User Manual
AC1200 WiFi Range Extender
Model EX5000
NETGEAR, Inc.
350 E. Plumeria DriveJanuary 2020
San Jose, CA 95134, USA202-12048-01
Support
Thank you for purchasing this NETGEAR product. You can visit
https://www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you use
only official NETGEAR support resources.
Compliance and Conformity
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
Trademarks
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
2
AC1200 WiFi Range Extender
Contents
Chapter 1 Overview
Meet Your Extender..............................................................................6
LEDs...................................................................................................6
Buttons...............................................................................................7
When to Use Your Extender................................................................7
How the Extender Works.....................................................................7
Chapter 2 Get Started
Install the WiFi Extender....................................................................10
Place the Extender and Apply Power..........................................10
Connect to an Existing WiFi Network..........................................10
Connect with WPS.....................................................................10
Connect with the NETGEAR Installation Assistant................12
Find the Best Location...................................................................13
Log In to the Extender After Installation..........................................13
Run Smart Setup Installation.............................................................14
Chapter 3 Maintain and Monitor the Extender
Change the Extender admin User Name and Password...............16
Turn Password Protection Off and On.............................................17
Recover a Forgotten User Name or Password................................17
Automatically Adjust for Daylight Saving Time..............................18
Manually Set the Extender Clock......................................................19
Back Up and Manage the Extender Configuration........................20
Back Up the Configuration Settings............................................20
Restore the Configuration Settings.............................................21
Return the Extender To Its Factory Default Settings......................22
Use the Reset Button.....................................................................22
Log In and Reset the Extender to Factory Settings....................22
Update the Extender Firmware.........................................................23
Check for New Firmware and Update the Extender.................24
Manually Upload Firmware to the Extender...............................24
Chapter 4 Extender Network Settings
View Connected Devices...................................................................27
Boost Your Video Streaming with FastLane Technology..............27
3
View WiFi Settings..............................................................................29
Change the WiFi Network Name......................................................29
Turn Off the SSID Broadcast to Create a Hidden Network...........30
Disable or Enable the WiFi Radios...................................................31
Change the WiFi Speed.....................................................................32
Use WPS to Add a Computer to the Extender’s WiFi Network....33
Use WPS with the Push Button Method......................................33
Use WPS with the PIN Method.....................................................34
Deny Access to a Computer or WiFi Device...................................35
Set Up an Access Schedule...............................................................36
Change the Extender’s Device Name..............................................37
Set Up the Extender to Use a Static IP Address..............................38
Use the Extender with MAC Filtering or Access Control...............39
Chapter 5 FAQs and Troubleshooting
FAQs.....................................................................................................42
Cannot Connect to the Extender......................................................42
Cannot Join a WiFi Network and Receive an Error Message.......43
Cannot Access mywifiext.net............................................................43
Find Extender's IP Address...............................................................44
Chapter 6 Factory Settings and Technical Specifications
Factory Default Settings.....................................................................47
Technical and Environmental Specifications..................................47
4
AC1200 WiFi Range Extender
1
Overview
The WiFi Range Extender boosts your existing network range and speed, delivering
dual-band WiFi.
This chapter covers the following topics:
• Meet Your Extender
• When to Use Your Extender
• How the Extender Works
Note: For more information about the topics covered in this manual, visit the support
website at support.netgear.com.
5
Meet Your Extender
Before you install your extender, familiarize yourself with its LEDs and buttons.
LEDs
The following table describes the LEDs.
Table 1. LED descriptions
DescriptionLED
•
Solid green. The extender is powered on.
•
Solid amber. The extender is booting.
•
Off. The extender is powered off.
Power
This LED indicates the network connection between the extender and the
router or access point.
•
Solid green. Best connection.
•
Solid amber. Good connection.
•
Solid red. Poor connection.
•
Off. No connection.
Router
User Manual6Overview
AC1200 WiFi Range Extender
Table 1. LED descriptions (Continued)
DescriptionLED
This LED indicates the network connection between the extender and a
computer or mobile device.
•
Solid green. Best connection.
•
Solid amber. Good connection.
•
Solid red. Poor connection.
•
Off. No connection.
Device
•
Solid green. WiFi security is enabled (WPA or WPA2).
•
Blinking green. A WPS connection is being established.
•
Off. WiFi security is not enabled.
WPS
Buttons
The side panel contains the following buttons:
•
Reset button. Pressing the Reset button for about five seconds resets the extender.
