Vacuum Cleaner
Please read this user manual carefully before using.
Keep this manual for further guidance in case.
Suzhou Dibea Electrical Technology Co.,Lt
UV-10
d.
One-stop household cleaning solution provider.
EC REP
Wellkang Ltd(www.CE-marking.eu)
Address: No.19 Fuli Road, Guangfu Town, Wuzhong Economic Development Zone,
Suzhou, Jiangsu, China
Official website: www.dibea.com Email address: [email protected]
Table of ContentsTable of ContentsTable of ContentsTable of Contents
Special Declaration
Safety Instructions
Product Features
Product Components
Preparation before Using
Product Operation
Product Maintanance
Troubleshooting
Product Specification
Special DeclarationSpecial DeclarationSpecial Declaration
Before using this product, please read the safety instruction and follow all those
regular safety instruction and follow all those regular safety precautions.
Dibea will not responsible for any damage caused by self operation or using the
accessories that are not provided from factory. Thanks for your understanding.
Note:
Indoor use only, do not use this product outdoors.
Residential use only, do not use this product to clean commercial / industrial
wastes.
Dry use only, do not use this product in wet or moist environment. Do not
handle any part of the plug or appliance with wet hands.
Safety InstructionsSafety InstructionsSafety InstructionsSafety Instructions
Do not use to pick up flammable or combustible liquids, such as petrol, or
use in areas where they or their vapours may be present.
Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
Do not allow to be used as a toy. Close attention is necessary when used
by or near children. Children should be supervised to ensure that they do
not play with the appliance.
Use only as described in this Operating Manual. Do not carry out any
maintenance other than that shown in this manual, or advised by the DIBEA
official customer service.
Power Supply
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Do not plug or unplug this product with a wet hand.
Do not charge the unit outdoors.
Unplug when not in use for extended periods, during transportation and before
maintenance or servicing.
This product use 220V AC power, use only DIBEA or DIBEA recommended
accessories and replacement parts.
UV Lamp
This product contains a UV lamp, do not watch the bottom of product during
using to avoid UV leakage.
Do not apply the UV lamp directly on human or animal skin.
Do not use UV focus on one place for continuous use.
Using Range
Do not use to pick up flammable or combustible materials (lighter fluid, gasoline
, kerosene, etc.) or use in areas where they may be present.
Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner,etc.).
Do not use vacuum cleaner in an enclosed space filled with vapors given off by
oil base paint, paint thinner, some moth proofing substances, flammable dust,or
other explosive or toxic vapors.
Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
Do not pick up anything that is burning or smoking, such as cigarettes,matches,
or hot ashes.
Do not use without dust cup or filters in place.
Do not pick up any liquid, water included.
Safety InstructionsSafety InstructionsSafety InstructionsSafety Instructions
Please read thorogh this user manual before using the product. Any operations
that oppose to description in this user manual may cause damage to human or
product.
Other
Children, mentally or physically challenged adults should use this product
under supervision.
Do not sit on the top of this product.
Users lacking relevant experience and knowledge should carefully use this
product after fully reading this manual and fully understanding the product.
If there's any questions occur before or during using this product, please do not
use and contact DIBEA official customer service for help.
Production FeatureProduction FeatureProduction FeatureProduction FeatureProduction Feature
This product is a hand-held vacuum cleaner with ultraviolet disinfection
function. It uses advanced intelligent technology to automatically control the
ON/OFF of the UV lamp. It is ingenious in design, strong in suction, convenient
in operation, safe and reliable.
Feature
Instruction
Easy Operation
254 nm UV Light
One-click ON/OFF
Effective kills the mites, bacteria or any
other bed bugs on the fabric surfaces.
Intelligent UV Sensors
The UV light is ON only when the UV light
sensors on both sides of the UV light are
within 3cm of the fabric surface at the
same time.
High-frequency Vibration
The high-frequency vibration of the
pulsating pad loosens the dust and dirt and
brings the dust to the surface of the fabric.
Prepairation before Using
Product ComponentsProduct ComponentsProduct ComponentsProduct Components Product Components
Suction Port
Label
Infrared Sensor
UV Light
To avoid danger of suffocation, keep away from babies and children.
Do not plug in your vacuum until you are familiar with all instructions and
operating procedures.
To reduce the risk of electric shock, turn power switch off and disconnect
plug from electrical outlet before performing maintenance or troubleshooting
checks.
Wheel
Handle
Air Outlet
Suction Port
ON/OFF
Dust Collector
UV Light Indicator
Dust Collector Lock
ABS Machine Body
Handle
Handle Lock
Power Cord
Take Off the Dust Collector from the Handle
Long press the handle lock to take off the handle.
Use a coin to rotate 90 degrees along the
lock/unlock mark marked at both sides of
the brush and take out the holder.
HEPA Filter
ON/OFF
Take Off the Handle from the Machine
Turn OFF and unplug the machine.
