OWNER'S MANUAL
VACUUM CLEANER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
A9L-TITAN / A9L-TOWER
MFL05759030
Rev.00_073025
www.lg.com
Copyright © 2025 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
CAUTION ...........................................................................................................10
INSTALLATION
Product Overview.............................................................................................12
Storing the Accessories ...................................................................................15
OPERATION
Getting Started .................................................................................................17
Charging the Battery .......................................................................................19
Using the Mop Nozzle.....................................................................................20
Using the Nozzles and Tools...........................................................................24
MAINTENANCE
Cleaning the Appliance...................................................................................27
Cleaning the Nozzles .......................................................................................31
TROUBLESHOOTING
Before Calling for Service................................................................................35
3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘
WARNING
’ and ‘
CAUTION
’ as
described below.
Safety Messages
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic
precautions, including the following:
Technical Safety
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
This symbol is displayed to indicate matters and
operations that can cause risk. Read the part with this
symbol carefully and follow the instructions in order to
avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
4
SAFETY INSTRUCTIONS
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
• Do not allow the appliance to be used as a toy. Close attention is
necessary when used by or near children.
• Do not allow children to play with or hang on the appliance.
• Do not use the appliance with damaged power cord or plug. The cord
must be replaced. If the appliance is not working as it should, has
been dropped, damaged, left outdoors, or dropped into water, return
it to an LG Electronics service centre.
• Do not pull or carry by cord, use cord as a handle, close a door on
cord, or pull cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the
cord.
• Place the cords from other appliances out of the area to be cleaned.
Battery
• Never use the battery, adapter, and the charging station from other
appliances with this appliance. Use only the battery and the charging
station provided by LG Electronics.
• Never use the battery, adapter, and the charging station from this
appliance with other appliances.
• Unplug the power cord and remove the battery if the appliance will
not be used for an extended period of time.
• Do not use modified or damaged batteries.
• Do not disassemble, remove or short-circuit the battery.
• When disposing of the battery or the appliance, remove the battery
from the appliance and safely dispose of it.
• Have specifically designated battery packs replaced when it is no
longer able to hold a charge.
• Refer to the
Charging the Battery
section instructions for the
method of replacing the battery.
5
SAFETY INSTRUCTIONS
ENGLISH
• When disposing of this appliance, follow regulations for disposal of
rechargeable lithium-ion batteries.
• Follow all local ordinances and regulations when handling or
disposing of the battery.
• Prevent unintentional starting. Ensure the switch is in the off position
before connecting to the battery pack, picking up or carrying the
appliance.
• Disconnect the battery pack from the appliance before making any
adjustments, changing accessories, cleaning, serviing, or storing
appliance.
• When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another.
• Under abusive conditions, liquid may be ejected from the battery. If
this happens, avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
• If the appliance is to be stored unused for a long period, the batteries
should be removed.
• Before removing the battery, you must turn off this appliance.
• When fitting the battery into the product body, insert it completely
until it clicks.
Battery Specifications
• One or two batteries are provided, the number of batteries varies
depending on the model purchased.
-
Battery Model Name
: EAC633822**
-
Type
: Rechargeable Lithium-ion Battery
-
Rated Capacity
: 2400 mAh
Installation
• To avoid an electrical shock or fire, do not install, charge or store the
appliance where it may be exposed to water, rainfall or high
humidity.
6
SAFETY INSTRUCTIONS
• Install, charge and store the appliance in a well-ventilated place.
• Avoid operating the appliance in areas where there is a risk of
leakage of flammable gas, industrial oil or metallic dust.
• Do not store or install the appliance, power cord or plug near heating
devices or open flames.
• Install the charging station on a firm, level surface.
• Do not use or store the appliance at temperatures below 5 ℃ or
above 38 ℃.
• Do not store or install the appliance where it is exposed to
temperatures below freezing or exposed to outdoor weather
conditions.
• When installing or moving the appliance, be careful not to pinch,
crush, or damage the power cord or plug.
Operation
• Read all instructions before using the appliance, and save these
instructions.
• Use only as described in this manual. Use only manufacturer’s
recommended attachment.
• This appliance is designed for normal indoor domestic use only. It is
not to be used for any non-residential, commercial, or industrial
application.
• Do not handle the power cord, plug, or appliance controls with wet
hands.
• Wipe any moisture or dirt off the cord or plug with a dry cloth.
• Never attempt to operate this appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug. Take it to an authorized LG
Electronics service centre or dealer for assistance.
• Do not apply excessive force to the power cord to bend it, or place it
under a heavy object as this will damage it.
• Do not use multiple-outlet adapters with this appliance. Make sure to
use a power socket with a capacity of 10 A.
7
SAFETY INSTRUCTIONS
ENGLISH
• Do not plug the appliance into a damaged or loose outlet.
• Make sure to unplug the power cord when the appliance is not to be
used for an extended period of time.
• Do not damage, alter, excessively bend, twist, pull, pinch or heat the
power cord.
• Before using the appliance, remove any wire or string on the floor.
• Avoid touching the prongs of the power plug with your finger(s) when
unplugging the power cord.
• Do not cover the power cord with a rug or carpeting.
• Push the power plug firmly into the wall outlet so that it is not loose.
• If the product has been submerged, contact an LG Electronics service
centre or dealer for instructions before resuming use.
• If the product makes a strange noise or emits an odour or smoke,
discontinue use and contact an LG Electronics customer information
centre.
• Only qualified technicians or service personnel from LG Electronics
may disassemble, repair or modify the appliance.
• Never insert a sharp metallic object such as a pin, nail or knife in a
hole or gap in the appliance or the charging station.
• Do not vacuum liquids with this appliance. Make sure that no water,
beverage or detergent gets inside the appliance or the charging
station.
• Do not allow the appliance to sweep up blades, thumb tacks,
sawdust, sharp objects, or hot or cold ashes.
