INSTALLATION AND USER’S GUIDE
15,000 GALLON
REPLACEMENT SALT CHLORINATOR CELL
25,000 GALLON 40,000 GALLON
SKU: SKU: SKU:
90160
90161
90162
90162
90161
90160
1
TABLE OF CONTENTS
13DISCLAIMER
SPECIFICATION
5INSTALLATION DIAGRAM
5INSTALLATION
4
4PRODUCT OVERVIEW
4PRODUCT INFORMATION
2
Legends and Symbols
2IMPORTANT SAFETY INSTRUCTIONS
1TABLE OF CONTENTS
13Customer Service
13Disclaimer
STEP 2
6
STEP 1
7
STEP 4
7
STEP 3
GENERAL SAFETY INFORMATION 3
6
STEP 6
8
STEP 5
9
STEP 8
9
STEP 7
8
10
STEP 10
10
STEP 9
11STEP 12
11
STEP 11
12REPLACEMENT PARTS
12REPLACEMENT PARTS
IMPORTANT SAFETY INSTRUCTIONS
2
For safety reasons, children should not be allowed to use this product.
Packing materials and plastic bags are not toys. Keep them away from children to prevent the risk
of suffocation.
Failure to comply with all instructions and warnings may lead to severe bodily
injury or even death. For optimal safety and functionality, it is advisable to have the product installed
and serviced by a certified service professional. Prior to using this product, installers, operators, and
owners must carefully review these warnings and all instructions provided in the owner's manual. It
is essential to leave these warnings and the owner's manual with the owner for their reference and
safety.
ATTENTION INSTALLER: This manual contains vital information regarding the installation,
operation, and safe use of this product. It is essential to provide this manual to the end user of the
product. Failure to read and follow all instructions could lead to severe injuries.
USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY
DANGER: Ignoring these hazards can result in death, severe personal injury, or
significant property damage.
WARNING: Indicates potential hazards that can result in severe personal injury,
death, or significant property damage. Ignoring these warnings presents a real
danger.
CAUTION: Indicates potential hazards that can result in minor or moderate
personal injury, property damage, or actions that are unpredictable and unsafe.
Ignoring these cautions presents a potential hazard.
NOTICE: This label indicates important special instructions that are not directly
related to hazards.
This guide provides instructions for installing and using the product. If you have any questions about
the equipment, please contact XtremepowerUS.
This guide contains important information about safely installing and operating this product. After
installation, make sure to share this information with the owner/operator or leave it with them for
their reference.
Legends and Symbols
When you come across the safety-alert symbol on your equipment or in this manual, pay attention
to the following signal words and remain vigilant about the potential for personal injury.
IMPORTANT SAFETY INSTRUCTIONS
DANGER
WARNING
WARNING
NOTE
DANGER
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
3
GENERAL SAFETY INFORMATION
• High Voltage Electrocution Hazard
• Hazardous voltage can shock, burn, cause serious injury, or death. To reduce the risk of
electrocution and electric shock:
▪ Only qualified technicians should remove the equipment.
▪ Replace damaged wiring immediately.
▪ Ensure the equipment is properly connected.
• Electric Shock: Electrical wiring must follow local codes and NEC® standards.
• Child Safety: Do not allow unsupervised children to use this product.
• Temperature Impact: Higher temperatures may require more chlorine. Adjust based on
factors like bather load, temperature, and debris.
• Gas Build-Up: Turn off the unit when adjusting plumbing valves to avoid hazardous gas
build-up.
• Installation: Ensure pool materials are compatible with chlorine and salt. Operate the chlo-
rine generator only when the pump is running.
WARNING
NOTE
• Maintain proper pool chemistry at all times.