Air Inlet
Dust Collector
Button
Cyclonic Filter
Rotating brush and the brush holder is pre-
Note: Put in the cyclonic filter first, then the cotton filter & HEPA filter.
Always keep the air outlet downward to ensure that the dust in the dust colletor not
Take out the filters: Move along the vertical direction of the dust collector.
scattered.
Installing of Rotating brush and the Brush Holder
assembled when you receive this product.
Rotating Brush Holder
Rotating Brush
OperationOperation
ON/OFF Button
1. Connect the power cord to the socket, press
the ON/OFF botton, and the vacuum cleaner will
start to work.
2. Make sure that the distance between the
bottom of the machine and the cleaning target is
less than 3cm, otherwise the ultraviolet lamp of
the vacuum cleaner will stop working.
3. Press the button again in to stop the machine.
Note: When the UV light indicators turn on, the UV light is working properly.
Dust
Collector
Hook
Handle Groove
Handle
Lock
Lock
Unlock
Hold still the handle with one hand.
Turn the dust cup clockwise with the other hand,
align the UNLOCK icon on the dust cup with the
middle of the handle, gently pull the dust cup off.
Cleaning the Dust Collector
Cleaning and MaintenanceCleaning and MaintenanceCleaning and Maintenance Cleaning and Maintenance
STORAGE
Unplug when not in use for extended periods and before maintenance or servicing.
Put the product in a dry indoor place, do not put it outdoors or in any places that are
not dry.
CLEANING
Turn OFF the product.
Take out the dust collector, clean the dust collecting cup and filter with cold tap
water, leave them COMPLETELY DRY.
Clean the machine body with dry cotton cloth, do NOT wash the machine body.
Note: Wash filter with cold water at least once every month.
E
First the Hepa filter is encased by paper towel, gently pat small dust out (as figure 1)
Press filter lock button and take out filter assy, cleaning dust tank (as figure 2).
Put dust tank back to main body and close the cover.
Note: The dust tank needs to be completely dry after cleaning before
installation.
nsure the filter is completely dry before refitting.
Cleaning host outlet
Check the air outlet and air inlet and remove
the obstacles before install the handle back to
the machine body.
Note:
Do not remove the filter on the air outlet. You
can never put it back!
Cleaning host outletCleaning host outlet
Product Specifications
Item Specifications
Voltage
120V/50Hz
Power
300W
0.4L
Dust Tank
Vacuum Power
15Kpa
UV Wavelength
254nm
Weight
1.65kg
Size
310*260*220mm
1
2
inlet
outlet
TroubleshootingTroubleshootingTroubleshooting
The vacuum
won't work
Power connection error
The roller brush is entangled by
hair.
Take out the roller brush and
clean it.
Check the power cord, press ON.
Poor Suction
The dust tank is blocked by dust
The filter is blocked by dust.
The air outlet is blocked.
Clean the dust collector.
Empty and clean the filter.
Clean the air outlet.
The cleaned objects do not have
strong reflection or the distance is
The UV light
won't work
too long.
The machine is placed vertically
The two transparent films on the
bottom of the machine are covered
by dust.
Clean them with half-wet
Usually, the machine will turn on
the UV light automatically when
Angle is greater than 30°
approaching the objects(3cm)
cotton cloth.
Possible Causes
SolutionProblem
WARNING:
To reduce the risk of electric shock, turn OFF the ON/OFF button and
unplug from electrical outlet before performing maintenance or
troubleshooting checks.
1 Year Limited Warranty
If a claim is received within one year of receipt and the product is
found to have failed under the warranty we shall, at our option:
1. repair the product,
2. exchange the product with a product that is new or which has
been manufactured from new or serviceable used parts and is at
least functionally equivalent to the original product.
Please note:
Proof (both the original and any subsequent) delivery/purchase
should be provided before any work can be carried out on your
fans or routine maintenance components such as filters, belts, or
brushes, but if the routine maintenance components are
damaged within one year, you can contact DIBEA for related
accessories, we will offer you with discounts .
DIBEA appliance. Without this proof, any work carried out will be
chargeable, keep your receipt or delivery note.
Any parts which are replaced by DIBEA will become the property
of DIBEA . The repair or replacement of your DIBEA appliance
under guarantee will not extend the period of guarantee.
This warranty applies to product used for personal, and not
commercial or rental, service. This warranty does not apply to
DIBEA does not guarantee the repair or replacement of a product
where a defect is the result of:
（a）Accidental damage, faults caused by negligent use or care,
misuse, neglect, carelessness or operation or handling of the
appliance which is not in accordance with the This User Manual.
（b）Use of the appliance for anything other than normal
domestic household purposes.（c）Use of parts not assembled
dor installed in accordance with the instructions of DIBEA.（ ）
Use of parts and accessories which are not genuine DIBEA
components. （e）Faulty installation (except where installed by
DIBEA).（f）Repairs or alferations carried out by parties other
than DIBEA or its authorised agents.（g） The product is NOT
used in the same country in which it was sold.
SERVICE: us-support@dibea.com