• Do not allow children to use the appliance.
• Do not let children or pets get close to the appliance when using,
charging or storing.
• Do not insert the nozzle or tools in your mouth.
• Keep clothing and hair, fingers, or other parts of the body away from
openings and moving parts.
• Do not operate the appliance with the suction inlet or outlet blocked.
• Do not use the appliance without the dust bin and filters in place.
8
SAFETY INSTRUCTIONS
• Do not use in an enclosed space where vapors are present from paint
thinner, mothproofing substances, flammable dust or other
explosive or toxic materials.
• Do not touch the charging terminals on the appliance or the charging
station, or insert an electrified object inside the appliance or the
station.
• Always store the appliance on the charging station when it is not in
use.
• Do not lean the appliance on walls, chairs or tables.
• If the earth leakage breaker is tripped when the product is put on the
charging station, immediately remove the appliance from the
charging station. Contact an LG Electronics customer service centre.
• Use extra care when cleaning on stairs.
• Do not use or store a heating device or flammable substance(ether,
benzene, alcohol, chemicals, combustible sprays, insecticide, air
freshener or cosmetics) in close proximity to the appliance.
• Do not attempt to clean up a liquid substance (water, beverage),
odourous substances (candy, chocolate, pet excrement), metallic
objects (blades, pins), flammable substances, burning/
smoking(cigarettes, matches, or hot ashes), surfactants, or glass
shards with this appliance.
• In the event of a gas leak(natural gas, propane gas, etc.), do not
operate this or any other appliance. Open a window or door to
ventilate the area immediately.
• Do not hold the charging station upside down with the battery in the
charging station.
• Do not expose the appliance, and the battery in particular, to heat, a
heating device or direct sunlight.
• Do not keep the appliance or its battery inside a vehicle which is
exposed to direct sunlight.
• Never allow any water, beverage or detergent to get inside the
battery.
• Do not apply physical impacts to the battery.
9
SAFETY INSTRUCTIONS
ENGLISH
Maintenance
• Make sure to unplug the power cord when cleaning or maintaining
the charging station.
• Do not wash the inlet port or the dust bin with water or detergent.
• Do not use detergents, polishes or air fresheners to clean the dust
bin.
• Do not apply or spray a flammable substance (gasoline or thinner) or
surfactants (detergent or bath soap) on the appliance.
• Wash hands after handling nozzles. The nozzles contain carbon fiber,
and contact may cause minor skin irritation.
Disposal
• Keep packing materials out of the reach of children. Packaging
materials can pose a suffocation risk for children.
• Destroy the carton, plastic bag, and other packing materials after the
appliance is unpacked. Children might use them for play. Cartons
covered with rugs, bedspreads, or plastic sheets can become airtight
chambers.
• Dispose of this appliance according to local, state, and regional laws
and regulations.
• Contact your local city council or the related government authority
before disposing of this appliance.
Mop Nozzle
• Do not use the mop nozzle to clean up sharp objects such as glass
shards, wires, blades, or pins. The sharp objects could become
embedded in the mop pads and cause injury when you clean the
pads.
10
SAFETY INSTRUCTIONS
CAUTION
CAUTION
• To reduce the risk of injury to persons, malfunction, or damage to the
product or property when using the appliance, follow basic safety
precautions, including the following:
Operation
• This appliance has a built-in safety device to prevent damage from
overheating. If the appliance becomes overheated after extended
use, it may automatically turn off. If this occurs, leave the appliance
in a cool, well-ventilated area for about an hour before turning on the
power again.
• Do not subject the product to shocks or drop it.
• Do not install wet or damp filters.
• Always use a soft cloth to clean the appliance. Do not clean the
product with a volatile or organic solvent(thinner or acetone).
• Do not clean the same spot repeatedly for an extended period of
time. Doing so may damage the carpet or flooring surface.
• Keep fingers away from pinch points when assembling the appliance
or the charging station.
• Do not apply force or any impact to the Cyclonic Mesh Filter.
• Do not remove the battery during operation.
Mop Nozzle
• Do not use the mop nozzle for any purpose(for example, polishing a
car, cleaning windows) other than domestic floor cleaning.
• Do not use the mop nozzle to vacuum up liquids(water, beverage).
• When using the mop nozzle, always attach the mop pads.
• Do not clean a coated, rough or delicate floating floor and carpets
with the mop nozzle.
11
SAFETY INSTRUCTIONS
ENGLISH
• Do not use the mop nozzle to clean the same spot repeatedly for an
extended period of time. The water injection at the mop nozzle may
cause water to get into the dust inlet and damage the appliance.
• Do not step on the mop nozzle.
• Wet floors can pose a slip hazard. Allow floors to dry completely
before allowing anyone to walk on them.
• Do not store the appliance by attaching the water tank filled with
water to the mop nozzle.
12
INSTALLATION
INSTALLATION
Product Overview
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Front View
*1 This feature is only available on some models.
a
Product Body
b
Extension Pipe
c
Nozzle
d
Battery (Dual Battery
*1
)
e
Exhaust Filter
f
Kompressor Lever
g
Pre-filter
h
Cyclonic Mesh Filter
i
Dust Bin
NOTE
• Use the vacuum cleaner only with the provided charging station. Using a charging station other than the
one designed to be used with the vacuum cleaner, as improper sealing of the chagring station may
result and dust not being emptied from vacuum cleaner.
13
INSTALLATION
ENGLISH
Accessories
*1 This accessory is only available on some models.
Included Accessories
a
Product Body
b
Extension Pipe
c
Pre-filter
d
Exhaust Filter
e
Battery (Dual Battery
*1
)
Basic Accessories
a
Combination Tool
b
Crevice Tool
Nozzles
a
Dual Floor Max Nozzle
b
Pet Nozzle
Mop Kit
a
Mop Nozzle
*1
b
Mop Pads for General Cleaning
*1
NOTE
• The batteries, exhaust filter and the pre-filter will
eventually need to be replaced. Contact an LG
Electronics customer service centre.
