Shark® Genuine Components.
• Faulty installation (except where installed by Shark®).
• Repairs or alterations carried out by parties other than Shark® or its agents.
What happens when my guarantee runs out?
Shark® does not design products to last for a limited time. We do appreciate that there may be a desire for
our customers to want to repair their vacuum cleaners after the guarantee has lapsed. In this case please
contact our Freephone customer service help line and ask about our out of guarantee program,
on 0800 862 0453.
Where can I buy genuine Shark
®
spares and accessories?
Shark® spares and accessories are developed by the same engineers who developed your Shark® vacuum.
You’ll find a full range of accessories, spares and replacement parts for all Shark® machines at sharkclean.co.uk
Only use Shark® branded filters and accessories. Damage caused by use of non-Shark parts may not be
covered by your guarantee.
FIVE (5)YEAR LIMITED GUARANTEE
NOTES
NV180UK_IB_MP_Mv1_250513
@sharkcleaninguk
@sharkcleanuk
@sharkcleanuk
SHARK is a registered trademark in the United Kingdom of
SharkNinja Operating LLC.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get a complete understanding of your new
Shark Navigator Upright Vacuum
Illustrations may dier from actual product. We are constantly striving to improve our products;
therefore the specifications contained herein are subject to change without notice.
SharkNinja Europe Limited,
1st/2nd Floor 3150 Century Way,
Thorpe Park, Leeds, LS15 8ZB, UK
+44 (0)800 862 0453
www.sharkclean.co.uk
