SJ-108
Compact Anodized Aluminum
5,000 mAh Power Bank
Instruction Manual
Product Overview
Wireless charging
Pad for Qi-compatible
devices
Operating Instructions
Package Contents
• Power Bank
• Instruction Manual
• USB-C Charging Cable (Not Included)
• Keep out of reach of children.
• Keep away from water, moisture, fire, and excessive heat.
• Do not use or store below 14°F (-10°C) or above 113°F (45°C).
• Avoid strong magnetic fields and corrosive materials.
• Do not disassemble, modify, or repair the product.
• Stop use immediately if the product becomes hot, swollen,
deformed, or damaged.
Safety & Care Instructions
• Wireless charging performance may vary depending on the device,
protective case, and charging environment.
• For optimal performance, use a certified 20W or higher USB power
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
• This device may not cause harmful interference
• This device must accept any interference received, including
interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
adapter.
•
Keep the charging surface clean and free of metal objects during use.
Notes
Specifications Specifications
• Model: SJ-108
• Battery Type: Polymer Lithium Battery
• Battery Capacity: 5000mAh
• USB-C Input: 5V 3A / 9V 2A / 12V 1.5A
• USB-C Output: 5V 3A / 9V 2.22A / 12V 1.67A
• Wireless Charging Output: 5W / 7.5W / 10W / 15W
• Dimensions: 60 × 79 × 6.12 mm
• Weight: 116 g (4.09 oz)
Power Button
LED Indicator
USB-C Charging Port
Before First Use
• Recharge the battery periodically if the product is not used for
an extended period.
• If the battery has been completely discharged, allow it to charge
for 1-2 hours before use.
Check Battery Level
• Press the Power Button once.
• The LED indicator will light up to display the current battery level.
Wireless Charging
1. Place your Qi-compatible device on the wireless charging pad.
2. Charging will begin automatically when the device is properly aligned.
3. The LED indicator will remain on while charging.
Charging the Power Bank
1. Connect a USB-C cable to the USB-C port.
2. Connect the other end to a USB power adapter.
3. Use a 20W or higher USB power adapter for the best
charging performance.
Low Battery Protection
• When the battery voltage drops below the protection threshold, the
charging output will automatically turn off to help protect the battery.
75 mm
60 mm
360mm
说明书尺寸60x75mm
材质：80g书纸
NOTE 2: Any changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure r
equirement. The device can be used in portable exposure condition
without restriction.
