此符号表示，根据WEEE指令(2012/19/EU)和国家法律，由
于这种类型的废弃物会有潜在的有害物质，可能对环境和
人类健康产生负面影响，所以本产品不应与您的家庭垃圾
一起处置，应将本产品交由授权的电气和电子设备（WEEE）回收站回
收。同时，您在正确处理本产品的同时将有助于自然资源的有效利用。
如需了解更多有关您可以在何处放置废物回收设备的信息，请联系
您当地的城市办事处、废物管理局或家庭废物处理服务部门。
未经合规方明确批准的变更或修改可能会使用户失去操作
设备的权限。此设备符合FCC规则第15条部分的要求。操作
须符合以下两个条件：（1） 此设备可能不会造成有害干扰，（2）此设备
必须接受接收到的任何干扰，包括可能导致意外操作的干扰。
23.844 mm
DA8 演讲麦 DA8 演讲麦 DA8 演讲麦 DA8 演讲麦
DA8 演讲麦
DA8 演讲麦
DA8 演讲麦 DA8 演讲麦
尊敬的用户：
感谢您选购得胜DA8演讲麦，为了您能够更好地了解使用本产
品，建议您在使用前仔细阅读本说明书。
若存在有疑问或者您有宝贵的建议，可通过拨打
得胜官方服务热线400 6828 333或微信扫描二维码
关注得胜官方公众号与我们联系。
展开尺寸：425*240mm/80g书写纸 双面印单黑 1:1
适用于演讲、教学、宣传、K歌等场合
• 喇叭规格：50mm
• 频率响应：150Hz-12kHz
• 峰值功率：12W
• 扬声器阻抗：4Ω
• 总谐波失真：THD≤5%
• 信噪比：80dB(A-Weighted)
@4R,3W
• 电池类型：锂离子电池
• 手持便携扩音器，集麦克风与音箱一体，告别复杂设备；
• 小蛮腰人体工学设计，握感舒适，迷你轻便易收纳；
• 选用全音域喇叭，高保真音质，久听护耳、声音清晰；
• DSP防啸叫芯片，精准抑制啸叫杂音，拾音轻松，保护嗓子；
• 智能待机设计，闲置45分钟自动关机，杜绝空耗省电耐用；
• 内置大容量锂电池，充电3小时，使用时间约10小时；
• 支持无线音频播放，摆脱线材束缚，畅享音乐更自由。
前言
Preface
产品特性
DA8演讲麦�....�.......����.....�������..�..�.1个
Type-C充电线�....�.........�����..�..�����.�...1条
挂绳�....�.........�����..�..�����.��...............1条
说明书�....�.........�����..�..�����.��...........1份
• 拾音器：背极式驻极体
• 指向性：超心型
• 频率响应：60Hz-16kHz
• 灵敏度：-42±2dB（0dB=1V/Pa，at 1kHz）
注：以上数据由得胜实验室测试得到，并拥有最终解释权！
① 电源键：长按2秒开机或关机；点按切换4种模式：演讲模式、主持
模式、K歌模式、音乐模式；双击快速返回演讲模式；在任何工作
模式下，无使用45分钟后自动关机。
② 数码显示屏：显示当前电池电量百分比、音量大小、工作状态等信
息。
③ 音量+键：点按增加音量，有“00-05”共6级音量调节；在K歌、音乐
模式下，长按切换上一曲。
④ 音量-键：点按减少音量，有“00-05”共6级音量调节；在K歌、音乐
模式下，长按切换下一曲。
⑤ Type-C接口：连接Type-C充电线为演讲麦充电。
一、无线连接配对方法
三、握持示意图
为避免电击、高温、着火、辐射、爆炸、机械危险以及使用不当
等可能造成的人身伤害或财产损失，使用本产品前，请仔细阅读并
遵守以下事项：
1. 使用产品时请确认所连设备与本产品是否匹配以及合理调整音
量大小，不要在超过产品功率及大音量下长时间使用，以免造成产
品异常；
2. 使用中若发现有异常（如冒烟、异味等），请立即关闭电源开关并
拔掉电源插头，然后将产品送售后服务网点检修；
3. 消费者若使用电源适配器供电，则应购买配套使用获得CCC认证
并满足标准要求的电源适配器；
4. 本产品及附件都应放置在室内干燥通风处，请勿长期存放在潮
湿、灰尘多的环境，使用中避免靠近火源、雨淋、进水、过度碰撞、抛
掷、振动本机及覆盖通风孔，以免损坏其功能；
5. 若产品需要固定于墙壁或天花板时，请确保固定到位，防止因固
定强度不足导致产品发生跌落危险；
6. 使用该产品时需遵守相关安全规定，法律法规明确禁止使用场合
请勿使用本产品，以免导致意外事故；
7. 请不要自行拆机改装或维修，以防止出现人身伤害，如有问题或
服务需求请联系当地售后服务网点跟进处理。
本说明书中内容符合截止印刷之日的技术规格。由于得胜公司
会不断改进产品，本说明书可能不符合您的特定产品的技术规格。
要获取最新版说明书，请访问得胜官网，然后下载说明书文件。技术
规格、设备或另售的附件在各个地区可能有所不同，如有问题请与
当地得胜销售网点确认。如需更多支持和深层产品信息，请浏览得
胜官方网站：https://www.takstar.com
版权所有 ©2026 得胜。得胜、TAKSTAR及其各自标志是得胜公
司在中国和/或其他国家/地区的注册商标或商标。所有其它商标均
是其各自所有者的财产。
DA8 Speech Microphone DA8 Speech Microphone DA8 Speech Microphone
11
DA8 Speech Microphone
12
DA8 Speech Microphone
13
DA8 Speech Microphone
14
DA8 Speech Microphone
15
DA8 Speech Microphone
16
Dear Customer,
Thanks for purchasing our product. Read this manual thoroughly
to use the product properly.