•
WPS button. Pressing the WPS button let's the extender connect to your existing
WiFi network through WPS. You can also connect WPS-enabled devices to the
extender using the WPS button.
•
Power button. Pressing the Power button turn the extender on or off.
When to Use Your Extender
NETGEAR recommends that you connect through the extender network only when the
WiFi device is in a “dead zone” where connection from the existing network is poor or
nonexistent. Data traffic routed through the extender is inherently slower than traffic
routed directly from the network.
How the Extender Works
The extender works like a bridge between a WiFi router (or a WiFi access point) and a
WiFi device outside the range of the WiFi router. The extender performs two main jobs:
•
The extender connects to a working WiFi network.
User Manual7Overview
AC1200 WiFi Range Extender
When the extender connects over WiFi to an existing network, it functions as a
network client, similar to how a WiFi device connects to a network.
•
The extender acts as an access point for WiFi devices.
The extender broadcasts its own WiFi network that WiFi devices can join. In its role
as an access point, the extender performs tasks that WiFi routers do, such as
broadcasting its network name (SSID).
The extender must do each of these jobs so that both ends of the bridge are in place.
Figure 1. Connect your extender
User Manual8Overview
AC1200 WiFi Range Extender
Install the WiFi Extender
Place the extender, apply power, and connect the extender to your WiFi network.
Place the Extender and Apply Power
To place the extender and apply power:
1. Place your extender in the same room as your WiFi router.
Proximity to the WiFi router is required only during the initial setup process.
2. Plug the extender into an electrical outlet.
3.
Wait for the Power LED to light amber and then turn green.
If the Power LED does not light, press the Power On/Off button on the side of the
extender.
Connect to an Existing WiFi Network
To extend the range of your WiFi network, you must connect the extender to your
existing WiFi network. You can do this in one of two ways:
•
Connect with WPS. For more information, see Connect with WPS on page 10.
•
Connect with web browser setup. For more information, see Connect with the
NETGEAR Installation Assistant on page 12.
Connect with WPS Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network
without typing the network name and password. For help with the WPS button on your
WPS-enabled device, check the instructions or online help that came with that device.
Some older equipment cannot use WPS.
Note: WPS does not support WEP network security or a hidden SSID network. If your
existing WiFi network uses WEP security or its SSID is hidden, follow the instructions in
Connect with the NETGEAR Installation Assistant on page 12.
To use WPS to connect the extender to your WiFi router:
1. Press the WPS button on the extender.
The WPS LED blinks.
2. Within two minutes, press the WPS button on your router.
When the extender connects to your existing WiFi network, the WPS LED on the
extender lights solid green and the Router LED lights.
User Manual10Get Started
AC1200 WiFi Range Extender
If the Router Link LED does not light, try again. If it still does not light, see Connect
with the NETGEAR Installation Assistant on page 12.
3.
If your WiFi router supports the 5 GHz band, repeat Steps 1 and 2 to connect the
extender to the 5 GHz band.
4.
Unplug the extender and move it to a new location that is about halfway between
your router and the area with a poor router WiFi signal.
The location that you choose must be within the range of your existing WiFi router
network.
5. Use the Router LED to help you choose a spot where the extender-to-router
connection is optimal.
6.
If the Router LED doesn’t light amber or green, plug the extender into an outlet
closer to the router and try again.
Keep moving the extender to outlets closer to the router until the Router LED lights
amber or green.
7.
On your computer or mobile device, find and connect to a new extender WiFi
network.
The extender creates two new extender WiFi networks. The extender’s new WiFi
network names are based on your existing WiFi network name, with _2GEXT and
_5GEXT at the end of the name.
For example:
•
Existing WiFi network name. MyNetworkName
•
New extender WiFi network names. MyNetworkName_2GEXT and
MyNetworkName_5GEXT
Use the same WiFi password that you use for your WiFi router.
User Manual11Get Started
AC1200 WiFi Range Extender
8. Test the new extender WiFi range by moving your computer or mobile device to
the area with a poor router WiFi signal:
a. Leave your computer or mobile device in the area with a poor router WiFi signal
and return to the extender.
b. Check the Device LED on the extender:
•
If the Device LED is solid green or amber, your new extender WiFi network
reaches the area with a poor router WiFi signal and your network setup is
complete.
•
If the Device LED is red, your new extender WiFi network does not reach the
area with a poor router WiFi signal.
You must move your computer or mobile device closer to the extender until
the Device LED turns solid green or amber.
