Figure 1
Figure 2
posts
post
split
sleeve
shelf
mounting
angle
Snap split sleeves onto posts at the desired location for the second shelf. Lower shelf onto posts until split
sleeves are snugly seated with corner collars. Repeat for additional shelves. Securely seat all shelves by
placing a board accross the corners of the shelves and gently tapping with a hammer. Shelf assembly is
now ready for use.
Remove 2 screws on end of table that secures top to side. Place the mounting angles on edge of tabletop
and replace screws through angles and into table. Repeat on other side. Once the mounting angles are
secure, screw posts to mounting angles. Hand tighten. Refer to Figure 1.
1
Additional Shelves
Mounting Plates
3
Referencing numbers on posts, snap plastic tapered split sleeves onto each post at desired location for shelf.
Refer to Figure 2. The thicker part of the taper goes towards the bottom. Make sure the rib on the split
sleeve is seated into the groove at the selected height. Place the first shelf over the posts until the split
sleeves are seated snugly within the collars.
First Shelf
2
4-Post Kit
• Four (4) - Post (18˝, 30˝, or 48˝ height)
• Two (2) - Mounting Angles
6-Post Kit
• Six (6) - Posts (18˝, 30˝ or 48˝ height)
• Two (2) - Mounting Angles
• One (1) - Mounting Plate
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING CARRIER FOR ANY DAMAGE.
SAVE YOUR BOX AND ALL PACKING MATERIALS.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
ASSEMBLY INSTRUCTIONS
Flexmaster Overshelf
For Hot Food Tables
INSTRUCTION SHEET
#312562
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2023 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A.
• Phone: 302/653-3000 • 800/441-8440 • Fax: 302/653-2065
• www.eaglegrp.com • www.eaglegrpnews.com • www.eaglemhc.com
EG9835 Revised 05/23
Parts Listings
