PS900C
EN Operator's manual 2-7
Contents
Introduction..................................................................... 2
Safety..............................................................................3
Assembly........................................................................ 5
Operation........................................................................ 5
Troubleshooting.............................................................. 6
Transportation, storage and disposal............................. 6
Technical data................................................................ 6
Introduction
Product description
The Husqvarna PS900C is a battery charger.
Intended use
Use the battery charger to charge batteries in applicable
Husqvarna products. Do not use the battery charger for
other tasks.
Battery charger overview
6
1
2
3
5
4
1. Battery charger
2. Power cord
3. Power plug, with different plugs for different markets
4. Charger ON/OFF switch
5. Charger plug
6. Power socket
Symbols on the battery charger
Read the operator's manual carefully
and make sure that you understand the
instructions before use.
The battery charger agrees with the
applicable EC directives.
This battery charger conforms to the
applicable UK regulations.
IP54 - The battery charger has protection
against dust and splashing water.
2 2395 - 001 - 13.03.2024
The battery charger or package of the
battery charger is not domestic waste.
Recycle it at an applicable disposal
location for electrical and electronic
equipment.
Scannable code.
Note: Other symbols/decals on the battery charger
refer to certification requirements for some commercial
areas.
Safety
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
WARNING: Used if there is a risk of
injury or death for the operator or bystanders
if the instructions in the manual are not
obeyed.
CAUTION: Used if there is a risk of
damage to the product, other materials or
the adjacent area if the instructions in the
manual are not obeyed.
Note: Used to give more information that is necessary
in a given situation.
Important safety instructions
WARNING: Read all
safety warnings and all
instructions. Failure to
obey the warnings and
instructions may result
in electrical shock, fire
and/or serious injury.
Note: Save all warnings and
instructions.
•
If the power cord is damaged,
it must be replaced by
the manufacturer, its service
agent or similarly qualified
persons in order to avoid
hazard.
•
Regularly examine that the
power cord is not damaged.
Immediately disconnect the
battery charger if the power
cord is damaged.
•
Only charge Husqvarna
original batteries with the
battery charger. If you have
questions, speak to your
Husqvarna dealer.
•
Do not charge non-
rechargable batteries.
•
Do not try to disassemble or
repair the battery charger. All
repairs are to be done by
an approved dealer only. Do
not use a damaged battery
charger.
•
Do not connect the battery
charger terminals to metal
objects.
•
The power plug must only use
a grounded mains socket.
2395 - 001 - 13.03.2024
3
•
The power plug must only
use a mains socket that has
protection from rain.
•
Use an approved and
grounded mains socket that is
not damaged.
•
Do not lift the battery
charger by the power cord.
To disconnect the battery
charger from a mains socket,
pull out the power plug. Do
not pull the power cord.
•
Keep all cables and extension
leads away from water, oil
and sharp edges. Make sure
that the power cord is not
caught between doors, fences
or equivalent.
•
Do not use a damaged
battery charger or battery.
•
Do not use the battery
charger when there is a risk
of lightning.
•
Do not use the battery
charger near flammable
materials or materials that
can cause corrosion. Pull out
the power plug to the battery
charger if there is smoke or
fire.
•
Keep the battery charger
away from children. Children
should be supervised to
ensure that they do not play
with the battery charger.
•
Keep the battery charger
clean and away from sunlight.
Note: Applicable for the UK
market only
•
This battery charger can
be used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
battery charger in a safe
way and understand the
hazards involved. Children
shall not play with the battery
charger. Cleaning and user
maintenance shall not be
made by children without
supervision.
Note: Applicable for the AU/NZ
market only
•
This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a
person responsible for their
safety. Children should be
supervised to ensure that
4
2395 - 001 - 13.03.2024
they do not play with the
appliance.
Assembly
To assemble the battery charger
Note: Only use the battery charger with the supplied
power cord set. Do not use external power cord set.
If the power cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid hazard.
1. Make sure that the power plug (A) is not connected
to a mains socket.
C
B
A
2. Connect the power cord (B) to the power socket (C)
on the battery charger.
3. Make sure that the lock function (D) is engaged.
D
Operation
To charge the battery
CAUTION: Use the battery charger
in conditions where the temperature is
between 0 °C (32 °F) and 40 °C (104 °F).
CAUTION: Only use the battery charger
in a location that has a good airflow.
1. Make sure that the charger ON/OFF switch is set to
OFF.
2. Connect the power plug to a grounded mains socket.
CAUTION: Only connect the battery
charger to a mains socket that has the
voltage and frequency specified on the
rating plate.
3. Connect the charger plug to the socket for the
battery charger on the product.
4. Set the charger ON/OFF switch to ON. If possible,
make sure that the product shows that the battery
charges.
Note: For the location of the charge indicator, refer
to the Operator's manual for the product.
5. Set the charger ON/OFF switch to OFF when the
battery is fully charged. For charge times, refer to the
Operator's manual for the product.
6. Disconnect the charger plug from the socket for the
battery charger on the product.
7. Pull the power plug to disconnect the battery charger
from the mains socket. Do not pull the power cord.
2395 - 001 - 13.03.2024 5
Troubleshooting
Troubleshooting
Symptoms Cause Solution
The battery does not charge. The battery charger is not correctly
connected to the mains outlet.
Connect the battery charger to a
mains outlet.
The power cord is not correctly con-
nected to the battery charger.
Connect the power cord to the bat-
tery charger.
The charger ON/OFF switch is set to
OFF.
Set the charger ON/OFF switch to
ON.
The battery charger is not correctly
connected to the product.
Connect the battery charger to the
product.
The battery is damaged.
Disconnect the battery charger and
speak to an approved servicing deal-
er.
The battery charger or the power
cord is damaged.
Disconnect the battery charger and
speak to an approved servicing deal-
er.
Transportation, storage and disposal
Transportation and storage
• Safely attach the battery charger during
transportation to prevent damage and accidents.
• Keep the battery charger away from metal objects,
for example nails, screws or jewelry.
• Keep the battery charger in a locked area to prevent
access for children or persons that are not approved.
• Put the battery charger in a dry, frost-free and clean
area. The ambient temperature must be between 0
°C / 32 °F and 50 °C / 122 °F.
• Keep the battery charger away from sunlight.
• Clean the battery charger before storage.
• Disconnect the battery charger before storage.
Disposal
Husqvarna battery chargers are not domestic waste.
Obey the disposal instructions.
• Obey the local disposal requirements and applicable
regulations.
• Recycle the battery charger and package at an
applicable disposal location.
• Speak to your local Husqvarna dealer for more
information on how to recycle and discard the battery
charger.
Technical data
TECHNICAL DATA
Battery charger PS900C
Output Voltage, VDC 58
Number of batteries that can be charged at the same
time
1–3
6 2395 - 001 - 13.03.2024
TECHNICAL DATA
Battery Husqvarna EV1 module
Type Li-ion
Capacity 58.8 V, Max. 38.5 Ah
2395 - 001 - 13.03.2024 7