Optional Accessories
*1 This accessory not included in any A9L models.
Each sold separately.
a
Hard Dirt Tool
*1
b
Mattress Tool
*1
c
Multi-angle Tool
*1
d
Flexible Crevice Tool
*1
e
Flexible Hose Extension
*1
f
Bedding Nozzle
*1
14
INSTALLATION
Specifications
Appliance
• Dimensions are given for the assembled product body, extension pipe and nozzle.
• Suction power is an average of suction power with IEC 62885-2, 5.8 standard tested by an independent
test lab. Individually measured data would be different from a lab test result.
• Battery run time is the result of using a fully charged battery according to the LG Electronics test
standard. Results may be different depending on actual use environment and period of use.
• Recommended maximum run time when using the mop nozzle is 60 minutes. Otherwise, the motor may
overheat.
*1 Up to 120 minutes run time when using 2 batteries in Eco power mode without any nozzle. Actual run
time may vary when using nozzle attachments and depending on the operating environment and
settings.
Charging Station
The provided charging station is different by the purchased models.
Model
A9L-TITAN / A9L-TOWER
Dimensions
(Width X
Depth X Height)
265 mm X 305 mm x 1120 mm
Weight
Approximately 2.88 kg
Power Consumption
350 W in
Turbo Mode
(Maximum 650 W)
105 W in
Normal Mode
53 W in
Eco Mode
Battery Run Time
(Using two battery)
Using with the Nozzle
*1
Up to 12 minutes in
Turbo Mode
Up to 40 minutes in
Normal Mode
Up to 70 minutes in
Eco Mode
Without any Nozzle
Up to 14 minutes in
Turbo Mode
Up to 60 minutes in
Normal Mode
Up to 120 minutes in
Eco Mode
Battery Run Time
(Using one battery)
Using with the Nozzle
*1
Up to 6 minutes in
Turbo Mode
Up to 20 minutes in
Normal Mode
Up to 35 minutes in
Eco Mode
Without any Nozzle
Up to 7 minutes in
Turbo Mode
Up to 30 minutes in
Normal Mode
Up to 60 minutes in
Eco Mode
Model
VDS-ST2TN
Input
220-240 V~ 50 Hz
Output
28.3 V
%
/ 1.15 A
Power Consumption
1700 W (Cleaning)
0.4 A (Charging)
15
INSTALLATION
ENGLISH
Storing the Accessories
Assembling and Storing the
Appliance
Follow these steps to safely assemble the
appliance.
1
Firmly attach the extension pipe
c
, nozzle
d
,
or tool onto the product body
a
.
• To detach the extension pipe, press the
extension pipe release button
b
.
2
Put the product body on the charging station.
• If the vacuum cleaner fits properly inside the
charging station, the alarm will sound. Wait
several seconds and if the alarm does not
sound, reinsert the vacuum cleaner, making
sure that the nozzle is horizontal.
Storing the Tools
Use the product to store the inlet and components
provided with the vacuum cleaner.
The components may differ depending on the
vacuum cleaner model.
Storing on Sides
1
Open the nozzle hook
a
on both sides of the
product.
• To open the nozzle hooks, press on the right
side. Be careful not to pinch fingers when
opening.
2
Hang the nozzle on the nozzle hook.
16
INSTALLATION
Storage Inside
1
Open the left door of the product and insert
the bedding nozzle or the pet nozzle
a
for
storage.
2
Open the right door and insert the
combination tool
b
and the crevice tool
c
for
storage.
NOTE
• Before moving the product, unplug it and
remove the vacuum cleaner, nozzles, and
accessories.
• To carry the product, open both doors and hold
the areas shown.
17
OPERATION
ENGLISH
OPERATION
Getting Started
Before Using the Appliance
• Support the bottom of the appliance when
cleaning an elevated surface.
• To avoid scratches on polished floors, keep tools
and the brushes and rollers of the nozzles free
from hair, grit, sand, or abrasive objects.
• Make sure that the exhaust filter, pre-filter and
the dust bin are properly assembled before
using the appliance.
• Close the dust bin cover properly before using
the appliance. If the dust bin cover is left open,
the suction strength may deteriorate and affect
the cleaning results.
• Store the appliance in the charging station or
place it flat on the floor when not in use. Leaning
the appliance against a wall or chair can result in
product damage or personal injury if the
appliance falls.
• Environmental conditions such as temperature
and humidity may cause static electricity to
accumulate on the appliance. Please contact LG
Electronics customer information centre if the
problem persists.
• Make sure to remove any foreign object such as
a sock or stocking before using the appliance.
Any foreign object on the inlet port or extension
pipe will prevent the appliance from functioning
properly.
• Please use the product at normal room
temperatures as the battery runtime may
deteriorate severely if used at temperatures
lower than 5 ℃ or higher than 38 ℃ for an
extended period of time.
• The battery runtime is dependent on the surface
type and the suction power.
• Follow manufacturer’s recommendations when
cleaning flooring, carpets, and rugs.
• Refer to the
Specifications
section for battery
runtime details.
Assembling Attachments
Nozzles and tools can be attached to either the
product body or the end of the extension pipe.
1
Insert the fully charged battery
a
into the
cavity at the bottom of the handle on the
product body and push the battery until it
clicks.
• If it is not properly inserted, the battery may
fall out, causing product to malfunction or
personal injury.
2
Attach the nozzles, tools, or extension pipe by
sliding them onto the inlet
b
on the body until
they click into place. The nozzles and tools can
also be attached to the end of the extension
pipe
b
.
• Detach the accessories by pressing the
release button
c
.
3
Adjust the extension pipe by pressing the
length adjustment button
d
on the back of the
pipe and sliding until it clicks into place at the
desired length.
18
OPERATION
• The extension pipe extends in four steps.