Connect with the NETGEAR Installation Assistant You can use the NETGEAR
installation assistant to connect your extender to your existing WiFi router network. To
use the NETGEAR installation assistant, you must launch a web browser on your computer
or mobile device.
To use the NETGEAR installation assistant to connect the extender to your WiFi
router:
1.
On a computer or mobile device, open the WiFi connection manager and find and
connect to the extender network called NETGEAR_EXT.
When you are connected to the extender, the Device LED lights.
2. Launch web browser.
3.
Enter http://www.mywifiext.net.
The NETGEAR installation assistant displays.
4. Follow the prompts to connect your extender to your existing WiFi network.
5.
Unplug the extender and move it to a new location about halfway between your
router and the area with a poor WiFi signal.
6.
Plug the extender into an electrical outlet and wait for the Power LED to light green.
7. Use the Router LED to help you choose a spot where the extender-to-router
connection is optimal.
User Manual12Get Started
AC1200 WiFi Range Extender
8.
If the Router LED doesn’t light amber or green, plug the extender into an outlet
closer to the router and try again.
Keep moving the extender to outlets closer to the router until the Router LED lights
amber or green.
9. Reconnect your computer or mobile device to the new extender WiFi network.
10. Test the new extended WiFi range by moving your computer or mobile device to
the area with a poor router WiFi signal:
a. Leave your computer or mobile device in the area with a poor router WiFi signal
and return to the extender.
b. Check the Device LED on the extender:
•
If the Device LED is solid green or amber, your new extender WiFi network
reaches the area with a poor router WiFi signal and your network setup is
complete.
•
If the Device LED is red, your new extender WiFi network does not reach the
area with a poor router WiFi signal.
You must move your computer or mobile device closer to the extender until
the Device LED turns solid green or amber.
11.
Plug the extender into an electrical outlet and wait for the Power LED to light green.
Find the Best Location
If the WiFi signal is weak, the first time you join the extender network, the Router LED
or Device LED is amber or red. If this happens, adjust the position of the extender:
•
If the Router LED is amber or red, move the extender closer to the router.
•
If the Device LED is amber or red, move the computer or mobile device closer to
the extender.
Log In to the Extender After Installation
After installation, you can log in to the extender to view or change the extender’s settings.
User Manual13Get Started
AC1200 WiFi Range Extender
To log in to the extender:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
When you are connected to the extender, the Device Link LED lights.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
Run Smart Setup Installation
You can use Smart Setup to change the extender settings. This is an easy way to connect
the extender to a different router or to change the extender WiFi network name (SSID)
or WiFi password.
To run Smart Setup:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin email and password and click the LOG IN button.
The Status page displays.
4. Click the SMART SETUP button.
5. Follow the prompts.
User Manual14Get Started
AC1200 WiFi Range Extender
3
Maintain and Monitor the Extender
This chapter covers the following topics:
• Change the Extender admin User Name and Password
• Turn Password Protection Off and On
• Recover a Forgotten User Name or Password
• Automatically Adjust for Daylight Saving Time
• Manually Set the Extender Clock
• Back Up and Manage the Extender Configuration
• Return the Extender To Its Factory Default Settings
• Update the Extender Firmware
15
Change the Extender admin User Name and
Password
You can change the admin user name and password to log in to the extender.
To add an extender user:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Password.
The Password Settings page displays.
6. To change the admin user name, enter a new email address in the New User Name
field.
7.
To change the admin password, enter a new password in the New Password field
and the Verify Password field.
8. Select questions and enter the answers.
9. Click the SAVE button.
Your settings are saved.
User Manual16Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
Turn Password Protection Off and On
NETGEAR recommends that you leave password protection on to help keep your network
secure. You can turn password protection off and on.
To turn password protection off or on:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Password.
The Password Settings page displays.
6.
Select the Password Off or Password On radio button.
7. Click the SAVE button.
Your settings are saved.
Recover a Forgotten User Name or Password
If you changed the password to access the extender and set up password recovery, you
can recover your password if you lose it.
User Manual17Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
To recover your password to access the extender:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Click the Username & Password Help link.
A page displays requesting the answers to your security questions.
If you forgot the answers to your security questions, restore the extender’s factory
settings and set up your login credentials again. See Return the Extender To Its
Factory Default Settings on page 22.
4. Enter the saved answers to your security questions.
5. Click the NEXT button.
Your admin user name and password displays.
6. Click the BACK button.
A login page displays.
7. Log in to the extender.
Automatically Adjust for Daylight Saving
Time
To set up the extender to automatically adjust for daylight saving time:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
User Manual18Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Do More > Access Schedule.
