Matco Tools MTCMEATTHER2 User Manual

MTCMEATTHER2

•Pressbuttontoincrease1degree,holditfor3secondstofastincrease.

•Pressbuttontodecrease1degree,holditfor3secondstofastdecrease.

5.7Temperaturealarm

•WhentheTHERMOTEMPvalueexceedSETTEMP,thenitwillsoundalarm.

•Soundalarm:bi-bi-bi-bi.

•Alarmicondisplayed.

•Insoundalarm,pressbuttontostopalarm.

5.8Timer

•InTIMERmode,whenthecapitalizedisplays"00:00",thenpressbuttontocountup,andwhen

iconblinks,itmeanscountup.

•Pressbuttontopausecountup.

•Themaximumcountuptimeis99h:59m.

5.8.1Countup

5.8.2Countdown

•InTIMERmode,pressbuttontoincrease1hour,holditfor3secondstofastincrease.

•Pressbuttontoincrease1minute,holditfor3secondstofastincrease.

•Pressbuttontocountdown,andiconblinking,itmeanscountdown.

•Pressbuttontopausecountdown.

•Whencountdownto"00:00",itwillbesound"bi-bi-bi-bi"for1minute,andicondisplayed.

•Pressbuttontostopalarm.

•Atsametimepressandbuttonstoclearnumberto"00:00".

6.Wastedisposal

Thisproducthasbeenmanufacturedusinghigh-gradematerialsandcomponentswhichcanberecycledand

reused.

Neverdisposeofemptybatteriesandrechargeablebatteriesinhouseholdwaste.Asaconsumer,

youarelegallyrequiredtotakethemtoyourretailstoreortoanappropriatecollectionsite

dependingonnationalorlocalregulationsinordertoprotecttheenvironment.

Thesymbolsfortheheavymetalscontainedare:Cd=cadmium,Hg=mercury,Pb=lead.

ThisinstrumentislabelledinaccordancewiththeEUWasteElectricalandElectronicEquipment.

Directive(WEEE).

Pleasedonotdisposeofthisinstrumentinhouseholdwaste.Theuserisobligatedtotake

end-of-lifedevicestoadesignatedcollectionpointforthedisposalofelectricalandelectronic

equipment,inordertoensureenvironmentally-compatibledisposal.

ME AT

-4- 2012286-97

MadeinChinatoMatcospeciﬁcations

HechoenChinasegúnlasespeciﬁcacionesdeMatco

4.Pourvotresécurité

1.Ceproduitestexclusivementdestinéaudomained'applicationdécritci-dessus.Ildevraitêtreutilisé

uniquementtelquepréciséparlesinstructions.

2.Lesréparations,modiﬁcationsouchangementsnonautoriséssurleproduitsontinterdits.

Attention!

Risquedeblessure:

1.Gardezcesinstrumentsetlespileshorsdeportéedesenfants.

2.Lespilesnedoiventpasêtrejetéesaufeu,court-circuitées,démontéesourechargées.Risqued'explosion!

3.Lespilescontiennentdesacidesnocifs.Lespilesfaiblesdoiventêtreremplacéesdèsquepossiblepour

évitertoutdommageéventuelcausépardesfuites.

4.N'utilisezjamaisunecombinaisondevieillesetdenouvellespilesensemble,nidespilesdetypesdiﬀérents.

5.Portezdesgantsdeprotectionrésistantauxproduitschimiquesetdeslunettesdesécuritélorsquevous

manipulezdespilesquifuient.

Informationsimportantessurlasécuritédesproduits!

1.Neplacezpasvotreappareilàproximitédetempératures,devibrationsoudechocsextrêmes.

2.Leproduitn'estpasétanche.

4.Porsuseguridad

1.Esteproductoestáexclusivamentedestinadoparaelcampodeaplicacionesdescritoanteriormente.Este

productodeberáusarsesolosegúnseadescritodentrodelasinstrucciones.

2.Seprohíbenlasreparaciones,modiﬁcacionesycambiosnoautorizadosalproducto.

¡Precaución!

Riesgodelesiones:

1.Mantengaestosinstrumentosylasbateríasfueradelalcancedelosniños.

2.Lasbateríasnodeberándesecharsealfuego,deshacerse,recargarseniestarsujetoaningúncortocircuito.

¡Riesgodeexplosión!

3.Lasbateríascontienenácidosdañinos.Lasbateríasdebajacargadeberáncambiarselomásprontoquesea

posibleconelﬁndeprevenirdañosocasionadosporalgunapérdidadelíquido.

4.Nuncauseningunacombinacióndebateríasviejasynuevasjuntas,nibateríasdediferentestipos.

5.Llevepuestoguantesylentesprotectoresresistentesalosquímicosalmomentodemanejarlasbaterías

conpérdidadelíquido.

¡Informaciónimportantesobrelaseguridaddelproducto!

1.Nocoloquesudispositivocercadelastemperaturasextremosas,lasvibracionesyloschoques.

2.Elproductonoesimpermeablecontraelagua.