4
Press the
Power
button to activate the
Normal
mode.
• To turn off the appliance, press the
Power
button again.
Adjusting the Suction Power
Adjust the suction power using the suction power
adjustment button on the handle.
a
Power
Button
• Press the
Power
button to turn the appliance
on or off.
• Press the
Power
button to activate
Normal
mode.
b
Suction Power Up (+) Button
• Press the + button to increase the suction
power. (
Eco
~
Normal
~
Turbo
)
c
Suction Power Down (-) Button
• Press the - button to decrease the suction
power. (
Turbo
~
Normal
~
Eco
)
Display
The handle of the appliance displays indicators for
clogged objects, filter cleaning alerts, battery
management, and the remaining battery charge.
a
Clogged Objects Indicator
• This indicator lights up when the interior of
the product body, Fixed pipe, inlets, nozzle,
exhaust filter, pre-filter, or cyclonic mesh
filter is clogged with foreign objects.
• If clogging persists, the motor will cycle and
the appliance will shut off. Remove the
foreign objects and clean the exhaust filter,
pre-filter and cyclonic mesh filter following
the steps in the
Removing Foreign Objects
section.
b
Filter Cleaning Cycle Alarm Indicator
• This indicator lights up when the appliance is
used for a certain period of time. Clean the
exhaust filter, pre-filter and cyclonic mesh
filter if necessary.
c
Battery Management Icon
• Genuine Battery Certification Notification: If
the battery is not genuine, the icon will flash
a red light.
• Battery Life Expiration Replacement
Notification: When the battery has reached
the end of its life and needs to be replaced,
the icon will display a solid red light.
d
Battery Level Indicator
• The remaining battery level is displayed in 3
stages according to the remaining battery
power.
• The battery level indicator blinks when the
battery needs to be charged.
19
OPERATION
ENGLISH
• As the product is charging, bars light up on
the battery level indicator to indicate the level
of charge.
• The battery level indicator light down when
the battery is fully charged.
Charging the Battery
Before Charging the Battery
• Make sure that the adapter is connected to both
the charging station and the power outlet.
• Fully charging a single battery usually takes 4
hours. It will take twice as long to charge both
the main and spare batteries.
• The battery will not be charged if the indoor
temperature is below 5 ℃. Only charge the
battery when indoor temperatures are between
5 ℃ and 38 ℃.
• The battery will eventually need to be replaced.
Due to the battery characteristics, runtime is
shortened after using the appliance repeatedly
for an extended period.
• The last bar on the battery indicator begins to
flash when the battery needs to be recharged.
Use the appliance with a fully charged battery.
• To maintain battery life on dual-battery models,
swap the positions of the two batteries
periodically, between the main body and the
spare charging station.
• If the main battery is charging on the charging
station, the spare battery will only start charging
once the main battery is fully charged.
Charging the Vacuum Cleaner
Storing the appliance on the charging station
automatically recharges the battery.
1
Press the
Power
button to turn the appliance
off.
2
Put the product body on the charging station.
• Make the extension pipe its shortest length
before placing the vacuum onto the charger.
• The appliance cannot be loaded onto the
charging station if either the combination
tool or the crevice tool is inserted. Use the
charging station only after removing the
combination tool or the crevice tool, if either
happens to be fitted
• When the vacuum is properly placed on the
charging station, the battery charge level is
displayed on the status display with the beep
sound. If you don't hear a beep, reload the
appliance on the charging station.
• When the charging is complete, the status
display turns off.
WARNING
• Make sure to securely fit the product body onto
the charging station. If the appliance falls off the
charging station, it could cause injuries, property
damage or product damage.
Charging the Spare Battery
After the vacuum cleaner has finished charging,
the spare battery will start charging.
One or two batteries are provided. The number of
batteries varies depending on the model
purchased.
CAUTION
• Keep fingers away from pinch points when
assembling or disassembling the battery from
the product body or the charging station to
avoid personal injury.
20
OPERATION
1
Lift the front of the control panel located at the
top of the charging station.
2
To insert, align the battery with the outline of
the battery charger.
3
Press the battery down into the compartment.
NOTE
• If the spare battery is inserted correctly, the
spare battery icon will be displayed. The spare
battery charging begins after the vacuum
cleaner battery charging is complete.
• Insert the spare battery completely. If the spare
battery is inserted correctly, the spare battery
icon will be displayed.
Using the Mop Nozzle
Before Using the Mop Nozzle
• The mop pads only rotate at one speed
regardless of what suction power setting the
product body is set to.
• To prevent product damage, the mop
attachment plate will automatically stop if there
are foreign objects stuck in the plate or if it is
subjected to a strong impact. Turn the appliance
off immediately and remove the foreign objects
or obstructions before resuming use.
• If you hear a noise while mopping, the mop pad
may have dropped off the mop attachment
plate. Turn off the product immediately and
reattach the mop to the attachment plate before
resuming use.
• Do not use a soiled mop pad to clean floors.
Using soiled mop pads or pads containing debris
can damage flooring. Always check the pads
after each use.
• Use only authorized LG Electronics mop pads.
• Empty the dust bin and clean the exhaust filter
and the pre-filter after using the mop nozzle.
Using the Wet Mop Pads
Press the
Power
button. You can use the only mop
mode and not turn on the dust suction function.
• Press the
~
button to turn on the dust suction
function.
21
OPERATION
ENGLISH
• Press the
button once while pressing the
~
button once to turn off the dust suction function.
CAUTION
• Do not assemble or disassemble the nozzle while
the appliance is turned on. Doing so may result
in injury.
• Set the water adjustment button to the
STOP
position when not using the appliance for an
extended period of time. Failure to do so may
result in product failure.
• Do not let the appliance stand on the floor while
the wet mop pads are attached. Doing so may
result in damage or swelling to wood flooring.
• Do not use on PVC or PU mat for infants or
children. Friction can cause the motor to
overheat.
