www.PyleUSA.com
Features:
• Includes Additional Shelf for Increased Storage Capacity
• Attachable and Lockable Heavy-Duty Wheels
• High Quality Steel Frame Construction
• Strong and Durable
• 4 Wheels with Locks on the Bottom
• Powder Coating Finish that Protects from Scratches and Corrosion
• Easy Access for Maintenance and Installation
• Suitable for Servers, Switches, Routers, Patch Panels, and Other Network Devices
• Compatible with 19" Equipment Standard
• Full set of Accessories for Wall-mounted Used
• Open Design Vented Shelves to Optimize Air Flow
• Updated Screw Wrenches to Improve the Installation Eciency
• User-friendly Design and Easy to Assemble
• Front American Standard Round Hole and Side Square Hole
• One 1U Vented Shelves and One 2U Vented Shelves
• Strong Load Capacity
What's in the Box:
• 70 Sets of Screws
• 50 Sets American Standard Inner Hexagon Screw
• 20 Sets Inner Hexagon Screws
• (2) Hexagonal Screwdrivers with Red Handle (0.11” x 0.19”)
• (1) Wrench
Technical Specs:
• Construction Materials: Steel
• Column Thickness; 0.07” -inches, and the Rest is 0.04” -inches
• Weight Capacity: Supports up to 440lbs of Equipment
• Item Weight: 23.76 –lbs.
• Product Dimensions (L x W x H):
PLRS10UW: 20.04” x 20.42'' x 17.5'' -inches
PLRS15UW: 20.04'' x 20.42'' x 26.25” -inches
PLRS20UW: 20.04'' x 20.42'' x 35'' -inches
Questions? Comments?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]
www.PyleUSA.com
Assembly
S.N DESC. QTY
PART NAME
1 LEFT FRAME 1
INSTALLATION ACCESSORIES
9 M8*12 SCREW 22
INSTALLATION TOOLS
14 M8 WRENCH 1
2 RIGHT FRAME 1
3 FRONT TOP BRACE 1
4 FRONT BOTTOM BRACE 1
5 BACK TOP BRACE 1
6 BACK BOTTOM BRACE 1
7 SHELF 1U 1
8 SHELF 2U 1 (2)
10 M8 NUT 22
11 M8*80 DYNABOLT 4
12 CASTER WITH BRAKE 4
13 10-32 SCREW 22
15 H5 Phillips Screwdriver 1
16 H3 Phillips Screwdriver 1
1
2
8
3
5
4
6
7
9
12
15
10
13
16
11
14
14
16
1
3
8
7
4
12
10
5
2
13
6
9
15
Step 1 Step 2
Step 3 Step 4
