Quick Start Guide
STRICH
pipe tones
PIPE TONES
Pocket Multi-Effects Guitar Pedal
STRICH
STRICH
PIPE TONES
OVERVIEW
STRICH pipe tone Compact Body, Professional Tone.
Pipe tone is a full-featured desktop multi-effects processor built for quitar and bass players. Whether for daily
practicestudio recording, or live performance,it delivers far more than its compact size suggests its a portable
tone power house you can take anywhere.
At its core, Pipe tone features advanced (Dynamic Spectrum Modeling) amp simulation technology,
combining universal black-box modeling with neural network training. It authentically captures the dynamics, frequency
response, and touch sensitivity of real tube ampliers, giving you a tone that feels as genuine as it sounds. With 30
built-in amp models, support for NAM (NFILE) imports with access to over 10,000 free tones, and third-party IR
loading,
your creative possibilities are virtually limitless.
Despite its ultra-compact design, Pipe tone comes loaded with 125 effect types and supports up to 10 simultaneous
modules, including GATE, OD/FX, AMP, CAB, EQ, MOD, DELAY, REVERB, LOOPER, and DRUM everything
guitarists and bassists need in a single streamlined unit.
Connectivity is just as versatile: dual Bluetooth for audio playback and MIDI editing via the mobile app, PC software for
parameter control and rmware updates, plus a 48kHz/24-bit USB audio interface with ASIO driver for professional
recording. With both headphone and stereo outputs, Pipe tone adapts seamlessly from desktop setups to the
stage.
Additional creative tools include a 40-second stereo looper, 100 drum patterns, 99 factory presets, a rechargeable
lithium battery, and a bright 2-inch color TFT display. For live performance, it also supports external expression pedals
or control footswitches, giving you precise control without compromise.
STRICH Pipe tone small in size, limitless in sound.
FEATURES
Advanced DSM (Dynamic Spectrum Modeling) amp modeling technology faithfully recreates tube amp dynamics,
tone, and feel.
Suitable for both guitar and bass, includes 25 guitar amps and 5 bass amps, with 25 built-in guitar cabs and 5 bass
cabs.
Desktop-style design with support for up to 10 simultaneous effect modules.
2-inch TFT color display for a clear, intuitive interface.
125 built-in effects including 40 amp models (10 x NFILE slots) and 40 cab models (10 x 3rd IR slots).
External control support with expression pedal and footswitch compatibility.
Up to 99 user presets for instant tone recall (01–80 for guitar, 81–99 for bass).
NAM le import with high-delity conversion for authentic amp tones.
40-second stereo Looper for practice and layering, with Auto Rec Mode for automatic recording. LOOP SYNC
allows
synchronization with the Drum machine.
100 drum machine patterns for rhythm training and inspiration.
High-quality 24-bit/48 kHz audio conversion with dedicated ADC and DAC, combined with advanced processing
algorithms for clear, detailed, and accurate sound reproduction.
Dual-mode Bluetooth plus companion mobile app and PC editor.
Stereo outputs, USB audio interface, and OTG support for mobile streaming and recording.
Rechargeable lithium battery for true portability, with up to 4 hours of continuous playtime.
03 04
6
7
8
9
10
CONTROL PANEL
Left Button
Used for preset selection and parameter control.
Right Button
Used for preset selection and parameter control.
Master Knob
Adjusts the global output volume.
Display
2-inch TFT color screen for clear and intuitive operation.
Edit Knob
Rotate and press to adjust parameters shown on the display.
1
2
3
4
5
Notes : Please use a 1 /4" TRS c able when us ing
the EXP/CTRL function. Otherwis e, the
function may not work properly.
POWER
Turns the device on or off. Powered by a built-in
Li-ion
battery.
USB-C
USB Type-C port for audio recording and streaming,
and for charging the built-in battery. Battery level is
shown on the dis play.
6
7
IN
1 /4" TS monoinput jack for connecting a guitar or
ba
ss.
8
9
EXP/CTRL
1 /4" TR S jack for connec ting an express ion pedal
(for volume control) or an external dual foots witch
( Ring=pres et down, Tip= pres et up).
OUT/PHONE S
1 /4" TRS s tereo output jack for connec ting to an
am pli er, audio interfac e, mixer, or headphones .
10
1
2
3
4
5
05 06