• If you use the mop nozzle for a long time with the
suction off, the motor may overheat
(recommended duration of use: 60 minutes).
When the moter overheats, the overheating
prevention function is activated and the
appliance is automatically turned off. Use the
appliance after cooling the heat for about one
hour in a cool, well-ventilated place.
Filling the Water Tank
1
Press the
PUSH
button
a
to remove the water
tank from the mop nozzle.
2
Open the water inlet cap
b
of the water tank
and fill the tank with water.
• Do not put liquid other than water and hot
water in the water tank.
3
Close the water inlet cap tightly.
• If the water inlet cap is not closed properly,
water may leak.
4
Attach the water tank to the mop nozzle again.
• Insert the 2 tabs
c
at the front of the water
tank into the slots
d
on the top of the mop
nozzle. Press down at the centre
e
to lock
the tank in place.
Attaching the Mop Pads
1
Wet both sides of the mop pads with water
then squeeze out any excess water before
attaching the pads.
• Do not attach pads while they are dripping
wet.
22
OPERATION
• Attaching and using mop pads while they
are dry may affect the cleaning results.
2
Place the mop nozzle upside down on the floor.
3
Align and attach the centre of the mop pad
with the centre of the mop attachment plate.
• Attach the Velcro on the mop pad to the mop
plate. Attaching the mop pad upside down
or improperly may affect the cleaning
results.
4
Assemble the mop nozzle to the appliance.
Adjusting the Amount of Water
Slide the water adjustment slider button to adjust
the amount of water released onto the mop pad to
either
High Mode
or
Low Mode
.
WARNING
• To avoid injury, do not attach the mop pad while
the mop attachment plate is rotating.
• Do not insert your hand between the rotating
mop plates. Doing so may result in injury. Never
use the Mop nozzle without fitting the damp
mop pads as this will damage the flooring.
CAUTION
• Do not let the appliance stand on the floor while
the wet mop pads are attached. Doing so may
result in damage or swelling to wood flooring.
Always check with the flooring manufacturer or
supplier for wet mopping suitability.
Using with the Mop Nozzle
1
Attach the water tank and mop pads to the
mop nozzle.
2
Slide the water adjustment slider button to
adjust the amount of water released onto the
mop pad to either
High Mode
or
Low Mode
.
3
Press the
Power
button to start cleaning.
Drying the Water Tank and Mop
Pads
Drying the Water Tank
When cleaning is completed, make sure to empty
the water tank and dry it before storing the mop
nozzle.
High Mode
: Slide the slider
button to clean ingrained dirt or
supply a large amount of water.
Low Mode
: Slide the slider
button to supply a small amount
of water for cleaning wood or
other flooring that can be
damaged by too much water.
STOP
: Position the slide button in
the center. This stops the supply
of water so you can go over areas
that are already wet.
23
OPERATION
ENGLISH
CAUTION
• Turn the water inlet caps to make sure they
remain open when storing the water tank. If
caps are closed and not properly dried, it may
cause odour.
• Do not remove the water inlet caps from the
water tank. Caps may tear.
• Do not add detergent, vinegar or baking soda to
the water tank when washing. It is not easily
removed in the water tank, which may soil the
floor.
• After cleaning, wipe off any remaining water on
the water supply inlet
a
on the mop nozzle with
a soft cloth. The water could drip onto the floor
and damage it.
• Do not pull or stretch the rubber gasket on the
water supply inlet. Doing so may tear or damage
it.
1
Open the water inlet cap on the side of the
water tank and empty the water tank. Shake
the water tank to remove the remaining water.
2
Leave the water inlet cap open and allow the
water tank to dry in a well-ventilated area out
of direct sunlight for at least 24 hours.
• Keep the water tank after water is
completely empty and dry. Moisture or
residual water in the tank may cause odour.
NOTE
• If the water supply pipe inside the mop nozzle is
filled with water, water may not come out
properly when the mop nozzle is used. If water
does not come out properly, follow the steps
below.
1
Attach a wet mop to the mop nozzle where
the water tank is separated and set the
amount of water to
High Mode
.
2
Place the mop nozzle on the floor, turn on
the power, and let it run for about 1 minute.
Drying the Mop Pads
After using the mop pads, hand wash them and
allow them to dry before storing them.
24
OPERATION
CAUTION
• Do not use as follows, as it may become
deformed.
- Do not use bleach or fabric softener when
washing the mop pads.
- Do not dry the pads in a clothes dryer.
- Do not boil the mop pad.
- Mop pads are a consumable item and should
be replaced when they wear or no longer
clean.
1
Separate the mop pads from the mop
attachment plate.
2
Hand wash the pads with a neutral detergent.
• Storing mop pads in a damp state can result
in an unpleasant odour. Set the pads in a
well-ventilated area out of direct sunlight for
at least 24 hours or until completely dry.
Using the Nozzles and
Tools
Before Using the Nozzles and
Tools
Some accessories are only available on some
models.
Specialized attachments can help you clean more
effectively. Tools and nozzles can be attached to
the product body or the extension pipe.
• Adjust the suction power if the inlet gets stuck on
the floor, carpet, or bedding.
• Each Nozzle is equipped with a motor and may
make a sound when operating.
CAUTION
• Do not use the Multi-Surface Nozzle or Slim Hard
Floor Nozzle on PVC or polyurethane mats for
infants and children. The mat may stick to the
nozzle, making it difficult to operate, causing
damage to the mat or static electricity on the
appliance. Clean mats using the crevice tool.
Dual Floor Max Nozzle
Use this nozzle to clean carpets, rugs or hard floor
surfaces.
Pet Nozzle
It is suitable for soft surfaces and pet hair removal.
CAUTION
• Do not use the nozzle following surface. It may
cause scratch or damage. Especially, do not
clean a coated or lacquered floor. If used
repeatedly, the coating may wear off.