The Access Schedule page displays.
6.
Select the Automatically adjust for daylight savings time check box.
7. Click the SAVE button.
Your settings are saved.
Manually Set the Extender Clock
If you turned on the access schedule, you can set the extender clock. The extender clock
makes sure that the that the WiFi access schedules are accurate.
To manually set the extender clock:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
User Manual19Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
5. Select Do More > Access Schedule.
The Access Schedule page displays.
6. In the Extender Clock section, select the Manual radio button.
7.
To specify the time, complete the fields or click the Sync Clock button to synchronize
the extender time to the time on the computer or mobile device that you are using.
8. Click the SAVE button.
Your settings are saved.
Back Up and Manage the Extender
Configuration
When the extender works correctly after initial setup, NETGEAR recommends that you
back up the extender configuration settings. After you have back up the settings, if you
change the extender configuration settings but are not content with the new settings,
you can restore the extender configuration to the backed-up settings.
Back Up the Configuration Settings
You can back up the configuration file of the extender.
To back up the extender configuration settings:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
User Manual20Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
5. Select Settings > Other.
The Other Settings page displays.
6. Click the BACKUP button.
Your browser extracts the configuration file from the extender. The backup file uses
an .cfg extenstion.
7.
If your browser is not set up to save downloaded files automatically, locate where
you want to save the file.
8. Click the OK button.
The extender configuration settings are backed up.
Restore the Configuration Settings
You can restore the configuration file of the extender to a previously saved configuration
file.
To restore the extender configuration settings:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Other.
The Other Settings page displays.
6. Click the BROWSE button.
7.
Locate and select the previously saved backup file.
The backup file uses a .cfg extension.
User Manual21Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
CAUTION: After you click the RESTORE button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender until it finishes
restarting!
8. Click the RESTORE button.
A confirmation pop-up window opens.
9.
Confirm your decision.
The extender configuration is restored and the extender restarts. This process takes
about one minute.
Return the Extender To Its Factory Default
Settings
Under some circumstances (for example, if you lose track of the changes that you made
to the extender settings), you might want to erase the configuration and reset the
extender to factory default settings.
To reset the extender to factory default settings, you can either use the Factory Reset
button on the side panel or log in to the extender and reset it.
Use the Reset Button
CAUTION: This process erases any settings that you configured in the extender.
To use the Reset button to return the extender to its factory default settings:
1.
Insert a straightened paper clip into the hole of the Reset button and hold it for
about seven seconds.
2. Release the button.
CAUTION: Do not try to go online, turn off the extender, shut down the computer,
or do anything else to the extender until it finishes restarting!
The extender resets and restarts. This process takes about one minute.
Log In and Reset the Extender to Factory Settings
CAUTION: This process erases any settings that you configured in the extender.
User Manual22Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
To log in to the extender and reset the extender's factory settings:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Other.
The Other Settings page displays/
CAUTION: After you click the RESET button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender until it finishes
restarting!
6. Click the RESET button.
A confirmation pop-up window opens.
7.
Confirm your decision.
The extender returns to its factory settings and restarts. This process takes about
one minute.
Update the Extender Firmware
You can log in to the extender and check if new firmware is available, or you can manually
load a specific firmware version to your extender.
User Manual23Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
Check for New Firmware and Update the Extender
Unless you changed the settings in the Firmware Update page previously, the extender
is set up to check for new firmware automatically at login.
To check manually for new firmware and, if available, update the firmware:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Firmware Update.
The Firmware Update page displays.
6. Click the CHECK ONLINE button.
7.
If new firmware is available, follow the onscreen prompts to update the firmware.
Note: You might need to unzip the firmware file. The firmware update process takes
about two minutes.
Manually Upload Firmware to the Extender
If you want to upload a specific firmware version, follow these instructions.
To manually upload a firmware file to your extender:
1.
Launch a web browser from a computer that is connected to your extender network.
2.
Download the firmware for your extender from the NETGEAR Download Center,
save it to your desktop, and unzip the file if needed.
User Manual24Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
You might need to unzip the firmware file.
3. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
4. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
5.
If your browser displays the Menu icon , click it.
The extender menu displays.
6. Select Firmware Update.
The Firmware Update page displays.
7. Click the BROWSE button.
8.
Locate and select the new firmware file.
The firmware file name ends with a .img or .chk extension.
CAUTION: After you click the UPLOAD button, do not try to go online, turn off the
extender, shut down the computer, or do anything else to the extender until it finishes
restarting!
