www.coyoteoutdoor.com
C3-DPC31 INSTALL GUIDE
Model No. Height Width Depth
Model No. Height Width Depth
C3DPC31
C3DPC31
Cutout Dimensions for Island
Overall Product Dimensions
24"
20
1
/2"
24"
10
1
/4"
OPENING HEIGHT
CUTOUT WIDTH
CUTOUT
HEIGHT
GRILL OPENING WIDTH
FRONT VIEW
1
1
/2" MIN
SUGGESTED
FOR
FRAMING
INCLUDING
COUNTERTOP
INTERIOR
DEPTH
TOP VIEW
26
1
/2"
OVERALL
HEIGHT
24"
26
1
/2"
20
1
/2"
OVERALL WIDTH
OVERALL WIDTH
1"
EXTERIOR
DEPTH
CUTOUT WIDTH
26
1
/2"
DIMENSIONAL RENDERINGS
2 anchor points are located on each side of the doors interior frame (top, bottom, left and right)
Due to wide variance of possible building materials, anchors are not included
When inserting your anchors be sure to use a framing square to ensure the door is not pulled out of square
Additional framing and/or support underneath the rear (hanging portion) of the cabinet is recommended
These specs are accurate but we always suggest having the product physically on site to ensure full understanding of how this
product will coordinate with your build
30"
23"
30"
30"
23"
Install Notes:
26
1
/2"
30"
20
1
/2"
23"
24"
24"