- Clothing, bedding
- Leather cushioned sofas, cushions
- Carpet
- Vinyl flooring, tiles, marble, etc.
Bedding Nozzle
This nozzle lets you clean sheets and bedding more
effectively. It removes dust in bedding using strong
suction and a punching motion.
25
OPERATION
ENGLISH
• Lower the suction level when vacuuming
bedding such as duvet covers to avoid the thin
fabric getting sucked into the nozzle.
Crevice Tool
Use this tool to remove dust from corners or
narrow spaces.
• Use it for areas with static electricity such as
mats.
• Use it with the
Turbo
mode to clean pet hair out
of furniture, mats, or tight areas like corners.
Combination Tool
Can be used in either crevice mode or brush mode
for cleaning corners or small gaps where dust and
dirt gather.
•
Crevice Mode
Use the tool in the crevice mode to clean flat
surfaces such as sofas or mattresses.
•
Brush Mode
Use the tool in the brush mode to clean delicate
surfaces such as frames or furniture.
- To convert modes, press the adjustment
button
a
and push forward.
Hard Dirt Tool
Firm bristles remove solidified dirt from hard
surfaces. Clean up hair or foreign objects that are
entangled in carpets or rugs.
Mattress Tool
Use this tool to clean up dust and foreign objects
from mattresses, delicate fabrics, and upholstery.
Flexible Crevice Tool
This tool is flexible and its length can be adjusted,
making it especially useful for cleaning inside
26
OPERATION
vehicles or in narrow spaces under and behind
furniture where an angled tool is needed.
Using the Brush
To convert the tool from crevice to brush mode,
press in on the sides of the brush head
a
and pull
the brush down.
• To convert back to the crevice mode, press in on
the brush release button
b
and slide the brush
up.
Adjusting the Length
To adjust the length of the tool, press and hold the
release button
c
on the side of the tool. Pull or
push on the brush head
d
to extend or retract the
extension tube.
Multi-angle Tool
This tool has a soft brush that can be adjusted to a
variety of angles, making it especially useful for
cleaning vehicle consoles or the tops of furniture.
Flexible Hose Extension
Connect this flexible, extendable hose between the
product body and the tools to clean hard to reach
areas.
• The flexible hose extension cannot be used with
the Nozzle.
Using the Kompressor Lever
Use the Kompressor lever to compress hair and
fibers inside the dust bin after vacuuming and
before emptying the dust bin.
• The vacuum must be turned off before using the
Kompressor lever.
• Compressing the dust clears it off the interior
walls of the dust bin and allows you to vacuum
for longer periods before emptying the dust bin.
It also makes cleaning the dust bin easier and
less messy.
• The dust bin must be at least half full for the
compression plate to be effective.
• Press the Kompressor lever down several times
to compress the dust and clean off the interior
walls of the dust bin.
27
MAINTENANCE
ENGLISH
MAINTENANCE
Cleaning the Appliance
Before Cleaning the Appliance
To maintain the optimum suction power, the
cyclonic mesh filter, the exhaust filter and the pre-
filter should be cleaned regularly and washed
under running water at least once a month.
• Turn off the power before cleaning the
appliance.
• The frequency of cleaning varies depending on
the usage environment and usage time. In a
dusty environment, clean frequently.
WARNING
• Never wash the Nozzle, rotating brush or
product body with water. Water could reach the
motor and cause electric shock or fire.
• Do not use the cleaner without any of the filter
fitted as this will allow foreign objects to enter
the motor. Doing so may cause electric shock,
fire or product damage.
• Do not allow foreign objects to enter the motor.
Doing so may cause electric shock, fire or
product damage.
• Do not insert fingers or sharp objects into the
motor. Doing so could cause product damage,
personal injury or electric shock.
CAUTION
• Do not apply force or allow impacts to the
cyclonic mesh filter. Doing so could deform the
filter, compromise product performance, or
cause the product to malfunction.
• If the Kompressor lever does not return to the
top, remove the cyclonic mesh filter from the
dust bin and clean it. A clogged or dirty filter may
cause poor product performance.
Removing Foreign Objects
If the appliance is clogged with foreign objects, the
suction power changes, the motor cycles
repeatedly, and the foreign objects clogging alarm
icon blinks.
If clogging persists, the appliance will turn off
automatically to prevent damage. Separate the
battery from the product body and remove the
foreign objects before resuming use of the
appliance.
• Check the inside of the product body, above the
Kompressor working plate, the Fixed pipe, inlets,
exhaust filter, pre-filter and cyclonic mesh filter
for foreign objects.
• If the inlets are not completely blocked, the
foreign objects clogging alarm indicator may not
light up.
• If the sound of the appliance becomes loud or
the cleaning performance is poor, check for
foreign objects.
Cleaning the Dust Bin
Empty and clean the dust bin after every use.
28
MAINTENANCE
• If the dust bin is completely full of dust or the
filter is clogged, the suction power may be
reduced.
CAUTION
• Do not use the appliance without the cyclonic
mesh filter installed. Doing so could damage the
appliance.
1
Remove the battery from the product body
before cleaning the dust bin.
2
Push down the Kompressor lever
a
several
times to collect and compact the dust from the
outside of the cyclonic mesh filter and the
interior walls of the dust bin.
• Foreign objects which become lodged in the
cyclonic mesh filter may be difficult to
dislodge with the Kompressor lever. Remove
the cyclonic mesh filter and use a soft brush
to clean it.
3
Press the dust bin cover release button
b
to
open the dust bin cover. Shake the dust bin to
empty it.
• Be careful as dust or foreign objects may
spill out when opening the dust bin. Empty
the dust bin into a wastebasket or where
dust and foreign objects can be easily
removed.
• The dust bin can be wrapped in a plastic bag
to contain the dust when emptying the dust
bin.
WARNING
• If the Kompressor lever does not slide down
smoothly, foreign objects may be trapped
between the dust bin and the cyclonic mesh
filter. Clean the dust bin and cyclonic mesh filter
to avoid product damage.