9. Click the UPLOAD button.
The firmware update starts and the extender restarts. The firmware update process
takes about two minutes.
User Manual25Maintain and Monitor the
Extender
AC1200 WiFi Range Extender
4
Extender Network Settings
This chapter covers the following topics:
• View Connected Devices
• Boost Your Video Streaming with FastLane Technology
• View WiFi Settings
• Change the WiFi Network Name
• Turn Off the SSID Broadcast to Create a Hidden Network
• Disable or Enable the WiFi Radios
• Change the WiFi Speed
• Use WPS to Add a Computer to the Extender’s WiFi Network
• Deny Access to a Computer or WiFi Device
• Set Up an Access Schedule
• Change the Extender’s Device Name
• Set Up the Extender to Use a Static IP Address
• Use the Extender with MAC Filtering or Access Control
26
View Connected Devices
You can view a list of devices that are connected to the extender network.
To view connected devices:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Connected Devices.
The Connected Devices page displays. The devices connected to the extender
dsipalys on the page.
Boost Your Video Streaming with FastLane
Technology
Get the most out of your HD entertainment with FastLane technology. With FastLane
technology, the extender connects to your router using one band and connects to your
devices using another band. Because a band is dedicated to each function, performance
is enhanced.
If all your devices and your WiFi router support only the 2.4 GHz band, or all your devices
and your WiFi router support only the 5 GHz band, do not enable FastLane Technology.
User Manual27Extender Network Settings
AC1200 WiFi Range Extender
When you enable FastLane Technology, two options are available:
•
Use the 2.4 GHz band to connect the extender to the WiFi devices and use the 5
GHz band to connect the extender to the WiFi router. Use this mode if your WiFi
router supports the 5 GHz band but the devices that you want to use for gaming and
streaming support the 2.4 GHz band.
•
Use the 5 GHz band to connect the extender to the WiFi devices and use the 2.4
GHz band to connect the extender to the WiFi router. Use this mode if the devices
that you want to use for gaming and streaming support the 5 GHz band but your
WiFi router supports the 2.4 GHz band.
To activate FastLane mode:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Do More > FastLane.
The FastLane Technology page displays.
6. Select the FastLane Technology radio button.
The page adjusts and displays two more radio buttons.
7. Select a radio button:
• Router-to-Extender in 2.4 GHz only and Extender-to-Device in 5 GHz only
• Router to Extender in 5 GHz only and Extender-to-Device in 2.4 GHz only
8. Click the SAVE button.
Your changes are saved.
User Manual28Extender Network Settings
AC1200 WiFi Range Extender
View WiFi Settings
To view the WiFi settings:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
Change the WiFi Network Name
To change the WiFi network name:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
User Manual29Extender Network Settings
AC1200 WiFi Range Extender
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6.
In each Network Name (SSID) field, type a network name.
7. Click the SAVE button.
Your settings are saved.
Turn Off the SSID Broadcast to Create a
Hidden Network
By default, the extender broadcasts its WiFi signal so that its wireless network names
(SSIDs) are easy for you to find and connect to from your computer, tablet, or
smartphone. You can turn off the SSID broadcast to create a hidden WiFi network. To
connect to a hidden network you must know its SSID and password and manually enter
them.
To turn off the SSID broadcast to create a hidden network:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
User Manual30Extender Network Settings
AC1200 WiFi Range Extender
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6. Clear the Broadcast the Network Name (SSID) check box.
7. Click the SAVE button.
Your settings are saved.
Disable or Enable the WiFi Radios
By default, the extender’s WiFi radios broadcast signals in the 2.4 GHz and 5 GHz bands.
If you disable the WiFi radios, then no one can connect with WiFi to the extender.
To enable or disable the WiFi radios:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6. Select or clear the Enable 2.4 GHz WiFi check box.
7. Select or clear the Enable 5 GHz WiFi check box.
8. Click the SAVE button.
User Manual31Extender Network Settings
AC1200 WiFi Range Extender
Your settings are saved.
Change the WiFi Speed
The 2.4 GHz network WiFi speed to set to a specific WiFi speed. You can only change
the 5 GHz WiFi speed.
To change the WiFi speed:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless.
The WiFi Settings page displays.
6. In the 5 GHz network WiFi Speed menu, select a speed.
7. Click the SAVE button.
Your settings are saved.