If you have any questions or suggestions, please contact our local
sales service.
For speeches, teaching, promotions, and karaoke.
• Speaker: 50mm
• Frequency Response: 150Hz-12kHz
• Peak Power: 12W
• Speaker Impedance: 4Ω
• Total Harmonic Distortion: THD≤5%
• Signal-to-Noise Ratio: 80dB (A-Weighted) @ 4R, 3W
• Battery Type: Lithium-ion Battery
• Battery Capacity: 3.7V/2000mAh
• Charging Spec: 5V
⎓1A
• Charging Time: Approx. 3 hours
• Operating Voltage Range: 3.4V-4.2V
• Operating Time: Approx. 10 hours
• Product Weight: Approx. 182g
• Product Dimensions: Φ68mm × 202mm (Dia. × Height)
1 × DA8 Speech Mic
1 × USB-C Charging Cable
1 × Lanyard
1 × User Manual
• Transducer: Back-electret Condenser
• Polar Pattern: Supercardioid
• Frequency Response: 60Hz-16kHz
• Sensitivity: -42±2dB (0dB=1V/Pa, at 1kHz)
Note: The above data are measured by Takstar laboratory which
has the final interpretation right!
III. Grip Diagram
② Digital Display: Shows current battery percentage, volume
level, working status and other information.
③ Volume + Button: Press to increase volume, 6 adjustable levels
(00-05); long press for previous track in karaoke/music mode.
④ Volume - Button: Press to decrease volume, 6 adjustable levels
(00-05); long press for next track in karaoke/music mode.
⑤ Type-C Port: Connect a Type-C charging cable to charge the
speech microphone.
Features
Applications
Package Contents
Specifications
Function Descriptions
About This Manual
• All-in-one portable handheld voice amplifier with integrated mic
& speaker, no complex equipment needed.
• Ergonomic slim-waist design, comfortable grip, compact and
lightweight for easy storage.
• Full-range speaker delivers clear, hi-fi sound, ear-friendly for
prolonged use.
• DSP anti-feedback chip precisely suppresses howling and noise,
ensures easy sound pickup and throat protection.
• Smart standby with 45-minute auto power-off when idle,
power-saving and durable.
• Built-in high-capacity lithium battery: 3-hour charge for approx.
10 hours of runtime.
• Supports wireless audio playback for cable-free, unrestricted
music enjoyment.
Speech Microphone
Microphone Capsule
Note: For first-time use, it is recommended to fully charge the
battery first. When the battery is fully charged, please stop
charging it to prevent overcharging. If not in use for a long time,
charge it once every six months to avoid over-discharging, which
may affect battery performance.
Safety Instructions
To avoid electric shock, overheat, fire, radiation, explosion,
mechanical risk and injury or property loss due to improper use,
please read and observe the following items before use:
1. Please check if the power of the connected equipment
matches with that of this product before operation. Adjust the
volume to proper level during operation. Do not operate at
over-power or high-volume level for extended time to avoid
product malfunction.
2. If there is any abnormality during use (e.g., smoke, strange
odor), please kill the power switch and unplug from power
source, then send the product to the local after-sales service for
repair.
3. Power adapter used, if any, should be approved by CCC
certification or similar standards and comply with the power
supply requirements.
4. Keep this product and its accessories in a dry and ventilated
area. Do not store in a humid or dusty area for extended time.
Keep away from fire, rain, liquid intrusion, bumping, throwing,
vibrating, or from blocking any ventilation openings, to prevent
malfunction.
5. The product must, when installed on walls or ceilings, be fixed
firmly in place at adequate strength to prevent from falling.
6. Please abide by safety rules during operation. Do not use the
product in places prohibited by laws or regulations to avoid
accident.
7. Do not disassemble or repair the product unauthorized to
avoid injury. If you have any questions or require any services,
please contact our local after-sales service.
I. Wireless Connection Pairing
Operating Instructions
To use the wireless connection feature for the first time, pair it
with your phone or other smart devices as follows:
1. After powering on, press the power button to switch to karaoke
or music mode, entering search pairing mode; the screen shows
a flashing "BL".
2. Enable the wireless connection on your phone, search for
"TAKSTAR DA8", and tap to connect. A prompt sound will indicate
success.
