User manual
SKU:2IHPP2300
Model:2IHPP2300(AST-WR416)
Type-C Input and Output:DC 5V/2.1A
Wireless Output:5W
Capacity:5000mAh/3.85V/19.25Wh
Wireless Power Bank Function Introduction:
LED Power Indicator:
The wireless power bank has 4 white LED lights to indicate power level, corresponding to 25%, 50%, 75% and 100% respectively.
While charging: The LED lights turn on incrementally from 25% to 100%. All 4 lights stay solid when fully charged.
While discharging: The LED lights turn off gradually from 100% down to 25%. All lights turn off when power runs out.
When battery power is low, the 25% indicator light flashes to remind low power.
Wireless charging adopts one green indicator lamp: The wireless charger supports automatically power on function at wireless output
area, the green indicator keep on during working.
Green light flashes under foreign object detection.
Wireless charging will auto shut off in around 20 seconds without phone placement or FOD trigger.
Button function:
Single click to check remaining battery, turn on Type-C output and wireless function.
Long press the button to close all outputs and LED display.
Mobile wireless power bank protection functions:
Over voltage protection, over-discharge protection, over current protection, FOD foreign object protection and battery
over-temperature protection.
Charge and discharge simultaneously:
Supports charging itself and supplying power to other devices at the same time.
IMPORTANT SAFETY PRECAUTIONS
When using your Power Bank, basic safety precautions should always be followed, including.
READ ALL INSTRUCTIONS BEFORE USING YOUR POWER BANK.
1.Never expose your power bank to high temperatures, extreme cold, high humidity.moisture, or water.
2.To avoid the risk of electric shock, never attempt to open or repair your power bank without the assistance of a certified professional.
3.Your power bank is not to be used by children or the infirm without adult supervision.
4.Unplug your smartphone or USB device from your power bank when it is fully charged.
5.Do not use your power bank at temperatures under 32°F (0°C) or over 104°F(40°C).
6.Do not drop or throw your power bank or subject it to strong impacts or physical trauma.
7.Please charge the power bank every 3 months to prevent the degradation of battery performance caused by over-discharging.
8. Contact the manufacturer for support if you detect any abnormalities when using your power bank. In addition, do not continue to
use your power bank if you detect any leak age smoke, or fire.
9. If fluid from inside the power bank gets into your eyes, do not rub your eyes. Wash your eyes with clean water and immediately
contact a physician.
10. When connected, Do not place your power bank on flammable materials such as rugs,carpets, or bedding.
11. Clean your power bank using a soft cloth or paper towel.
12. Do not use harsh chemicals when cleaning your power bank, and never submerge it in water.
FCC Information and Copyright
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
FCC RF warning statement: the device has been evaluated to meet general RF exposure requirement , The device can
be used in portable exposure condition without restriction.
