Model No.:BC-90U-E
INSTRUCTION MANUAL
It is important that you read these instructions before using your portable
refrigerator and we strongly recommend that you keep them in a safe place
for future reference.
Adjustable Temperature Dial
Leveling Your Refrigerator
Refrigerator Interior Shelves
Food Storage Information
1
3
4
4
4
4
4
5
5
5
6
7
7
7
8
9
9
10
10
11
11
12
Normal Operating Sounds You May Hear
1
DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be
Repaired Only By Trained Service Personnel. Do Not Puncture Refrigerant
Tubing
CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used.
Consult Repair Manual/Owner’s Guide Before Attempting To Service This
Product. All Safety Precautions Must be Followed
CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In Accordance
With Federal Or Local Regulations. Flammable Refrigerant Used
CAUTION – Risk Of Fire Or Explosion Due To Puncture Of Refrigerant
Tubing; Follow Handling Instructions Carefully. Flammable Refrigerant
Used
HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
2
1
2
4
5
7
6
3
Chamber
3
Leveling Your Refrigerator
•
•
4
Your refrigerator has two leveling legs which are located in the front
bottom corners of your refrigerator. Afer properly placing your
refrigerator in its final position, you can level your refrigerator.
Leveling legs can be adjusted by turning them counterclockwise to
raise your refrigerator or by turning them clockwise to lower your
refrigerator. The refrigerator door will close easier when the leveling
legs are extended.
Remove all packaging material. This includes the foam base and all
adhesive tape holding the refrigerator accessories inside and outside.
Inspect and remove any remains of packing, tape or printed materi-
als before powering on the refrigerator.
•
•
•
Install Limitations
Use of Extension Cord
Reversing the Door Hinge
5
Avoid the use of an extension cord because of potential safety hazards
under certain conditions. lf it is necessary to use an extension cord, use only
a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot
outlet that will accept the plug. The marked rating of the extension cord
must be equal to or greater than the electrical rating of the appliance.
Do not install your refrigerator in any location not properly insulated or
heated e.g. garage etc. Your refrigerator was not designed to operate in
temperature settings below 55° Fahrenheit.
Select a suitable location for the refrigerator on a hard even surface away
from direct sunlight or heat source e.g. radiators, baseboard heaters, cooking
appliances etc.
1. Remove the top hinge cover.
2. Using Phillips Head Screwdriver, loosen and remove the screws holding
top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side and insert the plugs in
the screw hole openings of the just removed screws.
5. Remove any loose items in the refrigerator and carefully turn refrigerator on
its back and place in a secure area.
6. Loosen the screws holding the lower hinge to the refrigerator and remove the
lower hinge.
7. Remove 2 plugs from the other side and insert in the previously removed
screw holes.
8. Remove door pin and reinsert to the underside of the lower hinge and tighten.
9. Align lower hinge and insert the2 screws into the holes on the opposite side.
10. Align hole in the door with the door pin and gently push down until firm.
11. Align top hinge with screw holes, insert screws and partially secure, check
that door and cabinet are properly aligned and then secure tightly.
12. Replace top hinge cover.
6
Adjustable Temperature Dial
Refrigerator Interior Shelves
lying-down
, keep it in the upright position and
7
Food Storage lnformation
Fresh Food
• When storing fresh food that is not prepackaged, be sure to wrap
or store food in airtight and moisture proof material unless otherwise
noted. This will ensure proper shelf life and prevent the transfer of
odors and tastes.
• Wipe containers before storing to avoid needless spills.
• Eggs should be stored in an upright position in their original carton to
maximize shelf life.
• Fruit should be washed and dried, then stored in sealed plastic bags
before storing in the refrigerator.
• Vegetables with skins should be stored in plastic bags or containers.
• Leafy vegetables should be washed and drained and then stored in
plastic bags or containers.
• Hot food should be allowed to cool before storing in the refrigeration.
This will prevent unnecessary energy use.
• Fresh seafood should be used the same day as purchased.
• When storing meats in the fresh food section, keep in the original
packaging or rewrap as necessary. Follow the suggestions below for
safe storage:
• Chicken 1-2 Days
• Ground Beef 1-2 Days
• Cold Cuts 3-5 Days
• Steaks/Roasts 3-5 Days
• Smoked/Cured Meats 7-10 Days
• All others 1-2 Days
8
Defrosting
Normal Operating Sounds You May Hear
9
10
11
Make sure the refrigerator is not in direct contact with sunlight.
Place a level on top of the refrigerator. If the refrigerator is not level,
adjust the front leveling legs.
desired
12
ROWAN ELECTRIC APPLIANCE LLC
8:30am-5:30pm P.S.T. Monday to Friday
Thank you for purchasing this product! If you have any questions about the
product such as missing parts, damaged products, product assembling and
operation, please contact us via customer service phone:213-446-7172
V1