• Do not force the Kompressor lever down if
foreign objects are caught around the working
plate of the Kompressor system. Doing so may
cause product damage. Never hit the main body
of the unit or its filters against a hard surface to
remove debris or blockages. Doing so can
damage the unit.
4
Insert the crevice tool
d
into the cyclonic mesh
filter
c
and turn it counterclockwise to remove
the filter.
5
Remove the pre-filter from the Cyclonic Mesh
Filter.
• When separating the Cyclonic Mesh Filter,
the pre-filter is separated in an assembled
29
MAINTENANCE
ENGLISH
state. If it was not separated together with
the Cyclonic Mesh Filter, check the inside of
the vacuum cleaner and take out the pre-
filter.
6
Grab the dustbin and turn it to the left to
separate the dustbin.
7
Remove dust from the dust bin, Cyclonic Mesh
Filter, and pre-filter using a cleaning brush,
etc., and wash them with water at least once a
month.
• If any stains remain, soak in lukewarm water
(about 40 degrees) for 30 minutes and then
wash with a brush.
• To avoid odor and the malfunction of the
motor, allow the cyclonic mesh filter to dry
completely in a well-ventilated area out of
direct sunlight for at least 24 hours before
reassembling.
8
Use the combination tool
e
to clean out dust
or foreign objects inside the dust bin.
• Do not wash the product body or motor with
water.
9
Turn the product body over again and shake it
while pressing down the lever to remove the
dust.
10
Turn the product body over, lift the
Kompressor lever up, and clean the inside of
the working plate with a damp paper towel.
• Do not push the Kompressor lever down
hard. The working plate may be damaged.
Cleaning the Filters
Clean the exhaust filter regularly and wash them in
running water at least once a month to maintain
the optimum suction power of the appliance.
30
MAINTENANCE
Allow them to dry in the sun before re installing
them.
• The frequency of cleaning depends on where
and how often you use the product. Clean the
filters more frequently if the appliance is used
regularly or in areas with a lot of dust.
• Filters are consumables. Please purchase more
filters from an authorized service center.
1
Remove the battery from the product body.
2
Grasp the exhaust filter cover and turn it to the
left to open the cover.
3
Lift the open cover.
4
Lift out the exhaust filter
a
from the product
body.
5
Use the combination tool
c
to clean any dust
off the motor.
• Do not wash the motor with water.
6
Clean the exhaust filter by brushing the dust
off it regularly and wash it in running water at
least once a month.
• Do not remove the sponge filter attached to
the exhaust filter when washing the exhaust
filter. Otherwise, the sponge filter may be
lost or damaged.
• To avoid odor and the malfunction of the
motor, allow the exhaust filter to dry
completely in a well-ventilated area out of
direct sunlight for at least 24 hours before
reassembling.
31
MAINTENANCE
ENGLISH
7
Assemble a completely dry exhaust filter
a
to
the product.
• When assembling the exhaust filter,
assemble it according to the groove.
8
Close the exhaust filter cover, press down and
turn it to the right to lock the cover.
CAUTION
• Do not use the appliance without the exhaust
filter installed. Doing so could result in product
damage.
Cleaning the Nozzles
Clean the nozzle and rotating brush regularly.
CAUTION
• Always separate the nozzle from the product
body or remove the battery before cleaning. If
the nozzle starts to operate during cleaning, it
could cause an injury.
• Keep fingers away from pinch points when
assembling the nozzle on the appliance or the
rotating brush on the nozzle.
• Do not use the rotating brush as a wet mop. It
may cause product damage.
• Do not rinse or submerge the rotating brush or
nozzle in water. It may cause product damage.
Cleaning the Dual Floor Max
Nozzle
Clean the brush and roller heads before each use.
• If the brush contains foreign objects, the brush
may not spin or a noise may occur during
operation. This could also damage the flooring.
1
Press the nozzle release button
a
to remove
the nozzle from the extension pipe or product
body.
32
MAINTENANCE
2
Turn the nozzle upside down. Press the button
on the nozzle and turn the cover lock clockwise.
3
Pull the brush cover forward and pull the main
brush out.
4
With the left button of the sub-brush pressed,
pull the sub-brush out.
5
Attach the crevice tool to the product body and
use the vacuum to remove foreign objects and
dust from the main brush, sub-brush and the
bottom of the nozzle.
6
Use a damp towel or cloth to remove any
remaining foreign objects and dust from both
the brush and the bottom of the nozzle.
• Carefully use a tweezers to remove foreign
objects from the nozzle rollers.
• Do not rinse or submerge the rotating brush
or nozzle in water.
• Use a wet towel or cloth to clean both the
rotating brush and nozzle.
7
Slide the brushes back into the nozzle and
rotate the cover back into place. Turn the cover
lock clockwise to lock the cover.
33
MAINTENANCE
ENGLISH
Cleaning the Pet Nozzle
1
Press the nozzle release button
a
to remove
the nozzle from the extension pipe or product
body.
2
Remove the rotating brush while holding down
the
PUSH
button on the nozzle.
3
Attach the crevice tool to the product body and
use the vacuum to remove foreign objects and
dust from the brush and the bottom of the
nozzle.
4
Use a damp towel or cloth to remove any
remaining foreign objects and dust from the
brush and the bottom of the nozzle. Remove
foreign objects, debris and hair from all Rollers
of the nozzles using tweezers.
5
Insert the left side of the brush
b
into the
groove
c
inside the nozzle.
6
Press the cover of the brush to lock the brush
until a clicking sound is heard.
Cleaning the Bedding Nozzle
1
Press the nozzle release button to remove the
nozzle from the extension pipe or product
body and turn the nozzle upside down.