DANGER
4
MODEL / SKU #
POOL CAPACITY
CELL LIFETIME
(APPROX. 3 YEARS WITH
8-HOUR DAILY USE)
POWER CORD LENGTH
SPECIFICATION
PRODUCT INFORMATION
PRODUCT OVERVIEW
PRODUCT INFORMATION
WATER
INFLOW
WATER
OUTFLOW
13.3 FT 13.3 FT 13.3 FT
UP TO 15,000
GALLONS
10,000 HOURS
UP TO 25,000
GALLONS
10,000 HOURS
UP TO 40,000
GALLONS
10,000 HOURS
90160 90161
90162
INSTALLATION
5
INSTALLATION
INSTALLATION DIAGRAM
POOL CARTRIDGE FILTER POOL PUMP
POOL
INLET PORT
POOL
OUTLET PORT
SWIMMING POOL
SALT CHLORINATOR CELL
SALT CHLORINATOR CONTROL BOX
WATER FLOW VALVE
INSTALLATION
6
STEP 1
STEP 2
AIR RELIEVE VALVE
WATER FLOW VALVE
ELECTRIC POWER SOURCE
OFF
INSTALLATION
7
STEP 3
EXISTING SALT CHLORINATOR CELL
SALT CHLORINATOR CONTROL BOX
SALT CHLORINATOR
CELL PLUG
STEP 4
EXISTING SALT CHLORINATOR CELL
INSTALLATION
8
STEP 5
STEP 6
EXISTING SALT CHLORINATOR CELL
NEW SALT CHLORINATOR CELL
WATER INFLOW
WATER OUTFLOW
INSTALLATION
8
STEP 7
STEP 8
NEW SALT CHLORINATOR CELL
SALT CHLORINATOR
CELL PLUG
NEW SALT CHLORINATOR CELL
INSTALLATION
9
SALT CHLORINATOR CONTROL BOX
INSTALLATION
10
STEP 9
STEP 10
AIR WATER
WATER FLOW VALVE
ELECTRIC POWER SOURCE
ON
INSTALLATION
11
STEP 11
STEP 12
AIR RELIEVE VALVE
SALT CHLORINATOR CONTROL BOX
RESET
1
1
0
2
0
3
0
4
0
5
0
6
0
7
0
8
0
9
0
1
0
0
Calibrate Salt Reading:
• With the pump running, switch from "Auto" to
"Off," then back to "Auto." Wait for the click.
• After the click, press the diagnostics button
5 times to start calibration.
• When the display matches the pool’s salt
level, switch to "Super Chlorinate," then
back to "Auto."
AUTO
OFF
SUPER CHIORINATE
INSTALLATION
12
REPLACEMENT PARTS
PARTS DIAGRAM
1
2
ITEM
1
2
DESCRIPTION
CELL BODY
UNION NUT FIT 2” UNION SLIP
QTY
1
2
13
DISCLAIMER
DISCLAIMER
PLEASE READ THE FOLLOWING CAREFULLY
The manufacturer and/or distributor have provided the parts list and assembly diagram in this
manual for reference purposes only. They do not make any representation or warranty to the buyer
that they are qualified to make repairs to the product or replace any parts of the product. In fact, the
manufacturer and/or distributor expressly state that all repairs and parts replacements should be
undertaken by certified and licensed technicians, and not by the buyer.
The buyer assumes all risk and liability arising from their repairs to the original product or
replacement parts or arising from their installation of replacement parts. It is strongly advised that
qualified professionals handle any repairs or replacements to ensure safety and proper functioning
of the product. Improper installation and operation may result in injury, property damage, or voiding
of warranty. The manufacturer and/or distributor shall not be held responsible for any accidents,
damages, or malfunctions resulting from the buyer's installation and operation of the product. It is
essential to follow all safety guidelines and recommendations provided in this manual and to seek
professional assistance if unsure about the installation or operation procedures.
CUSTOMER SERVICE
If you have any questions about ordering our pool pumps and replacement parts or pool products,
please feel free to contact us using the following contact information:
Customer Service and Technical Support
Phone: (909) 628-0880
Email: [email protected]
Hours of Operation: Monday – Friday, 9AM – 4PM (CST)