User Manual32Extender Network Settings
AC1200 WiFi Range Extender
Use WPS to Add a Computer to the
Extender’s WiFi Network
WPS (WiFi Protected Setup) lets you connect a computer or WiFi device to the extender’s
network without entering the WiFi network passphrase or key. Instead, you use a WPS
button or enter a PIN to connect.
If you use the push button method, the WiFi device that you are trying to connect must
include a physical button or a software button. If you use the PIN method, you must
know the PIN of the WiFi device that you are trying to connect.
WPS supports WPA and WPA2 WiFi security. If your extender network is open (no WiFi
security is set), connecting with WPS automatically sets WPA + WPA2 WiFi security on
the extender network and generates a random passphrase. You can view this passphrase
on the WiFi Settings page (for more information, see View WiFi Settings on page 29).
Use WPS with the Push Button Method
For you to use the push button method to connect a WiFi device to the extender’s WiFi
network, the WiFi device that you are trying to connect must include a physical WPS
button or an onscreen WPS button that you can click.
To use WPS to add a computer or WiFi device to the extender’s WiFi network:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Do More > Connect Devices (WPS).
User Manual33Extender Network Settings
AC1200 WiFi Range Extender
The Connected Devices (WPS) page displays.
6. Leave the Push Button (recommended) radio button selected.
7. Click the WIFI PROTECTED SETUP (WPS) button.
For two minutes, the extender attempts to add the computer or WiFi device to its
WiFi network.
8. Within two minutes, go to the computer WiFi device and press or click its WPS
button.
9.
To verify that the WiFi device is connected to the extender’s WiFi network, select
Settings > Connected Devices.
The WiFi device displays onscreen.
Use WPS with the PIN Method
To use the PIN method to connect a WiFi device to the extender’s WiFi network, you
must know the PIN of the WiFi device that you are trying to connect.
To add a computer or WiFi device to the extender’s WiFi network:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Do More > Connect Devices (WPS).
The Connect Devices (WPS) page displays.
6. Select the PIN Number radio button.
The page adjusts.
User Manual34Extender Network Settings
AC1200 WiFi Range Extender
7.
Type the PIN of the WiFi device in the field.
8. Click the NEXT button.
For four minutes, the extender attempts to find the computer or WiFi device.
9.
Within four minutes, go to the WiFi device and use its WPS software to join the WiFi
network.
10.
To verify that the WiFi device is connected to the extender’s WiFi network, select
Settings > Connected Devices.
The WiFi device displays onscreen.
Deny Access to a Computer or WiFi Device
By default, access control is disabled so that it is easy for you to connect to the extender’s
WiFi networks.
You can deny network access to specific computers and WiFi devices based on their
MAC addresses. Each network device is assigned a MAC address, which is a unique
12-character physical address, containing the hexadecimal characters 0–9, a–f, or A–F
only, and separated by colons (for example, 00:09:AB:CD:EF:01). Typically, the MAC
address is on the label of the WiFi device. If you cannot access the label, you can display
the MAC address using the network configuration utilities of the computer. You might
also find the MAC addresses on the Connected Devices page (see View Connected
Devices on page 27).
To use WiFi access control to deny access:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
User Manual35Extender Network Settings
AC1200 WiFi Range Extender
The extender menu displays.
5. Select Settings > Connected Devices.
The Connected Devices page displays.
6. In the WiFi Devices section, select the Enable Access Control check box.
The WiFi devices table displays the names and MAC addresses of WiFi devices that
are connected to the extender.
7.
Select the Deny check box for the device.
8. Click the SAVE button.
Your settings are saved and that device cannot connect to the extender’s WiFi
network.
Set Up an Access Schedule
You can control access to all users during specific periods of the day. You can set up
an access schedule that prevents Internet access through the extender network based
on the times that you set.
To set up an access schedule:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Do More > Access Schedule.
The Access Schedule pahe displays.
User Manual36Extender Network Settings
AC1200 WiFi Range Extender
6. Select the Access Schedule On radio button.
The page adjusts.
7. In the Days menu and the Time menu, select the day and time when you want to
disable Internet access.
8.
Click the Add Time button to add the time that you specified to the Scheduled Times
table.
9. Click the SAVE button.
Your settings are saved.
Change the Extender’s Device Name
The default name is EX3800.
To change the extender’s device name:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless Settings.
The WiFi Settings page displays.
6. Scroll down and click the IP Address heading.
The page expands.
7.
In the Device Name field, type a name.
User Manual37Extender Network Settings
AC1200 WiFi Range Extender
8. Click the SAVE button.
Your settings are saved.
