PARALLEL CONNECTION
THE PREMISE OF CONNECTION
To connect in parallel, batteries should meet the below conditions:
a. identical batteries with the same battery capacity (Ah) and BMS (A);
b. from the same brand (as lithium battery from different brands has their
special BMS);
c. purchased in near time (within one month).
Support connecting up to 4 identical batteries in parallel for up to:
16V 400Ah battery system.
LIMITATION FOR SERIES/PARALLEL CONNECTION
Parallel Connection
16V 400Ah
100Ah
100Ah
100Ah
100Ah
16V
16V
DO NOT Support
Series Connection