MTCMEATTHER2

-5- 2012286-97

BBQThermometer&TimerInstructionManual

Model:MTCMEATTHER2

1.Descriptionofparts

Fig.1:Thermometer

-1-

Fig.2:LCDDisplay

B1

B2

B3

B4

B5

B7

B6

B1:

B2:

B3:

B4:

B5:

B6:

Timericon:

Currenttemperature

Temperaturealarmicon

Timeralarmicon

S ettemperature

Meatandtasteiconchoose

countdown

countup

B7:

Temperatureicon

HR :hourMIN:minute

MTCMEATTHER2

MEAT

A1

A2

A3

A4

A7

A6

A5

O N

O F F

A8

A1:LCDdisplay

A2:Buttons

A3:Sensorplug

A4:Timerandtemperatureswitch

A5:Batterycover

A6:Switchof˚Cand˚F

A7:Support

A8:Powerswitch

2012286-97

•ThenLCDdisplay:

5.2Modechoose

5.3Temperatureunitchoose

5.4Buttonsfunction

5.5Meatandtastechoose

•InTEMPERATUREmode,pressbuttontochoosemeatandtaste,thebacklightturnonfor5seconds

andthemeaticonisblinking.

•Pressbuttonandtochoosemeatandtaste,pressbuttonagaintoconﬁrmchoose,

andthemeaticonwillstopblinking,alsothesettemperatureautomaticallychangedasabovesheet.

5.6Temperaturesetting

•InTEMPERATUREmode,ifyoudonʼtwantthetemperaturevalueinprogramed,thenyoucanpress

orbuttontosetthetargettemperaturevalue,theSETTEMPvaluewillbechanged.

MTCMEATTHER2

ME AT

BUTTONS TIMER

TE MPE R ATUR E

Press 

Hold

Press 

Hold

Press 

Hold

Increasehour

Fastincreasehour

Startandstopcount

Nofunction

Increaseminute

Fastincreaseminute

Increasesettemperature/choosemeat

Fastincreasesettemperature

Chooseandentermeat

Nofunction

Decreasesettemperature/choosemeat

Fastdecreasesettemperature

-3-

TIMERmode TEMPERATUREmode

Celsius Fahrenheit

MEAT

TAS TE

TE MP

AND

Poultry Beefwell Pork Beefmed Hamburger Beefrare Fish

74°C/165°F 77°C/170°F 77°C/170°F 71°C/160°F 71°C/160°F 63°C/145°F 63°C/145°F

ME AT

Temperaturemode,unit°C Temperaturemode,unit°F Timermode

2012286-97

MTCMEATTHER2

-2-

2.Beforeyoustartusingit

1.Pleasemakesuretoreadtheinstructionmanualcarefully.

Thisinformationwillhelpyoutofamiliarizeyourselfwithyournewdevice,tolearnallofitsfunctions

andparts,toﬁndoutimportantdetailsaboutitsﬁrstuse,howtooperateitandtogetadviceintheeventof

amalfunction.

2.Followingandrespectingtheinstructionsinyourmanualwillpreventdamagetoyourinstrumentandloss

ofyourstatutoryrightsarisingfromdefectsduetoincorrectuse.

3.Weshallnotbeliableforanydamageoccurringasaresultofnonfollowingoftheseinstructions.

Likewise,wetakenoresponsibilityforanyincorrectreadingsandforanyconsequenceswhichmayresult

fromthem.

4.Pleasetakeparticularnoteofthesafetyadvice!

5.Pleasekeepthisinstructionmanualforfuturereference.

3.Speciﬁcations

1.Measuringrange:0°C~+250°C(32°F~482°F)

2.Accury:0°C~100°C(32°F~212°F),1°C(2°F)

101°C~150°C(214°F~302°F),2°C(4°F)

151°C~200°C(304°F~392°F),4°C(8°F)

201°C~250°C(394°F~482°F),5%

3.Powerconsumption:2X1,5VAAA(notincluded).

4.Backlight.

5.Countdown/up:99h:59m.

6.Meatandtastechoose.

7.Temperaturealertsetting.

8.Stainlesssteelsensorlength:about100mm.

4.Foryoursafety

1.Thisproductisexclusivelyintendedfortheﬁeldofapplicationdescribedabove.Itshouldonlybeusedas

describedwithintheseinstructions.

2.Unauthorizedrepairs,modiﬁcationsorchangestotheproductareprohibited.

Caution!

Riskofinjury:

1.Keeptheseinstrumentsandthebatteriesoutofthereachofchildren.

2.Batteriesmustnotbethrownintoaﬁre,short-circuited,takenapartorrecharged.Riskofexplosion!

3.Batteriescontainharmfulacids.Lowbatteriesshouldbechangedassoonaspossibletopreventdamage

causedbyleaking.

4.Neveruseacombinationofoldandnewbatteriestogether,norbatteriesofdiﬀerenttypes.

5.Wearchemical-resistantprotectiveglovesandsafetyglasseswhenhandlingleakingbatteries.

Importantinformationonproductsafety!

1.Donotplaceyourdevicenearextremetemperatures,vibrationsorshocks.

2.Productisnotwaterproof.

5.Operation

5.1Insertingthebatteriesinthethermometer

•Removetheprotectivefoilfromthedisplay.

•Removethebatterycoverandinserttwonewbatteries1,5VAAA,polarityasillustrated,closethe

batterycompartmentagain.

•TurnonthedeviceanditwillalertyouwithabeepandallLCDsegmentswillbedisplayedforashort

moment.

2012286-97
