APP
Download the soundcore app to adjust EQ settings, update firmware, and explore more.
If your earbuds cannot connect with the soundcore app, re-install the app or update it to the latest version in your mobile app store.
Click this link to download: http://dl-soundcore.soundcore.com/qcdl?flow=soundcore
OVERVIEW
1. Earhook
2. Touch Control Area
3. USB-C Charging Port
4. Reset Button
5. LED Indicator
WEARING
Pick up the earbuds from the charging case, then rotate the ear hooks along the auricle of your ear to achieve proper positioning.
CHARGING
*Remember to tear off the protective films on the earbuds before first use.
1.Place the earbuds in the charging case and close it.
•Fully dry off the earbuds and the USB-C charging port before charging.
2. Connect the charging case to a power supply by using a certified USB-C charging cable.
Low Battery Indication
Earbuds: You will hear a voice prompt of battery running low.
Charging case: The LED indicator will light up in red for 3 seconds and then go off.
POWERING ON & PAIRING
After removing the insulation stickers on the earbuds, return earbuds to the charging case, then press the reset button to activate Bluetooth pairing. Also, you
can pair by closing and reopening the case lid once the earbuds are back in the case. Subsequently, the earbuds will automatically power on and enter
Bluetooth pairing mode when connecting for the first time. Select "soundcore V30i" on your device's Bluetooth list to connect. When pairing, the LED
indicator on the charging case will start flashing. After the pairing is successful, the LED indicator on the charging case will stay on for 3 seconds and then go
off.
Once connected successfully, they'll automatically reconnect to your device every time you open the charging case, as long as you haven't deleted the pairing
history from your device.
TOUCH CONTROLS
TWS mode Mono mode
Play / Pause Touch twice (R) Touch twice
Previous track Customize in soundcore app /
Next track Touch twice (L) /
Answer / End a call Touch twice (L/R) Touch twice (L/R)
Reject a call Touch and hold for 2 seconds (L/R) Touch and hold for 2 seconds
Volume up *Enable in soundcore app /
Volume down *Enable in soundcore app /
Activate voice
assistant
*Enable in soundcore app *Enable in soundcore app
Customize Touch Controls on soundcore App
Tap Controls in the home page, you'll be able to personalize the following actions for touch controls on either the left or right earbud: Raise/lower volume,
switch songs, play/pause music, wake up the Voice Assistant, and none.
POWERING OFF
To power off, return the earbuds to the charging case and close it.
*The earbuds will automatically power off after 30 minutes if they are not connected. The duration can be customized in the soundcore app.
RESET
Reset if the earbuds have issues pairing with each other or with other devices.
Delete the pairing history from your Bluetooth device first. Place the earbuds in the charging case and leave the case open. Press and hold the reset button on
the charging case for 10 seconds until the LED indicator on the charging case flashes red three times. At this time, your earbuds have been successfully reset.
FIRMWARE UPDATE
You will be informed once a new firmware version is detected when you connect the earbuds to the app. Ensure the earbuds are placed in the charging case
and the case remains open until the firmware update is complete. During the update, ensure the earbuds are being charged and avoid any usage.
SPECS
Specifications are subject to change without notice.
Input 5V 1A
Output 5V 0.3A (0.15A per port)
Battery capacity
70mAh × 2 (earbuds);
500mAh (charging case)
Charging time
2 hours (earbuds);
2 hours (charging case)
Driver unit 14.2mm dynamic driver
Frequency response 20 Hz - 20 kHz
Impedance 11Ω
Waterproof rating (earbuds) IPX5
Bluetooth version 5.3
Bluetooth range 10 m / 33 ft
Maximum volume 89.5dB
Customer Service
support.mea@soundcore.com (For Middle East and Africa Only)
support@anker.com (
⽇
本
)
+1 (800) 988 7973 (US/Canada)
+44 (0) 1604 936200 (UK)
+49 (0) 69 9579 7960 (DE)
03 4455 7823 (
⽇
本
)
+86 400 0550 036 (
中
国
)
+82 02-1661-9246 (
한
국
)
+971 529750842 (Middle East & Africa)
+971 8000320817 (UAE)
+966 8008500030 (KSA)
+965 22069086 (Kuwait)
+20 8000000826 (Egypt)
+61 3 8331 4800 (Australia)
+90 (850) 460 14 14 (Türkiye)
+8 (800) 511-86-23 (Russia)
+91 18003138831 (India)
Note: The 'x' of SN Code: xxxxxxxxxxxxxxxx is a variable, see below table.
Variable 'x' Range of variable Content
Eighth 8,9,A,B,C... Denotes the year, 8 means 2018, 9 means
2019, A means 2020, B means 2021, C
means 2022, and so on.
Ninth and tenth 01,02,03...
Denotes weeks, 01 means the first week in
this year, 02 means the secondary week in
this year, and so on.
Eleventh 1-7
Denotes date, 1 means Monday, 2 means
Tuesday..., 7 means Sunday and so on.
The last five 00001-99999 Denotes serial No.
Hereby, Anker Innovations Limited declares that this device is in compliance with The Product Security and Telecommunications Infrastructure (Security
Requirements for Relevant Connectable Products) Regulations 2023. For the Statement of Compliance, visit the website:
https://uk.soundcore.com/pages/psti-related.
