Operating Instructions:
OBD2 MEMORY SAVER
Part No. 80
UNPACKING:
After unpacking unit, inspect carefully for any damage that may have occurred during transit. Check for loose, missing, or damaged
parts. If any damage is observed, a shipping damage claim must be filed with carrier. Do not use the OBD2 Memory Saver if broken,
bent, cracked or if any damaged parts (including labels) are noted. Any part that appears damaged in any way, operates abnormally,
or is missing parts should be removed from service immediately. If you suspect that the OBD2 Memory Saver was subjected to shock
load (a load that was dropped suddenly, unexpectedly, etc.) immediately discontinue use until it has been checked by a factory
authorized service center.
The following safety information is provided as guidelines to help you operate your OBD2 Memory Saver under the safest possible
conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not known
or not followed. The following safety instructions are to provide the user with the information necessary for safe use and operation.
Please read and retain these instructions for the continued safe use of your service system. Failure to follow instructions listed below
may result in serious injury. In addition, make certain that anyone that uses the equipment understands and follows these safety
instructions as well.
WARNING: Pursuant to California Proposition 65,
This product contains chemicals known to the state of California
to cause cancer and birth defects or other reproductive harm.
Wash hands after handling.
The only OBD2 Memory Saver designed for use with lithium portable power units with fuse and back charge protection. The OBD2
Memory Saver works with multi-use lithium portable power products This includes most other lithium jump starters on the market.
Please read and save these instructions. Read through this owner’s manual carefully before using this product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury
and/or damage to product or property. Please retain instructions for future reference.
WARNING
!
IMPORTANT INSTRUCTIONS AND SAFETY RULES
!
1. Know your tool. Read this manual carefully. Learn the tool’s applications and limitations, as well as, potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark work areas invite accidents.
3. Keep children away. All children should be kept away from the work area. Never let a child handle a tool without strict
adult supervision.
4. Do not operate this tool if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if
your judgment or reflexes are impaired while taking drugs. If there is any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should be worn at all times when operating this tool. Use ANSI approved safety
glasses. Everyday eyeglasses are NOT safety glasses. Dust mask, non-skid safety shoes, hard hat or hearing protection
should be used in appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neckties, rings, bracelets or other jewelry may present a potential hazard
when operating this tool. Keep all apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance at all times when operating this tool.
8. Check for damage. Check your tool regularly. If part of the tool is damaged it should be carefully inspected to make sure
that it can perform its intended function correctly. If in doubt, the part should be repaired. Refer all servicing to a
qualified technician. Consult your dealer for advice.
9. Keep away from flammables. Do not attempt to operate this tool near flammable materials or combustibles.
Failure to comply may cause serious injury or death.
10. Store idle tools out of the reach of children and untrained persons. Tools may be dangerous in the hands of untrained users.
INSTRUCTIONS:
1. Turn off any accessories: light, radio, etc.
2. Make sure vehicle is off and remove key.
3. Connect the OBD2 Memory Saver to the vehicle’s OBD2 port. Make sure the connector is fully engaged.
4. Connect the OBD2 Memory Saver Plug to your 12V DC power supply’s EC5/or 12V barrel connector port.
Make sure the plug is firmly in place.
5. Disconnect the vehicles battery cables and perform maintenance. Never leave unattended while in use.
6. When maintenance is complete, connect vehicle cables to the vehicle battery.
7. Immediately remove OBD2 Memory Saver from the power source and then the OBD2 adapter from the OBD2 vehicle port.
OBD2 MEMORY SAVER
Operating Instructions:
Part No. 80
NOTE:
Never start the vehicle or turn on the accessories with the OBD2 Memory Saver connected to the vehicle.
NOTE:
Do not use an extension cable on either end of the memory saver. Doing so could cause the vehicle’s memory to be lost or cause
the other vehicle damage.
When working with a vehicle’s battery, review all of the battery manufacturer’s and vehicle manufacturer’s safety
instructions, warnings and directions regarding battery disconnection, removal and replacement.
WARRANTY
CONTACT US:
1 YEAR LIMITED WARRANTY
From 90 Days from the original purchase date of this product, manufacturer will warranty this product. If you find any defect in material
or workmanship, through normal usage, return it to the place of purchase or to manufacturer for repair or replacement at our discretion.
In order to obtain this service send your tool and proof of purchase, transportation pre-paid, to Returns Dept., 7900 Industrial Village Rd.
Greensboro, NC 27409. We will not be responsible for lost or damaged goods during transportation, please insure your package. If our
inspection verifies the defect, we will either repair or replace the product at our election, or we may elect to refund the purchase price if
we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if we determine
there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you must bear the cost of returning
the product. Manufacturer will not provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not
limited to, abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. Manufacturer reserves the right to
makes any changes in construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold. We make every effort to assure that its products meet high quality and durability standards, and warrants to the original
purchaser that this product is free from defects in materials and workmanship for the period of 1 Year days from the date of purchase.
This warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations
outside our facilities, criminal activity, improper installation, and normal wear and tear or to lack of maintenance. We shall in no event
be liable for death, injuries to persons or property, or for incidental, and contingent, special or consequential damages arising from the
use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation
of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state.
CAUTION:
!
The vehicle’s electrical system is receiving power from the Memory Saver through the OBD2 port. Therefore, the vehicle’s battery
connectors are electrically live and will still conduct electricity. They must be covered with an insulator to prevent the connectors from
touching metal or each other and causing a short circuit. Allowing a short circuit to occur could cause damage to the electrical system
of the vehicle.
CAUTION:
!
Consumable components such as batteries are not covered by the warranty.
This warranty is invalidated if any of the following occurs, but not limited to this list:
• Failure to follow instructions in the User’s Manual
• Accidental and or unreasonable use or misuse
• Mishandling
• Over charging or overloading
• Extended storage without recharging
• Repairs by and unauthorized person or any modification
• Normal wear or accident