Set Up the Extender to Use a Static IP
Address
The extender comes set up to use a dynamic IP address, which is the correct setting for
most home networks.
To set up the extender to use a static IP address:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless Settings.
The WiFi Settings page displays.
6. Scroll down and click the IP Address heading.
The page expands.
By default, the Dynamically get IP Address from Router radio button is selected.
7. Select the Use Static IP Address radio button.
8.
Complete the fields to specify the IP network IP addresses.
9. Click the SAVE button.
Your settings are saved.
User Manual38Extender Network Settings
AC1200 WiFi Range Extender
Use the Extender with MAC Filtering or
Access Control
When the WiFi device connects through the extender to your router, the MAC address
of the wireless device that is shown on the router is translated to another MAC address.
If your router's MAC filter, wireless access control, or ACL is enabled, the WiFi device
connects to the extender but cannot get an IP address from the extender and cannot
access the Internet. To allow the wireless device to receive an IP address from the
extender and access the Internet, you must provide the translated MAC address to the
router.
To add a translated MAC address to your router:
1.
Log in to your router and disable the MAC filter, wireless access control, or ACL.
For more information about how to disable your router’s MAC filter, wireless access
control, or ACL, see your router’s documentation.
2.
Power on the extender and connect all of your WiFi devices to the extender.
3.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
4. Log in to your extender:
•
If your extender and router use different WiFi network names (SSIDs), enter
www.mywifiext.net.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
A login page displays.
5. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
6.
If your browser displays the Menu icon , click it.
The extender menu displays.
7. Select Settings > Connected Devices.
The Connected Devices section displays the MAC addresses and virtual MAC
addresses for computers and WiFi devices that are connected to the extender
network.
User Manual39Extender Network Settings
AC1200 WiFi Range Extender
8. On the router, add the extender’s virtual MAC address and all the virtual MAC
addresses connected to the extender network to your router’s MAC filter table.
9.
Enable the router’s MAC filter, wireless access control, or ACL.
User Manual40Extender Network Settings
AC1200 WiFi Range Extender
FAQs
This section provides answers for difficulties you might experience with the extender.
The web browser setup keeps asking me for my network password (passphrase)
or security key, and I am sure that I entered the correct password. What can I do?
The extender is probably placed at the borderline of the range covered by the router
or access point. For more information about where to place the extender, see Find
Extender's IP Address on page 44.
If you are using WEP security, make sure that you are typing the network password in
the correct field.
I forgot my admin email address and password. What can I do?
In the login window, click the Username & Password Help link to answer the security
questions that you set up during the initial setup. For more information, see Recover a
Forgotten User Name or Password on page 17.
To restore factory settings:
1. Use a sharp object such as a pen or paper clip to press and hold the Reset button
on the extender for seven seconds until the Power LED lights amber.
2.
Release the Reset button and wait for the extender to reboot.
The extender resets and returns to the factory default settings.
Cannot Connect to the Extender
If you cannot connect to the extender, determine what prevents you from connecting:
•
If you cannot access www.mywifiext.net, see Cannot Access mywifiext.net on page
43 for more information.
•
If you forgot your user name or password, click the Username & Password Help
link. For more information, see FAQs on page 42.
•
If your browser displays an error page, include http:// in the address field of your
browser by typing http://www.mywifiext.net.
•
If you already set up the extender but can no longer connect to it over WiFi, check
to see if the Device LED is off or red.
User Manual42FAQs and Troubleshooting
AC1200 WiFi Range Extender
Cannot Join a WiFi Network and Receive an
Error Message
To join a WiFi network, you must know its network name (also called the SSID) so that
you can select it. If the network is secure, you must know the passphrase or key. If the
extender does not connect to the network that you select, the cause might be one of
the following:
•
It is possible that you typed the network name, passphrase, or key incorrectly. Use
Smart Setup (see Run Smart Setup Installation on page 14) to select a WiFi network
and retype the passphrase or key. The passphrase or key is case-sensitive. For
example, PASSWORD25 is not the same as Password25 or password25.
•
If the extender cannot detect your WiFi network, check to see if your WiFi network
is still working. Make sure that the WiFi router is turned on. If possible, move the
extender closer to the WiFi router.
•
If the extender Device Link LED is red, the WiFi connection between the WiFi router
and the extender is poor. You can establish the best connection with a clear line of
sight between the extender and the WiFi router. Make sure that no physical obstacles
exist between the extender and the WiFi router, and try to move the extender closer
to the WiFi router.
