Installation Instructions
BW-WS Water Sensor
Water
Sensor
The water sensor is designed to warn you of a potential flood. If you are installing
it in the sump pit, it must be installed between the basement floor and the primary
float switch. If there is a failure with either the main pump or the plumbing system,
the water level will rise past the primary float switch and activate the water sensor.
When the water sensor is activated, it will send a signal to the connected module
and you will receive a notification on the registered mobile device.
Note: This water sensor is only designed to give you a warning of a potential
problem; it will not activate the primary pump.
Installing the Water Sensor
The water sensor should be mounted near the top of the pit or where it is appropriate for your
installation (see diagram). Attach the water sensor very securely with the included hose clamp.
Be sure the water sensor is positioned vertically with the mounting bracket at the top. Plug the water
sensor into the bottom of the controller. Do not tilt the water sensor. Do not position the water sensor
on the side of the discharge pipe facing the drain tile or any incoming rush of water.
Testing the Water Sensor
Li up the float on the water sensor with your ngers. As long it is up, the high water alarm warning
light and the audible alarm should be on. When the float is down, the warning light and audible alarm
will turn o.
Maintenance
Each time the high water alarm is activated it must be cleaned and retested to ensure it is working
properly.
LIMITED WARRANTY
By opening this package and using this GLENTRONICS, INC. product, you are agreeing to be bound by the terms of the GLENTRONICS, INC. limited warranty (“warranty”) as set
out below. Do not use your product until you have read the terms of the warranty. If you do not agree to the terms of the warranty, do not use the product and return it within the
return period stated on your purchase receipt from the retail store or authorized distributor where you purchased it for a rend.
To the extent permitted by law, this warranty and the remedies set forth are exclusive and in lieu of all other warranties, remedies and conditions, whether oral, written, statuto-
ry, express or implied. GLENTRONICS, INC. disclaims all statutory and implied warranties, including without limitation, warranties of merchantability and tness for a particular
purpose and warranties against hidden or latent defects, to the extent permitted by law. GLENTRONICS, INC. will not be liable for any incidental, special or consequential dam-
ages for breach of any express or implied warranties on this product. In so far as such warranties cannot be disclaimed, GLENTRONICS, INC. limits the duration and remedies of
such warranties to the duration of this express warranty and, AT GLENTRONICS, INC.'s option, the repair or replacement services described below. Some states (countries and
provinces) do not allow limitations on how long an implied warranty (or condition) may last, so the limitation described above may not apply to you.
Any and all causes of action arising from, led as a result of or in reference to, this warranty or the products described under this warranty shall be governed by and construed
under the laws of the State of Illinois. Any cause of action arising from, led as a result of or in reference to, this warranty or the products described under this warranty shall be
led only in the Circuit Court of the 18th Judicial District, Lake County, Waukegan, Illinois, or in the Northern District of Illinois if led in Federal Court. The maximum liability for
any product described in this warranty shall be the cost of product replacement only.
If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be aected or impaired.
What is Covered by this Warranty?
GLENTRONICS, INC. warrants to the end purchaser that its pumps, switch and control unit products are free from defective materials and workmanship for the periods indicated below:
All parts and labor (excluding installation) for a period of:
• 1 year from the date of purchase
The defective product must be returned directly to the factory, postage prepaid with the original bill of sale or receipt to the address listed below. GLENTRONICS, INC., at its
option, will either repair or replace the product and return it postage prepaid.
What is NOT Covered by this Warranty?
This warranty does not cover the cost or value of damaged property, including expressly any property that has been aected by water overflow, seepage or flooding. If GLEN-
TRONICS, INC. determines that a product is deemed defective under this warranty agreement, it will repair or replace the PRODUCT ONLY. GLENTRONICS, INC. will not cover the
cost to reinstall the product, nor will GLENTRONICS, INC. pay the cost of having a plumber or contractor repair or replace the product.
GLENTRONICS, INC. will not repair or replace a product that was installed incorrectly. A product shall be considered “installed incorrectly” when it deviates in any way from the
instructions described in this manual.
This warranty does not cover product problems resulting from handling liquids hotter than 104 degrees Fahrenheit, handling inflammable liquids, solvents, strong chemicals
or severe abrasive solutions; user abuse; misuse, neglect, improper maintenance, commercial or industrial use; improper connection or installation, damages caused by light-
ning strikes; excessive surges in AC line voltage; water damage to the controller; other acts of nature, or failure to operate in accordance with the enclosed written instructions.
How to Obtain Warranty Service
Within thirty (30) days of the product’s defective performance, the unit must be shipped, freight prepaid, or delivered to GLENTRONICS, INC. to provide the services described
hereunder in either its original carton and inserts, or a similar package aording an equal degree of protection. Products not received by GLENTRONICS, INC. at the address
indicated below within thirty (30) days of the product’s defective performance will not be considered for warranty service. Products received aer one (1) year from the date of
purchase, fall outside of the timeframe for warranty service and will not be eligible for warranty service. The product must be returned to GLENTRONICS, INC. for inspection in
order to be considered for warranty service. If the product is not returned to GLENTRONICS, INC. or the product is inspected by any person, plumber, contractor or business other
than GLENTRONICS, INC., this warranty shall no longer be valid. Prior to defective operation, the unit must not have been previously altered, repaired or serviced by anyone
other than GLENTRONICS, INC., or its agent; the serial number on the unit must not have been altered or removed; the unit must not have been subject to accident, misuse,
abuse or operated contrary to the instructions contained in the accompanying manual. The dealer's dated bill of sale, or installer’s invoice must be retained as evidence of the
date of purchase and to establish warranty eligibility.
Where are Products Sent for Warranty Service?
Glentronics, Inc., 645 Heathrow Drive, Lincolnshire, IL 60069
How Can I Obtain More Information?
By calling 800-991-0466. 1806201 11/2023
