US EU UK AU
Choose the compatible outlet adapter for your region and slide it in into place.
3
Slide the released outlet adapter up.
2
To disconnect the attached outlet adapter slide the switch on the top of the device away from the connector.
1
QUICK GUIDE
145W USB-C 4-PORT GAN
TRAVEL CHARGER
REPLACING OUTLET ADAPTER
PD1 & PD2 ports support PD 3.1 @ 140W.
140W charging speed on PD1 or PD2 ports can be acheved only if single port is in use.
Must use compatible MagSafe cable to reach 140W charging speeds.
Four port connection
6
PD1
PD2
PD3
PD4
65W
30W
25W
20W
Triple port connection
5
PD1
PD2
PD3
PD4
PD1 + PD2 + PD3
65W + 30W + 45W
PD1 + PD2 + PD4
65W + 30W + 45W
PD1 + PD3 + PD4
100W + 25W + 20W
PD2 + PD3 + PD4
100W + 25W + 20W
Dual port connection
4
PD1
PD2
PD3
PD4
Single port connection
3
PD1
PD2
PD3
PD4
140W
140W
45W
45W
PD1 + PD2 65W + 65W
PD1 + PD3 100W + 45W
PD1 + PD4 100W + 45W
PD2 + PD3 100W + 45W
PD2 + PD4 100W + 45W
PD3 + PD4 25W + 20W
Connect and charge up to four USB-C devices at a time.
Total max output is 145W
2
PD1
PD2
PD3
PD4
PD1
PD2
PD3
PD4
Plug in cables (sold separately) to charger’s USB-C PD
ports.
1
CHARGING YOUR DEVICES
