1. Select location for clothesline unit and for knob retainer plate on
opposite wall.
2. Attach mounting bracket in vertical position to finish wall with
screws furnished placing white nylon disc between wall and mount-
ing bracket.
3. Attach retainer plate on opposite wall and placing white nylon oval
between wall and retainer plate so the top of retainer pate is at
same height from floor as top of mounting bracket. The cord will
then belevel when in use.
4. Place set screw at top of mounting bracket and place unit on
mounting bracket correctly.
5. Tighten set screw to secure unit to mounting bracket.
OPERATION
Pull out clothesline and book cord knob into retainer plate on opposite
wall. Turn center locking knob clockwise to keep strain off cord when
in use. Nylon cord retracts by spring actuated reel, when center Lock-
ing knob is released and clothes line is removed from retainer plate.
Retractable Clothesline
Nylon Disc
Wourhing
Brachet
Round
Head
Screws
Chines
Line
Uait
Conle:
Locking
knob
Oval
Head
Screws
Kdob
Retainer
Plate
Naton
Oval
Set scrant