2
Attach the crevice tool to the product body and
use the vacuum to remove foreign objects and
dust from the bottom of the nozzle. Use a
damp towel or cloth to remove any remaining
foreign objects and dust from the bottom of
the nozzle. Remove foreign objects, debris and
hair from all Rollers of the nozzles using
tweezers.
34
MAINTENANCE
Cleaning the Mop Nozzle
1
Press the nozzle release button to remove the
mop nozzle from the extension pipe and turn
the nozzle upside down.
2
Use a damp towel or cloth to remove any
remaining foreign objects and dust from the
bottom of the mop nozzle. Remove foreign
objects, debris and hair from all nozzle rollers
using tweezers.
35
TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
Before Calling for Service
Operation
Symptoms Possible Cause & Solution
The appliance does not
operate.
Battery is fully discharged.
• Charge the battery.
Appliance is turned off.
• Press the
Power
button to turn on the appliance.
Suction power is too
weak.
Dust bin is full of dust.
• Empty the dust bin.
Filters are clogged.
• Clean the pre-filter and the exhaust filter.
Inlet is clogged.
• Remove any foreign objects from inside the product body or the extension
pipe.
Foreign object is on rotating brush, or in inlet port.
• Remove any foreign objects (thread, hair) from the rotating brush or the
inlet port.
The product body does
not appear to be
charging.
Power cord is unplugged.
• Plug the power cord securely into the outlet.
Foreign object is on the charging terminals.
• Remove dirt or foreign objects from the charging terminals with a dry
cloth.
Hot air is coming from
the product body.
Motor is cooling.
• If the appliance is running normally, the hot air is a result of the motor
cooling and is not a sign of malfunction.
The Kompressor lever
does not return.
Foreign objects which become lodged in the cyclonic mesh filter may be
difficult to dislodge with the Kompressor lever.
• Remove the cyclonic mesh filter and use the cleaning brush, etc. to clean it.
A strange odour is
coming from the
appliance.
Appliance was purchased within the last 3 months.
• The cleaner may emit a smell of rubber for about 3 months after purchase.
Dust bin is full of dust.
• The dust in the bin may cause some odour. Empty the bin and clean it.
36
TROUBLESHOOTING
Mop Nozzle
A strange odour is
coming from the
appliance.
Foreign object is on the filter.
• The filter may emit an odour if it has not been cleaned for some time. Clean
the pre-filter and exhaust filter regularly.
Pre-filter, Exhaust Filter or the Cyclonic Mesh Filter were installed while
damp or wet.
• Wash the filters with running water. To avoid odour, allow the pre-filter to
dry completely in a well-ventilated area out of direct sunlight for at least 24
hours before reassembling.
Exhaust filter was installed while damp or wet.
• Wash the exhaust filter with running water. To avoid odour, allow the
exhaust filter to dry completely in a well-ventilated area out of direct
sunlight for at least 24 hours before reassembling.
The appliance makes
too much noise.
Vacuum cleaner is running in Turbo mode.
• The motor may be louder at the higher suction power settings. This is
normal.
The appliance turns off
unexpectedly or by
itself after the motor
speed fluctuates
repeatedly.
Battery is not fully charged.
• The battery must be fully charged before cleaning. If the problem persists
when the battery is fully charged and the pipes and attachments are clear
from obstructions, contact an LG customer information centre for service.
Foreign object is in the product body, extension pipe, inlet port or
nozzle.
• Remove any foreign objects from the product body, extension pipe, inlet
port or nozzle.
Filters are clogged.
• Clean the pre-filter and the exhaust filter.
The rotating brush
does not rotate.
Brush is improperly installed.
• Remove the brush, clean it if necessary and attach it again.
Foreign object is on rotating brush.
• If a foreign object becomes stuck in the rotating brush during operation,
the rotating brush will stop rotating to protect the brush motor. Turn the
product off immediately. Once the product is turned off, remove the
foreign object from the rotating brush before resuming use.
Symptoms Possible Cause & Solution
The mop pad
attachment plate does
not rotate.
Mop pads are improperly installed.
• Remove the mop pads, clean them if necessary and attach them again.
Symptoms Possible Cause & Solution
37
TROUBLESHOOTING
ENGLISH
The mop pad
attachment plate does
not rotate.
Mop nozzle is pressed too hard against the floor.
• The mop attachment plate stops automatically to protect the product. This
is not a failure. Attach the mop pads securely to the mop attachment plate
and press the power button to resume use.
Foreign object is between mop attachment plate and mop pads.
• Remove foreign objects from the mop nozzle attachment plate and press
the power button to resume use.
There is no water
coming out of the mop
nozzle.
Water tank is empty.
• Fill the water tank. Remove the battery or detach the nozzle before filling
the water tank.
Water tank is improperly attached to mop nozzle.
• Properly attach the water tank to the mop nozzle. Remove the battery or
detach the nozzle before properly securing the water tank to the nozzle.
Water supply adjustment button is set to STOP.
• Press the
High
or
Low
water adjustment button all the way down. The
water will not come out if the button is set to
STOP
.
The water outlet was clogged by hard water scale or other foreign
substances.
• Use a sharp pin to remove the blockage.
There is moisture in
the water tank.
Water tank is not allowed to dry completely after use.
• Empty the water tank, set it out of direct sunlight, and allow it to dry
completely after use.
A strange odour is
coming from the
appliance.
Foreign object is on the dust inlet of the mop nozzle.
• Wet dust in the mop nozzle may result in odour. Make sure to wipe the
dust inlet of the mop nozzle with a wet wipe after each use.
Mop pads make the
floor dirty.
Mop pads are not cleaned properly after use.
• Clean the mop pads thoroughly after each use. Using soiled mop pads may
make the floor dirtier.
The appliance makes
too much noise.
This is the sound generated when the pump at the inlet of the mop is
operating.
• This is normal.
The mop pads were improperly attached on the plates.
• Align and attach the centre of the mop pad with the centre of the mop
attachment plate.
Symptoms Possible Cause & Solution
Memo
Memo