If you use Smart Setup, and the extender does not connect to the WiFi router, does not
connect to the Internet, or cannot get an IP address from the WiFi router, Smart Setup
displays a message to notify you that the extender is not configured.
To run Smart Setup again, click the YES button. To manually configure the extender,
click the NO, CONFIGURE MANUALLY button.
Cannot Access mywifiext.net
When you try to access www.mywifiext.net to set up your extender, you might receive
an error message that says you are not connected to the extender's WiFi network. This
website is not a regular Internet website. It is a local web address used to log in to the
extender web interface and view the extender's settings.
Your computer or mobile device must be connected to your extender network to access
www.mywifiext.net.
User Manual43FAQs and Troubleshooting
AC1200 WiFi Range Extender
Try these troubleshooting tips to connect to www.mywifiext.net:
•
If you're trying to access www.mywifiext.net for the first time to set up your extender,
see Connect with the NETGEAR Installation Assistant on page 12 and follow the
instructions.
•
After you connect your computer or mobile device to the extender network, make
sure that the extender's Device LED is solid green or amber.
If the Device LED is not lit, open your computer's or mobile device's WiFi connection
manager and make sure that your device is still connected to the extender network.
•
Launch a web browser and enter the extender's default IP address, which is
192.168.1.250.
If this IP address does not work, your extender's IP address might have changed.
You can log in to your router to view your extender's IP address. For more information,
see Find Extender's IP Address on page 44.
•
If your extender and router use the same WiFi network name (SSID), enter
http://<extender’s IP address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find
Extender's IP Address on page 44.
•
Clear your web browser's cache and browsing history and try again.
For more information, see the help content for your web browser.
•
Try using another web browser.
•
Assign a static IP address to your computer.
Before you change any network settings, note your current Default gateway
(Windows) or Router (Mac) address. Use the IP address 192.168.1.249 and the
subnet mask 255.255.255.0.
For more information, see your computer's documentation.
Find Extender's IP Address
If your extender and router use the same WiFi network name (SSID) and you want to
log in to your extender using an Android device, you must use the extender's IP address.
You can log in to your router to find your extender's IP address. If you own a NETGEAR
router, use the following example to find the extender's IP address. If you do not own
a NETGEAR router, see your router's documentation.
Note: The following instructions might not apply to your NETGEAR router. For more
information, see your NETGEAR router's user manual.
User Manual44FAQs and Troubleshooting
AC1200 WiFi Range Extender
To log in to your extender and find your extender's IP address:
1.
Launch a web browser from a computer or mobile device that is connected to the
router network.
2.
Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
A list of devices connected to your router displays.
5. Find your extender in the list and note your extender’s IP address.
User Manual45FAQs and Troubleshooting
AC1200 WiFi Range Extender
Factory Default Settings
To reset the extender to factory default settings, you can use the Reset button on the
side panel or you can log in and click the onscreen RESET button. For more information,
see Return the Extender To Its Factory Default Settings on page 22.
The following table shows the factory default settings.
Table 2. Factory default settings
Default SettingsFeature
EnabledSmart Setup
EnabledWiFi communication
NETGEAR_EXTWiFi network name (SSID)
DisabledSecurity
Auto
1
Transmission speed
Varies by regionCountry/region
802.11a/b/g/n/acOperating mode
54/145/300 MbpsData rate in the 2.4 GHz band
54/145/300/433/867 MbpsData rate in the 5 GHz band
Client enabledDHCP
1
Maximum WiFi signal rate (IEEE Standard 802.11). Actual throughput can vary. Network conditions and environmental
factors, including volume of network traffic, building materials and construction, and network overhead lower actual
data throughput rate.
Technical and Environmental Specifications
The following table shows the technical and environmental specifications.
User Manual47Factory Settings and Technical
Specifications
AC1200 WiFi Range Extender
Table 3. Technical specifications
Technical Specifications
Data and routing protocols: TCP/IP, DHCP server and client, DNS relay,Network protocol and
standards compatibility
•
Dimensions: 72.5 x 72.5 x 64.8 mm (2.85 x 2.85 x 2.55 in.)
•
Weight: 152 g (0.34 lb)
Physical specifications
•
Operating temperature: 32° to 104°F (0° to 40°C)
•
Operating humidity: 90% maximum relative humidity, noncondensing
Environmental
802.11ac, 802.11a, 802.11g, 802.11bInterface
User Manual48Factory Settings and Technical
Specifications
AC1200 WiFi Range Extender