3. On subsequent power-ups, if a wireless connection has been
made before, it will automatically reconnect to the last used
device.
4. Press and hold the "-" button, then press the power button to
disconnect the wireless connection.
使用说明
Grip Diagram
Label Meanings
This device is compliant with the limits of the European
Council Directive on the approximation of the laws of the
member states relating to electromagnetic compatibility according to
RL2004/108/EG and European Low Voltage Directive RL2006/95/EG.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the complying
party may cause the user to lose permission to operate the device.
This manual contains up-to-date technical specifications as of
printing. However, specifications contained herein may not
conform to your particular product since Takstar is constantly
improving its products. Also, specifications, devices or
accessories available may vary from region to region. If you
have any questions, please contact our local sales outlet. For
the latest version/more information, please visit our website:
https://www.takstar.com/
Copyright ©2026 TAKSTAR. TAKSTAR, 得胜 and their
respective logos are registered trademarks or trademarks of
Takstar company in the PRC, and/or other countries. All other
trademarks are the property of their respective owners.
DA8 Speech Microphone
17
This symbol indicates that this product should not be
disposed of with your household waste, according to the
WEEE directive (2012/19/EU) and your national law. This
product should be handed over to an authorized
collection site for recycling waste electrical and electronic
equipment (WEEE). Improper handling of this type of waste could
have a possible negative impact on the environment and human
health due to potentially hazardous substances that are generally
associated with WEEE. At the same time, your cooperation in the
correct disposal of this product will contribute to the effective usage
of natural resources. For more information about where you can
drop off your waste equipment for recycling, please contact your
local city office, waste authority, or your household waste disposal
service.
1) This device may not cause harmful interference, and
2) This device must accept any interference received,
including interference that may cause undesired operation.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
• 电池规格：3.7V/2000mAh
• 充电规格：5V
⎓1A
• 充电时间：约3小时
• 工作电压范围：3.4V-4.2V
• 使用时间：约10小时
• 产品重量：约182g
• 产品尺寸：Φ68mm*202mm
（直径*高）
USB-C Charging Port
二、充电与电量指示
首次使用无线连接功能时，需要与手机或其他智能设备配对连接，
操作步骤如下：
1. 演讲麦开机后，点按电源键切换到K歌或音乐模式，自动进入搜
索配对，屏幕显示“BL”闪烁；
2. 打开手机的无线连接功能，搜索“TAKSTAR DA8”并点击连接，成
功后伴有提示音；
3. 下次开机后，如果是已进行过无线连接，将自动回连最后一次使
用的设备；
4. 按住-键，再点按电源键可断开无线连接。
提示：初次使用时，建议先充满电；当电池充满时，请停止对电池充
电，避免电池过充；如长时间不用，需每半年充电一次，避免电池过
放，对电池性能产生影响。
Type-C接口
数码显示屏
显示电池电量、音量等工作信息
音量“-”
点 按 音 量 - ，长 按 下 一 曲
电源键
长按开/关机，点按切换4种
模式，双击返回演讲模式
Digital Display
Displays battery level,
volume and other operating
information.
Power Button
Long press to power on/off;
press to switch between 4
modes; double-click to return
to speech mode.
音量“+”
点 按 音 量 + ，长 按 上 一 曲
根据RL2004/108/EG和European Low Voltage Directive
（欧洲低电压指令）RL2006/95/EG的测试结果表明，本产品
符合欧共体关于电磁兼容性的成员国法律整合的指令中所规定的限
值。
广东得胜电声有限公司制造
地址: 中国广东省惠州市博罗县龙溪街道夏寮村委会
大门村夏照（得胜创业园）
服务热线：400 6828 333 传真：0752 6383950
邮箱：xs@takstar.com
网址：www.takstar.com
Designed & Manufactured by:
Guangdong Takstar Electroacoustic Co., Ltd.
Address: Takstar Innovation Park, Xiazhao,
Damen Village, Xialiao Village Committee,
Longxi Street, Boluo County, Huizhou City,
Guangdong, P.R. China
Tel: 86 752 6383644 Fax: 86 752 6383952
Email: sales@takstar.com
Website: www.takstar.com
Volume + Button
Press to increase volume;
long press for previous track.
Volume ‒ Button
Press to decrease volume;
long press for next track.
① Power Button: Long press 2s to power on/off; press to switch
among 4 modes (Speech, Host, Karaoke, Music); double-click
to quickly return to speech mode. Auto power-off after 45
minutes of inactivity in any working mode.
II. Charging and Battery Indication
注1： ○ ：表示该有害物质在该部件所有均质材料中的含量均不超出电器电子产品有害物质限制使用国家标准要求。
×
：表示该有害物质至少在该部件的某一均质材料中的含量超出电器电子产品有害物质限制使用国家标准要求。
注2：以上未列出的部件，表明其有害物质含量均不超出电器电子产品有害物质限制使用国家标准要求。
09
10
DA8
演讲麦
SPEECH MICROPHONE
FCC Radiation Exposure statement
The device has been evaluatec to meel general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
